- Page 1 DIGITAL PLAIN PAPER COPIER OPERATOR'S MANUAL FOR PRINTER FUNCTION NETWORK PRINTER BOARD GA-1040 USER'S GUIDE FOR UNIX FILTER...
- Page 2 Cet appareil numérique de la classe A est conformé à la norme NMB-003 du Canada. WARNING: Changes or modification made to this equipment, not expressly approved by Toshiba Tec or parties authorized by Toshiba Tec could void the user’s authority to operate the equipment. For European models only: WARNING: This product complies with Class A for network connection.
-
Page 3: Legal Notices
Under the copyright laws, this manual cannot be reproduced in any form without prior written permission of TOSHIBA TEC. No patent liability is assumed, with respect to the use of the information contained herein. No part of this manual may be copied in whole or part without permission. -
Page 4: Software License Agreement
Font Programs and Typefaces reproduced therefrom (“Trademarks”); and d. assign your rights under this Agreement to a transferee of all of your right, title and interest in and to the controller GA-1040 for TOSHIBA e- STUDIO28/35/45 provided the transferee agrees to be bound by all of the terms and conditions of this Agreement. -
Page 5: Proprietary Rights
Electronics For Imaging’s entire liability and your exclusive remedy under this warranty (which is subject to you returning the controller GA-1040 for TOSHIBA e-STUDIO28/35/45 to Electronics For Imaging or an authorized dealer) will be, at Electronics For Imaging’s option, to use reasonable... -
Page 6: Export Controls
ELECTRONICS FOR IMAGING OR ANY AUTHORIZED DEALER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. YOU ACKNOWLEDGE THAT THE PRICE OF THE CONTROLLER GA-1040 FOR TOSHIBA e-STUDIO28/35/45 REFLECTS THIS ALLOCATION OF RISK. BECAUSE SOME STATES/JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. -
Page 7: Table Of Contents
Introduction ... 1 ... 1 UIDELINES Pre-installation ... 2 ... 2 YSTEM EQUIREMENTS ... 2 OTIF UPPORT Motif 2.1... 2 Motif 1.2... 3 Obtaining the Installation Package ... 3 ... 3 NSTALLED ILES setup Installation Program... 6 NSTALLATION ROCEDURES ... 6 INSTALL NSTALLATION CRIPT... - Page 8 PPD Options... 35 ... 35 RINTING Methods of Printing ... 36 Printing from Unix applications ... 36 Messages ... 39 ... 39 NSTALLATION HASE Error Messages... 39 Status and Prompt Messages ... 40 RCUTIL ONFIGURATION ROGRAM CORE D ... 44 RIVER User’s Guide ...
-
Page 9: Introduction
Introduction This manual describes how to install the user software for the TOSHIBA GA-1040 Network Printer Board, set up printing, and manage print jobs from a Unix client. For information about setting up network servers and clients to use the GA-1040, see Administrator’s Guide. -
Page 10: Pre-Installation
Pre-installation System Requirements English versions of the following operating systems are supported for use with the GA-1040 Printer Driver: Sun Solaris 2.4 or later (SPARCstation) • Sun Solaris 8 (Intel) • HP-UX 10.0 or later • IBM AIX 4.0 or later •... -
Page 11: Motif 1.2
Motif 1.2 System Requirement HP-UX Motif 1.2 libraries: libXm Solaris Motif 1.2 libraries: libXm Motif 1.2 libraries: libXm Linux None To determine which version of Motif is installed in your Unix or Linux system, do the following system checks. Check if the following files exist: •... - Page 12 The driver cannot be installed on systems that have write-protection turned on for the /usr/local folder. The driver installation destination directory is fixed for each platform to the location specified in the table above. This is currently not configurable as there is no concept of registry in Unix systems where settings can be saved at installation time and that could be retrieved later by the driver at run-time.
- Page 13 Linux Additional Files shfilter.scr shfilter.clnt User’s Guide Description Middle script filter for Linux server installations used to parse parameters received from lp and passed to the CORE filter. The Linux installer assumes that the Korn shell exists in /bin. If Korn (ksh) does not exist in /bin, the /usr/local/tsbprn-ps/shfilter-ps.tos file must be modified to the existing shell in /bin.
