Specifications

Video camera recorder
System
Video recording system
Two rotary heads, Helical
scanning, FM system
Audio recording system
Rotary heads, FM system
Video signal
NTSC color, EIA standards
Usable cassette
8 mm video format cassette
(standard 8 mm)
Recording/Playback time
SP mode: 2 hours (P6-120)
LP mode: 4 hours (P6-120)
Fastforward/rewind time
Approx. 5 min. (P6-120)
Image device
CCD (Charge Coupled Device)
Viewfinder
Electronic viewfinder
Black and white
Lens
12x, Combined power zoom
lens, F1.8–2.7
1
Filter diameter 37 mm (1 ⁄
2
inches)
Focal distance
7 5
f = 5.4 – 64.8 mm ( ⁄ – 2 ⁄
32 8
inches)
When converted to a 35mm
still camera
CCD-TRV11: 39 – 468 mm
9 1
(1 ⁄ – 18 ⁄ inches)
16 2
CCD-TRV21: 47 – 564 mm (1
1
– 22 ⁄ inches)
4
Color temperature
Auto
Minimum illumination*
CCD-TRV11: 0.8 lx at F 1.8
(Visible minimum low light
0.4 lx)
CCD-TRV21: 4 lx at F 1.8
Illumination range
CCD-TRV11: 0.8 to 100,000 lx
CCD-TRV21: 4 to 100,000 lx
Recommended illumination
More than 100 lx
* Minimum illumination
expresses the light level a
camcorder requires to
produce a picture. Visible
minimum low light expresses
the light level to produce a
visible signal.
60
LCD screen
2.5 inches measured
diagonally
50.3 x 37.4 mm
1
( 2 x 1 ⁄ inches)
2
On-screen display
TN LCD/TFT active matrix
method
Total dot number
61,380 (279 x 220)
Input and Output connectors
Video output
Phono jack, 1 Vp-p, 75 ,
unbalanced
Audio output
Monaural, Phono jack, 327
mV, (at load impedance 47
k ), impedance less than 2.2
k
RFU DC OUT
Special minijack, DC 5 V
Earphone jack
Mini-jack
LANC control jack
Stereo mini-minijack (ø 2.5
mm)
MIC jack
Minijack, 0.388 mV, low
impedance with 2.5 to 3 V DC
output, impedance 6.8 k (ø
3.5 mm)
7 Speaker
⁄
8
Dynamic-speaker
General
Power requirements
7.5 V (AC power adaptor)
Average power consumption
CCD-TRV11
4.7 W during camera
recording using the LCD
3.6 W during camera
recording using the
viewfinder
CCD-TRV21
5.1 W during camera
recording using the LCD
4.0 W during camera
recording using the
viewfinder
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to +60°C (–4°F to
+140°F)
CCD-TRV11/TRV21 3-856-152-52.E/S
Dimensions (Approx.)
113 x 106 x 210 mm
1 1 3
(4 ⁄ x 4 ⁄ x 8 ⁄ inches) (w/h/
2 4 8
d)
Mass (Approx.)
Excluding the battery pack,
lithium battery, cassette and
shoulder strap
CCD-TRV11: 850g
CCD-TRV21: 860g
Including the battery pack NP-
55, lithium battery CR2025,
cassette P6-120 and shoulder
strap
CCD-TRV11: 1.1kg
CCD-TRV21: 1.1kg
Microphone
Electret condenser microphone,
monaural type
Supplied accessories
See page 6.
AC power adaptor
Power requirements
110 – 240 V AC, 50/60Hz
Power consumption
AC-V15: 18 W
AC-V16: 20 W
AC-V16A: 22 W
Output voltage
DC OUT in operation mode
AC-V15: 7.5 V, 1.6 A
AC-V16/V16A: 7.5 V, 1.8 A
Battery charge terminal
10 V, 1.1 A in charge mode
Application
Sony battery packs NP-55
(supplied), NP-55H, NP-C65,
NP-67, NP-77H, NP-77HD, NP-
98, NP-98D
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Dimensions (Approx.)
5 11
166 x 43 x 75 mm (6 ⁄ x 1 ⁄ x
8 16
3 inches) (w/h/d)
including projecting parts and
controls
Mass (Approx.)
AC-V15/V16: 420 g (15 oz)
AC-V16A: 450 g (16 oz)
Design and specifications are
subject to change without
notice.
