Page 2
The model and the serial numbers are located at the bottom of the unit. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. SPP-ID975 Serial No. ________________...
To reduce the risk of fire or injury to persons by battery, read and follow these instructions. 1. Use only the following type and size battery pack: Sony BP-T23. 2. Do not dispose of the battery pack in a fire. The cell may explode. Check with local codes for possible special disposal instructions.
Page 4
– Consult the dealer or an experienced radio/ TV technician for help. Note on Warranty Be sure to save the receipt and attach it to your warranty card when having your equipment repaired at an authorized Sony service station.
Table of contents Getting Started 6 Read this first 7 Step 1: Checking the package contents 8 Step 2: Setting up the base phone 11 Step 3: Preparing the battery pack 14 Step 4: Entering the area code 17 Identifying the parts Basics 20 Making calls Redialing...
Getting Started Read this first Before you use your phone, you must first set it up. Here’s a quick way to set up your phone: Steps 1, 2, 3 and 4. Step 1 Handset Getting Started (page 7) First, unpack the phone and the supplied accessories.
Step 1 Checking the package contents Make sure you have received the following items in the package. If anything is missing, contact your local Sony dealer. AC power adaptor (AC-T122) Telephone line cords (2) Base phone Wall bracket for base phone...
Step 2 Setting up the base phone Do the following steps: • Choose the best location • Connect the base phone • Choose the dialing mode Choose the best location Where you place the base phone affects the reception quality of the handset.
Page 9
Connect the base phone If you want to hang the base phone on the wall, see page 51. Hook the cord. To an AC outlet AC power adaptor (supplied AC-T122) Telephone line cord (supplied) To the telephone outlet To DC IN 9V To LINE Connect the telephone line cord to the LINE jack and to a...
Step 2: Setting up the base phone (continued) Notes • Use only the supplied AC-T122 AC power adaptor. Do not use any other AC power adaptor. • Connect the AC power adaptor to a continuous power supply. • Place the base phone close to the AC outlet so that you can unplug the AC power adaptor easily.
Step 3 Preparing the battery pack Charge the battery pack for more than 12 hours before you start using your phone. CHARGE lamp Slide open the battery compartment lid of the handset. Insert the battery pack (with contacts facing down) into the BP-T23 battery compartment.
Page 12
If the battery lasts only a few minutes even after 12 hours of charging, the usable life of the battery has expired and needs replacement. Contact your local Sony authorized dealer or service center, and ask for a Sony BP-T23 rechargeable battery pack.
Page 13
Handset spare battery usage As only one battery pack is supplied with this unit, it is necessary to purchase an additional battery pack (optional) for use as a handset spare battery pack. BP-T23 SPARE BATTERY lamp Open the battery compartment lid of the base phone.
Step 4 Entering the area code When you use this phone for the first time, or move to an area that has a different area code, you must enter your home area code. Otherwise, you cannot use some functions of this phone and the Caller ID functions. This is also necessary because the phone must be able to select an area code to properly dial call from the Caller ID list.
Page 15
Notes • If the home area code is already entered, it appears on the display in step 4. To enter a different home area code, see “To change the home area code” below. • Do not allow more than 20 seconds to elapse between each step of the procedure.
Page 16
Step 4: Entering the area code (continued) Press Jog Dial. ”ENTER AREA CODE“ appears on the display. Enter three digits of the local area code using the dialing keys. Press (PGM). You will hear a long confirmation beep. Notes • If the local area code is already entered, it appears on the display in step 5. To enter a different local area code, see “To change the local area code”...
Identifying the parts Refer to the pages indicated in parentheses for details. Handset 1 Antenna 2 Speaker 3 Jog dial (p. 14, 29, 41) 4 TALK button (p. 20, 24) Lets you make or receive a call. 5 INTERCOM button (p. 36) Lets you talk by using the base phone and handset.
Page 18
Identifying the parts (continued) Base Phone 1 Display window (p. 20, 26) 2 LINE lamp (p. 20, 24) Lights when the cordless handset is in use. 3 MESSAGES lamp (p. 49) Flashes when you have messages. 4 NEW CALL lamp (p. 41) Flashes when there is a “NEW”...
