COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis :
KS2A(N)
Model :
CL21A8W7X/DRI
CL21A8W7X/XAP
CL21A9W7X/XAX
CL25A6W7X/XAX
CL29D4W7X/DRI
CL29D4W7X/STR
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
CONTENTS
Specifications
Troubleshooting
Exploded Views and Parts List

Advertisement

loading

Related Manuals for Samsung CL21A8W7X/DRI

Summary of Contents for Samsung CL21A8W7X/DRI

  • Page 1: Table Of Contents

    COLOR TELEVISION RECEIVER Chassis : KS2A(N) Model : CL21A8W7X/DRI CL21A8W7X/XAP CL21A9W7X/XAX CL25A6W7X/XAX CL29D4W7X/DRI CL29D4W7X/STR COLOR TELEVISION RECEIVER CONTENTS Precautions Reference Information Specifications Alignment and Adjustments Troubleshooting Exploded Views and Parts List Electrical Parts List Block Diagrams Wiring Diagram Schematic Diagrams...
  • Page 2 ELECTRONICS © Samsung Electronics Co., Ltd. SEP. 2000 Printed in Korea 3KS2A(N)-2901...

  • Page 3: Precautions

    Heed the high voltage limits. These include not exceed 0.5 milliamp. Reverse the power- the X–ray Protection Specifications Label, and plug prongs in the AC outlet and repeat the the Product Safety and X-ray Warning Note on test. the service data schematic. Samsung Electronics...
  • Page 4 14. Components, parts and wiring that appear to have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheating, and correct any potential hazards. Samsung Electronics...
  • Page 5 Make sure that the portion around 8. Always connect a test instrument’s ground the serviced part has not been damaged. lead to the instrument chassis ground before connecting the positive lead; always remove the instrument’s ground lead last. Samsung Electronics...
  • Page 6 4. Do not use freon-propelled chemicals. These unpackaged replacement ESDs. Motions such can generate electrical charges that damage as brushing clothes together, or lifting a foot ESDs. from a carpeted floor can generate enough static electricity to damage an ESD. Samsung Electronics...
  • Page 7 5W x 2CH Sound Option Vitual Dolby Effect Turbo Sound Pseudo Stereo RCA Input Front Option S-VHS (AV2) Head-Phone Jacks 2 AV Input Back Option DVD Input(YPbPr) Option AV2 Monitor Audio Output Option S-VHS Specifications are subject to change. Samsung Electronics...
  • Page 8 MEMO Samsung Electronics...

  • Page 9: Reference Information

    Millimeter Hour Millisecond Inches Per Second Millivolt Kilowatt-hour Nanofarad Ω Kilogram Kilohertz Picofarad kΩ Kilohm Pound Kilometer Revolutions Per Minute km/h Kilometer Per Hour Revolutions Per Second Kilovolt Second (Time) Kilovolt-ampere Volt Kilowatt Volt-ampere Liter Watt Megahertz Watt-hour Samsung Electronics...
  • Page 10 Fail Safe Voltage Controlled Oscillator Ground VCXO Voltage Controlled Crystal Oscillator Green-Y Very High Frequency High Video Intermediate Frequency High-Frequency Variable Resistor HI-FI High Fidelity Video Tape Recorder Inductance-Capacitance VTVM Vacuum Tube Voltmeter Integrated Circuit Transistor Intermediate Frequency Samsung Electronics...
  • Page 11 D807 D805 FMG-G26S 6V Regulator IC804 KA7806 8V Controlled Regulator IC803 KA78R08 IC903 3.3V Regulator KA78RM33 MICOM Reset IC IC904 KIA7025AP Q909 IIC Level Shifter 2N7000 Q910 TCPN3081PA09A(S) Main Tuner with IF Block TU01 D813 FML-G12S Rectifier Diode Samsung Electronics...
  • Page 12 Table 2-3-1 VIDEO IC REMARK SPEC FUNCTION VDP3108B Basic 1H Comb Filter VDP3130Y 2H Comb Filter, DVD Input Table 2-3-2 SOUND AMP REMARK FUNCTION SPEC TDA7297 7W x 2CH, 10W x 2CH TDA7266S 3W x 2CH, 5W x 2CH Samsung Electronics...
  • Page 13 IC902 IC803, 805 IC804 Replace Check Normal Abnormal Check Q401 and IC902 Normal IC803 Horizontal Circuit Check FBT and B+(130V) Check Abnormal Check the resistance of SCL, SDA Line FD803 Replace FD803 Normal Check IC801, D801 FUSE Samsung Electronics...
  • Page 14 Abnormal Screen Voltage R.G.B Signal Output from IC201 Check Normal the signal output from IC201 Pin Check Normal Q202, Q203, Q204, Abnormal Q207, Q209, Q213, Q206, Q208, Q210 Check / Replace Check tuner B+ and Main CVBS IC201 Samsung Electronics...
  • Page 15 4 12 Check Normal Check the signal input IC602 B+ to IC601 Pin Abnormal Normal Abnormal Normal Check Check/Replace Replace Check IC601 B+ the resistance tuner B+ and SIF IC602 of FD802 Abnormal Check Check/Replace IC601 B+ Line (8V) Samsung Electronics...
  • Page 16 5-4 Horizontal Lines Appear on screen Horizontal Lines Apper on screen Check Normal Abnormal IC301 B+ (16V, -16V) Check B+ Line and the fusible Check resistance of R425, 424 Normal the VDP Signal output from IC201 Abnormal Check/Replace Check IC301 IC201 Samsung Electronics...

