・Example 2
When changing from A001 to C021.
Monitor Mode A
Iout
000.0A
>A001
REM
Press the
Iout
0000.0A
>A001
REM
Press the
Iout
0000.0A
>A001
REM
Press the
Iout
0000.0A
>C001
RS
Press the
code number display.
Iout
0000.0A
>C001
RS
Press the
(Automatically, C021 is selected, then data of C021 will be displayed. )
Iout
0000.0A
>C021
FA1
Press the
Iout
0000.0A
>C021
FA1
Chapter 10 LCD display and operating for SJ300/L300P series
key, then move the cursor to the bottom row.
1
1
key, then move the cursor to the code number display "A".
key 2 times to select "C" (display C001).
2
1
key 2 times, then move the cursor to second figure of
key 2 times to select "2".
2
key, then move the cursor to the head of top row.
STR