Page 19
qh REDIAL/PAUSE button (p. 23, 27) Redials the last number called/ inserts a pause in the dialing sequence. qj SPEED DIAL button (p. 26) Automatically dials the numbers programmed. qk DIAL MODE switch (p. 10) Selects pulse or tone dialing. ql RINGER LEVEL switch (p.
Basics Making calls (HOLD) (*TONE) (MUTING) Additional tasks Adjust the handset volume Put a call on hold Mute your voice Switch to tone dialing temporarily Basics Pick up the handset from the base phone. Press (TALK) and wait until “TALK” appears on the display. The display also shows the operation duration in hours, minutes and seconds.
Page 21
Notes • When you increase the sound volume, in some cases the back ground noise may be increased as well. You should adjust the volume accordingly. • If your conversation is muted and “CHANNEL SEARCHING” appears on the display, move closer to the base phone; otherwise, the call will be disconnected after one minute.
Page 22
Making calls (continued) Making calls through the speakerphone Press (SPEAKERPHONE) on the base phone. “SPEAKERPHONE” appears on the display and the display also shows the operation duration in hours, minutes and seconds. The SPEAKERPHONE lamp lights up. Dial the phone number. To adjust the speaker volume, press (VOLUME)(+) or (--).
Redialing Press (TALK) and wait until “TALK” appears on the display. The LINE lamp on the base phone lights up. If you’re at the base phone, press (SPEAKERPHONE). “SPEAKERPHONE” appears on the display and the SPEAKERPHONE lamp lights up. Press (REDIAL) to redial the last number dialed. If you’re at the base phone, press (REDIAL/PAUSE).
Receiving calls (CALL WAITING/ FLASH) (HOLD) (MUTING) Additional tasks Adjust the handset volume Put a call on hold Mute your voice Switch to another call (“call waiting” service*) Turn on/off the ringer of the handset * You need to subscribe to the service from your telephone company. Note If another call comes in by “call waiting”...
Page 25
If you have subscribed to the Caller ID service; • the caller’s number and/or name appears on the display when you receive a call (see page 40) or when another call comes in by “call waiting” service. • the ringer sound changes to a higher tone if the call matches the number stored on speed dialing keys or in the Phone Directory (memory match function;...
“space”, press (VOLUME)(+) to move the cursor to the right. Example: to enter “SONY”, press (7) four times (S), press (6) three times (O), press (VOLUME)(+) to move the cursor, press (6) twice (N), and press...
Page 27
Before entering a phone number in step 6 above, do as follows: Enter the outside line access digit (e.g., 9). Press (REDIAL/PAUSE). To change a stored number Store a new number, as described previously. SONY 1234567 1234567890123456 continued Telephone Features...
Speed dialing (continued) Making calls with speed dialing Press (SPEAKERPHONE). Press (SPEED DIAL). Enter the desired speed dialing number ( The phone number stored as the speed dialing number will be dialed. To check the phone number before speed dialing When not making a call with the base phone, press (SPEED DIAL) and then one of the dialing keys ((0) to (9)).
“space”, turn Jog Dial up to move the cursor to the right. Example: to enter “SONY”, press (7) four times (S), press (6) three times (O), turn Jog Dial up to move the cursor, press (6) twice (N), and press (9) three times (Y).
To store a number to be dialed via Private Branch Exchange (PBX) Before entering a phone number in step 5 above, do as follows: Enter the outside line access digit (e.g., 9). Press (PAUSE). Telephone Features (PGM) in steps 4 and 6. SONY 1234567 1234567890123456...
When the phone number of 17 digits or more has been entered, “–” is displayed next to 15th digit and then the all digits are displayed in two lines after about two seconds. SONY 1234567 DIAL EDIT ERASE 1234567...
Turn Jog Dial up to make “YES” flash, then press Jog Dial. You hear a long confirmation beep and the memory location is erased. Making calls from the Phone Directory Turn Press Telephone Features SONY 1234567 DIAL EDIT ERASE 1234567 ERASE NO YES 1234567 Press Jog Dial.
Page 33
• Alphabetical order: ABC...XYZ y symbols y * y # y 0 - 9 • Initial character: To search for “SONY” for example, press (7) and then turn Jog Dial to search through the names starting with P, Q, R, S or 7.
