Summary of Contents for Yamaha T115SE 2019

  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the T115S / T115SE / T115SEC, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 IMPORTANT MANUAL INFORMATION Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5: Table Of Contents

    TABLE OF CONTENTS OPERATION AND IMPORTANT LOCATION OF IMPORTANT LABEL ....1-1 Checking the brake lever RIDING POINTS ..........5-1 free play ............. 6-18 SAFETY INFORMATION ........1-2 Starting and warming up a Adjusting the brake pedal cold engine ...........5-1 free play ............ 6-18 DESCRIPTION ............2-1 Starting a warm engine ......
  • Page 7 IMPORTANT MANUAL INFORMATION T115S/T115SE/T115SEC OWNER’S MANUAL ©2013 by Yamaha Motor Co., Ltd. 1st edition, August 2013 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd is expressly prohibited. Printed in Malaysia...
  • Page 8: Location Of Important Label

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9: Safety Information

    SAFETY INFORMATION tersections are the most likely Safe Riding Be a Responsible Owner places for motorcycle accidents Perform the pre-operation checks each As the vehicle’s owner, you are to occur. time you use the vehicle to make sure it responsible for the safe and proper •...
  • Page 10 SAFETY INFORMATION the operator is veering wide on a tem become very hot during or af- Never ride under the influence of turn due to excessive speed or un- alcohol or other drugs. ter operation and can cause dercornering (insufficient lean an- burns.
  • Page 11 Yamaha accessories, which are avail- extra care when riding a motorcycle Shifting weights can create a sud- able only from a Yamaha dealer, have that has added cargo or accessories. den imbalance. Make sure that ac- been designed, tested, and approved...
  • Page 12 Wind may at- Yamaha vehicles. Yamaha is not in a Keep the following guidelines in mind, tempt to lift the motorcycle, or position to test the products that these as well as those provided under “Load-...
  • Page 13: Description

    DESCRIPTION Left view . Front Turn signal light /Auxilliary (page 6-28) 5 . Owner tool kit (page 6-1) 2 . Headlight (page 6-27) 6. Tail/brake light (page 6-2) 3 . Mirror 7. Shift pedal (page 5-2) 4 . Helmet holder (page 6-17) 8.
  • Page 14: Right View

    DESCRIPTION 4 10 Right view 1. Fuel tank cap 3-7) 6. Kick starter (page 6-18) 2. Rear brake light switch (page 3-7) Brake pedal (page 6-8) 3. Battery (page 3-6) Engine oil filter element 4. Front brake reservoir (page 6-25) 9.
  • Page 15: Controls And Instruments

    DESCRIPTION Controls and instruments 4. Main switch (page 3-1) 1. Left handlebar switches (page 3-4) 2. Speedometer unit (page 3-3) Right handlebar switches (page 3-4) Throttle grip. (page 3. Fuel meter (page 3-4) 6-21)
  • Page 16: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS Main switch/steering lock OF F (Push/Release) OF F L OCK LOCK (Insert) To unlock the steering OF F The main switch/steering lock controls All electrical systems are off. The key Insert the key in, and then turn it to the ignition and lighting systems, and is can be removed.
  • Page 17: Keyhole Cover

    INSTRUMENT AND CONTROL FUNCTIONS Keyhole cover 1. push shut bottom To open the keyhole cover 1. Shutter key To close the keyhole cover For open and close keyhole cover Insert the key head into the key hole Push the push shut bottom after cover receptacle as shown, and 2.
  • Page 18: Indicator Lights

    When this Neutral indicator light " " 2. Odometer Gear position indicator light “1” “2” “3” “4” occur, have a Yamaha dealer check The speedometer unit is equipped with 5. Engine trouble warning light " " the self diagnosis system.
  • Page 19: Fuel Gauge