  • Page 17: Alignment And Adjustments

    2. Turn on the TV. Set the Brightness and Contrast controls to minimum (zero beam current). 3. Adjust the Brightness and contrast controls to both extremes. Ensure that the high voltage does not exceed 30 KV under any conditions. Samsung Electronics...
  • Page 18 25V 1.0R/SDI 23V 1.3R/SDI 5. Turn the SCREEN VR until “MRCR G B” and “MRWDG” are green and those value are about 100. (The incorrect SCREEN Voltage may result that “MRCR G B” and “MRWDG” should be red) Samsung Electronics...
  • Page 19 7. Adjust CA-100 so that the final adjustment value can be fixed. 8. Use the Channel Up/Down ( / ) buttons to move the cursor on the adjustment modes. 9. Use the Volume +/- buttons to change the adjustment value. Samsung Electronics...
  • Page 20 PROM (sometimes MICOM) is replaced, the adjustment values should be controlled. - After the Service adjustment is completed, Do not select “Reset” in the service mode menu. (After above procedure is done, power is on initially and the “Plug and Play” will be operated.) Samsung Electronics...
  • Page 21 RED CUT OFF Control GREEN CUT OFF BLUE CUT OFF Control RED DRIVE Control GREEN DRIVE BLUE DRIVE Control SUB BRIGHT Control SUB CONTRAST Control SUB COLOR SUB TINT BCL THRESHOLD BCLGAIN BCL TIME DVD SUB TINT N. YC DELAY Samsung Electronics...
  • Page 22 Alignment and Adjustments 4-8-2(B) SCREEN CHANGE (I2C BUS GEOMETRIC ADJUSTMENT) V Shift V Amp V Slope V SC H EW H Trapizium H Symmetry H Parabola H Corner H Shift Samsung Electronics...
  • Page 23 TXK2566 TXK2754 TXK2067 TXK2567 CL663BW VIDEO ADJUST2 INIT B STRETCH-BTHR B DTRETCH-BTLT WDRGB B STERTCH-BAM CORING NTSC COMB FILTER RGB BRIGHT RG B CONTRAST EHT TIME EHT VERTICAL DTI CORING DTI GAIN DTI BAND EHT OFFSET EHT HORIZONTAL Samsung Electronics...
  • Page 24 GAIN 1 (VIDEO) DELAY 1 (VIDEO) PEAK VIDEO REF PEAK VIDEO GAIN LIMIT VALUE LIMIT VALUE VELOCITY DELAY VELOCITY DELAY VELOCITY CORING ACC-REF ACCR Samsung Electronics INCH 27V 1.3R 25V 1R 27V 1R 20V 1R 15" FLA 23V 1.3R TXK2550 TXK2060 TXK2554...
  • Page 25 TXK2567 CL663BW TXK2550 G2 Adjust TXK2060 MRC R G B TXK2750 TXK2554 MRC R G B Model TXK2767 CL25D4W TXK2066 CT-15A8 TXK2566 TXK2754 MRWDG TXK2067 TXK2567 IBRM CL663BW WDRV G2 Adjust MRC R G B MRWDG IBRM WDRV Samsung Electronics...
  • Page 26 BCL THRESHOLD SUB TINT SUB TINT BCLGAIN BCL THRESHOLD BCL THRESHOLD BCL TIME BCLGAIN BCLGAIN DVD SUB TINT BCL TIME BCL TIME N. YC DELAY DVD SUB TINT DVD SUB TINT N. YC DELAY N. YC DELAY 4-10 Samsung Electronics...
  • Page 27 DELAY 1 (VIDEO) PEAK VIDEO REF LIMIT VALUE PEAK VIDEO REF PEAK VIDEO GAIN VELOCITY DELAY PEAK VIDEO GAIN LIMIT VALUE VELOCITY CORING LIMIT VALUE VELOCITY DELAY ACC-REF VELOCITY DELAY VELOCITY CORING ACCR VELOCITY CORING ACC-REF ACCR Samsung Electronics 4-11...
  • Page 28 15" FLAT 21" FLAT 25" FLAT Model CL15A8 Model TXK2768 CL15A8 CL21A8 CL25A6 Model TXK2768 CL15A8 CL21A8 CL25A6 MRC R G B MRC R G B MRC R G B MR WDG IBRM IBRM WDRV WDRV WDRV 4-12 Samsung Electronics...
  • Page 29 OSD-B OSD-G OSD-R Scart1 Ident VDD 2.5V Scart2 Ident Key 1 X-TAL Out H-Sync X-TAL In V-Sync MICOM Reset Key 3 N.C. Key 2 N.C. X-Ray Protect VDD 3.3V IR Input Stand-By LED N.C. Time LED Relay Samsung Electronics 4-13...
  • Page 30 Scart1 Ident SC1-ID SC2-ID Scart2 Ident Key1 Key1 Input H-Sync Horizontal Sync Input Vertical Sync Input V-Sync Key3 Input Key3 Key2 Key2 Input X-Ray X-Ray Protection IR-In Remocon Signal Input STD-LED LED Drive Output(Red) TIM-LED LED Drive Output(Green) 4-14 Samsung Electronics...
  • Page 31 Fast Blank/Half Contrast Output OSD-B CORE VDD 2.5V VDD 3.3V PX.Y When The Caption Function Adopted, Used. PX.Y N.C. Not Used (Programmed Gound Level) N.C. Sound Amp Mute S-Mute High Picture On/Off Control Power Not Used (Programmed Gound Level) N.C. Samsung Electronics 4-15...
  • Page 32 MEMO 4-16 Samsung Electronics...