Setting the ringer type You can select a ringer type of the handset from four type. Turn Press Turning off the ringer of the handset Perform steps 1 to 3 above. Press (0). You will hear a confirmation beep. Press (OFF). When “RINGER”...
Switching the phones during a call You can easily switch between the handset and speakerphone on the base phone without disconnecting the call. To switch from the base phone to the handset LINE lamp SPEAKERPHONE lamp (SPEAKERPHONE) To switch from the handset to the base phone (TALK) Tips •...
Talking between the phones (Intercom) You can converse using the base phone and the handset. You can start the intercom from either phone. (TALK) (INTERCOM) (SPEAKERPHONE) Telephone Features To talk from the handset to the base phone Press (INTERCOM) on the handset. After the base phone rings twice, you will be connected automatically.
Page 37
Notes • If there’s an incoming call while on the intercom, only the base phone rings. To answer the call, press (INTERCOM) on the base phone or handset. The intercom is canceled and you can talk to the outside caller. •...
Transferring a call You can transfer a call between the handset and base phone without disconnecting the call. To transfer from the base phone to the handset (SPEAKERPHONE) (TALK) Tips • You can receive an intercom call on the handset even when “RINGER” is set to “RINGER OFF”.
To transfer from the handset to the base phone (TALK) (SPEAKERPHONE) You can receive an intercom call on the base phone even when the RINGER LEVEL switch on the base phone is set to OFF. The base phone will ring at a low level.
Caller ID Features Understanding the Caller ID service Caller ID allows the caller’s phone number to be shown on the display before the call is answered. In order to use this feature, you must first subscribe to the Caller ID service. The name of this service may vary depending on your telephone company.
Looking at the Caller ID list The phone stores the data of the last 20 calls received including “OUT OF AREA” and “PRIVATE” calls. It keeps track of all calls received; even if they were not answered. Viewing the Caller ID list You can look through the Caller ID list to check the phone number and/or name of the calls received on the handset’s display.
Looking at the Caller ID list (continued) About the “*” mark SMITH JOHN 1-201-123-4567 Erasing data from the Caller ID list Old data will be erased automatically when a 21st call comes in, but you can also manually erase unnecessary data one by one or erase the entire list.
Page 43
To erase the entire list at once Display any Caller ID data. Press Jog Dial. Turn Jog Dial up to make “ERASE” flash and press Jog Dial. Turn Jog Dial up to make “ALL” flash, then press Jog Dial. Turn Jog Dial up to make “YES” flash, then press Jog Dial.
Using the Caller ID list By using the Caller ID list, you can call back a phone number from the Caller ID list easily, or store numbers from the Caller ID list into the Phone Directory. Calling back a number from the Caller ID list Turn Press Notes...
Storing a number of the Caller ID list into the Phone Directory Display the name and phone number you want to store from the Caller ID list (see page 41). Confirm the number and press Jog Dial. Turn Jog Dial up to make “PGM” flash and press Jog Dial.
Using the Caller ID list (continued) To change the number of digits of the phone number If the number of digits of the phone number in the Caller ID list is different from the actual phone number, you need to adjust the number of digits of the phone number to call back or store into the Phone Directory.
Page 47
When the local area code matches SMITH JOHN 201-123-4567 SMITH JOHN 1-201-123-4567 Continue the operation to call or store the phone number with the correct number of digits (pages 44 and 45). Notes • You need to adjust the number of digits each time you call back from the Caller ID list as the changes to the Caller ID data is not stored in memory.
Using “Caller ID with call waiting” service This telephone is compatible with the “Caller ID with call waiting” service. Make sure that your telephone company offers this service. Like the basic Caller ID service, you need to subscribe to “Caller ID with call waiting”...
Using visual message waiting service If you subscribe to your telephone company’s message service which includes this feature, the display will show that you have messages waiting to be retrieved. MESSAGES lamp Note You cannot use this feature, if you have not subscribed to your telephone company’s message service.
