Revision A
Siemens BT300
HVAC Drive
Application Manual
www.sbt.siemens.com

Advertisement

Table of Contents
loading

Related Manuals for Siemens BT300

Summary of Contents for Siemens BT300

  • Page 1 Revision A Siemens BT300 HVAC Drive Application Manual www.sbt.siemens.com...

  • Page 3: Table Of Contents

    Startup Wizard ..........................3 PID Mini-Wizard ........................... 4 Multi-pump mini-wizard ........................ 5 Keypad of the drive...................7 Siemens keypad with graphical display ..................8 2.1.1 Keypad display ..........................8 2.1.2 Using the graphical keypad ......................8 Menu structure ........................... 13 2.2.1 Quick setup..........................13 2.2.2 Monitor............................

  • Page 4: Hour Support +1-800-877-7545 (Dial

    Siemens Industry, Inc. • 2 3.7.1 Fault appears..........................95 3.7.2 Fault history ..........................95 3.7.3 Fault codes ..........................96 24-hour support +1-800-877-7545 (Dial 2)

  • Page 5: Siemens Bt300 - Startup

    Back/Reset button. Pressing this button, you can return to the previous question in the Wizard. If pressed at the first question, the Startup Wizard will be canceled. Once you have connected power to your Siemens BT300 variable frequency drive, follow these instruc- tions to easily set up your drive.

  • Page 6: Pid Mini-Wizard

    Siemens Industry, Inc. • 4 Siemens BT300 - Startup Set value for Motor nominal current (ac- Range: Varies cording to nameplate) Set value Minimum frequency Range: 0.00...60.00 Hz value Maximum frequency Range: 0.00...320.00 Hz Now the Startup Wizard is done.

  • Page 7: Multi-Pump Mini-Wizard

    Siemens BT300 - Startup Siemens Industry, Inc. • 5 Sleep function? If option ‘Yes’ is selected you will be prompted for three more values: Sleep frequency limit 1 0.00...320.00 Hz Sleep delay 1 0...3000 s Wake-up level 1 Range depends on selected process unit.
  • Page 8 Siemens Industry, Inc. • 6 Siemens BT300 - Startup 24-hour support +1-800-877-7545 (Dial 2)

  • Page 9: Keypad Of The Drive

    EYPAD OF THE DRIVE The control keypad with graphical interface is the interface between the Siemens BT300 variable fre- quency drive and the user. With the control keypad it is possible to control the speed of a motor, to su- pervise the state of the equipment and to set the variable frequency driver's parameters.

  • Page 10: Siemens Keypad With Graphical Display

    Siemens Industry, Inc. • 8 Keypad of the drive Siemens keypad with graphical display The graphical keypad features an LCD display and 9 buttons. 2.1.1 Keypad display The keypad display indicates the status of the motor and the drive and any irregularities in motor or drive functions.
  • Page 11 Keypad of the drive Siemens Industry, Inc. • 9 STOP READY STOP READY STOP READY    Start/Stop Setup Ctrl. Place Auto Ctrl. Place Auto ID:172 M3.2.1 M3.2.1 M3.2.1 Ctrl. Place Auto Edit I/O Control FieldbusCTRL BACK KeypadStopButton RESET...
  • Page 12 Siemens Industry, Inc. • 10 Keypad of the drive STOP READY Keypad STOP Ready Keypad STOP READY Keypad Main Menu Choose action Hand/Auto ID:1805 ID:211  Monitor Hand Change direction ( 12 ) Auto Hand Control page Parameters  ( 21 )
  • Page 13 Keypad of the drive Siemens Industry, Inc. • 11 Before any parameters can successfully be copied from one drive to another, the drive has to be stopped when the parameters are downloaded. • First go into User settings menu and locate the Parameter backup sub-menu.
  • Page 14 Siemens Industry, Inc. • 12 Keypad of the drive 2.1.2.6 Adding an item to Favorites You might need to refer to certain parameter values or other items often. Instead of locating them one by one in the menu structure, you may want to add them to a folder called Favorites where they can easily be reached.

