Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
Compaq 303B PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
EL-MF877-00
Template Revision B
Notes
With a surface greater than 10 sq cm
(Mainboard and power supply board)
All types including standard alkaline and lithium coin
or button style batteries Located on the mainboard
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
located on power supply
system and power supply fan
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
PSG instructions for this template are available at
EL-MF877-01
Quantity
of items
included
in product
2
1
0
0
0
0
up to 8
0
0
2
0
0
0
Page 1
Advertisement
Related Manuals for HP Compaq 303B
Summary of Contents for HP Compaq 303B
- Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
- Page 2 Components, parts and materials containing radioactive substances 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool Size (if applicable)
- Page 3 2 Remove all the cables from PCA Take all the cables off PCA 3 Remove PCI & PCI-E card from the PCA Use screw driver to take off the screw as shown in the photo 3 Take PCI & PCI-E cards off the PCA Release memory socket levers by pulling outward.
- Page 4 4 、Remove HDD from the system Rotate the screw driver to take off the HDD holder 5 take off Front Panel Pull the button up and then take off the front panel 6 Take off ODD Use one hand to pull the steel up , and the same time take off ODD use the other hand EL-MF877-00 Page 4...
- Page 5 7 Take off system FAN Rotate screw driver to loose screw and then take the cooler off PCA 8 Take off CMOS battery Pull the battery holder as shown in the photo, and then the battery will off the PCA EL-MF877-00 Page 5 Template Revision B...
- Page 6 9 Take off PS from the Unit Use screw driver to loose screws and then take the PS off the Unit 10 cut off wire tie 11 open PS EL-MF877-00 Page 6 Template Revision B PSG instructions for this template are available at EL-MF877-01...
- Page 7 12 use screw driver to separate the small PCA from the main board and remove large Capacitors and PSU FAN EL-MF877-00 Page 7 Template Revision B PSG instructions for this template are available at EL-MF877-01...
