User Manual
Please use this manual together with the Service Manual for Order No. MKS9602M315
Model No. PV-M2046.
SPECIFICATIONS
ITEM
Head: 4 rotary heads helical scanning system
Input Level: VIDEO IN Jack (Phono type) 1.0 Vp-p 75Ω unbalanced
Video
Signal-to-Noise Ratio: SP:
Horizontal Resolution: Color/Monochrome: more than 230 lines
Head: Normal Mono: 1 stationary head
Hi-Fi Stereo:
Input Level: AUDIO IN Jack (Phono type) - 10dBV 50kΩ unbalanced
Output Level: AUDIO OUT Jack (Phono type) - 8dBV 1kΩ unbalanced
Frequency Response: Normal Mono: SP: 100Hz ~ 8kHz
VCR
Audio
Signal-to-Noise Ratio: Normal Mono: SP:
Wow and Flutter: Normal Mono: SP:
Hi-Fi Stereo:
Broadcast Channels:
Tuner
CATV Channels:
SPECIFICATION
more than 43dB
LP/SLP: more than 41dB
2 rotary heads
LP: 100Hz ~ 6kHz
SLP: 100Hz ~ 5kHz
Hi-Fi Stereo: SP/LP/SLP: 20Hz ~ 20kHz
more than 42dB
LP/SLP:
more than 40dB
Hi-Fi Stereo: SP/LP/SLP: more than 60dB
Less than 0.2% WRMS
LP:
Less than 0.3% WRMS
SLP: Less than 0.4% WRMS
Less than 0.015% WRMS
VHF 2 ~ 13, UHF 14 ~ 69
Midband A through I (14 ~ 22)
R
ITEM
CATV Channels:
Tuner
VCR
SP: 1-5/16 i.p.s (33.35mm/sec), LP: 21/32 i.p.s (16.67mm/sec),
Tape
SLP: 7/16 i.p.s (11.12mm/sec)
Speed
Record/Playback Time: 8 Hrs with 160min. type tape used in SLP mode
FF/REW Time: Less than 5min. (120min. type tape)
Tape
Tape width 1/2" (12.7mm) high density tape
Format
20 inch measured diagonal 90° deflection
DISPLAY
Tube
Source: 120V AC ± 10%, 60Hz ± 0.5%
Power
Consumption: Approx. 110 watts (power on), Approx. 7 watts (power off)
Television
EIA Standard (525 lines, 60 fields) NTSC Color Signal
System
GENERAL
Operating
41°F(5°C) ~ 104°F(40°C) (Temperature)
Condition
10% ~ 75% (Humidity)
Dimension
21-1/8"(536mm) (W) X 21-3/16"(538mm) (H) X 19-1/16"(484mm) (D)
Approx. 54.0 lbs (24.5 kg)
Weight
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
© 1996 Matsushita-Kotobuki Electronics Industries LTD.
All rights reserved. Unauthorized copying and distribution
is a violation of law.
-1-
ORDER NO. MKS9603M316
B6
Combination-VCR
PV-M2066
SPECIFICATION
Superband J through W (23 ~ 36)
Hyperband AA ~ EEE (37 ~ 64)
Lowband A-5 ~ A-1 (95 ~ 99)
Special CATV channel 5A (01)
Ultraband 65 ~ 94, 100 ~ 125
Printed in Japan
Advertisement
Related Manuals for Panasonic OmniVision PV-M2066
Summary of Contents for Panasonic OmniVision PV-M2066
-
Page 1: Specifications
ORDER NO. MKS9603M316 Combination-VCR PV-M2066 Please use this manual together with the Service Manual for Order No. MKS9602M315 Model No. PV-M2046. SPECIFICATIONS ITEM SPECIFICATION ITEM SPECIFICATION Head: 4 rotary heads helical scanning system CATV Channels: Superband J through W (23 ~ 36) Hyperband AA ~ EEE (37 ~ 64) Input Level: VIDEO IN Jack (Phono type) 1.0 Vp-p 75Ω... - Page 2 WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity should be serviced or repaired only by experienced professional technicians.
- Page 3 IV. SUMMARY B. HELPFUL SERVICE NOTES AND CAUTIONS (Please read) Servicing the VCR Section and the TV Section How to place the Stereo Amp C.B.A.: Support Angle -R 1. Service Position (1) Stereo Amp C.B.A. Screw (S-3) Service Position (1) is used for checking and replacing Mechanical and Electrical parts.
- Page 4 Wire and Lead Position Diagram After servicing, make sure that all wires and leads are placed in their original position. It is important for the best operation of the unit. Anode Cap 45° Degaussing Coil Deflection Yoke Grounding Wire Speaker -R Safety Tab SW Operation I White...
- Page 5 V. ADJUSTMENT PROCEDURES A. MECHANICAL ADJUSTMENT PROCEDURES 1. DISASSEMBLY OF CABINET PARTS DISASSEMBLY FLOWCHART DISASSEMBLY METHOD This flowchart indicates the disassembly steps of the cabinet parts and the P.C. Boards in order to gain access to the item(s) Step to be serviced. When reassembling, perform the step(s) in the /Loc.
- Page 6 1 Back Cover Hole (B) Rear View (S-1) Holes (A) Hole (B) 2 VCR Unit VCR Unit Guide Tabs (A) (S-1) Tabs (B) Fig. D2 Bottom view of VCR Unit Fig. D4 Anode Cap CRT C.B.A. 3 CRT Unit (L-1) P6001 (L-1) P354...
- Page 7 (S-6) (S-11) (S-5) 5 Power Supply 6 Stereo (L-4) Chassis Angle Ass'y Amp C.B.A. (S-3) (S-4) Clamper 7 Top Shield (S-12) Plate Ass'y P4502 (S-3) P801 9 VCR Chassis (S-3) Unit (S-3) (S-3) P1201 Clamper (L-3) Fig. D6 Fig. D8 P201 P202 P204...
- Page 8 3. ADJUSTMENT PROCEDURES (S-9) 11 Cassette Up REPLACEMENT OF UPPER CYLINDER Ass'y UNIT 1. REMOVAL OF UPPER CYLINDER UNIT Work with extreme care when removing or replacing the Upper Cylinder Unit. Do not touch Video Heads during servicing. 1. Remove 2 Screws with Washers (A) and gently lift the (S-10) Upper Cylinder Unit from the shaft, refer to Fig.
- Page 9 2. Tighten 2 Screws with Washers (A) shown in Fig. M4. 3. Clean the Upper Cylinder with a deerskin swab (Head Cleaning Stick) saturated with Ethanol. Note : Upon completion of replacement, perform “TAPE INTERCHANGEABILITY ADJUSTMENT,” Page 2-14, especially “HORIZONTAL POSITION ADJUSTMENT OF A/C HEAD,”...