  • Page 15: Menu Structure

    Keypad of the drive Siemens Industry, Inc. • 13 Menu structure 2.2.1 Quick setup The Quick Setup Menu includes the minimum set of most commonly used parameters during installation and commissioning. You can find more detailed information on the parameters of this group in Chapter 3.3.

  • Page 16: Parameters

    Siemens Industry, Inc. • 14 Keypad of the drive 2.2.3 Parameters Through this sub-menu, you can reach the application parameter groups and parameters. You can find more information on parameters in Chapter 3. 2.2.4 Diagnostics Under this menu, you can find Active faults, Reset faults, Fault history, Counters and Software info 2.2.4.1...
  • Page 17 Keypad of the drive Siemens Industry, Inc. • 15 2.2.4.4 Total counters Table 1: Diagnostics menu, Total counters parameters. Code Parameter Unit Default Description Amount of energy taken V4.4.1 Energy counter Varies 2291 from supply network. No reset. V4.4.3 Operating time...

  • Page 18: I/O And Hardware

    Siemens Industry, Inc. • 16 Keypad of the drive 2.2.5 I/O and hardware Various options-related settings are located in this menu. 2.2.5.1 Basic I/O Monitor here the status of inputs and outputs. Table 4: I/O and Hardware menu, Basic I/O parameters.
  • Page 19 Keypad of the drive Siemens Industry, Inc. • 17 2.2.5.2 Option board slots The parameters of this group depend on the option board installed. If no option board is placed in slots D or E, no parameters are visible. See Chapter 3.5.1 for the location of the slots.
  • Page 20 Siemens Industry, Inc. • 18 Keypad of the drive 2.2.5.5 Keypad Table 7: I/O and Hardware menu, Keypad parameters. Code Parameter Unit Default Description Time after which the dis- play returns to page P5.6.1 Timeout time defined with parameter P5.6.2.

  • Page 21: User Settings

    Keypad of the drive Siemens Industry, Inc. • 19 2.2.6 User settings Table 8: User settings menu, General settings. Code Parameter Unit Default Description Depends on language P6.1 Language selections Varies Varies Varies package. P6.2 Application selection M6.5 Parameter backup See Chapter 2.2.6.1 below.

  • Page 22: Favorites

    Siemens Industry, Inc. • 20 Keypad of the drive 2.2.7 Favorites Favorites are typically used to collect a set of parameters or monitoring signals from any of the keypad menus. You can add items or parameters to the Favorites folder, see Chapter 2.1.2.6.

  • Page 23: Siemens Application

    Specific functions of the Siemens application The Siemens BT300 application is an easy-to-use application for not only basic pump and fan applica- tions where only one motor and one drive is needed, but also offers extensive possibilities for PID con- trol.

  • Page 24: Example Of Control Connections

    24V auxiliary input voltage RS485 Serial bus, negative To Relay board RS485 Serial bus, positive 1 or 2 Selectable with DIP switches, see Siemens BT300 Installa- tion Manual Digital inputs can be isolated from ground. See Installation Manual. 24-hour support +1-800-877-7545 (Dial 2)

  • Page 25: Application - Quick Setup Parameter Group

    Siemens Application Siemens Industry, Inc. • 23 Table 12. Connection example, Relay board 1. From Relay board 1 Standard I/O board Default From term. From term. Terminal Signal #6 or 12 RO1/1 NC RO1/2 CM Relay output 1 RUN RO1/3 NO...

  • Page 26: Monitor Group

    1 = Activate See Chapter 1.1. Monitor group The Siemens BT300 drive provides you with a possibility to monitor the actual values of parameters and signals as well as status and measurements. Some of the values to be monitored are customizable. 3.4.1 Multi-monitor On the multi-monitor page, you can collect nine values that you wish to monitor.

  • Page 27: Basic

    Siemens Application Siemens Industry, Inc. • 25 3.4.2 Basic See Table 14 in which the basic monitoring values are presented. NOTE: Only Standard I/O board status are available in the Monitor menu. Status for all I/O board signals can be found as raw data in the I/O and Hardware system menu.

  • Page 28: Timer Functions Monitoring

    Siemens Industry, Inc. • 26 Siemens Application Table 15: Monitoring menu items. Code Monitoring value Unit Description Motor current monitor value with a fixed number of decimals and less filtering. Can be used e.g. Motor current with 1 deci- for fieldbus purposes to always get the right V2.2.22...

