TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
2.2. About lead free solder (PbF)---------------------------- 5
3 Service Navigation ----------------------------------------------- 6
3.1. Service Hint ------------------------------------------------- 6
3.2. Applicable signals ----------------------------------------- 7
4 Specifications ----------------------------------------------------- 9
5 Operating Instructions-----------------------------------------10
5.1. Options Adjustments-------------------------------------10
6 Service Mode -----------------------------------------------------12
sample data) -----------------------------------------------15
7 Troubleshooting Guide ----------------------------------------16
7.1. Self Check--------------------------------------------------16
7.2. No Power ---------------------------------------------------18
High Definition Plasma Display
Model No.
GPF11D Chassis
PAGE
7.3. No Picture-------------------------------------------------- 18
7.4. Local screen failure-------------------------------------- 19
8.1. Removal of Rear Cover -------------------------------- 20
8.2. Removal of HA-Board----------------------------------- 20
8.3. Removal of HHH-Board -------------------------------- 20
8.4. Removal of Slot Block ---------------------------------- 20
8.5. Removal of HX-Board----------------------------------- 21
8.6. Removal of DS-Board----------------------------------- 21
8.7. Removal of PB-Board----------------------------------- 21
8.8. Removal of DN-Board ---------------------------------- 22
8.9. Removal of D-Board------------------------------------- 22
8.10. Removal of P-Board------------------------------------- 22
8.12. Removal of Fan------------------------------------------- 23
8.14. Removal of SC-Board----------------------------------- 24
8.15. Removal of SS-Board----------------------------------- 25
8.16. Removal of C1, C2-Board ----------------------------- 25
© 2008 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
Order Number MTNC080865CE
TH-42PF11UK
B34 Canada: D10
PAGE

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic TH-42PF11UK

  • Page 1: Table Of Contents

    Order Number MTNC080865CE B34 Canada: D10 High Definition Plasma Display TH-42PF11UK Model No. GPF11D Chassis TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions----------------------------------------------- 3 7.3. No Picture-------------------------------------------------- 18 1.1. General Guidelines---------------------------------------- 3 7.4. Local screen failure-------------------------------------- 19 8 Disassembly and Assembly Instructions--------------- 20 2 Warning -------------------------------------------------------------- 4 2.1.
  • Page 2 TH-42PF11UK 12.40. SC-Board (3 of 3) Schematic Diagram ------------- 90 8.17. Removal of S1-Board------------------------------------26 8.18. Removal of Front Glass, V1, V2-Board and 12.41. SU-Board (1 of 2) Schematic Diagram ------------- 91 Cabinet ------------------------------------------------------26 12.42. SU-Board (2 of 2) Schematic Diagram ------------- 92 8.19.
  • Page 3: Safety Precautions

    TH-42PF11UK 1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.
  • Page 4: Warning

    TH-42PF11UK 2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensi- tive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor “chip”...
  • Page 5: About Lead Free Solder (Pbf)

    TH-42PF11UK 2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
  • Page 6: Service Navigation

    TH-42PF11UK 3 Service Navigation 3.1. Service Hint Board Name Function Board Name Function Digital Signal Processor, Microcomputer Data drive (Right) Format Converter Data drive (Left) Plasma AI Processor Speaker terminal Sub-Field Processor Power switch Slot Interface (Audio / Video / Sync Input Switch),...
  • Page 7: Applicable Signals

    TH-42PF11UK 3.2. Applicable signals...
  • Page 8 TH-42PF11UK...
  • Page 9: Specifications

    TH-42PF11UK 4 Specifications Power Source 110-127 V AC, 50/60Hz Power Consumption Power on 525 W Stand-by condition Save OFF 0.9 W, Save ON 0.5 W Power off condition 0.1 W Plasma Display panel Drive method: AC type 42-inch, 16:9 aspect ratio 36.2"...
  • Page 10: Operating Instructions

    TH-42PF11UK 5 Operating Instructions 5.1. Options Adjustments...
  • Page 11 TH-42PF11UK Option Menu for GPF11D series GPF11D chassis series have special function and operation setting facility called Option Menu. This Option Menu is useful for special function required customers. This should be set at the installation stage. Option menus default setting...
  • Page 12: Service Mode

    TH-42PF11UK 6 Service Mode 6.1. CAT (Computer Aided Test) mode To exit the CAT mode, access the ID mode and switch off the main power. 6.1.1. IIC mode Select the IIC mode by Up/Down button on the remote control at the front page of CAT mode and then press the Action button on the remote control.
  • Page 13 TH-42PF11UK 6.1.2. CD mode Select the CD mode by Up/Down button on the remote control at the front page of CAT mode and then press the Mute button on the remote control more than 3 seconds. Memory data change To exit the CD mode, press the R button on the remote control.
  • Page 14 TH-42PF11UK 6.1.4. MS mode Select the MS mode by Up/Down button on the remote control at the front page of CAT mode and then press the Mute button on the remote control more than 3 seconds. To exit the MS mode, press the R button on the remote control.
  • Page 15: Iic Mode Structure (Following Items Value Is Sample Data)

    TH-42PF11UK 6.2. IIC mode structure (following items value is sample data)
  • Page 16: Troubleshooting Guide

    TH-42PF11UK 7 Troubleshooting Guide 7.1. Self Check 7.1.1. Display Indication 1. Self-check is used to automatically check the bus line controlled circuit of the Plasma display. 2. To get into the Self-check mode, press the volume down button on the customer controls at the bottom of the set, at the same time pressing the OFF-TIMER button on the remote control, and the screen will show.
  • Page 17 TH-42PF11UK 7.1.2. Power LED Blinking timing chart 1. Subject Information of LED Blinking timing chart. 2. Contents When an abnormality has occurred to the unit, the protection circuit operates and resets to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.
  • Page 18: No Power

    TH-42PF11UK 7.2. No Power First check point There are following 3 states of No Power indication by power LED. 1. No lit. 2. Green is lit then turns red blinking a few seconds later. 3. Only red is lit. 7.3.
  • Page 19: Local Screen Failure

    TH-42PF11UK 7.4. Local screen failure Plasma display may have local area failure on the screen. Fig - 1 is the possible defect P.C.B. for each local area. Fig - 1...
  • Page 20: Disassembly And Assembly Instructions

