- Page 1 TOSHIBA Thermal Printer B-EP2DL/EP4DL SERIES Option Installation Manual Document No. EO15-33005 Original Sep., 2008 (Revised PRELIMINARY Linerless Label Kit, which are under development as of November 7, 2008, could be changed. PRINTED IN JAPAN...
- Page 2 Wireless LAN Board: B-EP700-WLAN-QM-R ------------------------------------------------------------ 2- 1 Bluetooth Module: B-EP700-BLTH-QM-R ---------------------------------------------------------------- 3- 1 CAUTION! 1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA TEC. 2. The contents of this manual may be changed without notification.
- Page 3 1. Linerless Label Kit: B-EP902-LL-QM-R/B-EP904-LL-QM-R The B-EP902-LL-QM-R/B-EP904-LL-QM-R linerless label kit is a platen roller unit designed for enabling the B-EP2DL/B-EP4DL series portable printer to issue linerless labels. The B-EP902-LL-QM-R is for the B-EP2DL series, and the B-EP904-LL-QM-R is for the B-EP4DL series, respectively. WARNING! 1.
- Page 4 Press the top cover open button and fully open the top cover. Remove the inner top cover using the following procedure. (For the B-EP2DL Series) Release the two hooks on the right side of the inner cover with a slotted jewellers screw driver and remove the inner cover from the top cover.
- Page 5 Linerless Label Kit Hook Hook Attach the inner cover in place. (For the B-EP2DL Series) First, fit the left side of the inner cover, then the right side. Top Cover Inner Cover (For the B-EP4DL Series) (1) First, fit the left side of the inner cover, then the right side.
- Page 6 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 1. Linerless Label Kit: B-EP902-LL-QM-R/B-EP904-LL-QM-R Make sure that the top cover can be closed completely. Change the printer setting to activate the linerless label kit. • Changing the Printer Setting Use the following procedure to change the printer setting to activate the linerless label kit. Load the battery pack in the printer.
- Page 7 2. Wireless LAN Board: B-EP700-WLAN-QM-R 2. Wireless LAN Board: B-EP700-WLAN-QM-R Thank you for purchasing TOSHIBA wireless LAN kit, B-EP700-WLAN-QM-R. The B-EP700-WLAN-QM-R is an optional wireless LAN interface board for the B-EP2D/EP4D Series. The pictures used in this document are those of the B-EP4D, but the installation procedure is common with the B-EP2D unless otherwise noted.
- Page 8 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 2. Wireless LAN Board: B-EP700-WLAN-QM-R Press the top cover open button to open the top cover. Remove the left side cover in the direction of the arrow. Left Side Cover Top Cover Top Cover Open Button NOTE: The gears shown in the picture below is not secured and is easily removed.
- Page 9 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 2. Wireless LAN Board: B-EP700-WLAN-QM-R NOTE: As the fold of the FPC cable differs depending on the printer, please connect a correct one to the printer. (Unit: mm) B-EP4D Series : Valley Fold FCC Cable Forming Indication Figure : Mountain Fold 28.5 14.5...
- Page 10 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 2. Wireless LAN Board: B-EP700-WLAN-QM-R Connect the FPC cable to the wireless LAN module. Pass the FPC cable through the slot, as shown in the picture. (B-EP4D model only) Wireless LAN Module FPC Cable FPC Cable Slot Ground...
- Page 11 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 2. Wireless LAN Board: B-EP700-WLAN-QM-R 10. Connect the FPC cable to the connector CN301 on the Main PC board. Main PC Board CN301 FPC Cable Fit the wireless LAN module into the following position. B-EP4D B-EP2D Wireless LAN Module...
- Page 12 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 2. Wireless LAN Board: B-EP700-WLAN-QM-R Close the front cover. Front Cover NOTES: Make sure that the pins on the both sides of the front cover are fit in position, as shown in the pictures below. Do not reassemble the Front Cover while the Top Cover Open Button is pressed.
- Page 13 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 2. Wireless LAN Board: B-EP700-WLAN-QM-R Mount the left side cover to the printer while fitting the tabs on the left side cover into the slots of the printer enclosure. B-EP4D Series: Fit the tabs A to D into the slot A’ to D’. Tab A Tab B Tab D...
- Page 14 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 2. Wireless LAN Board: B-EP700-WLAN-QM-R Mount the right side cover to the printer while fitting the tabs on the right side cover into the slots of the printer enclosure. B-EP4D Series: Fit the tabs A to C into the slot A’ to C’. Tab C Tab B Tab A...
- Page 15 TOSHIBA TEC sales agent. Do not disassemble, modify, or repair the product. Doing so may cause injury. Also, modification is against the Laws and Regulations for Radio Equipment. Please ask your TOSHIBA TEC sales agent for repair. Precaution in use This product communicates with other devices by radio.
- Page 16 3. Bluetooth Module: B-EP700-BLTH-QM-R 3. Bluetooth Module: B-EP700-BLTH-QM-R Thank you for purchasing TOSHIBA Bluetooth module, B-EP700-BLTH-QM-R. The B-EP700-BLTH-QM-R is an optional Bluetooth module for the B-EP2D/EP4D Series. The pictures used in this document are those of the B-EP4D, but the installation procedure is common with the B-EP2D unless otherwise noted.
- Page 17 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 3. Bluetooth Module: B-EP700-BLTH-QM-R Press the top cover open button to open the top cover. Remove the left side cover in the direction of the arrow. Left Side Cover Top Cover Top Cover Open Button NOTE: The gears shown in the picture below is not secured and is easily removed.
- Page 18 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 3. Bluetooth Module: B-EP700-BLTH-QM-R NOTE: As the fold of the FPC cable differs depending on the printer, please connect a correct one to the printer. (Unit: mm) B-EP4D Series : Valley Fold FCC Cable Forming Indication Figure : Mountain Fold 36.5 6.5 7.5...
- Page 19 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 3. Bluetooth Module: B-EP700-BLTH-QM-R Connect the FPC cable to the Bluetooth module. Pass the FPC cable through the slot, as shown in the picture. (B-EP4D model only) Bluetooth Module Slot FPC Cable Connect the FPC cable to the connector CN301 on the Main PC board. Main PC Board Connector CN301 FPC Cable...
- Page 20 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 3. Bluetooth Module: B-EP700-BLTH-QM-R Close the front cover. Front Cover NOTES: Make sure that the pins on the both sides of the front cover are fit in position, as shown in the pictures below. Do not reassemble the Front Cover while the Top Cover Open Button is pressed.
- Page 21 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 3. Bluetooth Module: B-EP700-BLTH-QM-R Mount the left side cover to the printer while fitting the tabs on the left side cover into the slots of the printer enclosure. B-EP4D Series: Fit the tabs A to D into the slots A’ to D’. Tab A Tab B Tab D...
- Page 22 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 3. Bluetooth Module: B-EP700-BLTH-QM-R Mount the right side cover to the printer while fitting the tabs on the right side cover into the slots of the printer enclosure. B-EP4D Series: Fit the tabs A to C into the slots A’ to C’. Tab C Tab B Tab A...
- Page 23 TOSHIBA TEC sales agent. Do not disassemble, modify, or repair the product. Doing so may cause injury. Also, modification is against the Laws and Regulations for Radio Equipment. Please ask your TOSHIBA TEC sales agent for repair. 3- 8...
- Page 24 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33005 3. Bluetooth Module: B-EP700-BLTH-QM-R Precaution in use This product communicates with other devices by radio. Depending on the installation location, orientation, environment, etc., its communication performance may deteriorate or devices installed near by may be affected. Keep away from a microwave.
