Summary of Contents for Sony VPD-LE100
Page 1
CLEARLY SPECIFYING THE SONY PRODUCT IDENTIFIED ABOVE, AND ENSURING THAT THE BUYER IS WELL INFORMED OF THE HIGH STANDARD OF PERFORMANCE THAT IS TO BE EXPECTED OF A SONY PRODUCT. THE INFORMATION IN THIS DOCUMENT IS CURRENT AS OF JUNE 2002. PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
General Information The purpose of this information is to provide the specification for a product whose primary purpose is the reproduction of video and / or computer graphics information for one or more viewers. This reproduction of this information is to be accomplished via a projection DLP display.
Page 3
720P (60Hz) 1035I (60 Hz) 1080I (50 and 60 Hz) 1080P (24 PsF) VGA Computer Graphics (Modes 1, 2 and 3, 60 - 85 Hz) VESA 800x600 Computer Graphics (56 - 85 Hz) VESA 1024 x 768 Computer Graphics (43 – 85 Hz) VESA 1152 x 864 Computer Graphics (70 –...
Page 4
the device. The device shall be addressable for control over multiple devices from a single remote control. The wired / wireless backlit projector remote control shall operate in the same fashion as the projector control panel, and shall accommodate infrared wireless operation, or operation via a standard mini-plug cable.
Performance Specifications This device shall employ the use of 3 Texas Instruments high-resolution 1.1-inch DMD chips. This device shall provide a light output of 10,000 ANSI lumens, when measured using a 1280 x 1024 native resolution signal. This device shall include a standard power zoom / focus / shift lens, and other lenses shall be available as options for a variety of short-throw and long-throw applications.
Audio L/R on RCA (Phono) Connectors RGB Computer / Component Video (Sync on Green, Composite, or Separate Sync) on a 9 pin (D9) Connector Audio L/R on RCA (Phono) Connectors RGB Computer / Component Video (Sync on Green, Composite, or Separate Sync) on a VGA (HD15) Connector with loop-through Audio L/R on RCA (Phono) Connectors Component Serial Digital Video on a BNC Connector with loop-through...
Safety Compliance Information This device shall be fully compliant with the following standards: UL 1950 cUL 950 FCC Class A IC Class A VCCI Class A JEIDA EN60 950 C-Tick 10.0 Warranty Information This device shall carry a 2-year manufacturer’s warranty, with a 90-day lamp warranty. Authorized servicing dealers of the devices’...
