18 en | Technical details
2.1.4 Technical specifications
Operating Voltage Range
Input Current @ 12V
Peak Current @ 12V
LED/beeper control inputs
Tamper Output
Dimensions (W x H)
2.1.5 Wiring instructions
Pin*
1 Power supply 5-16V
2 Power supply 0V
3 Data 0
4 Data 1
5 Tamper protection output
6 Green LED input
7 Red LED input
8 Beeper input
9 Data RxTx+
10 Data RxTx-
*Pin 1 is nearest the bottom of the reader
Wiegand interface
–
–
RS485 interface
–
NOTICE!
Independent of using Wiegand IF or RS485 IF please make sure
that the cables have a sufficiently large cross section and cable
shield is correct connected.
| V 1.2 | 2013.12
Function
max. cable length 150 m
min. 18 AWG recommended
max. cable length 1200 m
Technical manual
5-16 Vdc
65 mA
130 mA
Dry Contact, N.O.
Open collector, active low,
30 mA maximum sink current
44 x 137 mm
Preferred Wiegand IF
wiring color
red
black
green
white
violet
orange
brown
yellow
blue
gray
LECTUS duo 3000
RS485 IF
X X
X X
X
X
X
X
X
X
X
X
