- Page 2 MPMC202 Fast Ethernet Adapter Installation and Use PMC202A/IH1 Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com...
- Page 3 Motorola, Inc. assumes no liability resulting from any omissions in this document, or from the use of the information obtained therein. Motorola reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Motorola to notify any person of such revision or changes.
- Page 4 PCI Bus Fast Ethernet Adapter UserÕs Guide . ¨ Motorola and the Motorola symbol are registered trademarks of Motorola, Inc. AIXª is a trademarks of IBM. All other products mentioned in this document are trademarks or registered trademarks of their respective holders.
- Page 5 Related Documentation The publications listed below are referenced in this document. If not shipped with this product, Motorola manuals may be purchased by contacting your local Motorola sales ofÞce. Document Title Publication Number PCI Local Bus SpeciÞcation Rev 2.0; PCI Special Interest Group PCI Rev 2.0...
- Page 6 Motorola, Inc. assumes no liability for the customer's failure to comply with these requirements. The safety precautions listed below represent warnings of certain dangers of which Motorola is aware. You, as the user of the product, should follow these warnings and all other safety precautions necessary for the safe operation of the equipment in your operating environment.
- Page 7 All Motorola printed wiring boards are manufactured by UL-recognized manufacturers, with a ßammability rating of 94V-0. This equipment generates, uses, and can radiate electro- magnetic energy. It may cause or be susceptible to electro-magnetic interference (EMI) if not installed and WARNING used in a cabinet with adequate EMI protection.
-
Page 8: Table Of Contents
Introduction 2-1 Installation and ConÞguration Tasks 2-1 Packaging 2-1 Electro-static Discharge Precautions 2-2 Installing the MPMC202 on the Carrier Board 2-2 Connecting the Fast Ethernet Cable 2-5 Building Your Own Adapter Cable 2-6 Connecting Workstations 2-7 Starting the MPMC202 2-7 Installing the AIX Driver 2-8 ConÞguring the MPMC202 2-8... - Page 9 List of Figures MPMC202 Board Layout and Front Panel 1-2 LEDs on the MPMC202 Front Panel 1-8 Installing the MPMC202 on the Carrier Board 2-4 RJ-45 Adapter Cable Wiring Diagram 2-6 Workstation Connections 2-7 Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com...
-
Page 10: Overview
Fast Ethernet local area network (LAN) and a PCI bus-based host. It supports Fast Ethernet 10Base-T and 100Base-TX networking module with un-shielded twisted pair (UTP) RJ-45 cable. The MPMC202 can be used with both 10Mbps and 100Mbps networks. General Description... -
Page 11: Mpmc202 Board Layout And Front Panel
Introduction LED2 LED1 1918 9610 Figure 1-1. MPMC202 Board Layout and Front Panel Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com... -
Page 12: Key Features
At system start-up time, the MPMC202 automatically detects whether it is connected to a 10Mbps or a 100Mbps Ethernet connection. In order for autosensing to occur correctly, be sure to have the cable connected to the MPMC202 before powering up the system. Switched Hub Operation... -
Page 13: Speciþcations
Introduction Specifications Features The MPMC202 has these features: Form Factor Single-wide PCI Mezzanine Card (PMC) Dimensions 2.9 inches wide (74 mm) 5.9 inches long (149 mm) Host Bus Interface PCI Local Bus SpeciÞcation, Rev 2.0 IEEE Compliance IEEE P1386 and IEEE P1386.1 mezzanine card speciÞcation... -
Page 14: Operating Environment
Ring 802.5 (4MB, 16MB). Category 5 supports 100 meters of cable length between stations, and uses data grade modular wall outlets and patch cables. The MPMC202 is compliant with the 100 meter requirement of the TP-PMD specification. Terminal Connectors Category 5 data grade cable requires discrete modular data grade terminal connectors that plug into a panel or wall jack. -
Page 15: Category 5 Routing Considerations
Introduction Category 5 Routing Considerations Category 5 data grade cable requires delicate handling. Be aware of conditions to avoid that will reduce the performance of your network: Routing over fluorescent lighting fixtures Overly acute bends in cable Cables routed too closely together LAN Configuration Considerations Fast Ethernet supports a maximum of two Ethernet repeaters between any two end nodes (i.e., a workstation and a concentrator). -