  • Page 33: Electrical Parts List

    2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15 ...3 IC501 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS ..4 C305 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5 ...3 IC502 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS ..4 C306 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, ...3 IC503 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS ..4 C307 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5 ...3 IC601 1204-001594 IC-SOUND PROCESSOR;MSP3440G-B6,SDIP,52P, ..4 C308 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m Samsung Electronics...
  • Page 34 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5 ..4 D811 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP ..4 C817 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5..4 D901 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP ..4 C818 2401-000722 C-AL;2200uF,20%,25V,WT,TP,16x25,7.5 ..4 D902 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP ..4 C819 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5..4 D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP ..4 C820 2401-001054 C-AL;3300uF,20%,25V,GP,TP,18x25,7.5 ..4 D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP Samsung Electronics...
  • Page 35 ..4 L804 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- ..4 R249 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 L806 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500, ..4 R250 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..4 L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- ..4 R251 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 L809 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500, ..4 R252 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 36 ..4 R833 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R519 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R835 2003-002211 R-METAL OXIDE(S);91Kohm,5%,2W,AG,TP,3.9x ..4 R520 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R836 2003-002211 R-METAL OXIDE(S);91Kohm,5%,2W,AG,TP,3.9x ..4 R521 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R901 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R522 2008-000206 R-FUSIBLE(S);1ohm,5%,1/2W,AF,TP,2.5x6.5m ..4 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 37 ..4 R903 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M AA65-00011B CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,15M S.N.A ..4 R904 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M AA64-00818B INDICATOR LED;-,21A8,-,ACRYL,-,CLR,- ..4 R905 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M AA64-70123A BADGE-BRAND;AL,SAMSUNG,SILVER,L=50,FLAT, ..4 R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M AA96-00358C ASSY SPEAKER;-,16ohm(x2),5W(x2),3001-000 ..4 R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 3001-000280 SPEAKER;5W,16ohm,90dB,150Hz ..4 R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ...3...
  • Page 38 Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark AA63-10002A BAND-TIE;-,NYLON66 V2,-,-,L100,NTR,-,- S.N.A ASSY ACCESSORY * AA94-02412F ASSY ACCESSORY;CL15A8L7X/XAP,KS2A,PANAMA S.N.A AA68-01026C MANUAL USERS;-,-,SPA,B5,W/P100(G),-,-,-, AA68-01025C MANUAL USERS;-,-,ENG,B5,W/P100(G),-,-,-, AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,- AA69-30002A BAG-SHEET;LDPE,T0.05,W240,L400,-,L-TYPE, S.N.A AA26-90001F TRANS-MATCHING;-,300ohm/75ohm,NTSC,40-89 3721-000136 PLUG-CONVERSION;2P,4.0mm,N,NI Samsung Electronics...
  • Page 39 ASSY PCB MAIN(OPT) ...3 L408 AA27-00097A COIL HORIZ. WIDTH;-,700uH,DR15 X 27.5,US ...3 L808 AA27-00098A COIL CHOKE;-,-,24uH,10%,-,0.1,3.0A,DR10X ...3 LD901 AA96-00461A ASSY LED GUIDE;-,-,SL-255D,RED/GRN * AA94-02364YASSY PCB MAIN(OPT);CL21A8W7X/DRI,KS2A,-, ...3 LR401S AA27-00101A COIL LINEARITY;58uH,58uH,DR14x15 C:6.0,1 ...3 LX801S AA29-30002F FILTER-LINE NOISE;-,6mH,2.45A,-,- ..2 CN501B AA39-20054A LEAD CONNECTOR-ASSY;-,YBNH025-06,S,6P,40 ...3 NT802S...