  • Page 29: Pid1 Controller Monitoring

    Siemens Application Siemens Industry, Inc. • 27 3.4.4 PID1 controller monitoring Table 17: PID1-controller value monitoring. Code Monitoring value Unit Description V2.4.1 PID1 setpoint Varies Process units selected with parameter V2.4.2 PID1 feedback Varies Process units selected with parameter V2.4.3...

  • Page 30: Fieldbus Data Monitoring

    Siemens Industry, Inc. • 28 Siemens Application 3.4.7 Fieldbus data monitoring Table 20: Fieldbus data monitoring Code Monitoring value Unit Description Fieldbus control word used by application in bypass mode/ V2.8.1 FB Control Word format. Depending on the fieldbus type or profile the data can be modified before sent to application.

  • Page 31: Temperature Inputs Monitoring

    Siemens Application Siemens Industry, Inc. • 29 3.4.8 Temperature inputs monitoring Table 21: Temperature inputs monitoring Code Parameter Unit Default Description Measured value of Tem- perature Input 1. The list of temperature inputs are filled by taking the 6 first available temperature inputs starting -50.0...

  • Page 32: Application Parameter Lists

    Siemens Industry, Inc. • 30 Siemens Application Application parameter lists Find the parameter menu and the parameter groups as guided below. STOP READY Keypad STOP READY Keypad  Parameters Main Menu M3.1 Quick Setup  Motor Settings   ( 17 ) ( 2 ) ...

  • Page 33: Parameter Programming

    ‘DigIN / dI’ stand for digital input. ‘Slot_’ refers to the board; A and B are Siemens drive standard boards, D and E are option boards (see Figure 10). See Chapter 3.5.1.2. The number after the board letter refers to the respective terminal on the selected board.
  • Page 34 Siemens Industry, Inc. • 32 Siemens Application EXAMPLE: You want to connect the Control signal 2 A (parameter P3.5.1.2) to digital input DI2 on Standard I/O board. 3.5.1.1 Example programming with graphical keypad Locate the parameter Control signal 2 A (P3.5.1.2) on the keypad.

  • Page 35: Column Explanations

    Siemens Application Siemens Industry, Inc. • 33 3.5.1.2 Descriptions of signal sources: Table 23. Descriptions of signal sources. Source Function Slot0 1 = Always FALSE, 2-9 = Always TRUE SlotA Number corresponds to digital input in the slot. SlotB Number corresponds to digital input in the slot.

  • Page 36: Group 3.1: Motor Settings

    Siemens Industry, Inc. • 34 Siemens Application 3.5.3 Group 3.1: Motor settings 3.5.3.1 Basic Settings Table 24: Basic motor settings. Code Parameter Unit Default Description Find this value U (V) on the rating plate of the motor. This parameter sets the volt- P3.1.1.1...

  • Page 37: Group 3.2: Start/Stop Setup

    Siemens Application Siemens Industry, Inc. • 35 Table 25: Advanced motor settings. Code Parameter Unit Default Description 0 = Not used 1 = Always in stop state 2 = Controlled by DI P3.1.2.5 Motor preheat function 1225 3 = Temp limit (heat sink)
  • Page 38 Siemens Industry, Inc. • 36 Siemens Application Auto control place (I/O B): Start, stop and reverse commands are controlled by 2 digital inputs chosen with parameters P3.5.1.3 and P3.5.1.4. The functionality/logic for these inputs is then selected with pa- rameter P3.2.7 (in this group).

  • Page 39: Group 3.3: Control Reference Settings

    Siemens Application Siemens Industry, Inc. • 37 3.5.5 Group 3.3: Control reference settings The frequency reference source is programmable for all control places except PC, which always takes the reference from the PC tool. Auto control place (I/O A): The source of frequency reference can be selected with parameter P3.3.3.
  • Page 40 Siemens Industry, Inc. • 38 Siemens Application Table 27: Control reference settings. Code Parameter Unit Default Description Selection of ref source when control place is Fieldbus: 1 = Preset frequency 0 2 = Keypad Fieldbus control refer- 3 = Fieldbus P3.3.9...

