Dock

Speaker
(right)

Playing iPod using the dock

By connecting the supplied dock to your Hi-Fi
system, you can listen to the sound of the
docked player through the powerful speakers of
the Hi-Fi system.

Compatible portable player

●
Most Apple iPod models with 30-pin dock
connector as follows:
20GB, 40GB, 20/30GB photo, 40/60GB photo,
30GB video, 60GB video, mini and nano.
Dock
This system comes with a dock used for iPod.
Connect the cable of the dock to the system to
let the system and your iPod work together.

Dock adaptor

Before plugging your player in the dock, snap the
suitable dock adaptor into the dock to provide a
snug fit for the player to be docked.

Selecting the correct dock adaptor

●
8 dock adaptors of different type, as indicated at
the back of the adaptor, are included to fit the
following iPod:
20GB, 40GB, 20/30GB photo, 40/60GB photo,
30GB video, 60GB video, mini and nano.
16
Speaker
(left)

Installing the dock adaptor

1
Align two holes of the dock and two latches of
the adaptor, then gently push in the adaptor until
it clicks.
2
Removing the dock adaptor
●
Slightly push down the dock adaptor, as indicated
in the figure below, to un-latch the adaptor, then
take it out.
Portable player
Dock
1
