Summary of Contents for Motorola MH7021
- Page 1 AC2200 Tri-Band Mesh WiFi whole home WiFi system Quick Start Guide...
- Page 2 Ethernet Cable Power Adapter (varies by region) MH7021 is the model number for each Router and Satellite unit. MH7022 includes 1 Router, 1 Satellite, and 2 power adapters. MH7023 includes 1 Router, 2 Satellites and 3 power adapters. Para una Guía de Inicio Rápido en español, por favor...
-
Page 3: Let's Get Started
Let’s get started We highly recommend you use the MotoManage™ app to configure your Motorola whole home WiFi system. In addition to setting up your system, the app provides advanced security for all your devices, the ability to monitor and control your WiFi network remotely, advanced parental controls, and many other features. - Page 4 On/Off button on the back panel is pushed in. Wait for the Motorola logo to become solid green. This may take up to 2 minutes. If the Motorola logo does not stop blinking please see the Troubleshooting section at...
- Page 5 To setup the Satellite(s), first connect the supplied power adapter between the Satellite’s power adapter and a working electrical outlet. The Satellite’s Motorola logo on the front of the unit should be blinking green while the unit powers up. If the logo is not blinking green, check that the...
- Page 6 Satellite is out of range. If so, move the Satellite closer to the Router. After the Satellite syncs with the Router, the Motorola logo will turn either green or amber. If the logo turns green, the connection between the Router and the Satellite is strong.
-
Page 7: Rear Panel
Rear Panel ON/OFF button and POWER jack Press the power button in until it clicks for ON. Connect the supplied power adapter between the power jack and an electrical outlet. WAN/LAN and LAN ports On the Router unit, the WAN/LAN port is a WAN port. Use this port to connect your Router to your modem’s LAN port. - Page 8 Front Panel Light The Motorola Logo on the front of the units will change colors to indicate the status. COLOR DESCRIPTION Router: Connected to your modem. Satellite: Paired to the router with a strong signal. Solid Green Both: Unit is powering up.
-
Page 9: Troubleshooting Tips
Troubleshooting Tips What if I can’t make an Internet connection right after installation? • First turn the modem that provides your Internet connection off for at least 8 seconds, then on, to see if that fixes the problem. • Check that the Router’s power adapter is plugged into a live outlet, and the power button is pushed in. - Page 10 Satellite(s) close to these types of interfering devices. • You may need another Satellite unit to provide coverage throughout your home. The MH7021 is a single Satellite unit designed to work with the MH7022 or MH7023 whole home WiFi systems.
-
Page 11: Limited Warranty
We like to help. Please visit our support Website or call our support specialists. Our Website has our Motorola Mentor information, and also provides returns and warranty information. www.motorolanetwork.com/support Email: support@motorolanetwork.com Phone: 800-753-0797 or 617-753-0562 Our full-length user manual is available at www.motorolanetwork.com/MH7022manual... - Page 12 Safety Precautions These precautions help protect you and your MH7021. Do not put the MH7021 or its power adapter in water, since this is a shock hazard. The MH7021 should normally be installed indoors. If you use it outdoors, protect it from moisture and be careful about temperature.
