- Page 1 4-122-512-13 (1) LCD Monitor Instructions for Use Before operating the unit, please read this manual thoroughly and retain it for future reference. LMD-3250MD © 2008 Sony Corporation...
- Page 2 Consult your dealer. (According to standard EN60601-1-2 and CISPR11, Class B, Group 1) 6. Model LMD-3250MD is a monitor intended for use in a medical environment to display pictures from cameras or other systems, other than diagnostic X- ray equipment.
- Page 3 Caution When you dispose of the unit or accessories, you must obey the law in the relative area or country and the regulation in the relative hospital. For the customers in the USA Lamp in this product contains mercury. Disposal of these materials may be regulated due to environmental considerations.
- Page 4 LMD-3250MD. Guidance and manufacturer’s declaration-electromagnetic emissions The LMD-3250MD is intended for use in the electromagnetic environment specified below. The customer or the user of the LMD-3250MD should assure that it is used in such an environment. Emission test RF emissions...
- Page 5 Guidance and manufacturer’s declaration - electromagnetic immunity The LMD-3250MD is intended for use in the electromagnetic environment specified below. The customer or the user of the LMD- 3250MD should assure that it is used in such as environment. IEC 60601 test...
- Page 6 Guidance and manufacturer’s declaration - electromagnetic immunity The LMD-3250MD is intended for use in the electromagnetic environment specified below. The customer or the user of the LMD- 3250MD should assure that it is used in such as environment. IEC 60601 test...
- Page 7 Recommended separation distances between portable and mobile RF communications equipment and the LMD- 3250MD The LMD-3250MD is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the LMD-3250MD can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (Transmitters) and the LMD-3250MD as recommended below, according to the maximum output power of the communications equipment.
-
Page 8: Table Of Contents
Table of Contents Precaution ... 9 On Safety ... 9 On Installation ... 9 About the LCD Display Panel ... 9 About the Fluorescent Tube ... 9 On Cleaning ... 9 Disposal of the Unit ... 10 Recommendation to Use more than One Unit . 10 On Repacking ... -
Page 9: Precaution
A specially designed fluorescent tube is installed as the lighting apparatus for this unit. If the LCD screen becomes dark, unstable or does not turn on, consult your Sony dealer. On Cleaning Before cleaning Be sure to disconnect the AC power cord from the AC outlet. -
Page 10: Disposal Of The Unit
They make an ideal container which to transport the unit. If you have any questions about this unit, contact your authorized Sony dealer. On Fan Error The fan for cooling the unit is built in. When the fan stops and the RETURN button on the front panel blinks for fan error indication, turn off the power and contact an authorized Sony dealer. - Page 11 Accepts DVI-D (digital) input signals Adopting the scan converter allows this monitor to detect VGA, SVGA, XGA and SXGA digital computer signals input to the DVI input connector. To view SXGA signals when the DVI input is selected, use the cable within 3 m (118 inches) in length.
-
Page 12: Location And Function Of Parts And Controls
Location and Function of Parts and Controls Front Panel COMPOSITE COMPONENT HD15 USER MEM a Tally lamp You can check the status of the monitor by the color of the tally lamp. The tally lamp lights in green according to the setting of PARALLEL REMOTE in the REMOTE menu. -
Page 13: Input Select Buttons
j Input select buttons Press the button to monitor the signal input to each connector. A-1, A-2, B-1 and B-2 buttons are used when an optional input adaptor has been installed in the option slot. COMPOSITE button: to monitor the signal through the COMPOSITE IN connector Y/C button: to monitor the signal through the Y/C IN connector... -
Page 14: Input Signals And Adjustable/Setting Items
Input signals and adjustable/setting items Item Video* Y/C* CONTRAST* BRIGHT* CHROMA* PHASE* (NTSC) APERTURE COLOR TEMP COLOR SPACE AUTO CHROMA/ PHASE V SHARPNESS × MATRIX* COMPONENT LEVEL × NTSC SETUP (NTSC) SCAN GAMMA ASPECT* BLUE ONLY MONO × × SIZE SHIFT PITCH ×... -
Page 15: Side/Rear Panel
Side/Rear Panel a DC 5V/24V IN connector Connect the DC connector of the supplied AC adaptor. (power) switch The power is turned on or off. The monitor is turned on by pressing side c Loop-through output connectors Outputs the signals input to the input connectors (5 to 0). - Page 16 k Optional input slot An optional input adaptor can be installed according to your system configuration (see page 18). The upper slot is A and the lower slot is B. Press the A-1, A-2, B-1 or B-2 button to select the signal.
