O
WNER'S
Projection Television
50H12
© 2002 TOSHIBA CORPORATION
All Rights Reserved
M
ANUAL
TM
Owner's Record
The model number and serial number are on the back
of your TV. Record these numbers in the spaces below.
Refer to these numbers whenever you communicate
with your Toshiba dealer about this TV.
Model number:
Serial number:
23565686
