- Page 1 RPX Repeater Series Vehicle Charger HKPN4003A User Guide...
- Page 3 RPX Repeater in the vehicle. To reduce risk of injury, charge only the rechargeable Motorola authorized batteries listed in "Table 1: RPX Series Authorized Batteries" on page 5. Other batteries may explode, causing personal injury and damage.
- Page 4 To reduce the risk of fire, electric shock, or injury, do not operate the charger if it has been broken or damaged in any way. Take it to a qualified Motorola sales representative. Do not disassemble the vehicle charger, it is not repairable and replacement parts are not available.
-
Page 5: Operational Safety Guidelines
OPERATIONAL SAFETY GUIDELINES • This equipment is not suitable for outdoor use. Use only in dry locations/conditions. • Connect equipment only to an appropriately fused and wired supply of the correct voltage (as specified on the product). • The cigarette lighter socket outlet to which this equipment is connected to should be close by and easily accessible. -
Page 6: Vehicles Equipped With Air Bags
VEHICLES EQUIPPED WITH AIR BAGS • Do not place or install equipment in the area over an air bag or in the air bag deployment area. Air bags WARNING inflate with great force. If equipment is installed in the air bag deployment area and the air bag inflates, the equipment may be propelled with great... -
Page 7: Motorola Authorized Batteries
MOTOROLA AUTHORIZED BATTERIES Note: The batteries and Li-Ion Battery Frame Kit listed in Tables 1 and 2 below are approved for use with RPX Repeater and the HKPN4003A Vehicle Charger. Table 1: RPX Series Authorized Batteries Part Number Description Ultra High Capacity Li-Ion... - Page 8 OPERATING INSTRUCTIONS The vehicle charger will charge only the RPX Repeater using the Li-Ion Battery Frame P/N HKHN4004A with the Motorola authorized battery listed in "Table 1: RPX Series Authorized Batteries" on page 5. Other batteries may not charge.
- Page 9 Charging Inside the Vehicle Connect the vehicle charger connector into the RPX Repeater AC/DC jack. See figure 1 below. Plug the other end of the vehicle charger into the vehicle’s cigarette lighter outlet receptacle. The Power LED on the vehicle charger illuminates green to indicate proper connection to a power supply.
-
Page 10: Protection Fuse
Note: If voltage to the vehicle cigarette lighter socket runs through the vehicle ignition switch, make sure the ignition switch is turned on for continuos voltage to the RPX repeater. Protection Fuse The vehicle charger is equipped with a protection fuse. - Page 11 FCC and Other Regulatory Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device does not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
-
Page 12: European Union Directives Conformance Statement
12 VDC – 24 VDC (Switched or non-switched power) Output Voltage: 12 VDC +/-5 % Output Current: Continuos 2.0A For Motorola Customer Support call: 1-800-461-4575 in Canada 1-800-448-6686 in the USA 1-866-522-5210 on your TTY (Text Telephone) or visit us at: www.motorola.com/rpx... - Page 14 *68007024030* 68007024030-A MOTOROLA, the Stylized M Logo, and Motorola are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their respective owners. © 2009 by Motorola, Inc. All rights reserved.