-
Page 17: Connecting The Ac Power Cord
Connecting the AC Power Cord Connect the supplied AC power cord as illustrated. Two kinds of AC plug holders are supplied with this unit. Use the AC plug holder that fits the AC power cord most securely. Plug the AC power cord into the AC IN socket on the AC adaptor. -
Page 18: Installing The Input Adaptor
Installing the Input Adaptor Before installing the input adaptor, disconnect the power cord. Remove the panel of the optional input slot. Insert the input adaptor into the slot. Tighten the screws. Installing the Input Adaptor / Removing the Connector Cover Removing the Connector Cover When the unit is shipped from the factory, a connector... -
Page 19: Selecting The Default Settings
Selecting the Default Settings When you turn on the unit for the first time after purchasing it, select the area where you intend to use this unit from among the options. The default setting values for each area COLOR TEMP NORTH AMERICA ARGENTINA... -
Page 20: Selecting The Menu Language
2 If LATIN AMERICA is selected: L A T I N A M E R I C A P A L & P A L - N A R E A A R G E N T I N A P A R A G U A Y U R U G U A Y N T S C &... -
Page 21: Using The Menu
The setting items (icons) in the selected menu are displayed in yellow. USER CONFIG – SYSTEM SETTING M AT R I X : C O M P O N E N T L E V E L : xxxx N T S C S E T U P : G A M M A : F O R M AT D I S P L AY: xxxx... - Page 22 The menu icon presently selected is shown in yellow and setting items are displayed. USER CONFIG – SYSTEM SETTING M AT R I X : C O M P O N E N T L E V E L : N T S C S E T U P : G A M M A : F O R M AT D I S P L AY:...
-
Page 23: Loading User Memory
Loading USER MEMORY You can load the picture settings saved in the USER MEMORY menu (on page 31). COMPOSITE COMPONENT HD15 USER MEM USER MEM Press the USER MEM button. The USER MEMORY menu appears. U S E R M E M O R Y 1 / 3 xD E FA U LT ·... -
Page 24: Adjusting And Changing The Settings
MATRIX COMPONENT LEVEL NTSC SETUP GAMMA FORMAT DISPLAY LANGUAGE POWER SAVING PICTURE DELAY MIN MULTI DISPLAY SETTING MULTI DISPLAY ENABLE MULTI DISPLAY SUB INPUT SELECT POSITION FRAME FUNCTION BUTTON SETTING F1 BUTTON F2 BUTTON F3 BUTTON F4 BUTTON COMPUTER DETECT HD15 REMOTE PARALLEL REMOTE... -
Page 25: Color Temp/Space Menu
COLOR TEMP/SPACE menu The COLOR TEMP/SPACE menu is used for adjusting the picture white balance or color space. You need to use the measurement instrument to adjust the white balance. Recommended: Konica Minolta color analyzer CA-210 COLOR TEMP/SPACE xxxxxx C O L O R T E M P : M A N U A L A D J U S T M E N T : A D J U S T G A I N : A D J U S T B I A S :... - Page 26 Submenu Setting SUB CONTROL Adjusts finely the adjustment range of the button on the front panel for CONTRAST, BRIGHTNESS, CHROMA and PHASE. • CONTRAST: Adjusts the picture contrast. • BRIGHTNESS: Adjusts the picture brightness. • CHROMA: Adjusts color intensity. The higher the setting, the greater the intensity.
