Installation Guide
hp StorageWorks HA-Fabric
Manager Appliance
Product Version: FW v06.xx/HAFM SW v08.02.00
(July 2004) Second Edition
Product Number: AA–RU5FB–TE/958–000324–001
This document provides instructions to perform initial setup and configuration of the HAFM appliance. This
document also describes backup and restore procedures, install and upgrade procedures, HAFM appliance-specific
diagnostics, and how to optionally rack-mount the HAFM appliance in a standard, customer-supplied, 19-inch
equipment cabinet.

Advertisement

Table of Contents
loading

Related Manuals for HP StorageWorks HA-Fabric Manager

Summary of Contents for HP StorageWorks HA-Fabric Manager

  • Page 1 Installation Guide hp StorageWorks HA-Fabric Manager Appliance Product Version: FW v06.xx/HAFM SW v08.02.00 (July 2004) Second Edition Product Number: AA–RU5FB–TE/958–000324–001 This document provides instructions to perform initial setup and configuration of the HAFM appliance. This document also describes backup and restore procedures, install and upgrade procedures, HAFM appliance-specific diagnostics, and how to optionally rack-mount the HAFM appliance in a standard, customer-supplied, 19-inch equipment cabinet.
  • Page 2 Hewlett-Packard Company products are set forth in the express limited warranty statements for such products. Nothing herein should be construed as constituting an additional warranty. Printed in the U.S.A. hp StorageWorks HA-Fabric Manager Appliance Installation Guide (July 2004) Second Edition...

  • Page 3: Table Of Contents

    ......13 HP Storage Web Site ......13 HP Authorized Reseller .
  • Page 4 Configuring Appliance Names ......48 Configuring Gateway and DNS Server Addresses ....51 Configuring Windows 2000 Users .
  • Page 5 List of Figures 1.1. HAFM Appliance ....... . . 15 1.2.
  • Page 6 3.26. VNC Authentication Screen ......45 3.27. Welcome to Windows dialog box ......46 3.28.
  • Page 7 List of Tables 1. Document Conventions ....... . 11 1.1. Factory-Set Defaults (HAFM Appliance) .

  • Page 9: About This Guide

    Troubleshoot and resolve HAFM appliance and application problems. “About this Guide” topics include: • Overview • Conventions • Rack Stability • Getting Help Overview This section covers the following topics: • Intended Audience • Related Documentation hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 10: Intended Audience

    For a list of corresponding documentation, see the Related Documents section of the Release Notes that came with this product. For the latest information, documentation, and firmware releases, please visit the HP StorageWorks web site: http://h18006.www1.hp.com/storage/saninfrastructure.html. For information about Fibre Channel standards, visit the Fibre Channel Industry Association web site, located at: http://www.fibrechannel.org.

  • Page 11: Document Conventions

    Text set off in this manner indicates that failure to follow directions could result in damage to equipment or data. Note Text set off in this manner presents commentary, sidelights, or interesting points of information. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 12: Equipment Symbols

    WARNING: To reduce the risk of personal injury or damage to the equipment, observe local occupational health and safety requirements and guidelines for manually handling material. Rack Stability Rack stability protects personnel and equipment. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 13: Getting Help

    • Detailed, specific questions HP Storage Web Site The HP Web site has the latest information on this product, as well as the latest drivers. Access storage at: http://www.hp.com/country/us/eng/prodserv/storage.html. From this Web site, select the appropriate product or solution. hp StorageWorks HA-Fabric Manager Appliance Installation...

  • Page 14: Hp Authorized Reseller

    For the name of your nearest HP authorized reseller: • In the United States, call 1-800-345-1518 • In Canada, call 1-800-263-5868 • Elsewhere, see the HP Web site for locations and telephone numbers: http://www.hp.com. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 15: Initial Setup

    Edge Switches, and are a dedicated hardware and software solution that should not be used for other tasks. HP tests the HAFM application installed on the HAFM appliance, but does not compatibility test other third-party software. Modifications to the HAFM appliance hardware or installation of additional software (including patches or service packs) are not supported, and may interfere with normal operation.

