Siemens RUGGEDCOM RX1510 Installation Manual page 20

1.
RUGGEDCOM RX1510
Installation Manual, 12/2019, C79000-G8976-1055-16
Connect the power supply terminal block to the device.
European-style (Euroblock) Terminal Block
1
Positive/Live (+/L) Terminal
2
Ground Terminal
3
Negative/Neutral (-/N) Terminal
4
Figure 2.4 AC Terminal Block Wiring – European-style (Euroblock) Terminal Block for HIP
Power Supplies
2
Not Connected
1
Removable Screw Terminal Block
2
Non-removable Screw Terminal Block
3
Positive/Live (+/L) Terminal
4
Ground Terminal
5
Negative/Neutral (-/N) Terminal
6
Figure 2.5 AC Terminal Block Wiring – Screw Terminal Block for HI Power Supplies
2.5.1 Connecting High AC/DC Power
1 1
2
3
4
4
1
5
1
6
Installing the Device
3
4
5
6
11