    TH-42PF11UK 8 Disassembly and Assem- 8.3. Removal of HHH-Board 1. Remove 4 screws (D) and then remove the HHH Terminal bly Instructions Block. 2. Remove 4 screws (E). • To disassemble P.C.B., wait for 1 minute after power was off 3.
  • Page 21: Removal Of Hx-Board

    TH-42PF11UK 8.5. Removal of HX-Board 8.6. Removal of DS-Board 1. Remove the HA Terminal Block and the HHH Terminal 1. Remove the Slot Case. Block. (Refer to Removal of HX-Board) (Refer to Removal of HA-Board and HHH-Board) 2. Disconnect the connector (DS14).
  • Page 22: Removal Of Dn-Board

    TH-42PF11UK 8.8. Removal of DN-Board 8.9. Removal of D-Board 1. Disconnect the connectors (DN3, DN5, DN9, PB31, 1. Remove the Slot Block. PB32, PB33, PB34, PB35, PB38). (Refer to Removal of Slot Block) 2. Remove the flexible cables from the connectors (DN1, 2.
  • Page 23: Removal Of Speaker Terminal Block (L, R)

    TH-42PF11UK 8.11. Removal of Speaker Terminal 3. Remove 4 screws (H) and then remove the Fan (A). Block (L, R) 1. Remove each 3 screws and then remove the Speaker Terminal Block (H3 Circuit Board) (L, R). 2. Turn over the Speaker Terminal Block (L, R) and then dis- 4.
  • Page 24: Removal Of Su-Board And Sd-Board

    TH-42PF11UK 8.13. Removal of SU-Board and SD- 8.14. Removal of SC-Board Board 1. Remove the Speaker Terminal Block (R). (Refer to Removal of H3 Circuit Board (L, R)) 1. Remove the flexible cables from the connectors (SU1, 2. Disconnect the connectors (SU41, SD42, SD46).
  • Page 25: Removal Of Ss-Board

    TH-42PF11UK 8.15. Removal of SS-Board 8.16. Removal of C1, C2-Board 1. Remove 4 Fan Blocks. 1. Remove the Slot Block. (Refer to Removal of Fan) (Refer to Removal of Slot Block). 2. Disconnect the connectors (SS11, SS12, SS33, SS34, 2. Remove the Speaker Terminal Block (L,R).
  • Page 26: Removal Of S1-Board

    TH-42PF11UK 8.18. Removal of Front Glass, V1, 3. Remove 4 screws and then remove C1-Board. V2-Board and Cabinet 1. Remove the S1-Board Block. (Refer to Removal of S1-Board) 2. Disconnect the connectors (DS2, DS15). 3. Remove 4 screws ( ) and then remove the Fixed Plate (L, R).
  • Page 27 TH-42PF11UK 8.18.1. Removal of Front Glass 4. Remove 2 hooks and then remove the 5 Key Button from V2-Board. 1. Remove 23 screws and then remove the Fixed Angle 5. Disconnect the connector (V15) and then remove V2- (top, bottom, right, left).
  • Page 28: Removal Of Plasma Display Panel

    TH-42PF11UK 8.19. Removal of Plasma Display 10. Remove 4 screws and then remove D-Board. Panel The C1,C2 Boards are connected with the Plasma Display Panel for the repair. 1. Disconnect the Fan Relay Connectors. 2. Remove 14 screws and then remove 4 Fan Blocks (1, 2, 3, 4).
  • Page 29 TH-42PF11UK 15. Remove the flexible cables from the connectors (SU1, 19. Disconnect the connectors (C23, C25, SS34). SU2, SU3, SU4, SU11, SD1, SD2, SD3, SD4). 20. Remove the flexible cables from the connectors (SS61, SS63, SS64, SS66). 16. Disconnect the connectors (SU41, SD42, SD46).
  • Page 30 TH-42PF11UK 25. Remove 8 screws and then remove the Fixed Plate (bot- Caution: • Please confirm the installation place of Rear Cover Hook tom). Right, Rear Cover Hook Left, Rear Cover Spacers and Rear Cover Spacer Rings when you exchange the...
  • Page 31: Measurements And Adjustments

    TH-42PF11UK 9 Measurements and Adjustments 9.1. Adjustment Procedure 9.1.1. Driver Set-up 9.1.1.1. Item / Preparation 1. Set Aging pattern (white pattern signal) by IIC mode. 9.1.1.2. Adjustments 2. Set the picture controls as follows. Adjust driver section voltages. (Refer to the panel data on the Picture menu: Standard Panel Label).
  • Page 32 TH-42PF11UK 9.1.2. Initialization Pulse Adjust 1. Set Aging pattern (white pattern signal) by IIC mode. 2. Set the picture controls as follows. Picture menu: Standard Picture: +25 Aspect: Full 3. Connect Oscilloscope to TPSC1 and adjust VR16602 for 250V ± 10V.
  • Page 33 TH-42PF11UK 9.1.4. Adjustment Volume Location 9.1.5. Test Point Location...
  • Page 34: Adjustment

    TH-42PF11UK 9.2. Adjustment 9.2.1. RGB white balance adjustment Instrument Name Connection Remarks • RGB VGA60 W / B pattern PC input User setting: Normal • Color analyzer Panel surface (Picture menu: STANDARD) (Minolta CA-100 or equivalent) Procedure Remarks [Condition] Picture Menu: Standard •...
  • Page 35 TH-42PF11UK...
  • Page 36 TH-42PF11UK 9.2.2. HD white balance adjustment Instrument Name Connection Remarks • HD(1125/60i) W / B pattern (COMPONENT Output) PC input User setting: Normal • Color analyzer Panel surface (Picture menu: STANDARD) (Minolta CA-100 or equivalent) Procedure Remarks [condition] Picture Menu: STANDARD •...
  • Page 37 TH-42PF11UK...
  • Page 38 TH-42PF11UK...
  • Page 39: Block Diagram

    TH-42PF11UK 10 Block Diagram 10.1. Block (1 of 8) Diagram 63($.(5 7(50,1$/6 '6 6/27 ,17(5)$&(6<1& 352&(66256281' 352&(6625 63($.(5 / / / 7(50,1$/ $8',2 6(/(&7 63($.(5 /5B 7(50,1$/6 /5B / 6281' /5B 63 $03 5 5 5 63($.(5 5 &21752/ 7(50,1$/...
  • Page 40: Block (2 Of 8) Diagram

