SIMATIC NET
PG/PC - PROFIBUS
CP 5603
Operating Instructions
08/2016
A5E02146341A-04
___________________
Preface
___________________
Description of the device
___________________
Software installation
___________________
Hardware installation
___________________
Project engineering
___________________
Technical specifications
___________________
Approvals
1
2
3
4
5
6
A
Advertisement
Table of Contents
Related Manuals for Siemens SIMATIC NET PG PROFIBUS CP 5603
Summary of Contents for Siemens SIMATIC NET PG PROFIBUS CP 5603
- Page 1 ___________________ Preface ___________________ Description of the device ___________________ SIMATIC NET Software installation ___________________ Hardware installation PG/PC - PROFIBUS CP 5603 ___________________ Project engineering ___________________ Technical specifications Operating Instructions ___________________ Approvals 08/2016 A5E02146341A-04...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Table of contents Preface ..............................5 Description of the device ......................... 9 Product characteristics......................9 PROFIBUS interface ....................... 10 Meaning of the LED display ....................12 Software installation ..........................13 Installing the "SIMATIC NET PC Software" ................13 Uninstalling the "SIMATIC NET PC Software"................ 14 Hardware installation .......................... - Page 4 Table of contents CP 5603 Operating Instructions, 08/2016, A5E02146341A-04...
-
Page 5: Preface
Preface Scope of delivery Below, 5 delivery packages are introduced. CP 5603 communications processor – 6GK1 560-3AA00 The following components ship with the product: ● Communications processor CP 5603 consisting of a PCI-104 basic module with an active RS-485 module and 12-pin ribbon cable ●... - Page 6 You will find this documentation on the Product Support pages on the Internet under the following entry link: Support (https://support.industry.siemens.com/cs/ww/en/ps) Enter the entry ID shown below of the relevant manual as the search item. ● Configuration manual Commissioning PC Stations This provides you with detailed information on commissioning and configuring SIMATIC NET PC communications modules.
- Page 7 CP 5622 Industry Online Support In addition to the product documentation, the comprehensive online information platform of Siemens Industry Online Support at the following Internet address: (http://support.automation.siemens.com/WW/llisapi.dll?func=cslib.csinfo2&aktprim=99&lang= Apart from news, there you will also find: ● Project information: Manuals, FAQs, downloads, application examples etc.
- Page 8 Explanations of many of the specialist terms used in this documentation can be found in the SIMATIC NET glossary. You will find the SIMATIC NET glossary on the Internet at the following address: 50305045 (http://support.automation.siemens.com/WW/view/en/50305045) CP 5603 Operating Instructions, 08/2016, A5E02146341A-04...
-
Page 9: Description Of The Device
Description of the device Product characteristics Properties The CP 5603 communications processor has the following properties: ● PCI-104 interface ● Fast commissioning due to plug and play capability ● DP master operation (DP Base) with up to 124 DP slaves with full data consistency ●... -
Page 10: Profibus Interface
Description of the device 2.2 PROFIBUS interface Representation The following figure shows the CP 5603 communications processor with the active RS-485 module: PROFIBUS interface PROFIBUS network The physical link between the PROFIBUS interface and the PROFIBUS network is via a floating RS-485 interface that is part of the module. - Page 11 Description of the device 2.2 PROFIBUS interface PIN assignment The D-sub female connector has the following pin assignment: Short name Meaning Input/output Socket pin 1 is not connected. NC (M24) Socket pin 2 is not connected. With other MPI/DP components, the return line of the floating 24 V power supply may be via this pin.