Page 50
Using visual message waiting service (continued) If you move or change your telephone company Message waiting signals are sent in one of two ways: FSK signaling or “stutter” signaling (Your telephone company can provide you with more information about your service). The first time this phone receives a voice mail message, it will set itself to the FSK service and will lock out the stutter service if your telephone company is in FSK service.
Additional Information Mounting the base phone on a wall Hang-up tab AC power adaptor cord Wall bracket To remove the wall bracket, press the lower tabs. Raise the hang-up tab. Plug the telephone line cord to the LINE jack and the AC power adaptor to the DC IN 9V jack, and hook the cords.
• If the charge terminals of the base phone and handset are soiled, wipe them with a soft cloth. If you have any questions or problems concerning your phone, please consult your nearest Sony dealer. Additional Information For the customers in the USA RECYCLING NICKEL-CADMIUM BATTERIES Nickel-Cadmium batteries are recyclable.
Troubleshooting If you’ve experienced any of the following difficulties while using your phone, use this troubleshooting guide to help you remedy the problem. Should any problem persist, consult your nearest Sony dealer. Symptom You hear five short error beeps when you press (TALK).
Page 54
Troubleshooting (continued) Symptom You hear interference during conversation. Your conversation is muted and “CHANNEL SEARCHING” appear on the display. You hear a beep every three seconds and i and “BATTERY LOW” appears on the display. You hear five short error beeps and cannot store a number on a speed dialing key or in the Phone Directory.
Page 55
Symptom The caller’s name and/or phone number does not appear on the display during call waiting. You cannot dial the number from the Caller ID list. The memory match function does not work. You cannot use visual massage waiting service. The CHARGE lamp does not light up when you place the handset to charge.
Specifications General Frequency band 902 - 928 MHz Operating channel 30 channels Dial signal Tone, 10 PPS (pulse) selectable Supplied accessories See page 7. Handset Power source Rechargeable battery pack BP-T23 Battery charging time Approx. 12 hours Battery life Standby: Approx. 7 days Talk: Approx.
Index Adjusting volume handset volume 20, 24 speaker volume 22, 25 Area code 14 Battery pack charging 11 duration 12 Call waiting service 24, 48 Caller ID 40 Caller ID list 41 calling back 44 memory match function 40 storing in Phone Directory 45 Caller ID with call waiting 48...
Page 58
Anote el número de serie en el espacio que se proporciona a continuación. Refiérase a estos números cada vez que se comunique con su distribuidor Sony con respecto al producto. Modelo N SPP-ID975 Serie N...
Page 59
1. Sólo debe utilizar un paquete de pilas del siguiente tipo y tamaño: Sony BP-T23. 2. No deseche el paquete de pilas en una hoguera ya que la pila puede explotar.
Page 60
7. Si experimenta algún problema con este equipo (SPP-ID975), con respecto a la reparación o a la información sobre la garantía, póngase en contacto con Sony Direct Response Center: Tel 1-800-222-7669 (Inglés solamente). Si el equipo causa problemas en la línea, la compañía telefónica puede solicitarle que desconecte el equipo hasta que se resuelva el problema.
Page 61
Índice Preparativos Lea esto en primer lugar Paso 1: Comprobación del contenido del paquete Paso 2: Instalación del teléfono base 11 Paso 3: Preparación de la batería 14 Paso 4: Introducción del código de área 17 Identificación de las partes Operaciones básicas 20 Realización de llamadas Repetición de la marcación...
Preparativos Lea esto en primer lugar Antes de utilizar su teléfono, tendrá que instalarlo. A continuación se indica la forma rápida de hacerlo: Pasos 1, 2, 3, y 4. Paso 1 Microteléfono Preparativos (página 7) En primer lugar, desembale el teléfono y los accesorios suministrados.
Page 63
Paso 1 Comprobación del contenido del paquete Compruebe si con el paquete ha recibido los elementos siguientes. Si falta algo, póngase en contacto con su proveedor Sony. Adaptador de alimentación de CA (AC-T122) Cables de línea telefónica (2) Teléfono base Soporte mural para el teléfono base...
Page 64
Paso 2 Instalación del teléfono base Realice los pasos siguientes: • Elección del mejor lugar • Conexión del teléfono base • Elección del modo de marcación Elección del mejor lugar El lugar en el que coloque el teléfono base afectará la calidad de la recepción del microteléfono.