    INSTRUMENT AND CONTROL FUNCTIONS Fuel gauge Handlebar switches Right Left Horn switch “ ” Turn signal switch “ ” Red zone Start switch " " Dimmer switch “ ” Fuel gauge Start switch “ Horn switch “ ” " The fuel gauge indicates the amount of Press this switch to sound the horn.
  • Page 20: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS Brake p edal Shift pedal Brake lever 1. Shift pedal 1. Brake lever 1. Brake pedal. The shift pedal is located on the left The brake lever is located at the right The brake pedal is on the right side of side of the engine.
  • Page 21: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS Fuel tank cap Fuel 1. Before refueling, turn off the engi- ne and be sure that no one is sitt- ing on the vehicle. Never refuel while smoking, or while in the vicinity of sparks, open flames, or other sources of ignition such as the pilot lights of water heaters and clothes dryers.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS 3. Wipe up any spilled fuel imme- diately. NOTICE: Immediately Recommended fuel: wipe off spilled fuel with a cle - Regular unleaded gasoline only Fuel tank capacity: an, dry, soft cloth, since fuel 4.1 L may deteriorate painted sur- faces or plastic parts.
  • Page 23: Kickstarter

    INSTRUMENT AND CONTROL FUNCTIONS Kick starter Seat To close the seat 1. Fold the seat down, and then push it down to lock it in place. 2. Remove the key from the main switch if the motorcycle will be left unattended. TIP : Make sure that the seat is properly secured before riding.
  • Page 24: Helmet Holders

    INSTRUMENT AND CONTROL FUNCTIONS Helmet holders Storage compartment Sidestand The sidestand is located on the left side of the frame. Raise the sidestand or lower it with your foot while holding the vehicle upright. WARNING WARNING The vehicle must not be ridden with the sidestand down, or if the side- stand cannot be properly moved up (or does not stay up), otherwise the...
  • Page 25: Pre-Operation Checks

    Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage. Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 26: Pre-Operation Check List

    • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-12, 6-13 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-2 1 •...
  • Page 27 PRE-OPERATION CHECKS ITEM CHECKS PAGE • Check for damage. • Check tire condition and tread depth. Wheels and tires 6-1 3, 6-15 • Check air pressure. • Correct if necessary. • Make sure that operation is smooth. Brake pedal 6-16 •...
  • Page 28: Operation And Important Riding Points

    NOTICE : NOTICE: NOTICE : with all operating controls and Yamaha dealer check the electrical cir- their functions before riding. Do not ride through deep water cuit. Consult a Yamaha dealer re- (including puddles), otherwise the 3.
  • Page 29: Starting A Warm Engine

    OPERATION AND IMPORTANT RIDING POINTS TIP : Shifting Starting a warm engine If the engine fails to start by pushing the Follow the same procedure as for start- start switch, release the switch, wait a ing a cold engine. few seconds, and then try again. Each starting attempt should be as short as possible to preserve the battery.
  • Page 30: Tips For Reducing Fuel Consumption

    OPERATION AND IMPORTANT RIDING POINTS Tips for reducing fuel Engine break-in NOTICE : consumption There is never a more important period Make sure that the transmission in the life of your engine than the period Fuel consumption depends largely on is completely shifted into gear.
  • Page 31 OPERATION AND IMPORTANT RIDING POINTS 150–500 km (90–300 mi) 0-150 km (0-90 mi) 500 –1000 km (300 –600 mi) Avoid prolonged operation above 1/3 Avoid prolonged operation above 1/2 Avoid prolonged operation above 3/4 throttle. throttle. Rev the engine freely through throttle.
  • Page 32: Parking

    If any engine trouble should occ ur during the engine break-in period, immedia- tely have a Yamaha dealer check the vehicle.
  • Page 33: General Note

    Much can be gained from the correct use and maintenance of a motorcycle. 1. THE CUSTOMERS CAN USE THE FULLEST 2. A MOTORCYCLE CAN KEEP ITS PERFORMANCE POTENTIAL OF YAMAHA MOTORCYCLES CAPABILITY FOR A LONGER TIME Comparison of wear on engine parts (piston, piston ring, cylinder, etc.)
  • Page 34 OPERATION AND IMPORTANT RIDING POINTS 3. FUEL COST AND REPAIR EXPENSES CAN BE 4. A MOTORCYCLE CAN DEMAND A HIGH PRICE KEPT TO A MINIMUM WHEN IT IS TRADED IN AS A USED PRODUCT Fuel consumption With maintenance 100% Without maintenance Distance covered (km) Customer’s running cost...
  • Page 35: Periodic Maintenance And Minor Repair

