Page 1
Remove and Discard Socket Head Screw from the top of the Left Handrail. Left and Right is determined when facing the scale, as if you are the patient about to step onto the platform. Left Handrail P/N 82-00003 PROPLUSROD INSTALLATION INSTRUCTIONS REV20190801...
Page 2
Using the provided 6mm Allen Wrench, mount the Lower HR Mount Bracket to the Left Handrail using the provided M10 x 1.5 x 45mm Button Head Screw. Do not fully tighten the screw at this stage of assembly. P/N 82-00003 PROPLUSROD INSTALLATION INSTRUCTIONS REV20190801...
Page 3
Tighten both Screws with 5/32” Wrench. 7. Using the 8mm Allen Wrench, fully tighten and secure the Upper and Lower HR Mount Brackets by tightening the M10 x 1.5 x 45mm Button Head Screws. Assembly is now complete. P/N 82-00003 PROPLUSROD INSTALLATION INSTRUCTIONS REV20190801...