Page 16: Fast Ethernet Technology
Fast Ethernet Technology Fast Ethernet Technology 10Base-T Technology The popularity of 10Mbps Ethernet makes 10Base-T a natural baseline for faster Ethernet technologies. 10Base-T is a universal, world-standard LAN technology. Its cost per node is low because you do not usually need to upgrade your cables for installation. 100Base-TX Technology 100Base-TX technology is derived from 10Base-T. -
Page 17: Fast Ethernet Lan Controller Programming
PCI Fast Ethernet LAN Controller. AIX Driver The device driver for the DECchip 21140 Fast Ethernet LAN Controller on the MPMC202 is supplied with AIX 4.1.4 R4 or later releases. Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com... -
Page 18: Introduction
Configuring the MPMC202 on page 2-8. Reboot the system. Packaging The MPMC202 is packed in an anti-static package to protect it from any static discharge. Observe standard handling practices of static sensitive equipment. Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com... -
Page 19: Electro-Static Discharge Precautions
Wrist Strap Installing the MPMC202 on the Carrier Board Follow these steps to install the MPMC202 on the carrier board: 1. Place an ESD strap on your wrist and attach the grounding line end of the ESD strap to the chassis as a ground. The ESD strap must be secured to your wrist and to ground throughout the procedure. - Page 20 Installing the MPMC202 on the Carrier Board 8. Align the guide hole and P11 and P12 connectors on the MPMC202 over the guide pin and the PMC connectors on the carrier board. 9. Gently seat the MPMC202 onto the carrier board.
- Page 21 Installation GUIDE HOLE GUIDE PIN 1919 9610 Figure 2-1. Installing the MPMC202 on the Carrier Board Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com...
-
Page 22: Connecting The Fast Ethernet Cable
UTP Category 5 data grade cable that is terminated with an RJ-45 connector. The MPMC202 front panel has a 14-pin female DB-14 connector, J3. on the faceplate. Attach the supplied 6 inch adapter cable, part number 30NW9302B78, to J3 on the MPMC202, and then connect an RJ-45-terminated cable to the female RJ-45 jack on the adapter cable. -
Page 23: Building Your Own Adapter Cable
Installation Building Your Own Adapter Cable You may build your own adapter cable per the wiring diagram in Figure 2-2. Unshielded CAT-5 cable Not Used Not Used Not Used RJ-45 Jack Not Used J1 (Female) J3 (DB-14 Male) 11657.00 9610 Figure 2-2. -
Page 24: Connecting Workstations
Figure 2-3. Workstation Connections Starting the MPMC202 After installing the MPMC202 and attaching the cables, turn the power on as directed in the system manual. The MPMC202 should power-up automatically. Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com... - Page 25 MVME160x-0xx Follow the instructions in Chapter 3 for installing the driver. If the MPMC202 is present on one of these boards when AIX is installed and configured, the correct Fast Ethernet LAN controller driver is installed automatically during Initial Program Load (IPL).
-
Page 26: Installing The Aix Driver
This chapter describes installation of the AIX driver for the MPMC202Õs Fast Ethernet LAN device. Before installing the AIX device driver, install the MPMC202 onto the carrier board per the instructions in Chapter 2, and install the carrier board into the system chassis. - Page 27 AIX Driver Installation Leave the default values in the other fields and press Enter. An ÒokÓ command status message appears when the process is complete. 6. After the driver installation is complete, press F3 to return to the Devices menu. 7.
- Page 28 Index Numerics TCP/IP connectors 100 meter requirement 1-1, 1-3, 1-7 100Base-TX 1-1, 1-3, 1-5, 1-7 10Base-T data grade connectors 3Com hub DECchip 21104A Fast Ethernet LAN Controller programming adapter cable 1-8, 2-8 device driver wiring diagram installation AIX driver 1-8, 2-8, 3-1 installation auto-sensing electro-static discharge (ESD)
- Page 29 Index 1-1, 1-5, IEEE 802.3U Unshielded Twisted Pair cable installation AIX driver MPMC202 VME carrier board LAN configuration considerations workstation connections LEDs MVME130x MVME160x MVME260x MVME360x operating environment operation between Fast Ethernet devices operation with hubs Local Bus Specification, Rev. 2.0...