-
Page 14: Setup Installation Program
setup Installation Program Depending on your network environment, distribution of clients, and planned print configuration, you may run only server installations of the Unix driver, or both client and server installations. Pre-Installation Procedures Before running server or client install program, review the following points: Log in as the superuser (root) of the system to ensure that all files are installed •... -
Page 15: Syntax
system errors when launching the setup installation program directly on systems without Motif support. The install installation script will show an error message if it cannot find the Motif library in the system, except for Linux, where the driver is built to run even on systems without Motif support. - Page 16 Prints the usage guide. If no other parameter is specified, the program will terminate. Otherwise, it will launch the installation program either in graphical or text mode, depending on value of the “g” parameter. Uninstalls the specified <queue> [q:]<queue> The name of the local print queue to be set up or uninstalled. q: is optional.
-
Page 17: Notes On X_Querycolors
./install –u t:all g:no runs the setup installation program in un-install and text mode to un- install all print queues. ./install pshakuba s:hakuba p:direct cdepth:8 Runs in GUI mode and initialize the print queue, destination printer and port fields in the user interface. If Background color setting is removed from the Setup resource file, this will use the 8-bit color depth parameter to choose the background color for the user interface. -
Page 18: Gui Mode
GUI Mode The following buttons allows user to interactively control the installation and un- installation process. Install button • This button starts the installation process. This button is disabled until all required fields are filled in. Delete button • This button deletes selected print queue in the list of installed print queues. If there is no print queue available, this button is disabled. -
Page 19: Introduction Tab
Introduction Tab The Introduction tab shows information about the setup installation program. Figure 1 Introduction tab General Tab Figure 2 General Tab (Server Install) • Print Queue This is the name of the print queue to be created and associated with the Unix filter. -
Page 20: Advanced Tab
Printer Port/Remote Queue • On server install type, Printer Port is the Fiery printer port on the remote printer device. On client install type, Remote Queue is the server-type print queue on the UNIX/Linux Network Server. This is print, by default. Remote Server OS •... -
Page 21: Printer List
system requires the scripts to be in a different location, specify the new location in this field. Middle script/Client script • This is for Linux installations only: This is the name to give the actual script installed on the system. By default, this is shfilter-ps.tos for server install type, and is shfilter.clnt for client install type. -
Page 22: Status Dialog
Status Dialog The Status dialog shows messages describing the progress of the installation process. The Done button closes the dialog after a successful installation or after an error occurs during installation. It is disabled during the install process. If a fatal error occurs, the setup installation program terminates. -
Page 23: Uninstallation Mode
TOSHIBA e-STUDIO28/35/45 Unix Printer Driver The program will also prompt for other settings such as manpage path, middle script name, temporary files location, or UI Link path. Follow screen prompts to specify non-default settings. Whenever a yes/no type question is asked, the upper-case letter identifies the default response. - Page 24 TOSHIBA e-STUDIO28/35/45 Unix Printer Driver shown when the man command is used. If a manpage has no entry in the windex file, the said manpage may not be displayed using the man command. If windex exists in the main manpage directory, an entry for the manpage must be added into it.
-
Page 25: Rcutil Property Tabs
rcutil Property Tabs The GA-1040 Printer Driver rcutil configuration program consists of four property tabs: Setup, Personality, Options, and About tabs. Setup Tab This tab contains the standard printer settings: paper size, paper source, destination tray, media type, orientation, duplex, and number of copies. Paper Size The list of available paper sizes will be determined from the PPD associated with the driver. -
Page 26: Paper Source
Paper Source The list of available input paper trays will be determined from the PPD associated with the driver. The user can select any one of the available trays. Keyword Name papersource Option Name auto upper lower pfpu pfpl manual manualr Destination The list of available output trays will be determined from the PPD associated with the... -
Page 27: Orientation
Orientation The user can select Portrait, Landscape, Reverse Portrait, or Reverse Landscape. Keyword Name orientation Option Name portrait landscape reverseportrait reverselandscape Figure 9 Portrait Figure 10 Reverse Portrait User’s Guide Translation/Display Text Orientation Translation/Display Text Portrait Landscape Reverse Portrait Reverse Landscape Figure 8 Landscape Figure 11 Reverse Landscape... - Page 28 Duplex The user can select the output job to be Single (single-sided), Long (two-sided with long edge) binding, or Short (two-sided with short edge binding). Keyword Name duplex Option Name single long short Long Edge Binding The pages are bound on the long side, regardless of orientation. Figure 12 Portrait Short Edge Binding The pages are bound on the short side, regardless of orientation.