    TH-42PF11UK 10.2. Block (2 of 8) Diagram 6& 6&$1 '5,9( )250$7 &219(57(5 3/$60$ $, 352&(6625 6& 9686 32:(5 6833/< 6&$1 287 833(5 6&%2$5' (1(*5< 5(&29(5< 3$1(/ 0,&20 *HQ; 626 '(7(&7 ((3520 626B36 /('7,0(6 /('7,0(6 /('7,0(6 /('7,0(6 32:(5 626 626B6& 6867$,1 '5,9(...
  • Page 41: Block (3 Of 8) Diagram

    TH-42PF11UK 10.3. Block (3 of 8) Diagram +'0, ,1 $ +'0, ,1 % ,& '8$/ +'0, ,17(5)$&( 95(* ,& 9 ((3520 ,& '6 (',' $ )RU +' ,& 6/279 967% ,& 6/279 &21),* ,& ,& 67%9 ((3520 %8))(5 (',' $...
  • Page 42: Block (4 Of 8) Diagram

    TH-42PF11UK 10.4. Block (4 of 8) Diagram '6 6/27 ,17(5)$&(6<1& 352&(66256281' 352&(6625 '6 9 3 6/279 9 3 6/279 9 3 6/279 9 3 6/279 9 /$1 /$19 9 67% 67%9 $8',2 ,1 / $8',2 ,1 5 9'B 9 3 +'B 9 61' 35B 355 3%B /('7,0(6 /('7,0(6 3%% 9&&...
  • Page 43: Block (5 Of 8) Diagram

    TH-42PF11UK 10.5. Block (5 of 8) Diagram '6 6/27 ,17(5)$&(6<1& 352&(66256281' 352&(6625 63($.(5 9 3 9 3 63($.(5 / 7(50,1$/6 9 3 9 3 7(50,1$/ 9 3 / 287 63B/ 9 3 / 287 9 3 /$19 63B/ 9 /$1 9 67% 63($.(5 ,& 63($.(5 5 7(50,1$/6 9 7(50,1$/...
  • Page 44: Block (6 Of 8) Diagram

    TH-42PF11UK 10.6. Block (6 of 8) Diagram 9 3 9 3 ',*,7$/ 6,*1$/ 352&(6625 9 3 9 3 9 6: )$&725< 9 9 9 9 9 /9'6 5(&(,9(5 77/ 3$5$//(/ /9'6 ,1B$ >$@ &/. /9'6 &/. $6,& 287 $ 6&: ,1 $ ,& $B2$  2(...
  • Page 45: Block (7 Of 8) Diagram

    TH-42PF11UK 10.7. Block (7 of 8) Diagram POWER SUPPLY K602 MC602 MC203 MC603 COLD RECTIFIER RF601 Vsus F201 POWER SUPPLY K601 T201 D251 FORMAT CONVERTER, Vsus GEN. PLASMA AI PROCESSOR Vsus SS11 MC601 VR251 IC251 IC9500 DISCHARGE CONTROL Vsus PC201...
  • Page 46: Block (8 Of 8) Diagram

    TH-42PF11UK 10.8. Block (8 of 8) Diagram 32:(5 6:,7&+ 6: 6& 6&$1 '5,9( 32:(5 6:,7&+ 6& 739686 9VXV ,& 9) '&'& &219(57(5 ,& ,& 6&$1 287 833(5 6867$,1 '5,9( ,& ,19(57(5 7396(7 96(7 287 ,& (5525 '(7 3& 4 6&$1 739686 3&...
  • Page 47: Wiring Connection Diagram

    TH-42PF11UK 11 Wiring Connection Diagram 11.1. Wiring (1)
  • Page 48: Wiring (2)

    TH-42PF11UK 11.2. Wiring (2)
  • Page 49: Wiring (3)

    TH-42PF11UK 11.3. Wiring (3)
  • Page 50 TH-42PF11UK...
  • Page 51: Schematic Diagram

    TH-42PF11UK 12 Schematic Diagram 12.1. Schematic Diagram Notes...
  • Page 52: P-Board (1 Of 2) Schematic Diagram

    TH-42PF11UK 12.2. P-Board (1 of 2) Schematic Diagram AC CORD RECTIFIER <Exchange board only> <Exchange board only> 0'3/3% PFC CONTROL <Exchange board only> P-BOARD ETX2MM702MFH (1/2) TH-42PF11UK TH-42PF11UK P-Board (1 of 2) Schematic Diagram P-Board (1 of 2) Schematic Diagram...
  • Page 53: P-Board (2 Of 2) Schematic Diagram

    TH-42PF11UK 12.3. P-Board (2 of 2) Schematic Diagram P-BOARD ETX2MM702MFH (2/2) BIAS/PFC/MULTI CONTROL <Exchange board only> POWER CONTROL <Exchange board only> COLD COLD Vsus POWER SUPPLY <Exchange board only> CONTROL SWITCH +15V ERROR DET <Exchange board only> COLD COLD +5V(P) <Exchange board only>...
  • Page 54: Pb, V1 And V2-Board Schematic Diagram

    TH-42PF11UK 12.4. PB, V1 and V2-Board Schematic Diagram 72 )$1 '1%2$5' '1 5 5 5 5 5 5 N N N N N N '59 ' ' ' ' ' ' 0$&97 0$&97 0$&97 0$&97 0$&97 0$&97 )$1 626 )$1 &217...
  • Page 55: Ha-Board Schematic Diagram

    TH-42PF11UK 12.5. HA-Board Schematic Diagram +$%2$5' 7;1+$9%78 / -+$%% /$19 /$19 < < -6 -6 (5-*(<59 (5-*(<59 &20321(17 73 9,'(2 ,1 / < -+$%% 6B'(7 -6 -6 73 5(6(7 (5-*(<59 (5-*(<59 5(6(7 73 / 3:5B67$7 -. -+$%% & -6 -6 .4%%%%...
  • Page 56: Hx-Board Schematic Diagram

    TH-42PF11UK 12.6. HX-Board Schematic Diagram +;%2$5' 7=7139=7 -. 5 3&B5 .)%%$ 5 3&B* 3& ,1 )/ -0$% 5 3&B% )/ -0$% 5 3&B+' 5 N )/ -0$% 5 3&B9' 5 N )/ -0$% ,& 7954 5 5 5 ''& ((3520 ' %+&00...
  • Page 57: Hhh-Board (1 Of 4) Schematic Diagram

