DISK CONTROL BOARD
BKSI-2010
DISK CONTROLLER MEMORY BOARD
BKSI-2011
INSTALLATION MANUAL
1st Edition (Revised 2)
Serial No. 10001 and Higher (BKSI-2010)
Serial No. 10001 and Higher (BKSI-2011)

Advertisement

Table of Contents
loading

Summary of Contents for Sony BKSI-2011

  • Page 1 DISK CONTROL BOARD BKSI-2010 DISK CONTROLLER MEMORY BOARD BKSI-2011 INSTALLATION MANUAL 1st Edition (Revised 2) Serial No. 10001 and Higher (BKSI-2010) Serial No. 10001 and Higher (BKSI-2011)
  • Page 2 ! WARNING This manual is intended for qualified service personnel only. To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.
  • Page 3: Table Of Contents

    2-7. Location and Function of Switches/LEDs ........1-8 2-7-1. SCS-4 Board ................1-8 2-7-2. IO-116 Board ................1-9 2-8. NOVRAM Setup ................1-10 3. Information of BKSI-2011 ................1-16 3-1. Installation to BKSI-2010 .............. 1-16 4. Specifications ....................1-17 5. ISR ......................... 1-18 5-1.
  • Page 4: Manual Structure

    The following manual is prepared for this unit. • Maintenance Manual (Optional manual) This manual describes the information for periodic maintenance and detailed service. For obtaining the Maintenance Manual, please contact to your local Sony’s sales/ service office. 2(E) BKSI-2010...
  • Page 5: Installation

    Interface (SDDI), and interface between BKSI-2010 and disk drives is SCSI. BKSI-2010 can process one channel signal for input, and two channel signals for output through the SDDI. When BKSI-2011 is mounted on BKSI-2010, the BKSI-2010 can process four channel signals for output.
  • Page 6: Disk Control Concept

    1. Overview 1-3. Disk Control Concept APPLICATION (Software) BKSI-2040 EDITOR VS-BUS RS-422A BKSI-2010 VS-BUS RS-422A SDDI SDDI BUFFER SCSI SDDI SDDI BUFFER SMS : Server Management System (Software) : Intelligent Device Controller SDDI : Serial Digital Data Interface SPC : SCSI Protocol Controller : Disk Drive 1-2(E) BKSI-2010...
  • Page 7: Information Of Bksi-2010

    Then, attach the model label on the right side of the others. shield plate. • BKSI-2011 (MY-72 board) is used to mount on BKSI- This label position should be aligned with the slot 2010. installing the board.
  • Page 8: Connector Panel Installation

    2. Information of BKSI-2010 2-2. Connector Panel Installation 3. Attach the model label supplied with the BKSI-2010 in the chassis near the slot to install the board. General information for installation After the connector panel is inserted into a slot, the •...
  • Page 9: Location And Function Of Connectors

    Provides the Serial Digital Data Interface (SDDI) signal. 3 RS-422A connectors :D-sub 9-pin Used for RS-422A remote control. SONY DISK PROTOCOL signal is available for this terminal. This connector does not accept SONY VTR PROTOCOL signal. 4 SCSI connector :Differential-P type 68-pin Connects to SCSI devices using a 68-pin cable corresponding to FAST-WIDE (10 Mbyte/s, 16 bits) differential type SCSI, which is standard product.
  • Page 10: Connecting Connector And Cable

    If any cable is connected to the connectors on the connector panel when installing or servicing, use the connector or cable listed below or equivalent. BKSI-2010 Matching Connector/Cable Panel Indication Connector Connector Sony Part No. SDDI IN/OUT 1-560-069-11 BELDEN 8281 cable REMOTE A D-sub 9-pin, Female D-sub 9-pin, Male...
  • Page 11 2. Information of BKSI-2010 SCSI : SCSI (Differential-P type 68-pin, Female) <External View> Pin No. Signal Pin No. Signal +DB (12) –DB (12) +DB (13) –DB (13) +DB (14) –DB (14) –DB (15) +DB (15) –DB (P1) +DB (P1) GROUND GROUND –DB (0) +DB (0)
  • Page 12: Location And Function Of Switches/Leds

    2. Information of BKSI-2010 2-7. Location and Function of Switches/LEDs S3301-2 and 3:Baud Rate setting Sets the baud rate for the ISR and maintenance mode 2-7-1. SCS-4 Board by the ON and OFF combination. Do not set the switch to the ON and ON combina- tion.
  • Page 13: Io-116 Board

