Siemens CAB-MP Installation Instructions

Installation Instructions
Model CAB-MP
System Mounting Plate
INTRODUCTION
INSTALLATION
COMPATIBILITY
SPECIFICATIONS
P/N 315-033012-1
The SIEMENS Model CAB-MP Mounting Plate is used in CAB1, CAB2, CAB3 enclo-
sures for mounting the system modules. A total of one CAB-MP can be installed in
the CAB1, two CAB-MPs can be installed in the CAB2, and three CAB-MPs can be
installed in the CAB3.
Remove BATTERY and AC prior to working on equipment.
Refer to Figure 1 on page 2.
There is a top and bottom to the CAB-MP Mounting Plate. The top is where the word
“TOP” is stamped on the Mounting Plate.
1. Hold the CAB-MP in your hands with the word “TOP” at the top of the
plate. Place the four ¼” holes on the CAB-MP Mounting Plate over the
threaded studs in the desired location in the CAB enclosure.
2. Secure in place with the 10-32 nuts supplied.
The CAB-MP can be used in CAB1, CAB2, and CAB3 enclosures.
CAB-MP Mounting Plate: 19.18”W x 14.25”H
Siemens Building Technologies
Fire Safety