    TH-42PF11UK 12.7. HHH-Board (1 of 4) Schematic Diagram +++%2$5' 7;1+++9%78  +3' +3' 4 4 5 6./ 6./ 0$,19 5 ,& 5 &'%))' / 0$,19 ' ' $ 9 % 9 --+& 6'$B% %+&00 %+&00 & & ,& 6&/B% 9 1&...
  • Page 58: Hhh-Board (2 Of 4) Schematic Diagram

    TH-42PF11UK 12.8. HHH-Board (2 of 4) Schematic Diagram / 9+'0, --+& & & & 9*(1; / 9 9 --+& X & & & 9 9 X +++%2$5' 7;1+++9=78  +'0,B6&/ *(1;B+5B((3B6&/ +'0,B6'$ *(1;B+5B((3B6'$ / --+& 5 5 5 5 5 &...
  • Page 59: Hhh-Board (3 Of 4) Schematic Diagram

    TH-42PF11UK 12.9. HHH-Board (3 of 4) Schematic Diagram )/ (/.()$ ,& 9 ,& &'%=)) &21),* 520 / / / 9&21),* --+& &'%$+' 9&21),* --+& 95(* --+& &  9287 9 & & & & & ' & 5 & & X ,&...
  • Page 60: Hhh-Board (4 Of 4) Schematic Diagram

    TH-42PF11UK 12.10. HHH-Board (4 of 4) Schematic Diagram +++%2$5' 7;1+++9%78  PA3301 73 K5H4022A0023 & & X 5 +'0,B5 +'0,B/ 6/27B6&/ 6/27B6'$ 967% 6/27B654 5 73 967% & & 73 X 73 )/ (/.()$ 9 & & 9 X & &...
  • Page 61: Ds-Board (1 Of 6) Schematic Diagram

    TH-42PF11UK 12.11. DS-Board (1 of 6) Schematic Diagram ,& &'%$<< & & $95 9 '6%2$5' 713$  X & 5 5 N X & X 3%2$5' ' / 3 %%& *&0$ &203 6281'9 & & 9B & / --+& S...
  • Page 62: Diagram

    TH-42PF11UK 12.12. DS-Board (2 of 6) Schematic Diagram '6%2$5' 713$  'B9 'B9 6&/ 5 6'$ 5 ,& & 6281'9 X &$% & & & & X 63 $03 5 X X 5 X $B9 +%2$5' & +3B,1 +3B287 X &...
  • Page 63: Ds-Board (3 Of 6) Schematic Diagram

    TH-42PF11UK 12.13. DS-Board (3 of 6) Schematic Diagram '6%2$5' 713$  9B0 6281'9 5 5 ' 6/279 6/279 /$19 67%9B6 %$&&( 4 6'$/ 6/279 5 ' ' ' 5 5 0$=0/ 0$=0/ 0$=0/ 5 ' 4 /$19 %$&&( 4 6'$/...
  • Page 64: Ds-Board (4 Of 6) Schematic Diagram

    TH-42PF11UK 12.14. DS-Board (4 of 6) Schematic Diagram '6%2$5' 713$  9B0 / *&. 5 5 5 & 5 N N N *5((1B287 9'287 5 9&& ,& ,& 9B &-%$% &-%$5 +'287 5 5 & 6<1& 6,*1$/ ,19(57(5 6<1& 6:,7&+...
  • Page 65: Ds-Board (5 Of 6) Schematic Diagram

    TH-42PF11UK 12.15. DS-Board (5 of 6) Schematic Diagram '6%2$5' 713$  '1%2$5' 7(50 '1 )/ )/ 9B0 67%9 )$19 )-($ )-($ )/ )-($ & & & X )/ 67%9B6 )-($ ,& )/ & )-($ &-%$= 9!9 67%9B6 & 5(02&21B287 X 67%9 5(02&21B287...
  • Page 66: Ds-Board (6 Of 6) Schematic Diagram

    TH-42PF11UK 12.16. DS-Board (6 of 6) Schematic Diagram '6%2$5' 713$  '1%2$5' '1 7(50 9%2$5' 67%9 9 / --+& 67%9 / /('B* --+& /('B* ' / /('B5 0$=0/ --+& /('B5 ' / --+& .(<B'(7 0$=0/ .(<B'(7 / --+& / 5(02&21 --+&...
  • Page 67: Dn-Board (1 Of 8) Schematic Diagram

    TH-42PF11UK 12.17. DN-Board (1 of 8) Schematic Diagram '1%2$5' 7;1'19=78  5 6:B9 9 5 4 5 N 6'$/ 5 4 & 5 & %'+'& N X 5 )$&725< ' %-&0( '1 ,& 67%9 67%9 67%9 ,& 67%<9 &'%$<< &'%$<< 67%<9...
  • Page 68: Dn-Board (2 Of 8) Schematic Diagram

    TH-42PF11UK 12.18. DN-Board (2 of 8) Schematic Diagram 6:B9 5 +'B0 & 9&& 287B< ,& X ,1B$ 3%%2$5' &-%$$ ,1B% 3% 9!9 5 '1%2$5' 7;1'19=78  )$1B92/7$*( '6%2$5' '6%2$5' '6 '6 5 5 9'B0 )$1B92/7$*( & 73 9&& 287B< 5 ,&...
  • Page 69: Dn-Board (3 Of 8) Schematic Diagram

    TH-42PF11UK 12.19. DN-Board (3 of 8) Schematic Diagram $6,& 9&&,17 9 $6,& ,1387 IURP '6 $6,& 1& $6,& 9'( 9 ,& 9 &$% 6:B9 $6,&9 $6,& $B2$ 5 %B2$ 5 ,& & 1& ,& 1& / ,& /9$B5; ,& /9%B5; / $B2$ %B2$ ,&...
  • Page 70: Dn-Board (4 Of 8) Schematic Diagram

    TH-42PF11UK 12.20. DN-Board (4 of 8) Schematic Diagram ,& 6&: &$% 6&: $50 67%9 '1%2$5' 7;1'19=78  & 5 ' 0$=/ 6&:((3520 6&: $50 ,2 4 5 5 ,& 6'$/ ,& *,2>@ 626B,1+ )9B021 & 5 67%9 7954 ((3520B:3 X ,& $',1>@...
  • Page 71: Dn-Board (5 Of 8) Schematic Diagram