  • Page 40 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5..4 D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP ..4 C823 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP ..4 C825 2306-000122 C-FILM,MPPF;100nF,5%,50V,TP,7.3x4.0x5.0m ..4 D905 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP ..4 C826 2401-001363 C-AL;470uF,20%,16V,GP,TP,10x12.5,5 ..4 D906 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35, ..4 C827 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm ..4 D907 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP Samsung Electronics...
  • Page 41 ..4 L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- ..4 R250 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..4 L809 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500, ..4 R251 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 L901 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5, ..4 R252 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 L903 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5, ..4 R253 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 42 ..4 R831 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R519 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R832 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M ..4 R520 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R833 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R521 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R835 2003-002211 R-METAL OXIDE(S);91Kohm,5%,2W,AG,TP,3.9x ..4 R522 2008-000206 R-FUSIBLE(S);1ohm,5%,1/2W,AF,TP,2.5x6.5m ..4 R836 2003-002211 R-METAL OXIDE(S);91Kohm,5%,2W,AG,TP,3.9x 7-10 Samsung Electronics...
  • Page 43 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R937 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ASSY ACCESSORY ..4 R938 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R939 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M ..4 R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM * AA94-02737JASSY ACCESSORY;CL21A8W7X/DRI,KS2A,- S.N.A ..4 R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM AA68-01188A MANUAL USERS;-,-,SPA,B5,W/P100(G),-,-,-, S.N.A ..4 R943 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AA69-30002A BAG-SHEET;LDPE,T0.05,W240,L400,-,L-TYPE,...
  • Page 44 Electrical Parts List Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY CABINET * AA90-00375KASSY CABINET;21A8,CL21A8W7X/DRI S.N.A ..2 AV+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) S.N.A ..2 BACK AA63-60001X SPACER-FELT;FELT,T0.5,BLK,330X15,-,- S.N.A ..2 CB+CF AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW...
  • Page 45 ...3 IC803 1203-002085 IC-VOLTAGE REGULATOR;78R08,TO-220,4P,-,P ..4 C411 2301-000104 C-FILM,PEF;1.2nF,5%,50V,TP,6.5x3.0x5.5mm ...3 IC902 1103-001171 IC-EEPROM;24L161,16KBIT,DIP,8P,300MIL,10 ..4 C412 2301-000188 C-FILM,PEF;1nF,5%,100V,TP,10.5x12.5x6.5, ...3 L405 AA27-00096A COIL HORIZ. WIDTH;-,10.0mH,DR15 X 27.5,U ..4 C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5 ...3 L408 AA27-00097A COIL HORIZ. WIDTH;-,700uH,DR15 X 27.5,US Samsung Electronics 7-13...
  • Page 46 2306-000122 C-FILM,MPPF;100nF,5%,50V,TP,7.3x4.0x5.0m ..4 DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C826 2401-001363 C-AL;470uF,20%,16V,GP,TP,10x12.5,5 ..4 DZ202 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO ..4 C827 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm ..4 DZ203 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 DZ204 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C831 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D 7-14 Samsung Electronics...
  • Page 47 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 L906 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm ..4 R258 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q201 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R259 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R260 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R261 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-15...
  • Page 48 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7 ..4 R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R529 0403-001316 DIODE-ZENER;MTZJ3.0A,2.85-3.07V,500mW,DO ..4 R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R601 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R602 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R603 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R910 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 7-16 Samsung Electronics...