-
Page 29: Number Of Copies
Number of Copies The user can specify 1-999 copies. Keyword Name copies Type Integer Additional PPD-specified Property Tabs The Personality and Options tabs are examples of PPD-specified property tabs. The settings in PPD tabs are detected from the PPD configuration file associated with the driver during installation. - Page 30 Finishing The user can specify to turn on collation and stapling. Keyword Name finishing Option Name none sort group alternation stapleul stapleur staplel2 staplet2 saddle Hole Punch The Hole Punch setting is the selection for punch holes, whether turned off, or punched on the left or top of the page.
-
Page 31: Options Tab
Options Tab Pedestal Option This setting provides the choices for the installed pedestal devices. Keyword Name pedestaloption Option Name none pedestal1 pedestal2 Finisher Option This setting provides the choices for the installed finishing devices. Keyword Name finisher Option Name false hangingfinisher finisher saddle... -
Page 32: About Tab
Punch Unit This setting provides the choices for the installed punch unit devices. Keyword Name punchunit Option Name none 2hole 3hole 4holef 4holes About Tab The About tab displays the product name, version, copyright and patents information. Main Controls Exit button •... -
Page 33: Help Dialog
TOSHIBA e-STUDIO28/35/45 Unix Printer Driver Help Dialog The Help dialog provides a description of the GA-1040 Printer Driver, including the features enabled in the driver. Figure 19 Help dialog The F533Readme.txt file that is shipped with the driver contains the text displayed in the Help dialog. -
Page 34: Localization
Localization The buttons and settings fields in the user interface can be renamed by editing the Rcutil resource file. This file is found in /usr/lib/X11/app-defaults, except in Solaris where it is found in /usr/openwin/lib/X11/app-defaults. User’s Guide... -
Page 35: Using Rcutil
Using rcutil Running rcutil To launch the GUI setup program, run /opt/rcutil on the command line. $ /opt/rcutil <Return> Note: The rcutil configuration program uses the same PPD configuration file as the • CORE UNIX filter. It parses the PPD configuration file to display the settings in the GUI. -
Page 36: User Home Directory Access Restrictions
# System-Default Profile for rcutil #-Number of characters per line is expected to be less than 256. #-variables have to be in uppercase, values to be lowercase. PageSize = Ledger Destination = Inner Orientation = Reverse Portrait Duplex = Long Finishing = StapleUL Punch = Left If this file exists in the user’s home directory, it is parsed and the values are... - Page 37 TOSHIBA e-STUDIO28/35/45 Unix Printer Driver required to be turned on. This would allow the lp system account to have access to the settings file stored in the user’s home directory. If you’re having a problem printing in your system, check if the user’s home directory satisfies the condition described above.
-
Page 38: Constraints
TOSHIBA e-STUDIO28/35/45 Unix Printer Driver Constraints As settings are changed, the program checks if the selection violates some constraints specified in the PPD configuration file. The constraints are rules that tell when an option is valid when combined with other options. For example, Punch holes cannot be done if there is no puncher. -
Page 39: Illustrated Process And Data Flow
Illustrated Process and Data Flow GUI Process rcutil (GUI) program is invoked by user Read defaults from PPD. Read settings from .f533rc User’s Guide .f533rc • When Save settings button is clicked on, the non-default settings are saved back to the settings file. -
Page 40: Unix Core Driver Process
Unix CORE Driver Process Unix CORE driver is invoked by lp command. Read defaults from PPD. Read settings Parse command Apply features and generate output file. User’s Guide .f533rc from .f533rc Command line parameters line... -
Page 41: Printer Driver Details
Printer Driver Details This section describes in detail the features available in the GA-1040 Printer Driver. Standard Options Feature Keyword:Option Copies copies:# Range 1 – 999 Paper Size pagesize:<param> letter ledger legal statement Paper Source papersource:<param> auto upper lower pfpu pfpl manual manualr... - Page 42 Feature Keyword:Option Duplex duplex:<param> single long short Relay relay:<param> Options list options:<param> Language language:<param> selection postscript Text mode text:<param> Pesc mode pesc:<param> User’s Guide Non-native form For simplex, print single sided. If not simplex specified, the printer’s front panel duplex, double, vd, d sets the default to either simplex or hduplex, hd duplex.