-
Page 27: User Config Menu
Submenu Setting PICTURE CONTROL Adjusts to monitor the picture more clearly. • SIZE H: Adjusts the horizontal size of the picture. The higher the setting, the larger the horizontal size of the picture. The lower the setting, the smaller the horizontal size of the picture. - Page 28 Submenu Setting LANGUAGE Selects the menu or message language from among seven languages. • ENGLISH: English • FRANÇAIS: French • DEUTSCH: German • ESPAÑOL: Spanish • ITALIANO: Italian • : Japanese • : Chinese POWER SAVING Sets the power saving mode on or off.
- Page 29 FUNCTION BUTTON SETTING USER CONFIG – FUNCTION BUTTON SETTING F 1 B U T T O N : xxxx F 2 B U T T O N : xxxx F 3 B U T T O N : xxxx F 4 B U T T O N : xxxx Submenu Setting...
-
Page 30: Remote Menu
COMPUTER DETECT USER CONFIG – COMPUTER DETECT xxxxx DV I : xxxxx H D 1 5 : Submenu Setting COMPUTER The appropriate preset memory is set for DETECT the signal from DVI and HD15 input connector. Select “PRESET1” for the standard PC signal. -
Page 31: Key Inhibit Menu
KEY INHIBIT menu KEY INHIBIT K E Y I N H I B I T : You can lock the setting so that they cannot be changed by an unauthorized user. Select OFF or ON. If you set to ON, all items are displayed in black, indicating the items are locked. -
Page 32: Troubleshooting
To change the name Press the + or – button to select the memory number in the USER MEMORY menu, then press the ENTER button. The USER MEMORY setting menu appears. U S E R M E M O RY 1 / 3 0 1 U S E R 0 1 xS AV E : ·... -
Page 33: Specifications
BNC type (1) Loop-through, with 75 ohms automatic terminal function LCD monitor (LMD-3250MD) DC IN: 24 V 5.0 A 5 V 0.060 A (Supplied from AC adaptor) AC adaptor (Sony, AC-110MD) AC IN: 100-240 V, 50/60Hz, 1.53 A to 0.58 A... - Page 34 Design and specifications are subject to change without notice. Note Always verify that the unit is operating properly before use. SONY WILL NOT BE LIABLE FOR DAMAGES OF ANY KIND INCLUDING, BUT NOT LIMITED TO, COMPENSATION OR REIMBURSEMENT ON ACCOUNT OF THE LOSS...
- Page 35 Composite System Component BKM-227W BKM-229X 1080/25PsF 1080/24P 1080/25P 1080/30P 1080/50I 1080/60I 720/50P 720/60P *1 The frame rate is also compatible with 1/1.001. *2 Component only About the preset signal This unit has a preset memory for signals connected to the DVI and HD15 input terminals (the preset memory). When a preset signal is input, the unit automatically detects the signal type and recalls the data for the signal from the preset memory to adjust it to an optimum...
- Page 36 PRESET 1 Available HD15 input signal formats VESA DMT Dot clock Resolution [MHz] 640 × 480 60 Hz 25.175 800 × 600 56 Hz 36.000 800 × 600 60 Hz 40.000 800 × 600 72 Hz 50.000 800 × 600 75 Hz 49.500 800 ×...
- Page 37 Others Dot clock Resolution [MHz] 720 × 400 70 Hz 28.322 1280 × 800 60 Hz 68.900 Available DVI input signal formats Range of DVI input signal (available to 1920 × 1080 / 60Hz) Vertical frequency: 50.0 to 85.1 Hz Horizontal frequency: 31.5 to 77.0 kHz Dot clock: 25.175 to 148.000 MHz Picture size, phase: automatic discrimination by the...
- Page 38 PRESET 7 (Selected using DVI in the menu) Preset signal [kHz] 1422 × 1064 33.75 712 × 480 15.734 704 × 572 15.625 PRESET 8 (Selected using DVI in the menu) Preset signal [kHz] 1280 × 1008 33.75 712 × 480 15.734 704 ×...
-
Page 39: Dimensions
Dimensions Front When an optional stand SU-32FW is attached 783 (30 392 (15 Rear (VESA Mount Instruction) 400 (15 300 (11 * Length of M6 screws (4) Monitor cabinet Attached object 10 ( Side When an optional stand SU-32FW is attached AC adaptor M6 screw 124.3 (5) - Page 40 Sony Corporation...