Page 65
Conexión del teléfono base Si desea colgar el teléfono base de una pared, consulte la página 51. Enganche el cable. A un tomacorriente de CA Adaptador de alimentación de CA (AC-T122 suministrado) Cable de línea telefónica (suministrado) A la toma telefónica A DC IN 9V A LINE...
Page 66
Paso 2: Instalación del teléfono base (continuación) Notas • Utilice solamente el adaptador de alimentación de CA AC-T122 suministrado. No utilice ningún otro adaptador de alimentación de CA. • Conecte el adaptador de alimentación de CA a un tomacorriente que suministre continuamente alimentación.
Page 67
Paso 3 Preparación de la batería Antes de utilizar su teléfono, cargue la batería durante más de 12 horas. Lámpara CHARGE Deslice y abra la tapa del compartimiento de la batería del microteléfono. Inserte la batería (con los contactos hacia abajo) en el BP-T23 compartimiento para la misma.
Page 68
Si la batería dura solamente algunos minutos incluso después de 12 horas de carga, la duración útil de la misma habrá expirado, y habrá que reemplazarla. Póngase en contacto con su proveedor o con un centro de reparaciones autorizado por Sony, y solicite una nueva batería BP-T23 Sony. Nota La duración de la batería puede variar dependiendo de las condiciones de...
Page 69
Utilización de una batería de repuesto para el microteléfono Como con esta unidad solamente se suministra una batería, tendrá que adquirir otra (opcional) para utilizarla de repuesto para el microteléfono. BP-T23 Lámpara SPARE BATTERY Abra la tapa del compartimiento de la batería del teléfono base. Inserte la batería (con los contactos hacia abajo) en el compartimiento para la misma.
Page 70
Paso 4 Introducción del código de área Antes de utilizar este teléfono por primera vez, o cuando se traslade a un lugar con código de área diferente, tendrá que introducir el código de su área. De lo contrario no podría utilizar ciertas funciones de este teléfono ni las de identificación de demandantes.
Page 71
Notas • Si el código de área inicial ya está introducido, aparecerá en el visualizador en el paso 4. Para introducir un código de área diferente, consulte “Para cambiar el código de área inicial” indicado a continuación. • No deje que transcurran más de 20 segundos entre cada paso del procedimiento. Sugerencias •...
Page 72
Paso 2: Introducción del código de área (continuación) Presione el mando de lanzadera. En el visualizador aparecerá “ENTER AREA CODE”. Introduzca los tres dígitos del código de área local utilizando las teclas de marcación. Presione (PGM). Usted oirá un pitido largo de confirmación. Notas •...
Page 73
Identificación de las partes Con respecto a los detalles, consulte las páginas indicadas entre paréntesis. Microteléfono 1 Antena 2 Altavoz 3 Mando de lanzadera (p. 14, 29, 41) 4 Botón de conversación (TALK) (p. 20, 24) Presiónelo para realizar o recibir una llamada.
Page 74
Identificación de las partes (continúa) Teléfono base 1 Visualizador (p. 20, 26) 2 Lámpara de línea (LINE) (p. 20, 24) Permanecerá encendida mientras esté utilizando el microteléfono inalámbrico. 3 Lámpara de mensajes (MESSAGES) (p. 49) Parpadeará cuando reciba mensajes. 4 Lámpara de nueva llamada (NEW CALL) (p.
Page 75
qh Botón de repetición de marcación/pausa (REDIAL/PAUSE) (p. 23, 27) Presiónelo para volver a marcar el último número llamado/insertar una pausa en la secuencia de marcación. qj Botón de marcación instantánea (SPEED DIAL) (p. 26) Presiónelo para marcar automáticamente números almacenados.
Page 76
Operaciones básicas Realización de llamadas (HOLD) (*TONE) (MUTING) Tareas adicionales Para Ajustar el volumen del microteléfono Poner una llamada en retención Silenciar su voz Cambiar temporalmente a marcación por tonos Operaciones básicas Tome el microteléfono del teléfono base. Presione (TALK) y espere hasta que en el visualizador aparezca “TALK”.