  • Page 41: Group 3.4: Ramp & Brakes Setup

    Siemens Application Siemens Industry, Inc. • 39 3.5.6 Group 3.4: Ramp & Brakes Setup Two ramps are available (two sets of acceleration time, deceleration time and ramp shape). The second ramp can be activated by a digital input. NOTE: Ramp 2 always has higher priority and is used if a digital input for ramp selection is activated or the Ramp 2 threshold is smaller than RampFreqOut.

  • Page 42: Group 3.5: I/O Configuration

    Siemens Industry, Inc. • 40 Siemens Application 3.5.7 Group 3.5: I/O Configuration 3.5.7.1 Digital inputs Digital inputs are very flexible to use. Parameters are functions that are connected to the required digital input terminal. The digital inputs are represented as, for example, DigIN Slot A.2, meaning the second input on slot A.
  • Page 43 Siemens Application Siemens Industry, Inc. • 41 Table 29: Digital input settings. Code Parameter Default Description FALSE = Setpoint 1 P3.5.1.24 PID2 select setpoint DigIN Slot0.1 1048 TRUE = Setpoint 2 FALSE = Not active P3.5.1.25 Motor 1 interlock DigIN Slot0.1...
  • Page 44 Siemens Industry, Inc. • 42 Siemens Application 3.5.7.2 Analog inputs Table 30: Analog input settings. Code Parameter Unit Default Description Connect the AI1 signal to the AnIN analog input of your choice P3.5.2.1 AI1 signal selection SlotA.1 with this parameter.
  • Page 45 Siemens Application Siemens Industry, Inc. • 43 Table 30: Analog input settings. Code Parameter Unit Default Description P3.5.2.29 AI5 custom. max -160.00 160.00 100.00 Custom range max setting 0 = Normal P3.5.2.30 AI5 signal inversion 1 = Signal inverted AnIN See P3.5.2.13.
  • Page 46 Siemens Industry, Inc. • 44 Siemens Application 3.5.7.3 Digital outputs, slot B (Basic) Table 31: Digital output settings on standard I/O board. Code Parameter Unit Default Description Function selection for Basic R01: 0 = None 1 = Ready 2 = Run...
  • Page 47 Siemens Application Siemens Industry, Inc. • 45 3.5.7.4 Expander slots D and E digital outputs Table 32: Slot D/E digital outputs. Code Parameter Unit Default Description Shows only parameters for existing outputs in slot D/E. Application dynamic Selections as in Basic R01...

  • Page 48: Group 3.6: Fieldbus Data Mapping

    Siemens Industry, Inc. • 46 Siemens Application 3.5.7.6 Expander slots D to E analog outputs Table 34: Slot D/E analog outputs. Code Parameter Unit Default Description Shows only parameters for existing outputs in slot D/E. Application dynamic Selections as in Basic AO1...

  • Page 49: Group 3.7: Prohibited Frequencies

    Siemens Application Siemens Industry, Inc. • 47 3.5.9 Group 3.7: Prohibited Frequencies In some systems it may be necessary to avoid certain frequencies due to mechanical resonance prob- lems. By setting up prohibit frequencies, it is possible to skip these ranges.

  • Page 50: Group 3.8: Limit Supervisions

    Siemens Industry, Inc. • 48 Siemens Application 3.5.10 Group 3.8: Limit supervisions Choose here: 1. One or two (P3.8.1/P3.8.5) signal values for supervision. 2. Whether the low or high limits are supervised (P3.8.2/P3.8.6) 3. The actual limit values (P3.8.3/P3.8.7). 4. The hysteresis for the set limit values (P3.8.4/P3.8.8).

