  • Page 1 DATASHEET SIEMENS 6ES7646-1DC20-0HC0 OTHER SYMBOLS: 6ES76461DC200HC0, 6ES76461DC20 0HC0, 6ES76461DC20-0HC0, 6ES7646 1DC200HC0, 6ES7646 1DC20 0HC0, 6ES7646 1DC20-0HC0, 6ES7646-1DC200HC0, 6ES7646-1DC20 0HC0, 6ES7646-1DC20-0HC0 RGB ELEKTRONIKA AGACIAK CIACIEK SPÓŁKA JAWNA Jana Dlugosza 2-6 Street 51-162 Wrocław www.rgbelektronika.pl Poland biuro@rgbelektronika.pl +48 71 325 15 05 www.rgbautomatyka.pl...
  • Page 2 YOUR PARTNER IN MAINTENANCE Repair this product with RGB ELEKTRONIKA ORDER A DIAGNOSIS LINEAR ENCODERS SYSTEMS INDUSTRIAL COMPUTERS ENCODERS CONTROLS SERVO AMPLIFIERS MOTORS MACHINES OUR SERVICES POWER SUPPLIERS OPERATOR SERVO PANELS DRIVERS At our premises in Wrocław, we have a fully equipped servicing facility. Here we perform all the repair works and test each later sold unit.
  • Page 3 Contents System Unit Mother Board SIMATIC Keyboard Controller Direct Key Module PC BI10/FI10/FI15 Bus Board Technical Description Displays Monitoring Module Touch Screen Hard Disk Drive Floppy Disk Drive Power Supply Appendices Guidelines for Handling Electro- statically-Sensitive Devices (ESD) Index...
  • Page 4 Trademarks SIMATIC , SIMATIC NET and SIMATIC HMI are registered trademarks of SIEMENS Third parties using for their own purposes any other names in this document which refer to trademarks might infringe upon the rights of the trademark owners.

  • Page 5: Table Of Contents

    ............2-49 SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...

  • Page 6: System Unit

    Removing and Installing a Fan 1-33 1.4.12 Removing and Installing the Power Supply Unit 1-34 1.4.13 Removing and Installing the CPU Board 1-35 1.4.14 Connecting the MPI/DP Interface 1-36 1.4.15 Reset Button 1-37 Error Diagnostics 1-39 SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...

  • Page 7: Technical Specifications

    (2.5A max 10s) 2.2A 0.2 A 0.24A Degree of protection SIMATIC PC FI10 Front IP65, otherwise IP20 Degree of protection SIMATIC PC BI10 Front IP20 Degree of protection SIMATIC PC FI15 Front IP65 (when flap of diskette drive closed) Safety Safety class Protection class I acc.

  • Page 8: Mother Board

    <5 spots Graphics Graphics chip SVGA-LCD Controller Cirrus GD7543 on PCI Windows accelerator Graphics memory 1 Mbyte DRAM Resolutions/frequencies/colors With LCD: up to 800x600/256 colors With CRT: up to 1024x768/256 colors at 72 Hz SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...
  • Page 9 Temp (with SafeCard only) LEDs on BI10 Disk * Isolation within the low voltage safety circuit (SELV) ** In the case of an installed direct key module, only a short ISA module can be fitted SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...

  • Page 10: Dimensions Of Expansion Modules

    Figure 1-1 XT Module (11,42) 2.54 (17 PL) 2.54 (30 PL) (0,1) (0,1) 23.0 max. 81.0 (0,2) (0,91) (All dimensions in mm) (3,19) (All dimensions ( ) in inches) 48,0 (1,89) Figure 1-2 AT Module SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...
  • Page 11 System Unit (11,42) (All dimensions in mm) (All dimensions ( ) in inches Figure 1-3 Long PCI Module (5 V) SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...

  • Page 12: Power Requirements Of The Components (Maximum Values)

    – Power Supply + 5V + 3.3V + 12V + 5Vp Maximum current delivery 8.0 A 2.2 A 1.5 A * 0.2 A 0.24 A * max. 2.5 A for 10 s SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...

  • Page 13: Removing And Installing Components

    Risk of damage to the unit! Note that only qualified personnel should be allowed to work on the open unit, so the warranty on the device is not affected. Authorized SIEMENS maintenance and repair centers offer you a specialist maintenance service. The user’s guide supplies you with their addresses.
  • Page 14 Touch components and modules only on their edges. Above all, do not touch the connecting pins or printed conductors. Do not operate the PC with the cover open. Tools Use a suitable crosstip or TORX screwdriver to remove or install components. SIMATIC PC BI10/FI10/FI15, Technical Description C79000-G7076-C773-03...