  • Page 16: Front Panel

    3 — Hard Disk Drive (HDD) LED 4 — Fan LED 5 — LAN 1 status indicator 6 — LAN 2 status indicator 7 — LCD navigation buttons 8 — Power on/off button hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 17: Factory Defaults

    Administrator HAFM application password (case sensitive) password LAN 1 (public interface) IP address 192.168.0.1 Subnet mask 255.0.0.0 Gateway address 0.0.0.0 LAN 2 (private interface) IP address 10.1.1.1 Subnet mask 255.0.0.0 Gateway address 0.0.0.0 hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 18: Kit Contents

    (through a standard web browser) to the appliance desktop. Current platforms may ship with more enhanced hardware, such as a faster processor, additional random-access memory (RAM), or a higher-capacity hard drive. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...
  • Page 19 Chapter 1. Initial Setup • Ship group kit, containing: • HAFM appliance. • Ten (10) square alignment washers (required for rack-mounting in HP 9000, 10000 and 11000 series racks). • HAFM application CD-ROM. • HAFM boot/restore CD-ROM. • Norton AntiVirus CD-ROM.

  • Page 20: Mounting Brackets, Slide Rails, And Bar Nuts

    Four (4) flat-head Phillips machine screws (#8 x 7/16) that secure the two-hole bar nuts, front brackets, and rear brackets. • Two (2) hexagonal-nut standoffs. Figure 1-4 illustrates the standoff and mounting screws. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 21: Hexagonal-Nut Standoff And Mounting Screws

    Chapter 1. Initial Setup Figure 1.4. Hexagonal-Nut Standoff and Mounting Screws hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 23: Installation

    • The mounting standard-to-mounting standard cabinet depth must be from 18 inches to 32 inches to accommodate the rack mount kit. The HP rack mount kit must be used to install the appliance. • It is the customer’s responsibility to accurately calculate power requirements for the appliance and switches installed in the cabinet.

  • Page 24: Three-Hole Bar Nut Alignment

    Using a #2 Phillips screwdriver and eight (8) of the ten pan-head Phillips screws (#10 x 1/2) and, if you are installing the server in an HP 9000, 10000 or 11000 rack, eight (8) square alignment washers, attach four (4) three-hole bar nuts to the rack-mounting...
  • Page 25 Attach each bar nut using two screws (first and third holes) per nut. Note If you are installing the bar nuts on an HP 9000, 10000, or 11000 series cabinet, add a square alignment washer to each screw, orienting the protruding alignment bumps with the rack-mounting standard.

  • Page 26: Front And Rear Bracket Assembly

    Attach each bracket assembly to the rack-mounting standards as shown in Figure 2-3. If the appliance mounts through the front of the cabinet, ensure the front bracket portion of the assembly faces the cabinet front. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 27: Installing Slide Rails

    2-4, attach the left and right slide rails to the appliance with ten (10) pan-head Phillips screws (M4 x 10 cm). Use five (5) screws per side. Ensure the screws are securely tightened. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 28: Installing The Appliance

    If the front bracket portions of the bracket assemblies are installed at the front of the cabinet (typical installation), install the server through the cabinet front. While fully supporting the appliance, slide the appliance and attached slide rails into the mounting brackets as shown in Figure 2-5. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 29: Appliance Installation

    Secure each standoff with a 5/16 open-end wrench. Note If you are installing the server in an HP 9000, 10000, or 11000 series rack you will also need to install a square alignment washer with each hexagonal-nut standoff. As shown in...

  • Page 30: Connecting The Hafm Appliance

    You can connect the HAFM appliance to the single customer-supplied corporate Ethernet LAN, with or without an HP-supplied Ethernet hub. This allows remote sessions to the HAFM appliance from anywhere on the corporate LAN, provides access to manage the Directors and Edge Switches on this LAN, and allows access to applications such as HP OpenView Storage Area Manager.

  • Page 31: Hafm Appliance Connections

    Do not connect the HAFM appliance to a network that could expose HAFM to a virus until Norton AntiVirus software is installed. Norton AntiVirus software is included with the HAFM appliance. HP recommends the you connect a PC and the HAFM appliance on a private LAN to perform initial setup. After initial setup is completed, you can connect the HAFM appliance to your LAN.