-
Page 12: Meaning Of The Led Display
Description of the device 2.3 Meaning of the LED display Meaning of the LED display Display Description Lit green Shows the token rotation (in other words, normal operation) Green off Incorrect bus parameters, defective bus or CP not in operation Green flashes at one second intervals Bad database Green and yellow flashing alternately... -
Page 13: Software Installation
Install the software as described in the installation manual "SIMATIC NET PC Software". You will find this installation manual on the Product Support pages under the following entry ID: 77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602) You should also note the current information on the "SIMATIC NET PC software" on the Product Support pages: Support (https://support.industry.siemens.com/cs/ww/en/ps/15362/pm) -
Page 14: Uninstalling The "Simatic Net Pc Software
"SIMATIC NET PC Software". You will find the installation manual on the "SIMATIC NET PC Software" DVD or on the Product Support pages under the following entry ID: 77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602) Requirement The Plug & Play manager is enabled in the BIOS. -
Page 15: Hardware Installation
Hardware installation Safety notices WARNING Electric shock possible - work only when the power supply is off Opening the PG/PC and plugging or pulling the communications processor is permitted only when the power is off. Turn off your PG/PC and pull the power cable connector before you start the hardware installation. -
Page 16: Installing Hardware
Hardware installation 4.2 Installing hardware Installing hardware CAUTION Electrostatic charge When handling the module, do not touch the connectors or electronic components. Please keep to the measures for avoiding electrostatic charges (ESD - electrostatic discharge). Setting the PCI-104 module address Every PCI-104 module must be given a module address according to its position. - Page 17 Hardware installation 4.2 Installing hardware CAUTION Operation of more than one CP 5603 in the SIMATIC Microbox Due to thermal requirements, a maximum of two CP 5603 may be operated in the SIMATIC Microbox at the same time. If you want to operate other PCI-104 modules along with the CP 5603 in a SIMATIC Microbox, note the section relating to thermal requirements in the manual of the SIMATIC Microbox.
- Page 18 Hardware installation 4.2 Installing hardware To install and connect up the CP 5603 follow the steps outlined below: 1. Shut down your PC and disconnected it from the power supply. 2. Open the PC housing as described in the manual accompanying your Microbox. 3.
- Page 19 Hardware installation 4.2 Installing hardware Procedure for installing a SIMATIC S7 modular Embedded Controller (mEC) The following figure shows the CP 5603 communications processor installed in a SIMATIC S7-mEC (modular Embedded Controller) CP 5603 Operating Instructions, 08/2016, A5E02146341A-04...
- Page 20 Hardware installation 4.2 Installing hardware To install and connect up the CP 5603 follow the steps outlined below: 1. Shut down your PC and disconnected it from the power supply. 2. Open the extension box as described in the manual of the mEC. 3.
- Page 21 Hardware installation 4.2 Installing hardware To identify the CP 5603 from the outside, various labels are included in the packaging. Fit the labels as suggested in the figure above. CP 5603 Operating Instructions, 08/2016, A5E02146341A-04...
-
Page 23: Project Engineering
Project engineering Configuring The following engineering or configuration tools are available to enable you to configure the communications processor: ● STEP 7 V5.5 ● STEP 7 Professional (TIA Portal) ● Communication settings (COML S7) The further procedure is described in the "Commissioning PC Stations" manual or in the relevant online help files. - Page 24 Project engineering CP 5603 Operating Instructions, 08/2016, A5E02146341A-04...
-
Page 25: Technical Specifications
Technical specifications CP 5603 Mechanical specification Module format PCI-104 (according to PCI-104 specification V1.0) Dimensions (W x D x H) in mm 90.17 x 95.84 x 20.53 Weight 77 g Electrical specification Supply voltage from PCI-104 slot Safety extra low voltage (SELV) according to EN 60950 +5 +/-5% VDC Maximum input current... - Page 26 Technical specifications Safety UL / CSA UL 60950-1 UL 508 Mechanical tests Oscillation IEC 60068-2-6 10 to 58 Hz Amplitude: 0.075 mm, 58 to 50 0Hz; Acceleration: 10 m/s , 10 cycles/axis Shock IEC 60068 2 27; 150 m/s (15 g), 11 ms, 3 shocks/axis in negative and positive direction Microbox expansion frame for the CP 5603 Mechanical specification...
-
Page 27: Dimension Drawings
Technical specifications 6.1 Dimension drawings Dimension drawings Note Dimensions are specified in mm. Microbox with a CP 5603 expansion frame CP 5603 Operating Instructions, 08/2016, A5E02146341A-04... - Page 28 Technical specifications 6.1 Dimension drawings CP 5603 Operating Instructions, 08/2016, A5E02146341A-04...
-
Page 29: Approvals
Declaration of conformity You will find the declaration of conformity for this communications processor on the Product Support pages under the following entry ID: 58826997 (https://support.industry.siemens.com/cs/ww/en/view/58826997) C-TICK approval The communications processor meets the requirements of the Australian AS/NZS 3548 standard according to EN 61000-6-3. - Page 30 ● Consult the dealer or an experienced radio/TV technician for help. Siemens AG is not responsible for any radio television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Siemens AG. The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user.