    2. Information of BKSI-2010 8 D1101(A-9):SDDI RX indicator 2-7-2. IO-116 Board When receiving the SDDI signal, it lights in green. 9 D1102(A-9):REC indicator When DMA data for the record process block is RV300 transferred on SCSI, it lights in green. RV100 0 D2201(A-9):SDDI TX1 indicator (Component side/A side)
  • Page 14: Novram Setup

    In this mode, Ciprico AR6712, MAV-S100, or MAV-S110 can be connected to the BKSI-2010. MAV-S110 and MAV-S110 can be combined but Ciprico and MAV Series cannot be combined. This mode is not used in STAS-10 (Sony Transmission Automation System). After changing the connection of the arrays, perform this setup.
  • Page 15 2. Information of BKSI-2010 Prepare Procedure 1. Turn off the power of SIU-80. 2. Connect the BKSI-2010 maintenance connector CN1101 (A-5) and the RS-232C connector COM1 of the personal computer using the communication cable. 3. Turn on the power of the2. Information of BKSI-2010 personal computer. 4.
  • Page 16 2. Information of BKSI-2010 Multi File Mode Items to be set up . Number of Arrays . Number of Audio Channels . Start Time Code Setup Procedure 1. Set the switch lever of the mode select switch (S3301) on the SCS-4 board as shown below. indicates the switch lever position.) 2.
  • Page 17 4. Enter “y”. The setting is written in NOVRAM and the SCS-4 board is reset automatically. SDC-OS Version x.xx(xxx xx, xxxx) (C)Copyright Sony Corporation 1996, 1997 File System Version 1.00(May 25,1995) (C)Copyright Sony Corporation 1996 SDC-Software Version x.xx(xxx xx, xxxx)
  • Page 18 2. Information of BKSI-2010 Single File Mode Items to be set up . Type of Array . Number of Audio Channels Setup Procedure 1. Set the switch lever of the mode select switch (S3301) on the SCS-4 board as shown below. indicates the switch lever position.) 2.
  • Page 19 4. Enter “y”. The setting is written in NOVRAM and the SCS-4 board is reset automatically. SDC-OS Version x.xx(xxx xx, xxxx) (C)Copyright Sony Corporation 1996, 1997 File System Version 1.00(May 25,1995) (C)Copyright Sony Corporation 1996 SDC-Software Version x.xx(xxx xx, xxxx)
  • Page 20: Information Of Bksi-2011

    Take care of the direction of bracket at installation. If the BKSI-2010 cannot process expanded channel signals even though the BKSI-2011 is installed, make sure that the PTTWH3X6 connectors are properly connected. For the more details of the confirmation, refer to the Maintenance Manual.
  • Page 21: Specifications

    SDDI SDDI IN/OUT connector (BNC type) 75 Ω, 270 Mbps SCSI SCSI connector (Differential-P type, 68-pin) BKSI-2011 General 5 °C to 40 °C (41 °F to 104 °F) Operating temperature –20 °C to +60 °C (–4 °F to +140 °F)
  • Page 22: Isr

    5. ISR 5-1. Overview The BKSI-2010 corresponds to an ISR (Interactive Status Reporting) function. Using this function, the status of the BKSI-2010 or the contents of a generated error can be intensively monitored and managed on the monitor screen of a personal computer. The data displayed on the monitor screen can be stored or printed as a file.
  • Page 23 5. ISR [File Block warning] Message Description DISK FULL There is no space in the disk ILLEGAL LOGICAL FORMAT DISK Logical format of the disk is illegal WRITE PROTECT DISK The disk is write-protected WRITE UNCOMPLETE FILE EXIST A file which has not been written completely exists in the disk [Input/Output (SCSI) Block warning] Message Description...
  • Page 24 5. ISR • Operation status In the operation status, displays a name of the file which BKSI-2010 accesses, in the hard disk, and its operation status. The followings show the operation status. Operation Status Indication Description STOP Be at a standstill to record, play back, write, and read CLOSE The file is closed PLAY...
  • Page 25: Isr Use Environment

    5-2. ISR Use Environment The ISR function is controlled by Sony application program software. For the program software, use, installation, and operation of a personal computer in which this program software can be used, consult with your local sony’s sale/service office.
  • Page 27 The material contained in this manual consists of information that is the property of Sony Corporation and is intended solely for use by the purchasers of the equipment described in this manual. Sony Corporation expressly prohibits the duplication of any portion of this manual or the use thereof for any...
  • Page 28 BKSI-2010 (SY) Printed in Japan Sony Corporation BKSI-2011 (SY) J, E 1997. 3 16 Broadcast Products Company 3-190-290-03 ©1996 Published by Broadcast Products Company...