  • Page 32: Powering On The Hafm Appliance

    • System date and time. • LAN 1 and LAN 2 Internet Protocol (IP) addresses. • Rotational speed status on multiple appliance fans. • Central Processing Unit (CPU) Temp • Hard disk capacity hp StorageWorks HA-Fabric Manager Appliance Installation Guide...
  • Page 33 Press the left edge (PUSH label) of the LCD panel to disengage the panel and expose the CD-RW drive. Insert a blank rewritable CD into the CD-RW drive and close the LCD panel. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 35: Configuration

    (TCP/IP) network information to conform to the customer’s LAN addressing scheme: • IP address. • Subnet mask. Note At some customer installations, TCP/IP addresses for the appliance may be allocated automatically using dynamic host configuration protocol (DHCP). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 36: Configuring Lcd Panel Password

    LAN 1 Setting?? message, and the password changes. Press the up and down arrow keys until Return?? is displayed, then press ENTER. The LCD panel returns to scrolling mode, which continually displays HAFM appliance operational information. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 37: Configuring Public Lan Addresses

    (9999), then press ENTER. The LAN 1 Setting?? message displays at the LCD panel. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 38: Lcd Panel (Dhcp Selection)

    LCD panel returns to the LAN 1 Setting?? message. Press the up and down arrow keys until Return?? is displayed, then press ENTER. The LCD panel returns to scrolling mode, which continually displays HAFM appliance operational information. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 39: Manually Configuring Public Lan Addresses

    Use the arrow keys as described in step 2 to input a new IP address, then press ENTER. The following message displays (Figure 3-11) with the current subnet mask. (The default subnet mask is 255.0.0.0). Figure 3.11. LCD Panel (Input Netmask) hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 40: Configuring Private Lan Addresses

    Configuring Private LAN Addresses Note Before starting this procedure, ensure that the LAN 2 interface is physically connected to the LAN. An LCD display of 0.0.0.0 indicates a physical LAN connection is not present. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 41: Manually Configuring Private Lan Addresses Using Dhcp

    Figure 3.16. LCD Panel (DHCP selection) Use the arrow keys as described in step 2 and select YES to use DHCP, then press ENTER. The following message displays (Figure 3-17): Figure 3.17. LCD Panel (Auto Get DNS) hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 42: Manually Configuring Private Lan Addresses

    To configure TCP/IP network information for the private LAN connection (LAN 2): At the LCD panel, press ENTER. The Welcome!! or operational information message changes to the following (Figure 3-20): Figure 3.20. LCD Panel (Password Entry) hp StorageWorks HA-Fabric Manager Appliance Installation Guide...
  • Page 43 Use the arrow keys as described in step 2 to input a new gateway IP address, then press ENTER. The following message displays (Figure 3-24) with the default DNS server IP address of 0.0.0.0. Figure 3.24. LCD Panel (Input DNS) hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 44: Configuring Additional Appliance Information

    To login and access the appliance desktop: Ensure the appliance and a browser-capable PC are connected through an Ethernet LAN segment. At the PC, launch the browser application (Netscape Navigator or Internet Explorer). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...
  • Page 45 Authentication screen displays (Figure 3-26). Figure 3.26. VNC Authentication Screen Type the default TightVNC viewer password and click OK. The Welcome to Windows dialog box displays (Figure 3-27). The default TightVNC password is password. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...
  • Page 46 The Log On to Windows dialog box displays (Figure 3-28). Note Do not simultaneously press the Ctrl, Alt, and Delete keys. This action logs the user on to the browser-capable PC, not the appliance. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 47: Log On To Windows Dialog Box

    Type the default Windows 2000 user name and password and click OK. The appliance’s Windows 2000 desktop opens. Note The default Windows 2000 user name is Administrator and the default password is password. Both are case-sensitive. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 48: Installing Anti-Virus Software

    Double-click the System icon. The System Properties dialog box displays with the General tab selected as the default. Click the Network Identification tab. The System Properties dialog box displays with the Network Identification tab open (Figure 3-29). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 49: System Properties Dialog Box (Network Identification Tab)

    Chapter 3. Configuration Figure 3.29. System Properties dialog box (Network Identification Tab) Click Properties. The Identification Changes dialog box displays (Figure 3-30). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 50: Identification Changes Dialog Box

    At the System Properties dialog box, click OK to close the dialog box and return to the Control Panel window. Click (X) at the upper right corner of the Control Panel window to return to the Windows 2000 desktop. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 51: Configuring Gateway And Dns Server Addresses

    Area Connection 2 icon. The Local Area Connection 2 Status dialog box displays (Figure 3-31). Figure 3.31. Local Area Connection 2 Status dialog box Click Properties. The Local Area Connection 2 Properties dialog box displays (Figure 3-32). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 52: Local Area Connection 2 Properties Dialog Box