  • Page 51: Group 3.9: Protections

    Siemens Application Siemens Industry, Inc. • 49 3.5.11 Group 3.9: Protections Parameters of Motor thermal protection (P3.9.6 to P3.9.10) The motor thermal protection is to protect the motor from overheating. The drive is capable of supplying higher than nominal current to the motor. If the load requires this high current, there is a risk that the motor will thermally overload.
  • Page 52 Siemens Industry, Inc. • 50 Siemens Application Table 39: Protections settings. Code Parameter Unit Default Description 0 = No action 1 = Alarm Response to external P3.9.2 2 = Fault (Stop according to fault stop mode) 3 = Fault (Stop by coasting) Response to Input P3.9.3...
  • Page 53 Siemens Application Siemens Industry, Inc. • 51 Table 39: Protections settings. Code Parameter Unit Default Description Response to Fieldbus P3.9.19 See P3.9.1 communication fault Slot communication P3.9.20 See P3.9.2 fault See P3.9.2 It is recommended to set this value to 2 if an option P3.9.21 Thermistor fault...

  • Page 54: Group 3.10: Automatic Reset

    Siemens Industry, Inc. • 52 Siemens Application 3.5.12 Group 3.10: Automatic reset Table 40: Autoreset Settings. Code Parameter Unit Default Description 0 = Disabled P3.10.1 Automatic reset 1 = Enabled The start mode for Automatic reset is selected with this P3.10.2...

  • Page 55: Group 3.11: Timer Functions

    3.5.13 Group 3.11: Timer functions The time functions (Time Channels) in the Siemens BT300 give you the possibility to program functions to be controlled by the internal RTC (Real Time Clock). Practically every function that can be controlled by a digital input can also be controlled by a Time Channel. Instead of having an external PLC controlling a digital input you can program the "closed"...
  • Page 56 Siemens Industry, Inc. • 54 Siemens Application Timers Timers can be used to set a Time Channel active during a certain time by command from a digital input (or a Time Channel). Remaining time Time Activation Duration 9137.emf 9137.emf Figure 12. Activation signal comes from a digital input or "a virtual digital input" such as a Time channel.
  • Page 57 Siemens Application Siemens Industry, Inc. • 55 Timer 1 The manual bypassing can be handled by a digital input 1 on slot A (by a different switch or connection to lighting). P3.11.6.1: Duration: 1800s (30min) P3.11.6.2: Assign to channel: Time channel 1 P3.5.1.18: Timer 1: DigIn SlotA.1 (Parameter located in digital inputs menu.)
  • Page 58 Siemens Industry, Inc. • 56 Siemens Application Table 41: Timer functions. Code Parameter Unit Default Description P3.11.3.2 OFF time 00:00:00 23:59:59 hh:mm:ss 00:00:00 1475 See Interval 1 P3.11.3.3 From day 1476 See Interval 1 P3.11.3.4 To day 1477 See Interval 1 P3.11.3.5...

  • Page 59: Group 3.12: Pid-Controller 1

    Siemens Application Siemens Industry, Inc. • 57 3.5.14 Group 3.12: PID-controller 1 3.5.14.1 Basic settings Table 42: PID Basic Settings. Code Parameter Unit Default Description If the value of the parameter is set to 100% a change of P3.12.1.1 PID gain 0.00...
  • Page 60 Siemens Industry, Inc. • 58 Siemens Application Table 42: PID Basic Settings. Code Parameter Unit Default Description Dead band area around the setpoint in process units.The PID output is locked if the P3.12.1.9 Dead band hysteresis Varies Varies Varies 1056...
  • Page 61 Siemens Application Siemens Industry, Inc. • 59 3.5.14.2 Setpoints Table 43: PID Setpoints. Code Parameter Unit Default Description P3.12.2.1 Keypad setpoint 1 Varies Varies Varies P3.12.2.2 Keypad setpoint 2 Varies Varies Varies Defines the rising and falling ramp times for setpoint P3.12.2.3...
  • Page 62 Siemens Industry, Inc. • 60 Siemens Application Table 43: PID Setpoints. Code Parameter Unit Default Description Minimum value at analog sig- P3.12.2.12 Setpoint 2 minimum -200.00 200.00 0.00 1073 nal minimum. Maximum value at analog P3.12.2.13 Setpoint 2 maximum -200.00 200.00...
  • Page 63 Siemens Application Siemens Industry, Inc. • 61 Table 44: PID Feedback. Code Parameter Unit Default Description Feedback 2 P3.12.3.6 See P3.12.3.3 source selection Minimum value at analog sig- P3.12.3.7 Feedback 2 minimum -200.00 200.00 0.00 nal minimum. Maximum value at analog sig- P3.12.3.8...
  • Page 64 The feedforward part does not use any feedback measurements of the actual controlled process value (water level in the example on page 87). Siemens feedforward control uses oth- er measurements which are indirectly affecting the controlled process value.
  • Page 65 Siemens Application Siemens Industry, Inc. • 63 3.5.14.6 Pressure Loss Compensation Table 47: Pressure Loss Compensation. Code Parameter Unit Default Description Enables pressure loss com- pensation for setpoint 1. P3.12.6.1 Enable setpoint 1 1189 0 = Disabled 1 = Enabled Value added proportionally to the frequency.