Page 77
Notas • Si aumenta el volumen del sonido, en algunos casos es posible que aumente también el ruido de fondo. Ajuste adecuadamente el volumen. • Si la conversación se silencia y en el visualizador aparece “CHANNEL SEARCHING”, acérquese al teléfono base. De lo contrario, la llamada se desconectaría después de 1 minuto.
Page 78
Realización de llamadas (continuación) Realización de llamadas a través del interfono Presione (SPEAKERPHONE) del teléfono base. En el visualizador aparecerá “SPEAKERPHONE” y también mostrará el tiempo de operación en horas, minutos, y segundos. La lámpara SPEAKERPHONE se encenderá. Marque el número de teléfono. Para ajustar el volumen del altavoz, presione (VOLUME)(+) o (--).
Page 79
Repetición de la marcación Presione (TALK) y espere hasta que en el visualizador aparezca “TALK”. La lámpara LINE del teléfono base se encenderá. Si se encuentra en el teléfono base, presione (SPEAKERPHONE). En el visualizador aparecerá “SPEAKERPHONE” y se encenderá la lámpara SPEAKERPHONE. Para repetir la marcación del último número marcado, presione (REDIAL).
Page 80
Recepción de llamadas (CALL WAITING/ FLASH) (HOLD) (MUTING) Tareas adicionales Para Ajustar el volumen del microteléfono Poner una llamada en retención Silenciar su voz Cambiar a otra llamada (servicio de “llamada en espera”*) Activar/desactivar el generador de llamada * Usted tendrá que subscribirse a este servicio poniéndose en contacto con la compañía telefónica.
Page 81
Si está subscrito al servicio de identificación del demandante; • el número y/o el nombre del demandante aparecerá en el visualizador cuando reciba una llamada (consulte la página 40) o cuando entre otra llamada con el servicio de “llamada en espera”. •...
Page 82
T t U t V t 8 W t X t Y t Z t 9 & t ’ t , t – t . t # Funciones del teléfono Ejemplo: para almacenar “SONY” “123-4567”. Presione (PGM). En el visualizador aparecerá “PROGRAM”.
Page 83
Antes de introducir el número de teléfono en el paso 6 anteriores, realice lo siguiente: Introduzca el dígito de acceso a la línea exterior (p. ej., 9). Presione (REDIAL/PAUSE). Para cambiar un número almacenado Almacene otro nuevo, como se ha descrito anteriormente. SONY 1234567 1234567890123456 continúa Funciones del teléfono...
Page 84
Marcación instantánea (continuación) Realización de llamadas con la marcación instantánea Presione (SPEAKERPHONE). Presione (SPEED DIAL). Introduzca el número de marcación instantánea deseado ((0) a (9)). El número de teléfono almacenado como número de marcación instantánea se marcará. Para comprobar el número de teléfono antes de la marcación instantánea Antes de realizar una llamada con el teléfono base, presione (SPEED DIAL) y después una de las teclas de marcación ((0) a (9)).
Page 85
T t U t V t 8 W t X t Y t Z t 9 & t ’ t , t – t . t # Ejemplo: para almacenar “SONY” “123-4567”. Presione (PGM). (No presione nunca (TALK).) DIRECTORY AREA RINGER Si “DIRECTORY”...
Page 86
Antes de introducir el número de teléfono en el paso 5 anterior, realice lo siguiente: Introduzca el dígito de acceso a la línea exterior (p. ej., 9). Presione (PAUSE). Funciones del teléfono número, oirá cinco pitidos cortos de error (PGM) en los pasos SONY 1234567 1234567890123456...
Page 87
Sugerencia Si introduce un número de teléfono de 17 o más dígitos, después del 15.º se visualizará “ –”, y los demás se visualizarán en dos líneas después de aproximadamente dos segundos. SONY 1234567 DIAL EDIT ERASE 1234567 1234567...
Page 88
Usted oirá un pitido largo de confirmación, y la ubicación de la memoria se borrará. Realización de llamadas desde el directorio telefónico Gire Presione Funciones del teléfono SONY 1234567 DIAL EDIT ERASE 1234567 ERASE NO YES 1234567 Presione el mando de lanzadera.