    Safety is an obligation of the owner. Pe- ence required for a particular job, have riodic inspection, adjustment and lubri- a Yamaha dealer perform it for you. cation will keep your vehicle in the safest and most efficient condition pos- sible.
  • Page 36: Periodic Maintenance And Lubrication Chart

    The annual checks must be performed every year, except if a kilometer-based maintenance is performed instead. From 8,000 km, repeat the maintenance intervals starting from 4,000 km. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 37 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ( 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check runout, spoke tightness and for damage. * Wheels • Tighten spokes if necessary (for spoke wheel). • Check tread depth and for damage. •...
  • Page 38 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ( 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check operation 22 * Front suspention • Check for oil leakage Front and rear brake 23 * • Check operation. switches Moving parts and cables •...
  • Page 39: Removing And Installing The Cowlings And Panel

    PERIODIC MAINTENANCE AND MINOR REPAIR To install and remove cowling. Removing and installing the cowlings and panel 1. Cowling A 1. Cowling rear 1. Cowling A 4. Side cover 2. Cowling B 5. Rear panel 2. Screw ( x4 ) 2.
  • Page 40 PERIODIC MAINTENANCE AND MINOR REPAIR Cowling B 1. Cowling B 1. Cover cowling B 2. Screw ( x2 ) 2. “Screw” cowling ( x2 ) To remove cowling B Remove screws cowling B as shown and remove cowling B. To install cowling B Install cowling B in the original position and install screws.
  • Page 41 PERIODIC MAINTENANCE AND MINOR REPAIR Panel Rear panel 1. Panel 1. Rear panel 2. Screw 2. Screw 3. Bolt To install rear panel To remove the panel 1. Place rear panel portion To remove rear panel 1. Open the seat. (See page 3-8.) first and press fit the 1.
  • Page 42: Checking The Spark Plug

    PERIODIC MAINTENANCE AND MINOR REPAIR Side cover Checking the spark plug The spark plug is an important engine component, which is easy to check. Since heat and deposits will cause any spark plug to slowly erode, the spark plug should be removed and checked in accordance with the periodic mainte- nance and lubrication chart.
  • Page 43 Do not attempt to diagnose such problems yourself. Instead, have a 4. Install the spark plug cap . Yamaha dealer check the vehicle. 5. Install the panel. 1. Spark plug gap...
  • Page 44: Engine Oil

    PERIODIC MAINTENANCE AND MINOR REPAIR Engine Oil The engine oil level should be checked before each ride. In addition, the oil must be changed in the periodic main- nance and lubrication chart. To check the engine oil level 1. Pl ace the vehicle on the center- stand.
  • Page 45 PERIODIC MAINTENANCE AND MINOR REPAIR 1. Oil filter element 1. Engine oil drain bolt 1. Bolt 2. O-ring 2. Oil filter element cover To change the engine oil 6. Install the oil filter element cover by TIP : 1. Start the engine, warm it up for installing the bolts, then tightening Skip step 4-6 if the oil filter element is several minutes, and then turn it off.
  • Page 46: Replacing The Air Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR Replacing the air filter element NOTICE : NOTICE : Always use Yamalube oil only. Before installing the engine oil drain Make sure that no foreign mate- bolt, do not forget to install the rial enters the crankcase. washer bolt.
  • Page 47 PERIODIC MAINTENANCE AND MINOR REPAIR 4. Insert the air filter element into the NOTICE: Make su- air filter case. re that the air filter element is properly seated in the air filter case. The engine should never be operated without the air filter element installed, otherwise the piston(s) and/or cylinder(s) may 1.
  • Page 48: Adjusting The Engine Idling Speed

