Sony SRS-PC41 Operating Instructions

SRS-PC41 3-856-032-21 E(1)
Features
The Sony SRS-PC41 is a compact-size speaker system • The "dynamic sound duct" assures a rich and
with a built-in power amplifier. This system can be powerful bass.
connected to a personal computer, Discman, • Two INPUT jacks enable you to connect two audio
WALKMAN headphone stereo, etc. systems at the same time to the SRS-PC41.
• The magnetically shielded speakers should have • AUDIO OUT jack enables you to connect an
little effect on a TV screen or recorded tapes, etc. additional sub woofer etc. to the SRS-PC41.
when placed close to them.
• IBB (Intelligent Bass Boost) circuit enables you to
WALKMAN is a registered trademark of Sony
obtain powerful bass, regardless of the sound
Corporation.
volume.
• Power output of 3 W + 3 W
Precautions
• Operate the system only on 9 V DC. If the TV picture or monitor display is
For AC operation, use only the supplied AC power
magnetically distorted
adaptor. Do not use any other AC power adaptor.
Although this system is magnetically shielded, there
• After operating the system with the AC power
may be cases that the picture on some TV sets/
adaptor, disconnect the AC power adaptor from the
personal computer sets may become magnetically
wall outlet if the system is not to be used for an
distorted. In such a case, turn off the power of the TV
extended period of time. The POWER switch on
set/personal computer set once, and after 15 to 30
the system does not turn the AC power adaptor off.
minutes turn it on again. For the personal computer
• If the system is not to be used for a long period of
set, take the appropriate measures such as data
time or is to be operated extensively on AC power,
storage before turning it off.
remove the batteries to avoid damage caused by
battery leakage and corrosion. When there seems to be no improve-
• Do not open the cabinet. Refer servicing to
ment,
qualified personnel only.
locate the system further away from the TV set/
• Do not leave the system in a location near heat
personal computer set. Furthermore, be sure not to
sources, or in a place subject to direct sunlight,
place objects in which magnets are attached or used
excessive dust, moisture, rain or mechanical shock.
near the TV set/personal computer set, such as audio
• Should any solid object or liquid fall into the
racks, TV stands, toys etc. These may cause magnetic
system, remove the batteries and have the system
distortion to the picture due to their interaction with
checked by qualified personnel before operating it
the system.
any further.
If you have any questions or problems concerning
• Do not use alcohol, benzine or thinner to clean the
your system that are not covered in this manual,
cabinet.
please consult your nearest Sony dealer.
• Although this system is magnetically shielded, do
not leave recorded tapes, watches, personal credit
cards or floppy disks using magnetic coding in
front of the system for an extended period of time.
Specifications
Amplifier section Battery life (at 5 mW + 5 mW output)
Power output 3 W + 3 W
Approx. 17 hours with Sony batteries
Input impedance 4.7 kilohms (at 1 kHz)
R6P (SR),
Approx. 35 hours with Sony alkaline
Speaker section
batteries LR6 (SG)
System Full-range bass reflex type
Dimensions Approx. 95 205
Speaker unit Full-range (magnetically shielded):
(3
ø 65 mm (2 5 / in.)
Mass Left speaker:
8
Nominal impedance
6 ohms (OFF/DIRECT)
Right speaker: Approx. 500 g
Rated input power
3 W (OFF/DIRECT)
Supplied accessory
General
AC power adaptor (1)
Power requirement
Optional accessories
DC 9 V, six size AA (R6) batteries (left
Plug adaptor PC-236MS, PC-234S
speaker only)
Connecting cord RK-G138, RK-G136HG
Inputs Left speaker: Input cord (2 m) with
Sub woofer SA-W101
stereo mini plug
(INPUT 1)
Design and specifications are subject to change without
Stereo mini jack
notice.
(INPUT 2)
Right speaker: Input cord (1.5 m) with
monaural mini plug
Output Stereo mini jack (AUDIO OUT)
110 mm (w/h/d)
3 / 8 1 / 4 3 / in.)
4 8 8
Approx. 580 g
(1 lb. 4 oz.)
Operating Instructions
(1 lb. 2 oz.) not incl.
batteries Before operating the unit, please read this manual
thoroughly and retain it for future reference.
Owner's Record
The model number is located on the front of the
unit and the serial number is located inside the
battery compartment. Record the serial number in
the space provided below. Refer to them
whenever you call upon your Sony dealer
regarding this product.
Model No. SRS-PC41
Serial No.___________________
3-856-032-21 (1)
Active Speaker
System
SRS-PC41
Sony Corporation © 1995
Printed in Japan
WARNING
To prevent fire or shock hazard, do not expose
the unit to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.
SRS-PC41 3-856-032-21 E(1)
