Craftsman 65018 Assembly Instructions Manual page 16

Shed Assembly – Walls/
17
18
Continued
G
1
R x4
Align tabs on bottom of back panel (G) with slots along
floor. Lower back panel into slots and lock in place by
sliding panel toward corner. Note: To allow back panel
to overlap left back corner, tilt out slightly as you slide it
into position. Note: Use a rubber mallet to "push" back
panel (G) into locked position, aligned with left back
corner.
Secure panels with four easy bolts (R). Work from floor
to roof. DO NOT use torque wrench. Use easy bolt easy
driver and hand tighten. Easy bolt head will be flush
when fully seated. DO NOT over tighten easy bolts.
Note: You may hear a click when easy bolt has been
tightened completely.
16