    2. Attach the diagnostic tachometer throttle grip. Periodically check the to the spark plug lead. Yamaha dealer make the adjustment. throttle cable free play and, if neces- 3. Check the engine idling speed sary, adjust it as follows.
  • Page 49: Valve Clearance

    To prevent this cycle, note the following points from occurring, the valve clearance regarding the specified tires. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart.
  • Page 50 (minimum tread depth), if the tire the weight evenly from side to side. has a nail or glass fragments in it, or if Yamaha Motor Co., Ltd. Check the condition and pressure of the sidewall is cracked, have a Yamaha your tires. NEVER OVERLOAD dealer replace the tire immediately.
  • Page 51: Wheels

    When a tire tread be replaced. begins to show crosswise lines, The wheel should be balanced have a Yamaha dealer replace whenever either the tire or wheel the tire immediately. has been changed or replaced. An 1. Oil...
  • Page 52: Checking The Brake Lever Free Play

    There should be no free play at the 1. Brake pedal free play adjusting nut brake lever end. If there is free play, 1. Brake pedal free play have a Yamaha dealer inspect the WARNING brake system. The brake pedal free play should mea- After adjusting the drive chain sure 25.0 –35.0 mm (0.98 –1.38 in) at...
  • Page 53: Adjusting The Rear Brake Light Switch

    Yamaha grooves have almost disappeared, have turn the adjusting nut in direction (a). To...
  • Page 54: Checking The Front Brake Fluid Level

    Yamaha dealer check the cause. Recommended brake fluid: DOT 4 Changing the brake fluid Have a Yamaha dealer change the 1. Minimum level mark TIP : brake fluid at the intervals specified in Insufficient brake fluid may allow air to...
  • Page 55: Drive Chain Slack

    PERIODIC MAINTENANCE AND MINOR REPAIR To check the drive chain slack To adjust the drive chain slack Drive chain slack 1. P lace the motorcycle on the cen- terstand. 2. Shift the transmission into the neu- tral position. 3. Spin the rear wheel several times to locate the tightest portion of the drive chain.
  • Page 56 PERIODIC MAINTENANCE AND MINOR REPAIR 4. Tighten both locknuts, and then 3. To tighten the drive chain, turn the tighten the axle nut and brake adjusting nut at each end of the torque rod nut to their specified swingarm in direction (a), To loos- torque.
  • Page 57: Cleaning And Lubricating The Drive Chain

    If a cable is damaged maintenance chart. follows. or does not move smoothly, have a NOTICE : Yamaha dealer check or replace it. WARNING ! Damage to the outer The drive chain must be lubricated sheath may interfere with proper ca- after washing the motorcycle and riding in the rain.
  • Page 58: Lubricating The Brake Lever

    Recommended lubricant: Recommended lubricant: WARNING Engine oil Lithium-soap-based grease (all-pur- If the centerstand or sidestand does pose grease) not move up and down smoothly, have a Yamaha dealer check or re- pair it. Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-24...
  • Page 59: Lubricating The Swingarm Pivots

    WARNING! To avoid injury have a Yamaha dealer check or re- securely support the vehicle so pair it. that there is no danger of it fal- ling over.
  • Page 60: Checking The Steering

    2. Hold the lower ends of the front fork legs and try to move them for- ward and backward. If any free play can be felt, have a Yamaha dealer check or repair the steering. 6-26...
  • Page 61: Battery

    Avoid any contact with To charge the battery skin, eyes or clothing and al- Have a Yamaha dealer charge the bat- ways shield your eyes when tery as soon as possible if it seems to working near batteries. In case have discharged.
  • Page 62: Replacing The Fuse

    “OFF”, then discon- 4. If the fuse immediately blows nect the negative lead before again, have a Yamaha dealer disconnecting the positive lead. check the electrical system 1. Spare fuse and main fuse 2. If the battery will be stored for...
  • Page 63 4. Install the cowling. clockwise. from a lit headlight bulb, and do not 5. Have a Yamaha dealer adjust the touch the bulb until it has cooled 3. Remove the defective bulb by pull- headlight beam if necessary.
  • Page 64 PERIODIC MAINTENANCE AND MINOR REPAIR Replacing a turn signal light bulb or the tail/brake light bulb 1. Bulb 1. Inner lens 2. Inner lens screw 4. Insert a new bulb into the socket. 5. Install the socket (together with the 1.
  • Page 65: Front Wheel