-
Page 43: Ppd Options
PPD Options Feature Keyword:Option Rotate 180 userrotate180:<param> Degrees Finishing finishing:<param> none sort group alternation stapleul stapleur staplel2 staplet2 saddle Hole Punch punch:<param> none left Smoothing refine:<param> type1 Pedestal Option pedestaloption:<param> none pedestal1 pedestal2 Finisher Option finisher:<param> false hangingfinisher finisher saddle Punch Unit punchunit:<param>... -
Page 44: Methods Of Printing
The option can be in the non-native or native format. Native format means keyword:option while non-native means keywordoption. Some options can be specified as just option, for example, A4 or duplex. Methods of Printing Through rcutil Run rcutil • Make changes in the settings in the GUI •... - Page 45 TOSHIBA e-STUDIO28/35/45 Unix Printer Driver Printing in Netscape Navigator Specify in the print command the print queue and the options that will be applied to the printout. Figure 24 Print to Printer Figure 25 Print to File Then click on Print button to start printing the file through pshakuba print queue. In Figure 23, the printout will be double-sided (long edge) and will use tabloid paper size.
- Page 46 Printing in Adobe Acrobat Reader Specify in the print command the print queue and the options that will be applied to the printout. Figure 26 Acrobat Reader print dialog If printing to file, as in the following figure: Figure 27 Printing to file specify the destination file in the File Name field, then click the Print button.
-
Page 47: Messages
Messages The following tables show the messages that the installation program and the rcutil configuration program may generate, with the possible causes why the messages are shown. Installation Phase These messages are shown during installation phase. Error Messages Message Please install the Motif library. The <library>... -
Page 48: Status And Prompt Messages
Message You must be ‘root’ (superuser) to install. ERROR: The default folder for manpage of <manpage> does not exist. ERROR: Printer queue <printqueue> already exists. Status and Prompt Messages Message Un-install another queue? y/N Print Queue Name: Select print queue to delete [choice(s): 1-n] Validating <printqueue>... - Page 49 Message Install User Interface configuration program? Y/n Default driver path: Change driver path? y/N Specify a driver path? y/N Specify name of driver path: Default CORE filter manpage path: Change CORE filter manpage path? y/N Specify CORE filter manpage path? y/N Specify CORE filter manpage path: Default configuration program manpage path: Change configuration program manpage path? y/N...
- Page 50 Message Specify path for temporary files: OS of remote server to connect to 1 – Sun SunOS/Solaris 2 – HP UX 3 – IBM AIX 4 – Red Hat Linux Default: <platformID> Choose: Enable three-digit request numbers? y/N Default client middle script: Change client middle script? y/N Specify client middle script? y/N Specify client middle script:...
-
Page 51: Rcutil Configuration Program
Message To see supported CORE options, enter: man EFTPS To see GUI setup program manpage, enter: man rcutil rcutil Configuration Program Figure 31 Constraint violation error message Figure 28 When no setting is saved Figure 30 When any setting is saved Figure 29 Error when .f533rc cannot be written on. -
Page 52: Core Driver
CORE Driver A banner page is automatically printed if there’s an error in the print job. Figure 32 Banner page template The banner page contains the following header information. Error type Unrecognized non-native parameter Unrecognized native-format parameter (single word) Unrecognized native-format parameter (with colon) Constraint error For the unrecognized parameters, check for validity the non-native keyword or the... - Page 53 1-1, KANDA NISHIKI-CHO, CHIYODA-KU, TOKYO, 101-8442, JAPAN © 2002 TOSHIBA TEC CORPORATION All rights reserved...