Page 89
• Orden alfabético: ABC...XYZ y símbolos y * y # y 0 - 9 • Carácter inicial: Para buscar “SONY” por ejemplo, presione (7) y después gire el mando de lanzadera para buscar a través de los nombres que comiencen por P, Q, R, S, o 7.
Page 90
Ajuste del tipo de generador de llamada Usted podrá seleccionar entre cuatro tipos de generador de llamada del microteléfono. Gire Presione Desactivación del generador de llamada del microteléfono Realice los pasos 1 a 3 anteriores. Presione (0). Usted oirá un pitido de confirmación. Presione (OFF).
Page 91
Cambio de teléfono durante una llamada Usted podrá cambiar fácilmente entre el microteléfono y el interfono del teléfono base sin desconectar la llamada. Para cambiar del teléfono base al microteléfono Lámpara LINE Lámpara SPEAKERPHONE (SPEAKERPHONE) Para cambiar del microteléfono al teléfono base (TALK) Sugerencias •...
Page 92
Conversación entre los teléfonos (intercomunicación) Usted podrá conversar utilizando el teléfono base y el microteléfono. La intercomunicación podrá iniciarse desde cualquier teléfono. (TALK) (INTERCOM) (SPEAKERPHONE) Funciones del teléfono Para hablar del microteléfono al teléfono base Presione (INTERCOM) del microteléfono. Después de que el teléfono haya sonado (OFF) dos veces, usted se conectará...
Page 93
Notas • Si entra una llamada durante la intercomunicación, solamente sonará el teléfono base. Para responder a la llamada, presione (INTERCOM) del teléfono base o del microteléfono. La intercomunicación se cancelará y usted podrá hablar con la persona del exterior. •...
Transferencia de una llamada Usted podrá transferir una llamada entre el microteléfono y el teléfono base sin desconectarla. Para transferir del teléfono base al microteléfono (SPEAKERPHONE) (TALK) Sugerencias • Usted podrá recibir una llamada de intercomunicación en el microteléfono incluso aunque “RINGER” esté ajustado a “RINGER OFF”. •...
Page 95
Para transferir del microteléfono al teléfono base (TALK) (SPEAKERPHONE) Sugerencia Usted podrá recibir una llamada de intercomunicación en el teléfono base incluso aunque el selector RINGER LEVEL esté ajustado a OFF. El teléfono base sonará a bajo nivel. Presione (INTERCOM) para llamar al teléfono base.
Page 96
Funciones de identificación del demandante Acerca del servicio de identificación del demandante El servicio de identificación de demandantes permitirá que el número de teléfono de quien llame aparezca en el visualizador antes de contestar a la llamada. Para utilizar esta función tendrá que abonarse primero a este servicio.
Page 97
Comprobación de la lista de identificación de demandantes El teléfono almacena los datos de las últimas 20 llamadas recibidas, incluidas las de tipo “OUT OF AREA” y “PRIVATE”. Realiza un seguimiento de todas las llamadas recibidas, incluso si no se han contestado. Contemplación de la lista de identificación de demandantes Usted podrá...
Page 98
Comprobación de la lista de identificación de demandantes (continuación) Acerca de la marca “*” SMITH JOHN 1-201-123-4567 Borrado de datos de la lista de identificación de demandantes Los datos antiguos se borrarán automáticamente cuando entre la 21.ª llamada, pero usted también podrá borrar datos innecesarios, uno tras otro, o toda la lista.
Page 99
Para borrar todos los datos a la vez Haga que se visualicen los datos de identificación de usuarios. Presione el mando de lanzadera. Gire el mando de lanzadera hacia arriba para hacer que parpadee “ERASE”, y después presiónelo. Gire el mando de lanzadera hacia arriba para hacer que parpadee “ALL”...
Page 100
Utilización de la lista de identificación de demandantes Utilizando la lista de identificación de demandantes podrá devolver fácilmente la llamada a un número de teléfono de la lista de identificación de demandantes, o almacenar números de dicha lista en el directorio telefónico. Llamada a un número desde la lista de identificación de demandantes Gire...