    PERIODIC MAINTENANCE AND MINOR REPAIR Front wheel 4. Pull the wheel axle out, and then remove the wheel. NOTICE : Do- not apply the brake after the wheel has been removed toge ther with the brake disc, other wise the brake pads will be for- ced shut.
  • Page 66 PERIODIC MAINTENANCE AND MINOR REPAIR Rear wheel 6. While applying the front brake, push down hard on the handlebars several times to check if the front fork compresses and rebounds smoothly. 7. Connect the speedometer cable. 1. Retainer 2. Slot 1.
  • Page 67 PERIODIC MAINTENANCE AND MINOR REPAIR To install the rear wheel 7. Remove the axle nut and the wa- sher, and then pull the wheel axle 1. Insert the wheel axle from the left- out. hand side, and then install the wa- TIP : sher and axle nut.
  • Page 68 (See page 6-1 8.) for checking these vital systems your- self. However, should your motorcycle WARNING require any repair, take it to a Yamaha After adjusting the brake pedal free dealer, whose skilled technicians have play, check the operation of the the necessary tools, experience, and brake light.
  • Page 69: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 70: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE ucts onto seals, gaskets, sprock- cleaning products, solvent or Care ets, the drive chain and wheel thinner, fuel (gasoline), rust re- While the open design of a motorcycle movers or inhibitors, brake flu- axles. Always rinse the dirt and de- reveals the attractiveness of the tech- id, antifreeze or electrolyte.
  • Page 71 MOTORCYCLE CARE AND STORAGE After normal use 2. Apply a corrosion protection spray 7. Wax all painted surfaces. Remove dirt with warm water, a mild on all metal, including chrome- and 8. Let the motorcycle dry completely detergent, and a soft, clean sponge, nickel-plated, surfaces to prevent before storing or covering it.
  • Page 72 TIP : ing it with a tarp, while it is still 5. Perform the following steps to pro- Consult a Yamaha dealer for advice on wet, will allow water and humid- tect the cylinder, piston rings, etc. ity to seep in and cause rust.
  • Page 73 MOTORCYCLE CARE AND STORAGE TIP : d. Turn the engine over several 6. Lubricate all control cables and the times with the starter. (This will Make any necessary repairs before pivoting points of all levers and storing the motorcycle. coat the cylinder wall with oil.) pedals as well as of the side- WARNING !
  • Page 74: Specifications

    SPECIFICATIONS Dimensions: Spark plug (s): Lubrication system: Overall length: Manufacturer/model: Wet sump 1935 mm NGK CR6HSA / DENSO U20FSR-U Engine oil: Overall width: Spark plug gap: Type: 680 mm 0.6–0.7 mm (0.023–0.027 in) SAE20W40 or SAE20W50 Overall height: Clutch: Recommended engine oil grade: 1065 mm Clutch type: API service SF, SG type or higher...
  • Page 75 SPECIFICATIONS Rear: Spring/shock absorber type: Caster angle: 225 kPa (33 psi) (2.25 kgf/cm 2) Coil spring/oil damper 26.2 ° Loading condition: Wheel travel: Trail: 90 –110 kg (198 –243 lb) 100 .0 mm 73.0 mm Front: Rear suspension: Front tire: 200 kPa (29 psi) (2.00 kgf/cm 2) Type: Type:...
  • Page 76 SPECIFICATIONS Position light: 12 V , 3.4 W Meter lighting: Blue LED 0.3 W Neutral indicator light: 12 V, 1.7 W High beam indicator light: 12 V, 1.7 W Turn signal indicator light: 12 V, 1.7 W Luggage box illumination light: 16V, 380mW (white) LED Fuse: Fuse:...
  • Page 77: Consumer Information

    Record the key identification number, vehicle identification number and en- gine serial number in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