  • Page 15: Opening And Closing The System Unit (Computer Box)

    – Passive bus board – Fan (only in the FI15) – Hard disk drive – Floppy disk drive (only with FI10 and BI10) – Power supply SafeCard (optional) Below Figure 1-4 Opening the System Unit SIMATIC PC BI10/FI10/FI15, Technical Description 1-10 C79000-G7076-C773-03...

  • Page 16: Opening And Closing The Front Plate

    Only remove the screws that attach the shield plate to the front plate. The computer box of the FI15 can remain screwed to the shield plate. Figure 1-5 Removing the Front Plate of the FI10 SIMATIC PC BI10/FI10/FI15, Technical Description 1-11 C79000-G7076-C773-03...
  • Page 17 After removing the screws, tilt the box (together with the shield plate in the case of the FI15) backwards away from the front plate. The box is held by a hinge below and a cord above. SIMATIC PC BI10/FI10/FI15, Technical Description 1-12 C79000-G7076-C773-03...
  • Page 18 System Unit Figure 1-7 Removal for FI15 SIMATIC PC BI10/FI10/FI15, Technical Description 1-13 C79000-G7076-C773-03...
  • Page 19 – LC display – Inverter module – LC display plug adapter – Keyboard controller – Touch-screen controller (optional) – Touch-pad controller (only with FI15) – Touch-pad adapter (only with FI15) SIMATIC PC BI10/FI10/FI15, Technical Description 1-14 C79000-G7076-C773-03...

  • Page 20: Touch Screen

    Figure 1-9 Rear View of FI10 Front Plate LC display Inverter LCD plug adapter Touch screen controller (opt.) Keyboard Touch pad controller adapter Touch pad Figure 1-10 Rear View of FI15 Front Plate SIMATIC PC BI10/FI10/FI15, Technical Description 1-15 C79000-G7076-C773-03...

  • Page 21: Removing And Installing The Flat Screen / Inverter

    Caution Do not forget to mount the insulating sheet between the inverter module and sheet metal while installing. Figure 1-11 Removing the Display in the FI10 SIMATIC PC BI10/FI10/FI15, Technical Description 1-16 C79000-G7076-C773-03...
  • Page 22 System Unit Figure 1-12 Removing the Display in the FI15 (VGA TFT or SVGA TFT) SIMATIC PC BI10/FI10/FI15, Technical Description 1-17 C79000-G7076-C773-03...

  • Page 23: Removing And Installing The Keyboard Controller

    Before disconnecting all cables please write down their previous connections. Release the four mounting screws, then take out the keyboard controller module. Please proceed in reverse order to reassemble the unit. Figure 1-13 Removing the Keyboard Controller in the FI10 SIMATIC PC BI10/FI10/FI15, Technical Description 1-18 C79000-G7076-C773-03...
  • Page 24 System Unit Figure 1-14 Removing the Keyboard Controller in the FI15 SIMATIC PC BI10/FI10/FI15, Technical Description 1-19 C79000-G7076-C773-03...

  • Page 25: Replacing Backlight Tubes For Displays

    (see Figure 1-17). Reassemble the rear panel of the display (see Figure 1-18) and replace the 6 screws. Turn the 17 metal lugs back to the original skewed position. Check that the tube functions correctly. SIMATIC PC BI10/FI10/FI15, Technical Description 1-20 C79000-G7076-C773-03...
  • Page 26 Figure 1-15 Removing the Screws and Metal Hooks É É É É É É É É É É É É É É Change reflector film back plate Figure 1-16 Removing the Tube SIMATIC PC BI10/FI10/FI15, Technical Description 1-21 C79000-G7076-C773-03...
  • Page 27 É É É É É É (As sheet) reflector film É É É É É É É É É É É É É É reflector film back plate Figure 1-18 Reassembly SIMATIC PC BI10/FI10/FI15, Technical Description 1-22 C79000-G7076-C773-03...
  • Page 28 Install the new tube by following the above instructions in reverse order. Ensure that the tube socket locks in the display housing correctly. Note Always replace both tubes. back plate minus screwdriver Figure 1-19 Applying the Screwdriver SIMATIC PC BI10/FI10/FI15, Technical Description 1-23 C79000-G7076-C773-03...
  • Page 29 System Unit lamp unit ”t” marking side of lamp unit back plate ”s” marking metal portion at the side of the module lamp unit Figure 1-20 Sliding the Tubes In and Out SIMATIC PC BI10/FI10/FI15, Technical Description 1-24 C79000-G7076-C773-03...
  • Page 30 4 screws. Turn the 2 metal lugs back to the original skewed position. Check that the tube functions correctly. metal lugs back plate Figure 1-21 Metal Lugs on the Edge of the Display SIMATIC PC BI10/FI10/FI15, Technical Description 1-25 C79000-G7076-C773-03...
  • Page 31 É É É É É É É É É É É É É É É É É É É É É É É É É É É É Change reflector film Figure 1-23 Disassembling the Rear Panel of the Display SIMATIC PC BI10/FI10/FI15, Technical Description 1-26 C79000-G7076-C773-03...