  • Page 49 AA64-00823B KNOB CONTROL;-,21A9,-,ABS,HB,G3676 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,- AA64-00825B KNOB POWER;-,21A9,-,ABS,HB,G3676 AA26-90001F TRANS-MATCHING;-,300ohm/75ohm,NTSC,40-89 AA64-00827B WINDOW REMOCON;21A9,PC,-,-,-,V0,VIOLET,- AA64-00829B INDICATOR LED;21A9,ACRYL,-,CLR,-,-,- AA65-00011B CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,15M S.N.A ASSY-PCB,A/V FRONT AA64-70123A BADGE-BRAND;AL,SAMSUNG,SILVER,L=50,FLAT, AA64-00821F PANEL CONTROL;21A9 NT,HIPS,-,HB,G4309,-, * AA95-00631AASSY-PCB,A/V FRONT;-,CT-21A8,KS2A,-,-,- AA61-40113A STOPPER-PCB;501H,HIPS,NTR,HB,-,- S.N.A AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,- S.N.A CA02 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP...
  • Page 50 Electrical Parts List Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY CRT * AA94-02917AASSY CRT;AA03-00207A,+380mG,A51QDX991X0 AA03-00207A CRT COLOR;A51QDX991X001,-,21DF,0.74,-,UN 7-18 Samsung Electronics...
  • Page 51 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5 ...3 IC502 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS ..4 C408 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm ...3 IC503 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS ..4 C411 2301-000104 C-FILM,PEF;1.2nF,5%,50V,TP,6.5x3.0x5.5mm ...3 IC601 1204-001594 IC-SOUND PROCESSOR;MSP3440G-B6,SDIP,52P, ..4 C412 2301-000188 C-FILM,PEF;1nF,5%,100V,TP,10.5x12.5x6.5, ...3 IC803 1203-002085 IC-VOLTAGE REGULATOR;78R08,TO-220,4P,-,P ..4 C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5 Samsung Electronics 7-19...
  • Page 52 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 D908 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35, ..4 C825 2306-000122 C-FILM,MPPF;100nF,5%,50V,TP,7.3x4.0x5.0m ..4 DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C826 2401-001363 C-AL;470uF,20%,16V,GP,TP,10x12.5,5 ..4 DZ202 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO ..4 C827 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm ..4 DZ203 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 DZ204 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 7-20 Samsung Electronics...
  • Page 53 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 L904 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5, ..4 R255 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..4 L905 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R256 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 L906 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm ..4 R258 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q201 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R259 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-21...
  • Page 54 2008-000299 R-FUSIBLE(S);47ohm,5%,2W,AF,TP,3.9x10mm ..4 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R525 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 ..4 R903 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R526 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7 ..4 R904 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R529 0403-001316 DIODE-ZENER;MTZJ3.0A,2.85-3.07V,500mW,DO ..4 R905 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R601 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 7-22 Samsung Electronics...
  • Page 55 S.N.A AA64-00241C WINDOW-REMOCON;-,25A6,W971,PC,VO,VIOLET, CB+CF AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW S.N.A CB+TER AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW S.N.A CF+CRT AA61-10053A BRACKET-CRATER;-,7277,STS304,T0.5,-,-,- S.N.A ASSY HOLDER SPK CF+CRT AA60-10050V SCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S S.N.A DOME 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A AA64-01230B INLAY-COVER;D2,D3,PVC-SHEET,T0.4,94V0,-, S.N.A * AA91-00339AASSY HOLDER SPK;-,PP,8ohm/15W,blk,housin TER+RJ AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW S.N.A Samsung Electronics 7-23...
