ABB devices All packaging materials and devices from ABB bear the markings and test seals for proper disposal. Always dispose of the packing materials, electronic devices and their components via authorized collection facilities or disposal companies.
® ABB Welcome Terminal description Front overview Fig. 1 Front overview Function Light sensor Infrared LED (total of six) Indicating LED (total of three: ring, call and door open) Speaker and microphone integration Round pushbutton *If round pushbutton with ID card reader, see Chapter 5.3 for details.
® ABB Welcome Terminal description Fig. 2 Terminal description Functions Connector for device software update Rotary switch to set the address of outdoor station (1-9) Set feedback tone of pushbutton ON/OFF Set general call to all indoor stations in one family GC=ON, press button 1 and button 2, all indoor stations ring For details, see Chapter 5.2.
® ABB Welcome Round pushbutton with ID card reader Programming Function Command Indicating LED for door open Create admin card Swipe card 1x Green Enter settings Swipe admin card 1x Orange The system will designate the first card swiped within 60 seconds after powering up the system to be the admin card.
® ABB Welcome Technical data Designation Value Operating temperature -40 °F to +158 °F Protection (cover frame IP 54 assembled) Power supply, door opener 12 V DC, 250 mA (Lock-GND) Floating output, door opener 30 V AC or DC, 1 A...
® ABB Welcome Mounting and installation Warning Electric voltage! Direct or indirect contact with live components can cause dangerous currents to flow through the body, which may result in electric shock, burns or even death. Always disconnect the main power supply prior to installation and/or disassembly.
® ABB Welcome General installation instructions Terminate all branches of the wiring system via a connected bus device (e.g., indoor station, outdoor station, system device). Do not install the system controller directly next to the bell transformer or other power supplies (to avoid interference).