    TH-42PF11UK 12.21. DN-Board (5 of 8) Schematic Diagram ,& &$% 6&: 6&: 6(3$5$7( 32:(5 67%9 'B9 'B9 / 'B9 )/ )/ )/ --+& 9 67%9 )-($ 67%9 6&: )/$6+5206'5$0 ,2 )-($ )-($ & & & & $2B$ $2B$ X X...
  • Page 72: Dn-Board (6 Of 8) Schematic Diagram

    TH-42PF11UK 12.22. DN-Board (6 of 8) Schematic Diagram '1%2$5' 7;1'19=78  6&: 9'( 9 'B9 6&: *1' / & & 6&:B9 9 9 --+& ,& ,& $& ,& $' ,& $+ ,& & ,& ,& ,& ,& ,& ,& $& ,& $' ,&...
  • Page 73: Dn-Board (7 Of 8) Schematic Diagram

    TH-42PF11UK 12.23. DN-Board (7 of 8) Schematic Diagram ,& ''5B7B9 ,& 9 9 ''5 *1' &$%4- &$%4- 32:(5 )25 ''5 9- / ''5 *1' ''5 ,& 9664 ,& 9664 32:(5 )25 ''5 --+& / ,& 9664 ,& 966B7KHUPDO 73 --+& 73 ,&...
  • Page 74: Dn-Board (8 Of 8) Schematic Diagram

    TH-42PF11UK 12.24. DN-Board (8 of 8) Schematic Diagram '%2$5' 6&:B/9'6 ' 6&: 'LJLWDO RXW '1%2$5' 7;1'19=78  ,& 32'>@ ',63(1 ',63(1 ,& 32'>@ 6&: /9'6 7(50,1$7,21 3$1(/B67%<B21 3$1(/B67%<B21 ,& 32'>@ 73 ,& 32'>@ 5($'< 735'< 5($'< ,& 32'>@ ,& /9'6%5(6 ,&...
  • Page 75: D-Board (1 Of 7) Schematic Diagram

    TH-42PF11UK 12.25. D-Board (1 of 7) Schematic Diagram '%2$5' 713$%;6  39 5 N & & 5 & & & X & &6 &893 39 S 5 X / 5 3*22' N *&5= N &% & ' 5(),1 287 5...
  • Page 76: D-Board (2 Of 7) Schematic Diagram

    TH-42PF11UK 12.26. D-Board (2 of 7) Schematic Diagram '%2$5' 713$%;6  )$&725< '1%2$5' '1 67%9B0 ,& 67%9 &(%) 67%9B0 67%9 5(6(7 67% 9 ' %-&*' 9287 & & & & X X 39 &G & X &( 5(6(7 5 4...
  • Page 77: D-Board (3 Of 7) Schematic Diagram

    TH-42PF11UK 12.27. D-Board (3 of 7) Schematic Diagram '%2$5' 713$%;6  '1%2$5' '1 39 ,& &=%= ',6&+$*( &21752/ & & X 39 X ,& & -7$* X 01 ,& 9,'(23$1(/ &21752/ 5,*+7 7567 ,& 7567 ,& 39 ,& $$ ,& &.0, 7&.
  • Page 78: D-Board (4 Of 7) Schematic Diagram

    TH-42PF11UK 12.28. D-Board (4 of 7) Schematic Diagram '%2$5' 713$%;6  5 5 5 5 (;%+9-9 (;%+9-9 (;%+9-9 (;%+9-9 5 (;%9-9 ,& 01 9,'(23$1(/ &21752/ 5,*+7 /5B'59&/.8 ,& '59&/.8 39 / /5$9''9 --+& /5B'59&/.8 ,& '59&/.8 5 &/.' ,& '59&/.8 39...
  • Page 79: D-Board (5 Of 7) Schematic Diagram

    TH-42PF11UK 12.29. D-Board (5 of 7) Schematic Diagram '%2$5' 713$%;6  ,& &$%4- ''56'5$0 ,& 01 ,& 966B7KHUPDO ,& 9664 ,& 9,'(23$1(/ &21752/ 5,*+7 ,& 966B7KHUPDO 39 ,& 9664 ,& ,& 966B7KHUPDO ,& 9664 ,& ''57HUPLQDWH ,& 966B7KHUPDO ,& 9664 ,& ,&...
  • Page 80: D-Board (6 Of 7) Schematic Diagram

    TH-42PF11UK 12.30. D-Board (6 of 7) Schematic Diagram ,& 7567 -7$* ,& 7567 ,& 01 '%2$5' 713$%;6  &.620, ,& &.0, 5 9,'(23$1(/ &21752/ /()7 &.026, 5 ,& &.02 & ,& $$ ,& &.6, 7&. ,& $% 7&. ; ,& &.62...
  • Page 81: D-Board (7 Of 7) Schematic Diagram

    TH-42PF11UK 12.31. D-Board (7 of 7) Schematic Diagram ,& '%2$5' 713$%;6  01 9,'(23$1(/ &21752/ /()7 ,& ,& ,& ,& $966B/ ,& ,& ,& ,& ,& $966B/ WR ''5 ''57HUPLQDWH ,& ,& ,& ,& $966B/ &$%4< ,& & ,& ,& $% ,&...
  • Page 82: C1-Board (1 Of 3) Schematic Diagram

    TH-42PF11UK 12.32. C1-Board (1 of 3) Schematic Diagram &%2$5' 7;1&5/78  =$ =$ .$'= .$'= & & & =$ =$ .$'= .$'= & 9'$B9 9'$B9 5 5 5 5 (;%9-9 (;%9-9 (;%9-9 (;%9-9 & & 9 9 X X & &...
  • Page 83: C1-Board (2 Of 3) Schematic Diagram

    TH-42PF11UK 12.33. C1-Board (2 of 3) Schematic Diagram &%2$5' 7;1&5/78  & '%2$5' 7(50 ' &B9 5 5 N 5 < 5 (;%9-9 (;%9-9 $%B1&/.5 < $%B&/.5 $%B1&/.5 < $%B&/.5 < $$B1&/.5 $$B&/.5 < 5 (;%9-9 $%B1&/.5 < $%B&/.5 < $%B1&/.5...
  • Page 84: C1-Board (3 Of 3) Schematic Diagram

    TH-42PF11UK 12.34. C1-Board (3 of 3) Schematic Diagram &%2$5' 7;1&5/78  & '%2$5' ' 7(50 &B9 5 &%2$5' & & 5 (;%9-9 < 5 9B'(7 (;%9-9 $%B1&/./ $$B1&/./ < $%B&/.5 $$B''$ $%B1&/.5 < ''$ $%B&/.5 $$B''% < ''% < $$B''& 5 ''&...
  • Page 85: C2-Board (1 Of 3) Schematic Diagram