  • Page 56 ...3 RC918 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 RC939 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM ASSY CHASSIS PART * AA90-00118DASSY CHASSIS PART;KS2A,25A6 S.N.A AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M S.N.A AA65-00011B CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,15M S.N.A MAIN+H 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW S.N.A TER+HC 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW S.N.A AA61-20254A HOLDER-CHASSIS;-,CS-622A,HIPS,V0,BLK,- S.N.A 7-24 Samsung Electronics...
  • Page 57 ...3 L408 AA27-00097A COIL HORIZ. WIDTH;-,700uH,DR15 X 27.5,US ..4 C415 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm ...3 L808 AA27-00098A COIL CHOKE;-,-,24uH,10%,-,0.1,3.0A,DR10X ..4 C416 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m ...3 LD901 AA96-00461A ASSY LED GUIDE;-,-,SL-255D,RED/GRN ..4 C417 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ...3 LR401S AA27-00101A COIL LINEARITY;58uH,58uH,DR14x15 C:6.0,1 Samsung Electronics 7-25...
  • Page 58 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm ..4 D907 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP ..4 C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 D908 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35, ..4 C831 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C832 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 ..4 DZ202 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C835 2401-002286 C-AL;470uF,20%,16V,WT,TP,10x12.5,5 ..4 DZ203 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 7-26 Samsung Electronics...
  • Page 59 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R260 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R261 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q206 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..4 R262 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q207 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R263 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-27...
  • Page 60 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R911 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R603 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R912 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R604 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm ..4 R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R605 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R914 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R606 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R915 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 7-28 Samsung Electronics...
  • Page 61 S.N.A AA64-00892B INLAY BACK;D2,D3,RCA9P,PS SHEET,T0.3,BLK * AA95-00738AASSY-PCB,A/V FRONT;-,CT-29H1D,KS2A,NTSC, AA64-31266E CABINET-BACK;-,29D4,-,HIPS,HB,BLK,-,- CA06 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 CA07 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 REMOCON CN01A AA39-20068E LEAD CONNECTOR-ASSY;-,YBNH025-08,67096-0 CN05A AA39-20069C LEAD CONNECTOR-ASSY;-,YBNH025-05,67096-0 CN06A AA39-00070A LEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB * AA59-10110MREMOCON;-,TM59,SZM368ET,24,L/GRAY,SS,E JA01 3722-001031 JACK-RCA;3P,3.6MM,#18,AU JE01 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO Samsung Electronics 7-29...
  • Page 62 AA27-00096A COIL HORIZ. WIDTH;-,10.0mH,DR15 X 27.5,U ..4 C412 2305-000178 C-FILM,MPEF;10nF,5%,100V,TP,-,5mm ...3 L408 AA27-00097A COIL HORIZ. WIDTH;-,700uH,DR15 X 27.5,US ..4 C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5 ...3 L808 AA27-00098A COIL CHOKE;-,-,24uH,10%,-,0.1,3.0A,DR10X ..4 C415 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm ...3 LD901 AA96-00461A ASSY LED GUIDE;-,-,SL-255D,RED/GRN ..4 C416 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 7-30 Samsung Electronics...
  • Page 63 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm ..4 DZ204 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..4 C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D ..4 C831 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 DZ303 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D ..4 C832 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 ..4 DZ304 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D ..4 C835 2401-002286 C-AL;470uF,20%,16V,WT,TP,10x12.5,5 ..4 DZ305 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D Samsung Electronics 7-31...
