Switching on/off | Menu settings

Switching on/off

The factory default behavior is that the monitor
switches on automatically when the operating
voltage is applied.
After switching on, the Bosch logo or a stored
custom logo is displayed for 15 seconds
(please refer to the "Customer logo menu"
section).
Note:
If no video source is present, the logo
is displayed for up to 3 minutes. After
that, the monitor's backlight is
switched off.
As soon as a video source is present,
it is displayed on the monitor.

Menu settings

The menu appears on-screen and disappears
again automatically after 10 seconds if no
buttons are pressed.

User menu

In the user menu you can make changes to the
picture settings during operation.
Opening the user menu
f Press the SET button.
Adjusting settings in the menu
f Repeatedly press the SET button until the
desired menu item appears.
Adjusting settings / accessing functions:
f Press the + or – button.
Robert Bosch Car Multimedia GmbH
Settings in the user menu
Menu item
Brightness
Contrast
H-Pos (VGA only)
V-Pos (VGA only)
Color (color saturation; CVBS
only)
Color Tint (NTSC only)
CVBS Termination (CVBS
only)
Scaling (CVBS only)
Notes:
f The brightness and contrast
settings are stored for each
video source separately.
If the CVBS picture is to be
f
transferred to other monitors,
switch off CVBS Termination.

Customer logo menu

In the customer logo menu you can adjust
settings for displaying a custom logo on the
monitor.
Opening the customer logo menu
and selecting a menu item
f Press the MENU button for approx.
3 seconds.
7 620 310 034 | 09.2014
en | 9
Setting
0 ... 100
On
Off
16:9
16:9
16:9
16:9
4:3