    TH-42PF11UK 12.35. C2-Board (1 of 3) Schematic Diagram &%2$5' 7;1&5/78  '%2$5' & ' 7(50 &B9 5 5 5 N 9B'(7 9B'(7 &B9 $$B''$ ''$ $$B''% ''% $$B''& & ''& X $$B''$ ''$ $$B&/./ $$B''% ''% $$B1&/./ $%B&/./ < $$B''& $%B1&/./...
  • Page 86: C2-Board (2 Of 3) Schematic Diagram

    TH-42PF11UK 12.36. C2-Board (2 of 3) Schematic Diagram &%2$5' 7;1&5/78  &B9 &B9 & & X 66%2$5' $$B&/./ 66 $$B1&/./ $%B&/./ < $%B1&/./ $%B&/./ < $%B1&/./ < 5 < (;%9-9 $%B&/./ < $%B1&/./ $%B&/./ < $%B1&/./ <  *1' 5 <...
  • Page 87: C2-Board (3 Of 3) Schematic Diagram

    TH-42PF11UK 12.37. C2-Board (3 of 3) Schematic Diagram &%2$5' 7;1&5/78  =$ & =$ .$'= .$'= & 66%2$5' & 66 & & =$ 9'$B9 .$'= & 5 9 N =$ .$'= 9'$B9 9'$B9 5 5 5 5 (;%9-9 (;%9-9 (;%9-9 (;%9-9...
  • Page 88: Sc-Board (1 Of 3) Schematic Diagram

    TH-42PF11UK 12.38. SC-Board (1 of 3) Schematic Diagram ,& &&%$'& 9B) 9686 6&%2$5' 7XNSC1AYUU6  9287 5 5 5 ' & & &20 0$')/: X ' 0$')/: ,& &=%= 4 4 )(7 '5,9(5 %+)3)$ 3*53 ,& &6+&0+ *$7( 5 & 9 &-%$%...
  • Page 89: Sc-Board (2 Of 3) Schematic Diagram

    TH-42PF11UK 12.39. SC-Board (2 of 3) Schematic Diagram &2/' )/2$7,1* *1' 96(7 5 $$B&3+ 3& ' 5 0$=0/ %3%$ 4 9686 6&%2$5' 7XNSC1AYUU6  %&+30 5 $$B&(56 4 5 5 %&)+/ 3& & 5 ' %3%$ & & %(&.3 5...
  • Page 90: Sc-Board (3 Of 3) Schematic Diagram

    TH-42PF11UK 12.40. SC-Board (3 of 3) Schematic Diagram 9686 96(7 / ' 73 *&.$ %+&05 5 N 7396(7 5 626B6& N 96(79 5 5 5 5 N 5 5 73 $$B6,' N N 5 5 ' 73 5 $$B6,8 0$-/...
  • Page 91: Su-Board (1 Of 2) Schematic Diagram

    TH-42PF11UK 12.41. SU-Board (1 of 2) Schematic Diagram 68%2$5' 7;1685/78  7R VW SLQV RI 7R QG SLQV RI 6&$1 (/(&752'(6 6&$1 (/(&752'(6 &+$ 2&0 & $$B6,8 $$B2&8 $$B2&8 5 ' $$B/$78 0$;(/ $$B/$78 $%B $%B $&B $&B $'B $'B...
  • Page 92: Su-Board (2 Of 2) Schematic Diagram

    TH-42PF11UK 12.42. SU-Board (2 of 2) Schematic Diagram 68%2$5' 7;1685/78  7R UG SLQV RI 7R WK SLQV RI 6&$1 (/(&752'(6 6&$1 (/(&752'(6 $)B $)B $*B $*B $+B $+B $,B $,B $)B $)B $*B $*B $+B $+B $,B $,B $)B...
  • Page 93: Sd-Board (1 Of 3) Schematic Diagram

    TH-42PF11UK 12.43. SD-Board (1 of 3) Schematic Diagram 6'%2$5' 7;16'5/78  '2:1 7R VW SLQV RI 7R QG SLQV RI 6&$1 (/(&752'(6 6&$1 (/(&752'(6 $&B $&B $'B $'B $(B $(B $)B $)B $&B $&B $'B $'B $(B $(B $)B $)B $&B...
  • Page 94: Sd-Board (2 Of 3) Schematic Diagram

    TH-42PF11UK 12.44. SD-Board (2 of 3) Schematic Diagram 6'%2$5' 7;16'5/78  '2:1 7R UG SLQV RI 7R WK SLQV RI 6&$1 (/(&752'(6 6&$1 (/(&752'(6 $*B $*B $+B $+B $,B $,B $-B $-B $*B $*B $+B $+B $,B $,B $-B $-B...
  • Page 95: Sd-Board (3 Of 3) Schematic Diagram

    TH-42PF11UK 12.45. SD-Board (3 of 3) Schematic Diagram 6'%2$5' 7;16'5/78  6&%2$5' 6& 6' 5 $$B&/.' 5 $$B&/.' $$B&/.8 5 $$B&/.8 5 $$B2&8 5 $$B2&8 5 5 $$B2&' 5 9B)B$ 5 5 $$B2&' ,& $$B/$78 5 & 9B)B% 3& &-%$=...
  • Page 96: Ss-Board (1 Of 2) And S1-Board Schematic Diagram

    TH-42PF11UK 12.46. SS-Board (1 of 2) and S1-Board Schematic Diagram 96869 66%2$5' 7;166$<88  739686 66 / 3%2$5' *== 3 9686 9686 & & & & 5 9 9 9 9 X X X X 5 5 ' 5 0$-/ 4 &...
  • Page 97: Ss-Board (2 Of 2) Schematic Diagram

    TH-42PF11UK 12.47. SS-Board (2 of 2) Schematic Diagram 66%2$5' 7;166$<88  ' 73 0$;'/ 5 & N X 73 66 5 & N X ' 73 0$;'/ 5 & N X 73 3$1(/ 6867$,1 5 & (/(&752'( N X 5 &...
  • Page 98: Printed Circuit Board