  • Page 66: Group 3.13: Pid-Controller 2

    Siemens Industry, Inc. • 64 Siemens Application 3.5.15 Group 3.13: PID-controller 2 3.5.15.1 Basic settings For more detailed information, see Chapter 3.5.14. Table 48: PID-2 Basic Settings. Code Parameter Unit Default Description 0 = Disabled P3.13.1.1 Enable PID 1630 1 = Enabled...
  • Page 67 Siemens Application Siemens Industry, Inc. • 65 Table 48: PID-2 Basic Settings. Code Parameter Unit Default Description The setpoint and feedback values are internally han- dled as percent, but can be scaled to process units on the panel. Process Unit selection selects unit.
  • Page 68 Siemens Industry, Inc. • 66 Siemens Application Table 48: PID-2 Basic Settings. Code Parameter Unit Default Description Dead band around the setpoint. When we are within this area the PID controller output will be locked. The size of the Dead P3.13.1.12...
  • Page 69 Siemens Application Siemens Industry, Inc. • 67 3.5.15.3 Feedback For more detailed information, see Chapter 3.5.14. Table 50: PID-2 Feedback Code Parameter Unit Default Description Choose a single signal used as feedback or make calcula- P3.13.3.1 Feedback function 1650 tions based on one or two signals.
  • Page 70 Siemens Industry, Inc. • 68 Siemens Application Table 51: PID-2 Process Supervision. Code Parameter Unit Default Description Process supervision is used to supervise that the actual value stays within some predefined limits. With this function we can e.g. P3.13.4.3 Lower limit...

  • Page 71: Group 3.14: Multi-Pump

    Siemens Application Siemens Industry, Inc. • 69 3.5.16 Group 3.14: Multi-pump The Multi-pump functionality allows you to control up to 4 motors (pumps, fans) with PID controller 1. The drive is connected to one motor which is the "regulating" motor connecting and disconnecting the other motors to/from the mains by means of contactors controlled with relays when needed in order to maintain the right setpoint.

  • Page 72: Group 3.16: Fire Mode

    Siemens Industry, Inc. • 70 Siemens Application 3.5.17 Group 3.16: Fire mode The drive ignores all commands from the keypad, fieldbuses and the PC tool and runs at preset frequency when activated. If activated, the alarm sign is shown on the keypad and the warranty is void.

