16 50V 20µs/div
SOUND/AV
17
0.5V 1ms/div
18
1V 1ms/div
19
200mV 500µs/div
20 500mV 20µs/div
All manuals and user guides at all-guides.com
WAVEFORMS
NOTE: The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
H-2
13A25/31A25C