    TH-42PF11UK 13 Printed Circuit Board 13.1. P-Board P-BOARD (FOIL SIDE) ETX2MM702MFH TH-42PF11UK TH-42PF11UK P-BOARD ETX2MM702MFH P-BOARD ETX2MM702MFH...
  • Page 99 TH-42PF11UK Parts Location Parts Location P-BOARD (FOIL SIDE) P-BOARD (COMPONENT SIDE) TRANSISTOR TRANSISTOR TRANSISTOR VOLUME TRANSISTOR TRANSISTOR TRANSISTOR VOLUME IC251 Q301 VR251 IC251 Q301 VR251 IC352 Q302 VR401 IC352 Q302 VR401 IC501 Q351 IC501 Q351 IC555 Q401 IC555 Q402 Q402...
  • Page 100 TH-42PF11UK P-BOARD (COMPONENT SIDE) ETX2MM702MFH TH-42PF11UK TH-42PF11UK P-BOARD ETX2MM702MFH P-BOARD ETX2MM702MFH...
  • Page 101: Pb-Board

    TH-42PF11UK 13.2. PB-Board Parts Location PB-BOARD (FOIL SIDE) PB-BOARD (COMPONENT SIDE) TEST POINT TRANSISTOR IC850 TPFAN IC850 Q850 TRANSISTOR Q850 PB-BOARD (FOIL SIDE) PB-BOARD (COMPONENT SIDE) TNPA3655AFS TNPA3655AFS TNPA3655 R 8 6 1 Q 8 5 0 R 8 6 1 O R D E R N O .
  • Page 102: V1, V2, S1 And H3-Board

    TH-42PF11UK 13.3. V1, V2, S1 and H3-Board V2-BOARD (FOIL SIDE) TNPA4601S V2-BOARD (COMPONENT SIDE) TNPA4601S V 1 5 V1-BOARD (FOIL SIDE) V1-BOARD (COMPONENT SIDE) TNPA4597S TNPA4597S R M 0 0 1 Q 1 5 4 0 D 1 5 5 4...
  • Page 103: Ha-Board

    TH-42PF11UK 13.4. HA-Board HA-BOARD (FOIL SIDE) HA-BOARD (COMPONENT SIDE) TXNHA1VBTU TXNHA1VBTU TNPA2845 ORDER TP034 TP036 CR NO.3 JS009 JS007 C022 JS008 R038 JS010 R040 R041 R042 IC002 C017 JS001 C018 C016 R037 C021 R036 JS004 C015 L007 C019 R035 JS002...
  • Page 104: Hx-Board

    TH-42PF11UK 13.5. HX-Board HX-BOARD (FOIL SIDE) TZTNP030VZT TNPA4489 Parts Location H X 1 S E E R E V E R S E F O R O R D E R N O . HX-BOARD (FOIL SIDE) J A 9...
  • Page 105: Hhh-Board

    TH-42PF11UK 13.6. HHH-Board HHH-BOARD (COMPONENT SIDE) HHH-BOARD (FOIL SIDE) TXNHHH1VBTU TXNHHH1VBTU C309 D325 D326 R577 D301 Q302 R560 C488 C301 C303 R578 C304 R559 R330 C498 R301 R561 C311 R431 R568 R594 D323 D311 D303 R325 D317 D306 C477 R331...
  • Page 106: Ds-Board

    TH-42PF11UK 13.7. DS-Board Parts Location DS-BOARD (FOIL SIDE) TRANSISTOR IC801 Q801 IC802 Q802 IC2305 Q803 IC3001 Q804 IC3007 Q807 IC3153 Q3002 IC8014 Q8010 IC8018 Q8011 Q8012 Q8013 Q8015 Q8020 Q8021 Q8022 Q8023 DS-BOARD (FOIL SIDE) TNPA4566 C 8 1 2 3...
  • Page 107 TH-42PF11UK Parts Location DS-BOARD (COMPONENT SIDE) TRANSISTOR TEST POINT IC803 Q805 TPJH1 IC804 Q806 TPJV1 IC805 Q2300 IC2301 Q2331 IC2302 Q2372 Q8002 IC2303 IC3002 Q8014 IC3003 Q8019 IC3005 Q8183 IC3006 Q8184 IC8005 Q8200 IC8007 Q8201 IC8008 Q8202 IC8017 IC8181 DS-BOARD (COMPONENT SIDE)
  • Page 108: Dn-Board

    TH-42PF11UK 13.8. DN-Board DN-BOARD (FOIL SIDE) TXNDN1VZTU C 9 2 6 C 9 2 7 R 0 4 7 C 2 6 0 C 2 4 3 T P 0 2 7 T P 0 2 8 C 2 6 3...
  • Page 109 TH-42PF11UK DN-BOARD (COMPONENT SIDE) TXNDN1VZTU C 1 9 7 R 7 2 5 C 4 6 8 D 0 0 2 D 0 0 1 C 3 0 1 D 0 5 7 C 0 3 8 R 0 4 4...
  • Page 110: D-Board

    TH-42PF11UK 13.9. D-Board D-BOARD (FOIL SIDE) TNPA4439BXS R 0 6 8 D 0 2 2 R 0 9 4 R 3 1 0 Q 0 5 6 R 0 7 8 R 0 9 5 R 0 7 3 R 1 1 1...
  • Page 111 TH-42PF11UK D-BOARD (COMPONENT SIDE) TNPA4439BXS C 5 5 1 R 2 8 0 Parts Location R 3 5 4 R 3 8 5 R 2 8 1 R 4 0 0 R 3 2 1 R 3 9 4 D-BOARD (COMPONENT SIDE)
  • Page 112: C1-Board

    TH-42PF11UK 13.10. C1-Board Parts Location C1-BOARD IC IC IC17101 IC17102 IC17103 C1-BOARD (FOIL SIDE) TXNC11RLTU TNPA4446 1 C1 S E E R E V E R S E F O R O R D E R N O . P b F...
  • Page 113: C2-Board

    TH-42PF11UK 13.11. C2-Board Parts Location C2-BOARD IC IC IC17201 IC17202 IC17203 IC17204 C2-BOARD (FOIL SIDE) TXNC21RLTU P b F T N P A 4 4 4 7 S E E R E V E R S E F O R O R D E R N O .
  • Page 114: Sc-Board