  • Page 73: Hvac Application - Additional Parameter Information

    Siemens Industry, Inc. • 71 HVAC Application - Additional parameter information Due to its simplicity of use, most parameters of the Siemens Application only require a basic description, which is given in the parameter tables in Chapter 3.5. In this chapter, you will find additional information on some of the more advanced application parameters.
  • Page 74 Siemens Industry, Inc. • 72 Siemens Application Stop function (P3.2.5) Selection Selection name Description number The motor is allowed to stop on its own inertia. The control by the Coasting drive is discontinued and the drive current drops to zero as soon as the stop command is given.
  • Page 75 Siemens Application Siemens Industry, Inc. • 73 Selection Selection name Note number CS1: Forward The functions take place when the contacts are closed. CS2: Backward Output frequency Set frequency 0 Hz Set frequency Run enable Ctrl signal 1 Ctrl signal 2...
  • Page 76 Siemens Industry, Inc. • 74 Siemens Application Selection Selection name Note number CS1: Forward (edge) CS2: Inverted stop Output frequency Set frequency 0 Hz Set frequency Run enable Ctrl signal 1 Ctrl signal 2 Keypad stop button 9176.emf Figure 16. I/O A Start/Stop logic = 1.
  • Page 77 Siemens Application Siemens Industry, Inc. • 75 Selection Selection name Note number Used to exclude the possibility of an unintentional start. The CS1: Forward (edge) Start/Stop contact must be opened before the motor can be CS2: Backward (edge) restarted. Output...
  • Page 78 Siemens Industry, Inc. • 76 Siemens Application Selection Selection name Note number CS1: Start CS2: Reverse Output frequency Set frequency 0 Hz Set frequency Run enable Ctrl signal 1 Ctrl signal 2 Keypad start button Keypad stop button 11094.emf Figure 18. I/O A Start/Stop logic = 3.
  • Page 79 Siemens Application Siemens Industry, Inc. • 77 Selection Selection name Note number Used to exclude the possibility of an unintentional start. The CS1: Start (edge) Start/Stop contact must be opened before the motor can be CS2: Reverse restarted. Output frequency...
  • Page 80 Siemens Industry, Inc. • 78 Siemens Application Selection Selection name Note number Combine activated inputs according to Table to choose the Pre- Binary coded set frequency needed. You can apply the Preset frequencies 1 to 3, depending on how Number (of inputs used) many of the inputs assigned for Preset frequency selections are active.
  • Page 81 Siemens Application Siemens Industry, Inc. • 79 [Hz] P3.4.2, P3.4.3 P3.4.1 P3.4.1 11096.emf Figure 20. Acceleration/Deceleration (S-shaped). Flux braking (P3.4.12) Instead of DC braking, flux braking is a useful way to raise the braking capacity in cases where additional brake resistors are not needed.
  • Page 82 Siemens Industry, Inc. • 80 Siemens Application NOTE: Long filtering time makes the regulation response slower! Unfiltered signal 100% Filtered signal t [s] P3.5.2.2 11097.emf Figure 21. AI1 signal filtering. Basic R01 function (P3.5.3.2.1) Table 56. Output signals via RO1.
  • Page 83 Siemens Application Siemens Industry, Inc. • 81 Table 56. Output signals via RO1. Selection Selection name Description Reserved PID1 supervision limits PID1 feedback value is beyond supervision limits. PID2 supervision limits PID2 feedback value is beyond supervision limits. Motor 1 control...
  • Page 84 Siemens Industry, Inc. • 82 Siemens Application Motor thermal time constant (P3.9.9) The time constant is the time within which the calculated thermal stage has reached 63% of its final val- ue. The bigger the frame and/or the slower the speed of the motor, the longer the time constant.
  • Page 85 Siemens Application Siemens Industry, Inc. • 83 Stall area Par. P3.9.12 Par. P3.9.14 11100.emf Figure 24. Stall characteristics settings. Stall time limit (P3.9.13) This time can be set between 1.0 and 120.0s. This is the maximum time allowed for a stall stage. The stall time is counted by an internal up/down counter.
  • Page 86 Siemens Industry, Inc. • 84 Siemens Application Torque Par. P3.9.16 Par. P3.9.17 Under load area Fieldweakening 5 Hz point 11102.emf Figure 26. Setting of minimum load. Underload protection: Time limit (P3.9.18) This time can be set between 2.0 and 600.0 s.
  • Page 87 Siemens Application Siemens Industry, Inc. • 85 Wait time (P3.10.3) Automatic reset: Trial time (P3.10.4) Number of trials (P3.10.5) The Automatic reset function keeps resetting the faults appearing during the time set with this parameter. If the number of faults during the trial time exceed the value of parameter P3.10.5, a permanent fault is generated.
  • Page 88 Siemens Industry, Inc. • 86 Siemens Application Dead band (P3.12.1.9) Reference Actual value Dead band delay (P3.12.1.10) Output locked 11105.emf Figure 29. Dead band. Sleep frequency limit 1 (P3.12.2.7) Sleep delay 1 (P3.12.2.8) Wake-up level 1 (P3.12.2.9) This function will put the drive into sleep mode if the frequency stays below the sleep limit for a longer period than that set with the Sleep Delay (P3.12.2.8).
  • Page 89 The feedforward part does not use any feedback measurements of the actual controlled process value (water level in the example on page 87). Siemens feedforward control uses other mea- surements which are indirectly affecting the controlled process value.
  • Page 90 Siemens Industry, Inc. • 88 Siemens Application Enable process supervision (P3.12.5.1) Actual value Upper limit P3.12.5.2) Refer ence Lower limit (P3.12.5.3) Delay (P3.12.5.4) Regulating mode Alarm or fault 11108.emf Figure 32. Process supervision. Upper and lower limits around the reference are set. When the actual value goes above or below, a counter starts counting up towards the Delay (P3.12.5.4).
  • Page 91 Siemens Application Siemens Industry, Inc. • 89 Enable setpoint 1 (P3.12.6.1) Setpoint 1 max compensation (P3.12.6.2) The sensor is placed in Position 1. The pressure in the pipe will remain constant when we have no flow. However, with flow, the pressure will drop farther down in the pipe. This can be compensated by raising the setpoint as the flow increases.
  • Page 92 Siemens Industry, Inc. • 90 Siemens Application MULTI-PUMP USE Motors are connected/disconnected if the PID controller is not able to keep the process value or feed- back within the defined bandwidth around the setpoint. Criteria for connecting/adding motors (also see Figure 35): •...
  • Page 93 Siemens Application Siemens Industry, Inc. • 91 EXAMPLE OF THE INTERLOCK LOGIC: If the motor starting order is 1->2->3->4->5 When the interlock of motor 3 is removed, i.e. the value of parameter P3.5.1.27 is set to FALSE, the order changes to: 1->2->4->5.
  • Page 94 Siemens Industry, Inc. • 92 Siemens Application Figure 36. Selection 1, Enabled: If the regulating motor needs to be included in the auto-change or interlock logic make the connection according to Figure 37 below. Each motor is controlled by a relay, but the contact logic ensures that the first connected motor is always connected to the drive and near the mains.
  • Page 95 Siemens Application Siemens Industry, Inc. • 93 Figure 37. Auto-change (P3.14.4) Selection Selection name Description The priority/starting order of the motors is always 1-2-3-4-5 in normal operation. It may have changed during its run if inter- Disabled added locks have been removed and again, but the priority/ order is always restored after a stop.