    Chapter 3. Configuration Figure 3.32. Local Area Connection 2 Properties dialog box Double-click the Internet Protocol (TCP/IP) entry. The Internet Protocol (TCP/IP) Properties dialog box displays (Figure 3-33). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 53: Internet Protocol (Tcp/Ip) Properties Dialog Box

    Preferred DNS server field, enter the DNS server IP address obtained from the customer’s network administrator, then click OK to apply the changes and close the dialog box. Click OK to close the Local Area Connection 2 Properties dialog box. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 54: Configuring Windows 2000 Users

    At the Windows 2000 desktop, click Start at the left side of the task bar (bottom of the desktop), then select Settings, then Control Panel. The Control Panel window displays. Double-click the Users and Passwords icon. The Users and Passwords dialog box displays (Figure 3-34). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 55: Changing Default Administrator Password

    To change the administrator password from the default (password) to a customer-specified password: Click the Send Ctrl-Alt-Del button at the top of the window surrounding the Users and Passwords dialog box. The Windows Security dialog box displays (Figure 3-35). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 56: Windows Security Dialog Box

    Do not simultaneously press the Ctrl, Alt, and Delete keys. This action controls the browser-capable PC, not the HAFM appliance. Figure 3.35. Windows Security dialog box Click Change Password. The Change Password dialog box displays (Figure 3-36). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 57: Change Password Dialog Box

    The New Password and Confirm New Password fields are case-sensitive. Click OK. The default administrator password changes and the Change Password dialog box closes. Click Cancel at the Windows Security dialog box to return to the Users and Passwords dialog box. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 58: Adding A New User

    Figure 3.37. Add New User Wizard (First Window) Type the appropriate new user information in the User name, Full name, and Description fields, then click Next. The second window of the Add New User wizard displays (Figure 3-38). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 59: Add New User Wizard (Second Window)

    Figure 3.38. Add New User Wizard (Second Window) Type the new user’s password in the Password and Confirm password fields, then click Next. The third window of the Add New User wizard displays (Figure 3-39). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 60: Setting Appliance Date And Time

    At the Windows 2000 desktop, click Start at the left side of the task bar (bottom of the desktop), then select Settings, then Control Panel. The Control Panel window displays. Double-click the Date/Time icon. The Date/Time Properties dialog box displays with the Date & Time page open (Figure 3-40). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 61: Date/Time Properties Dialog Box (Date & Time Tab)

    Note The Time Zone field must be set before the Date & Time field. Click the Time Zone tab. The Date/Time Properties dialog box displays with the Time Zone page open (Figure 3-41). hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 62: Date/Time Properties Dialog Box (Time Zone Tab)

    Click the day on the calendar to select the desired date. Click in the time field and enter the desired time, then click the adjacent up or down arrow and select AM or PM. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 63: Configuring And Enabling Event Notification Features

    SANworks Management Appliance or other server running the HP Proactive Services software. HP Proactive Services software is offered at no additional charge for subsystems covered under an on-site warranty or on-site storage hardware support contract. To order Proactive Services software, contact your Hewlett-Packard customer service representative.

  • Page 64: Configuring The Call-Home Via Dial-Out Feature

    Director, Edge Switch, or HAFM appliance problems. The problem is logged into the support facility’s tracking system for resolution. Obtaining Required Information You must contact the nearest HP technical support location to obtain some required information prior to beginning this procedure. Note Before contacting technical support, please read through this section to familiarize yourself with the steps and information required.

  • Page 65: Configuring Call-Home Feature

    3-42). Figure 3.42. Call Home Configuration dialog box At the Call Center Phone Number field, enter the telephone number for the HP Solution Center. Include necessary information, such as the country code, area code, or any prefix required to access a telephone line outside the facility.

  • Page 66: Hafm Main Window

    Figure 3-43. Figure 3.43. HAFM main window Select Monitor > Event Notification > Call Home..The Call Home Event Notification Setup dialog box displays, as shown in Figure 3-44. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 67: Configuring Identification Information For Directors And Edge Switches

    From the HAFM main window, double-click on the icon for the device. The Hardware View for the device is displayed. On the menu bar, select Configure > Identification. The Configure Identification dialog box displays, as shown in Figure 3-45. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 68: Configure Identification Dialog Box

    On the menu bar, select Maintenance > Enable Call Home Notification. Place a check mark in the Enable Call Home Event Notification option. Testing Remote Notification for instructions on testing the call-home feature. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 69: Configuring Proactive Services Call Home Via Lan Feature

    CSGIpAddress — Delete localhost and enter the IP address of the HP Services Gateway in appropriate format (xxx.xxx.xxx.xxx). If you have changed the contents of the hp.lan.properties file, reboot the HAFM appliance. Enabling Call-Home via LAN The HAFM appliance is now configured to automatically call-home through the LAN connection to a service support facility to report Director, Edge Switch, or HAFM appliance problems.