  • Page 64 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 Q208 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..4 R264 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm ..4 Q209 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R265 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm ..4 Q210 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..4 R267 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm ..4 Q211 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..4 R301 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4 7-32 Samsung Electronics...
  • Page 65 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R919 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R608 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R920 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R609 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R921 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M ..4 R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R923 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R924 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-33...
  • Page 66 AA39-20069C LEAD CONNECTOR-ASSY;-,YBNH025-05,67096-0 CN06A AA39-00070A LEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB REMOCON JA01 3722-001031 JACK-RCA;3P,3.6MM,#18,AU JE01 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO AA41-11017A PCB-A/V,SIDE;S51A,1L,FR-1,245x245x1.6T,A S.N.A * AA59-10110HREMOCON;-,TM59,SS,SZM368ET,24,-,-,L/GR RA01 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 RA02 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 AA63-10002A BAND-TIE;-,NYLON66 V2,-,-,L100,NTR,-,- S.N.A AA98-60006A ASSY-SUB,PART;S51A,A/V SIDE,PAL,- S.N.A ...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A 7-34 Samsung Electronics...
  • Page 67 WINDOW REMOCON ;-,21A8,-,PC,V0,VIOLET,- 1-10 6003-001026 SCREW-TAPTITE ;RH,+,B,M4,L15,ZPC(BLK),SWR 1-11 AA65-00011B CLAMP-WIRE ;ALL MODEL,NYLON 66,V2,NTR,15M 3 AA03-00207A CRT COLOR ;A51QDX991X001,-,21DF,0.74,-,UN AA65-00009B CLAMP-D,COIL ;NYLON 66,V0,-,-,21A8,- AA60-10050R SCREW-ASSY ;WC,HH,+,M5,L31.5,SWRCH18A,ZPC 3704-001105 SOCKET-CRT ;11P,20PI,26.5PI,NI,- AA64-00811C CABINET BACK ;21A8,-,HIPS,HB,BLK AA60-10050T SCREW-TAPPING ;RH,+,2S,M4,L20,ZPC(BLK),SW * AA96-20109C ASSY-POWER,CORD ;-,CP2/NO(4.0),H/C300,KKP Samsung Electronics...
  • Page 68 ;RH,+,B,M4,L12,ZPC(BLK),SWR AA03-00143A CRT COLOR ;-,A59QDF891X002,+380mG,25DF,90 AA65-30113A CLAMP-D,COIL ;NYLON 66,V2,BLK,TVI 25~29,- AA60-10050V SCREW-ASSY ;WC,HH,+,M6,L30,SWRCH18A,ZPC(S 4 AA65-30017A CLAMP-D,COIL ;NYLON-66,V0,NTR,DADH300,25 3704-001105 SOCKET-CRT ;11P,20PI,26.5PI,NI,- AA91-00339A ASSY HOLDER SP K;-,PP,8ohm/15W,blk,housin 6003-001026 SCREW-TAPTITE ;RH,+,B,M4,L15,ZPC(BLK),SWR AA64-00239D CABINET BACK ;-,25A6,-,HIPS,HB,BLK,-,- AA60-10050T SCREW-TAPPING ;RH,+,2S,M4,L20,ZPC(BLK),SW AA96-20112A ASSY-POWER,CORD ;-,EP2/NO,H/C300,KJ10,THA Samsung Electronics...
  • Page 69 1-11 AA64-00829B INDICATOR LED ;21A9,ACRYL,-,CLR,-,-,- 1-12 AA64-00827B WINDOW REMOCON ;21A9,PC,-,-,-,V0,VIOLET,- 1-13 6003-001019 SCREW-TAPTITE ;RH,+,B,M4,L12,ZPC(BLK),SWR AA03-00207A CRT COLOR ;A51QDX991X001,-,21DF,0.74,-,UN AA65-00009B CLAMP-D,COIL ;NYLON 66,V0,-,-,21A8,- AA60-10050R SCREW-ASSY ;WC,HH,+,M5,L31.5,SWRCH18A,ZPC 3704-001105 SOCKET-CRT ;11P,20PI,26.5PI,NI,- AA64-01155C CABINET BACK ;21A9,-,HIPS,HB,BLK AA60-10050T SCREW-TAPPING ;RH,+,2S,M4,L20,ZPC(BLK),SW AA96-20112A ASSY-POWER,CORD ;-,EP2/NO,H/C300,KJ10,THA Samsung Electronics...
  • Page 70 KNOB-CONTROL ;-,254,294,294D,G3676,ABS,HB 1-11 6003-001026 SCREW-TAPTITE ;RH,+,B,M4,L15,ZPC(BLK),SWR 1-12 AA64-40506A INDICATOR-LED ;-,294,299D,-,ACRYL,HB,CLR, 1-13 AA64-40505B WINDOW-REMOCON ;-,29D4,-,PC,V0,VIOLET,- 1-14 6003-001026 SCREW-TAPTITE ;RH,+,B,M4,L15,ZPC(BLK),SWR AA03-10027D CRT-COLOR ;-,A68KVL74X01(D),0mG,29,110de AA65-30017A CLAMP-D,COIL ;NYLON 66,V2,BLK,TVI 25~29,- AA60-10050R SCREW-ASSY ;WC,HH,+,M5,L31.5,SWRCH18A,ZPC AA64-31266E CABINET-BACK ;-,29D4,-,HIPS,HB,BLK,-,- 6003-001025 SCREW-TAPTITE ;RH,+,B,M4,L20,ZPC(BLK),SWR AA96-20109A ASSY-POWER,CORD ;-,CP2/NO(4.0),H/C400,KKP Samsung Electronics...

