- Page 1 MIC IP fusion 9000 HD Installation Manual...
-
Page 3: Table Of Contents
About this Manual Legal Information Safety Precautions Important Safety Instructions Important Notices Customer Support and Service Introduction Configuration with Project Assistant app Product Description Replacing a wiper assembly Maintenance Disposal Technical data Bosch Security Systems Installation Manual 2019-11 | 1.1 |... -
Page 4: Safety
Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly. -
Page 5: Safety Precautions
Notice! This symbol indicates information or a company policy that relates directly or indirectly to the safety of personnel or protection of property. Bosch Security Systems Installation Manual 2019-11 | 1.1 |... -
Page 6: Important Safety Instructions
– Do not point the camera at the sun. Bosch Security Systems will not be liable for any damage to cameras that have been pointed directly at the sun. When transporting, take extra care to protect the wiper and the camera window(s). - Page 7 Notice! Bosch recommends the use of surge/lightning protection devices (sourced locally) to protect network and power cables and the camera installation site. Refer to NFPA 780, Class 1 & 2, UL96A, or the equivalent code appropriate for your country/region, and to local building codes.
-
Page 8: Important Notices
Camera signal - Protect the cable with a primary protector if the camera signal is beyond 140 feet, in accordance with NEC800 (CEC Section 60). Environmental statement - Bosch has a strong commitment towards the environment. This device has been designed to respect the environment as much as possible. - Page 9 This is a class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures. Note: Changes or modifications not expressly approved by Bosch could void the user’s authority to operate the equipment.
-
Page 10: Customer Support And Service
| Safety MIC IP fusion 9000 HD Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Telephone: 800-366-2283 Fax: 800-366-1329 Email: cctv.repair@us.bosch.com Customer Service... -
Page 11: Introduction
You can also use the Project Assistant app to complete the initial configuration of the camera. In order to use this device with the Project Assistant app by Bosch, you must download the app from the Bosch Download Store, from Google Play, or from the Apple Store. -
Page 12: Product Description
MIC-WKT-IR Washer Kit VG4-A-PSU1 24 VAC (96 VA) power supply MIC-ALM-WAS-24 Alarm and washer interface VG4-A-PSU2 accessory unit MIC-9K-IP67-5PK Connector kit MIC-9K-SNSHLD-W Sunshield (white) MVS-FCOM-PRCL Serial protocol license for IP cameras 2019-11 | 1.1 | Installation Manual Bosch Security Systems... -
Page 13: Replacing A Wiper Assembly
MIC IP fusion 9000 HD Replacing a wiper assembly | en Replacing a wiper assembly Put a piece of thin, protective material between the window glass and the wiper to prevent accidental damage. Bosch Security Systems Installation Manual 2019-11 | 1.1 |... - Page 14 With one hand, hold the wiper arm firmly in place to restrict rotational movement. With the other hand, using a 7mm Hex socket or nut driver, rotate the acorn nut counter- clockwise until the nut is free from the wiper shaft. 2019-11 | 1.1 | Installation Manual Bosch Security Systems...
- Page 15 MIC IP fusion 9000 HD Replacing a wiper assembly | en Remove the wiper spring, hub, arm, and blade assembly from the wiper shaft. Assemble the new wiper arm on the new wiper hub. Bosch Security Systems Installation Manual 2019-11 | 1.1 |...
- Page 16 | Replacing a wiper assembly MIC IP fusion 9000 HD Insert the new blade assembly into the new wiper arm. Slide the new wiper hub and the attached parts onto the wiper shaft. 2019-11 | 1.1 | Installation Manual Bosch Security Systems...
- Page 17 MIC IP fusion 9000 HD Replacing a wiper assembly | en Slide the new wiper spring onto the wiper shaft and over the new wiper arm. Bosch Security Systems Installation Manual 2019-11 | 1.1 |...
- Page 18 MIC IP fusion 9000 HD Apply Loctite 243 to the cavity of the acorn nut. 10. Lightly thread the new acorn nut onto the wiper shaft over the new wiper spring and new wiper hub. 2019-11 | 1.1 | Installation Manual Bosch Security Systems...
- Page 19 12. With the other hand, using a 7mm Hex socket or nut driver, tighten the new acorn nut clockwise to a torque value of 1.0 Nm. Bosch Security Systems Installation Manual 2019-11 | 1.1 |...
-
Page 20: Maintenance
No User-serviceable Parts Except for the external wiper blade, the device contains no user-serviceable parts. Contact your local Bosch service center for device maintenance and repair. In the event of failure, the device should be removed from site for repair. -
Page 21: Disposal
Disposal | en Disposal Disposal Your Bosch product has been developed and manufactured using high- quality materials and components that can be reused. This symbol means that electronic and electrical devices that have reached the end of their working life must be disposed of separately from household waste. -
Page 22: Technical Data
| Technical data MIC IP fusion 9000 HD Technical data For product specifications, see the datasheet for your camera, available on the appropriate product pages of the Online Product Catalog at www.boschsecurity.com. 2019-11 | 1.1 | Installation Manual Bosch Security Systems... - Page 23 MIC IP fusion 9000 HD Technical data | Bosch Security Systems Installation Manual 2019-11 | 1.1 |...
- Page 24 | Technical data MIC IP fusion 9000 HD 2019-11 | 1.1 | Installation Manual Bosch Security Systems...
- Page 26 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2019...