  • Page 32: Removing And Installing The Floppy Disk Drive In The Bi10/Fi10

    Install the disk drive and ensure that the previous orientation of the floppy disk drive is retained; that is, the disk drive cable must be fed in from below. SIMATIC PC BI10/FI10/FI15, Technical Description 1-27 C79000-G7076-C773-03...

  • Page 33: Removing And Installing The Floppy Disk Drive In The Fi15

    Follow the above instructions in reverse order to install the new drive. The new drive must be of the same type as the drive you removed. Figure 1-25 Installing the Floppy Disk Drive in the FI15 SIMATIC PC BI10/FI10/FI15, Technical Description 1-28 C79000-G7076-C773-03...

  • Page 34: Removing And Installing The Hard Disk Drive

    Release the four screws which mount the floppy disk drive to the vibration reducing part of the support. Take the hard disk drive out of the drive support. Figure 1-26 Removing the Support for the Hard Disk Drive SIMATIC PC BI10/FI10/FI15, Technical Description 1-29 C79000-G7076-C773-03...
  • Page 35 System Unit Figure 1-27 Removing the Hard Disk Drive from the Support Proceed in reverse order to install a new drive. SIMATIC PC BI10/FI10/FI15, Technical Description 1-30 C79000-G7076-C773-03...
  • Page 36 (provided that both modules are of the same type and version; in any other case refer to the corresponding documentation of your module). Proceed in reverse order to install a new expansion module. SIMATIC PC BI10/FI10/FI15, Technical Description 1-31 C79000-G7076-C773-03...

  • Page 37: Removing And Installing The Bus Board

    Release the screws on the exterior of the system housing and pull the bus board out of the mother board. Figure 1-29 Removing and Installing the Bus Board Proceed in reverse order to install the bus board. SIMATIC PC BI10/FI10/FI15, Technical Description 1-32 C79000-G7076-C773-03...

  • Page 38: Removing And Installing A Fan

    Disconnect the connector for the fan cable at the power supply and lift the fan out. Figure 1-30 Removing and Installing the Fan Proceed in reverse order to install the fan. Note You must install a fan of the same type. SIMATIC PC BI10/FI10/FI15, Technical Description 1-33 C79000-G7076-C773-03...

  • Page 39: Removing And Installing The Power Supply Unit

    To install the power supply proceed in reverse order. Mains Voltage The 90 W power supply unit for the SIMATIC PC BI10/FI10/FI15 is Changeover designed for AC input voltages of 120V/240V +6% –10 % and input currents of 1.4A/0.8A for AC mains voltages at 50/60 Hz.

  • Page 40: Removing And Installing The Cpu Board

    Figure 1-32 Removing and Installing the CPU Module Proceed in reverse order to reinstall the board or to install a new one. Note Replacement CPU modules are supplied without memory submodules, processor, cooling unit, or voltage transformer. SIMATIC PC BI10/FI10/FI15, Technical Description 1-35 C79000-G7076-C773-03...

  • Page 41: Connecting The Mpi/Dp Interface

    9.6 Kbps up to 1.5 Mbps. Note For further information on configuring a PROFIBUS-DP network please refer to the “S7-300 Hardware and Installation manual,” Order no.: 6ES7030-0BA00-8AA0. *) Isolated within SELV circuit SIMATIC PC BI10/FI10/FI15, Technical Description 1-36 C79000-G7076-C773-03...

  • Page 42: Reset Button

    (for example, the tip of a ballpoint pen or the end of an opened paper clip). The following diagram of the FI15 shows the position of the reset button. 127.5 132.5 Figure 1-33 FI15 with Reset Button SIMATIC PC BI10/FI10/FI15, Technical Description 1-37 C79000-G7076-C773-03...
  • Page 43 This reset button can be activated by hand, without the need for any additional tool. The following figure shows the position of the reset button on the FI10 and BI10 devices. Reset Button Figure 1-34 FI10, BI10 with Reset Button SIMATIC PC BI10/FI10/FI15, Technical Description 1-38 C79000-G7076-C773-03...

  • Page 44: Error Diagnostics

    PS/2 port has been disabled in Check SETUP settings SETUP Mouse pointer moving erratically Trackball dirty Clean trackball and housing Drive cover cannot be opened Filter cap not properly fixed Push filter cap in proper position SIMATIC PC BI10/FI10/FI15, Technical Description 1-39 C79000-G7076-C773-03...
  • Page 45 System Unit SIMATIC PC BI10/FI10/FI15, Technical Description 1-40 C79000-G7076-C773-03...