  • Page 70: Testing Remote Notification

    Click Send Test. A Call-home test message is transmitted and an Information dialog box displays. Click OK. Confirm with the HP technical support representative assisting you with configuration of the call-home feature that the call-home test was successful. Configuring E-Mail Event Notification In addition to call-home functionality, notifications of many events can be sent via e-mail.
  • Page 71 Chapter 3. Configuration For information on configuring e-mail event notification, see hp StorageWorks HA-Fabric Manager User Guide. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 73: Regulatory And Safety Information

    (SAN) technology, and Fibre Channel director and switch technology. The product contains no serviceable parts that require internal access during normal operation or prescribed maintenance conditions. This appendix covers the following topics: hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 74: Regulatory Compliance Id Numbers

    BOISA-0304 The HP StorageWorks HAFM appliance Regulatory Model Number can be found on the product label, along with the required approval markings and information. When requesting certification information for this product, always refer to this Regulatory Model Number. This Regulatory Model Number should not be confused with the marketing name or product number for your HAFM appliance.

  • Page 75: Class A Equipment

    Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio or television technician for help. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 76: Declaration Of Conformity For Products Marked With Fcc Logo-U.s. Only

    (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions regarding your product, refer to http://www.hp.com. For questions regarding this FCC declaration, contact: Hewlett-Packard Company Product Regulations Manager 3000 Hanover St.

  • Page 77: Canadian Notice (Avis Canadien)

    Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms (the equivalent international standards are in parenthesis): hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 78: Japanese Notice

    Also approved under UL 1950, 3rd Edition/CSA C22.2 No. 950-95, Safety of Information Technology Equipment Japanese Notice TELECOMMUNICATIONS NOTICE FOR JAPAN The modem supplied with this equipment, part number MT5634ZPX-PCI, is approved for use in Japan. The Japanese approval number is A00-1160JP. Taiwanese Notice hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 79: German Noise Declaration

    Use a portable field service kit with a folding static-dissipating work mat. If you do not have any of the suggested equipment for proper grounding, have an Authorized HP Reseller install the part. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 80: Fcc Part 68 Notice

    Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 81: R&Tte Directive

    The equipment has been approved in accordance with Council Decision 99/5/EC on radio equipment and terminal telecommunication equipment and the mutual recognition of their conformity. Declaration of Conformity The Declaration of Conformity is shown below. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...
  • Page 82 Appendix A. Regulatory and Safety Information hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 83: Tools Required

    Tools required to install the HAFM appliance and associated hardware include a: • Door key with 5/16-inch socket (provided with the cabinet). • #2 Phillips screwdriver. • 5/16 open-end wrench. • Standard (7-inch) slip-joint pliers. • Standard (4-inch) diagonal side-cutter pliers. hp StorageWorks HA-Fabric Manager Appliance Installation Guide...

  • Page 85: Index

    Index Index accessing appliance, 44 adding user, 58 cables, FCC compliance statement; FCC compliance statement, cables, 76 call home configuring dial-out, 64 LAN, 69 testing, 70 Canadian notice, 77 CE marking, 77 changing administrator password, 55 configuring, 35 appliance name, 48 call home, 65 dial-out, 64 enabling dial-out, 65...
  • Page 86 Index call home, 63 e-mail, 70 gateway, 51 identification, 67 LCD password, 36 private LAN, 40 manually, 42 using DHCP, 41 proactive services, 69 public LAN, 37 manually, 39 using DHCP, 37 Windows 2000 user, 54 connecting appliance, 30 power, 32 declaration of conformity, 76, 81 DOC notice (Canadian), 80 document conventions, 11...
  • Page 87 Index accessing, 44 factory defaults, 17 installing, 15 Norton AntiVirus, 48 help obtaining, 13 installing appliance, 28 attaching brackets, 23 HAFM appliance, 23 Norton AntiVirus, 48 slide rails, 27 intended audience, 10 Japanese notice, 78 kit contents, 18 proactive services, 69 R&TTE directive, 81 regulatory compliance notices, 73 related documentation, 10...
  • Page 88 Index call home, 70 text symbols, 11...
