FM/AM
Cassette Car
Stereo

Operating Instructions

Owner's Record
The model and serial numbers are located on the bottom of the unit.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer regarding this
product.
Model No. XR-1100 Serial No.
For installation and connections, see the supplied installation/connections
manual.
XR-1100
2000 Sony Corporation
3-868-315-11 (1)
US

Advertisement

Table of Contents
loading

Related Manuals for Sony XR-1100

Summary of Contents for Sony XR-1100

  • Page 1: Operating Instructions

    The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. XR-1100 Serial No.
  • Page 2 You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. Welcome! Thank you for purchasing the Sony Cassette Car Stereo. This unit lets you enjoy a variety of features. Features General Built-in power amplifier (max.
  • Page 3 Therefore, we recommend cleaning the tape head once a month or so with the separately available Sony Cassette Cleaning Set. If the sound does not improve after using a cleaning cassette, please consult your nearest Sony dealer.

  • Page 4: Table Of Contents

    Cassettes longer than 90 minutes The use of cassettes longer than 90 minutes is not recommended except for long continuous play. The tapes used for these cassettes are very thin and tend to be stretched easily. Frequent playing and stopping of these tapes may cause them to be pulled into the cassette deck mechanism.

  • Page 5: Location Of Controls

    9 During radio reception: Preset number buttons 9 During tape playback: button 7 q; SEEK/MANU button 8 qa LOCAL (local seek) button 8 qs DSPL (display mode change/time set) button 6 D-BASS SEEK DSPL MANU LOCAL XR-1100 (Automatic Tuner Activation)

  • Page 6: Getting Started

    Getting Started Setting the clock The clock has a 12-hour digital indication. For example, setting it to 10:08 Display the time. (Press the button during unit DSPL operation.) Press the button for more than two DSPL seconds. The hour digit blinks. Set the hour digits.

  • Page 7: Cassette Player

    Cassette Player Listening to a tape After inserting the cassette, playback will start automatically. To change the tape direction, press both the m and the M buttons at the same time. Indication of tape transport direction The side facing up is being played. The side facing down is being played.

  • Page 8: Radio

    Radio Searching for stations automatically — Automatic tuning Select the desired band. A MEM FM1 t FM2 t AM t FM1 TUNER Press either side of the SEEK/MANU button momentarily to search for the next station (automatic tuning). For higher frequencies SEEK MANU...

  • Page 9: Memorizing Only The Desired Stations

    Memorizing only the desired stations Select the desired band. A MEM FM1 t FM2 t AM t FM1 TUNER Tune in the station which you wish to store on the preset number button. Press and hold the desired preset number button ( two seconds until you hear a beep tone.

  • Page 10: Attenuating The Beep Tone

    If the fuse blows, check the power connection and replace the fuse. If the fuse blows again after replacement, there may be an internal malfunction. In such a case, consult your nearest Sony dealer. Fuse (10 A) Warning Never use a fuse with an amperage rating exceeding the one supplied with the unit as this could damage the unit.

  • Page 11: Dismounting The Unit

    Dismounting the unit Insert the supplied tool between the unit and the frame, and rotate 90° to release the hidden mounting spring. Repeat on the opposite side and remove the frame. 10 mm ( 90° Insert a flathead screwdriver between the bracket and mounting spring.

  • Page 12: Specifications

    Specifications AUDIO POWER SPECIFICATIONS POWER OUTPUT AND TOTAL HARMONIC DISTORTION 17 watts per channel minimum continuous average power into 4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 1% total harmonic distortion. Cassette player section Tape track Wow and flutter Frequency response...

  • Page 13: Troubleshooting Guide

    Troubleshooting guide The following checklist will assist in the correction of most problems which you may encounter with your unit. Before going through the checklist below, refer to the connection and operating procedures. General Problem No sound Tape playback Problem The sound is distorted.
  • Page 16 Sony Corporation Printed in Malaysia...
