Display; Sound; Language; Call Settings - D-Link DWR-720/PW User Manual

‐ Security: Configuration settings for Set up SIM card lock and Screen lock
‐ Fast dialling: Used to configure fast dial keys when you press and hold a
number key on the home screen
‐ Bluetooth: Enable/Disable Bluetooth feature, Scan & Pair other Bluetooth
devices to Phone
‐ Factory data reset: Here you can reset and erase all data on the phone.
‐ Phone Info: Here you can view Status, Model, Versions and Build number for
the Phone
Under the Display setting, you have the option to:
‐ Brightness: You can adjust the light intensity for the background light that
illuminates the screen. Use the left or right key to adjust the brightness level
from dim to bright
‐ Display Dim: If no key is pressed with a set period, the background light will
dim automatically. This is to protect the LCD screen and save battery life. The
default time is set to 5 minutes.
Additional Feature "Return to Home Page" can be enabled to return the screen
to the Home Page when the screen dims. By default this feature is disabled.
‐ Font size: You can set display font size: Small/Normal/Large/Extra‐large
‐ Interface style: This will adjust the layout of the Menu Screen, you can select
between Default/Grid/Big Grid
Return to Home Page setting
This feature is used to return the user to the Home Page when the phone display dims. When enabled,
the phone will automatically return the current screen to the Home Page when the display dims. If
disabled, the screen will remain on the same page when the display dims.
To Enable:
1. Select Display Dim and set the time in which you wish for the display to dim, and press the left soft
key to confirm.
2. A pop‐up message will be displayed. Confirm by selecting [OK] and the left soft key to confirm
3. Choose [Enable] and press the left soft key to confirm.
Note: During a phone call, the screen will return to the Home Page when the screen dims. To return to
the call screen, press the green dial button.
Back to Table of Contents
10.1 Display
To Disable:
1. Select Display Dim and set the time in which you wish for the display to dim, and press the left soft
key to confirm.
2. A pop‐up message will be displayed. Confirm by selecting [OK] and the left soft key to confirm
3. Choose [Disable] and press the left soft key to confirm.
You can set your phone language display to English, Español, Português
Voicemail: You will need to setup your voicemail number before you can access this feature, contact your mobile
service provider for the settings. Select [Service] and choose [My carrier], then select [Setup] to enter the
[Voicemail number] with the [left soft key]. Once the correct number has been entered, press down and select
[OK] or [Cancel] to exit.
21
Back to Table of Contents
10.2 Sound
Under the Sound setting, you have the option to:
‐ Volume: Adjust the volume for Music, Ringtone & Notifications, Alarms. Press
left or right to adjust the volume and up or down to change the selection. Once
done, scroll down to the bottom and select [OK]
‐ Phone ringtone: You can change the ringtone here, press the [left soft key] to
confirm
‐ Default notification sound: You can change the notification sound for alerts
here
‐ Touch sounds: You can change the keypad tone volume here, select between
Close / low / medium / high (Volume Off / soft / normal / loud)
10.3 Language
10.4 Call settings
Under the Call settings, you have the option to:
‐ Voice Call: You can set Voicemail, Call forwarding, Call barring, Additional
settings
‐ Fixed Dialling Numbers (FDN): Numbers can be added to the FDN list, and
when activated, FDN restricts outgoing calls to only those numbers listed, or to
numbers with certain prefixes
‐ Minute reminder: Enable/Disable reminder at 50s of every minute
‐ Delay dial: Delay dial is the time or delay that occurs from the time a number
has been dialled until the caller or called party hears ringing. Time can be set to
between 0~7 seconds
‐ Call Ended Toast Dial: After the call ends, a notification will show on screen
about the duration of your call.
The default is 3 seconds, and can be set to a max of 20 seconds or disabled.
Voice Call settings
22