Page 101
Almacenamiento de un número de la lista de identificación de demandantes en el directorio teléfonico Haga que se visualice el nombre y el número de teléfono que desee almacenar de la lista de identificación de demandantes (consulte la página 41). Confirme el número y presione el mando de lanzadera.
Page 102
Utilización de la lista de identificación de demandantes (continuación) Para cambiar el número de dígitos del número de teléfono Si el número de dígitos del número de teléfono de la lista de identificación de demandantes es diferente al número de teléfono real, tendrá...
Page 103
Cuando el código de área local coincida SMITH JOHN 201-123-4567 SMITH JOHN 1-201-123-4567 Continúe la operación para llamar al número o para almacenarlo con el número correcto de dígitos (páginas 44 y 45). Notas • Usted no necesitará ajustar el número de dígitos cada vez que llame desde la lista de identificación de demandantes ya que los cambios de los datos de identificación de demandantes no se almacenarán en la memoria.
Page 104
Utilización del servicio de “Identificación de demandantes con llamada en espera” Este teléfono es compatible con el servicio de “Identificación de demandantes con llamada en espera”. Compruebe si su compañía telefónica ofrece este servicio. Al igual que el servicio de identificación de demandantes, usted tendrá que abonarse a “Identificación de demandantes con llamada en espera”...
Page 105
Utilización del servicio de espera de mensajes visuales Si usted se abona al servicio de mensajes de su compañía telefónica que incluya esta función, el visualizador le indicará que usted tiene mensajes en espera de que los escuche. Lámpara MESSAGES Nota Usted no podrá...
Page 106
Utilización del servicio de espera de mensajes visuales (continuación) Si se traslada o cambia de compañía telefónica Las señales de mensaje en espera se transmitirán de dos formas: Señalización FSK o señalización de “tartamudeo” (su compañía telefónica podrá proporcionarle más información sobre este servicio). La primera vez que este teléfono reciba un mensaje de correo vocal, se ajustará...
Page 107
Información adicional Montaje del teléfono base en una pared Lengüeta de colgado Cable del adaptador de alimentación de CA Soporte Tomacorriente mural de CA Sugerencia Para retirar el soporte mural, presione las lengüetas inferiores. Levante la lengüeta de colgado. Enchufe el cable de la línea telefónica en la toma LINE y el adaptador de alimentación en la toma DC IN 9V, y enganche los...
Page 108
• Si los terminales de carga del teléfono base y el auricular están sucios, límpielos con un paño suave. En caso de duda o problemas con el teléfono, consulte a su proveedor Sony más próximo. Información adicional Para clientes en EE.UU.
Page 109
Solución de problemas Si experimenta cualquiera de las dificultades siguientes cuando utilice el teléfono, use esta guía para poder solucionar el problema. Si el problema persiste, póngase en contacto con su proveedor Sony. Síntoma Se oyen cinco pitidos cortos de error al presionar (TALK).
Page 110
Solución de problemas (continuación) Síntoma Se oyen interferencias durante la conversación. La conversación se silencia y en el visualizador aparece “CHANNEL SEARCHING”. Se oye un pitido cada tres segundos y en el visualizador aparecen i and“BATTERY LOW”. Se oyen cinco pitidos cortos de error y no es posible almacenar un número en una tecla de marcación instantánea o en el...
Page 111
Síntoma El nombre y/o el número de teléfono del demandante no aparecen en el visualizador durante la función de llamada en espera. No es posible marcar un número desde la lista de identificación de demandantes. La función de correspondencia de memoria no funciona. No es posible utilizar el servicio de mensajes visuales.
Page 112
Especificaciones Generales Banda de frecuencias 902 - 928 MHz Canales de operación 30 canales Señal de marcación Tonos y pulsos (10 pps), seleccionable Accesorios suministrados Consulte la página 7. Microteléfono Fuente de alimentación Batería BP-T23 Tiempo de carga de la batería Aprox.
Page 113
Índice alfabético Ajuste del volumen volumen del interfono 22, 25 volumen del microteléfono 20, 24 Almacenamiento de datos en el directorio telefónico Batería carga 11 duración 12 Batería de repuesto 13 Borrado código de área local 16 directorio telefónico 32 datos de identificación de demandantes 42 último número marcado...