  • Page 71: Block Diagrams

    Schematic Diagrams 8. Block Diagrams 8-1 Power Diagram Samsung Electronics...
  • Page 72 Schematic Diagrams 8-2 Block Diagram Samsung Electronics...

  • Page 73: Wiring Diagram

    Wiring Diagram 9. Wiring Diagram FRONT AV PCB CN06A TO SPEAKER CN05A CN01A CN501B GT804 CN502B +16V Heater 180V CN501A CN602 B Out G Out R Out CN701 Sense CN502A +16V Heat 220V GT102 Samsung Electronics...
  • Page 74 MEMO Samsung Electronics...

  • Page 75: Schematic Diagrams

    Schematic Diagrams 10. Schematic Diagrams 10-1 MAIN 1/4 (WITH EW) TP07 TP01 TP10 TP08 TP02 TP09 TP03 TP09 TP01 TP06 TP10 TP04 TP08 TP05 TP05 TP03 TP07 TP02 TP04 TP06 : Power Line : Signal Line Samsung Electronics 10-1...
  • Page 76 Schematic Diagrams 10-2 MAIN 2/4 TP11 TP12 TP13 TP12 TP13 TP14 TP15 TP11 TP14 TP15 : Power Line : Signal Line 10-2 Samsung Electronics...
  • Page 77 Schematic Diagrams 10-3 MAIN 3/4 TP22 TP16 TP23 TP17 TP23 TP22 TP24 TP18 TP16 TP18 TP17 TP25 TP19 TP21 TP19 TP20 TP24 TP25 TP20 TP21 : Power Line : Signal Line Samsung Electronics 10-3...
  • Page 78 Schematic Diagrams 10-4 MAIN 4/4 TP32 TP26 TP33 TP27 TP35 TP33 TP26 TP34 TP34 TP28 TP27 TP32 TP35 TP29 TP31 TP28 TP29 TP30 TP30 TP31 : Power Line : Signal Line 10-4 Samsung Electronics...
  • Page 79 Schematic Diagrams 10-5 POWER (W/O -EW) Samsung Electronics 10-5...
  • Page 80 Schematic Diagrams 10-6 PIP 10-6 Samsung Electronics...
  • Page 81 Schematic Diagrams 10-7 VIDEO SWITCH Samsung Electronics 10-7...

This manual is also suitable for:

Cl29d4w7x/strCl21a8w7x/xapCl21a9w7x/xaxCl25a6w7x/xaxCl29d4w7x/dri