  • Page 96: Application - Fault Tracing

    Fault history menu which can be browsed. You will find the fault codes in the table below. NOTE : When contacting Siemens because of a fault condition, always note the texts and codes on the keypad display.

  • Page 97: Fault Appears

    Siemens Application Siemens Industry, Inc. • 95 3.7.1 Fault appears When a fault appears and the drive stops, examine the cause of the fault, perform the actions advised here and reset the fault as instructed below. 1. Press the button on the keypad for one second or Reset 2.

  • Page 98: Fault Codes

    Siemens Industry, Inc. • 96 Siemens Application 3.7.3 Fault codes Table 57. Fault codes and descriptions. Fault Fault Fault name Possible cause Remedy code Over-current The drive has detected too high a current Check loading. (hardware fault) (>4*I ) in the motor cable: Check motor.
  • Page 99 Siemens Application Siemens Industry, Inc. • 97 Table 57. Fault codes and descriptions. Fault Fault Fault name Possible cause Remedy code Communication between control board and power unit has failed. Watchdog has reset the CPU. Reset the fault and restart.
  • Page 100 Siemens Industry, Inc. • 98 Siemens Application Table 57. Fault codes and descriptions. Fault Fault Fault name Possible cause Remedy code AC drive over- temperature (fault, heatsink) Check the correct amount and flow of AC drive over- cooling air. temperature Too high temperature measured in power Check the heatsink for dust.
  • Page 101 Siemens Application Siemens Industry, Inc. • 99 Table 57. Fault codes and descriptions. Fault Fault Fault name Possible cause Remedy code Option board changed for one not present Device changed Set the option board parameters in the same slot before. No parameter set- (different type) again.
  • Page 102 Siemens Industry, Inc. • 100 Siemens Application 24-hour support +1-800-877-7545 (Dial 2)