    TH-42PF11UK 13.12. SC-Board SC-BOARD (FOIL SIDE) TXNSC1AYUUS Z A 4 2 1 Z A 4 2 2 Z A 4 1 2 Z A 4 1 1 T P 3 5 T P 8 1 T P 7 8 T P 6 3...
  • Page 115 TH-42PF11UK 6& Parts Location Parts Location SC-BOARD (FOIL SIDE) SC-BOARD (COMPONENT SIDE) TEST POINT TRANSISTOR TEST POINT TP41 Q16667 TP42 Q16701 IC16784 IC16464 Q16401 TP43 Q16702 IC16786 IC16465 Q16402 TP46 TP44 Q16743 IC16471 Q16403 IC16788 TP82 TP45 Q16762 IC16791 IC16501...
  • Page 116 TH-42PF11UK SC-BOARD (COMPONENT SIDE) TXNSC1AYUUS Z A 4 1 2 Z A 4 2 1 Z A 4 1 1 C 7 7 3 Z A 4 2 2 R 8 8 6 H.V. DANGER H.V. DANGER H.V. DANGER H.V. DANGER...
  • Page 117: Su-Board

    TH-42PF11UK 13.13. SU-Board SU-BOARD (FOIL SIDE) TXNSU1RLTU C 9 2 9 SUMM1 C 9 0 7 C 3 5 0 C 3 4 8 C 9 0 2 Parts Location R 3 7 5 SU-BOARD R 3 8 7 1 0 0...
  • Page 118: Sd-Board

    TH-42PF11UK 13.14. SD-Board SD-BOARD (FOIL SIDE) TXNSD1RLTU R 9 8 6 SDMM1 P b F TNPA4413 C 9 7 8 S E E R E V E R S E F O R O R D E R N O .
  • Page 119: Ss-Board

    TH-42PF11UK 13.15. SS-Board Parts Location SS-BOARD (FOIL SIDE) TRANSISTOR TEST POINT TP25 TPSOS8 TP26 TPSS1 IC16301 TP27 TPVDA TP28 TPVe TRANSISTOR TP29 TPVe2 Q16001 TP30 TPVSUS Q16002 TP31 VOLUME Q16003 TP33 Q16021 TP34 VR16000 Q16022 TP36 TP10 Q16023 TP38 TP11...
  • Page 120 TH-42PF11UK Parts Location SS-BOARD (COMPONENT SIDE) TRANSISTOR TRANSISTOR TEST POINT Q16141 Q16161 IC16131 Q16001 TPSS1 Q16191 IC16151 Q16002 TPSOS8 Q16251 IC16241 Q16003 TPVDA Q16280 IC16251 Q16021 TPVe Q16301 IC16301 Q16022 TPVSUS Q16302 IC16302 Q16023 Q16304 IC16303 Q16024 Q16321 VOLUME Q16041...
  • Page 121: Exploded View And Replacement Parts List

    TH-42PF11UK 14 Exploded View and Replacement Parts List 14.1. Exploded View and Mechanical Replacement Parts List Please click the radio button for “Diagrams ll/Parts List” on the menu bar. 14.2. Electrical Replacement Parts List 14.2.1. Replacement Parts List Notes...
  • Page 122 TH-42PF11UK 14.2.2. Electrical Replacement Parts List Safety Ref. Part No. Part Name & Pcs Remarks Description Safety Ref. Part No. Part Name & Pcs Remarks C357 ACKZE1E471ST ELECTROLYTIC Description CAPACITOR C358 ACKZE1E471ST ELECTROLYTIC F201 HU216005BEP CARTRIDGE CAPACITOR FUSE(LEADTYPE) C401 ECQE2104SKF...
  • Page 123 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C701 ACKZE1A471C ELECTROLYTIC C2356 ECJ1VB1H102K 1000PF, K, CAPACITOR C702 ECQV1H103JL2 0.01UF, J, C2357 ECJ1VB1H102K 1000PF, K, C703 ECQV1H224JL 0.22UF, J,...
  • Page 124 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C3012 F1H1H103A975 C 0.001UF, K, C3205 F1H1C104A144 0.1UF, K, 16V C3207 F1K1C1060004 C 0.010UF, C3013 F1H1H103A975 C 0.001UF, K,...
  • Page 125 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C3351 F1G1C104A077 0.10UF, K, C3405 ECJ1VB1A105K 0.01UF, Z, C3353 F1G1C104A077 0.10UF, K, C3405 ECJ3YB1E106M 10 UF, K, 25V C3406...
  • Page 126 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C3444 F1G1C104A077 0.10UF, K, C3494 F1G1C104A077 0.10UF, K, C3445 F1G1C104A077 0.10UF, K, C3495 F1G1C104A077 0.10UF, K, C3446 ECJ1VB1H102K 1000PF, K,...
  • Page 127 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C3544 F1G1C104A077 0.10UF, K, C4106 F1J1E104A227 0.10UF, Z, C3545 F1G1C104A077 0.10UF, K, C4108 F1H1C103A143 0.10UF, C4109 F1J1E104A227 0.10UF, Z,...
  • Page 128 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C4194 F1H1H9R0A972 9.0UF, C4272 F1H1C104A143 0.1UF, K, 16V C4273 F1H1C104A143 0.1UF, K, 16V C4195 EEEHB0G221P 220PF, J, 4V C4274 F1H1C104A143 0.1UF, K, 16V...
  • Page 129 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C4383 F1G1A104A012 C 0.01UF, K, C8114 ECJ3YB1E106M 10 UF, K, 25V C8115 ECJ3YB1E106M 10 UF, K, 25V C4386 F1G1A104A012 C 0.01UF, K,...
  • Page 130 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C9120 F1G1C104A116 0.10UF, K, C9170 F1G1C104A116 0.10UF, K, C9121 F1G1C104A116 0.10UF, K, C9171 F1G1C104A116 0.10UF, K, C9122 F1G1C104A116 0.10UF, K,...
  • Page 131 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C9211 F1G1C104A116 0.10UF, K, C9537 F1G1C104A116 0.10UF, K, C9212 F1J1A106A043 C 0.010UF, K, C9538 F1G1C104A116 0.10UF, K, C9213 F1G1C104A116 0.10UF, K,...
  • Page 132 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C9882 F1G1C822A116 8200UF, K, C14922 F1L2E104A028 1000UF, C14923 F1L2E104A028 1000UF, C9883 F1G1H101A731 100PF, K, 50V C14925 F1L2E104A028 1000UF, C9884...
  • Page 133 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C16242 F1H1C105A008 1UF, K, 16V C16593 F1H1H102A971 1000PF, K, C16243 F1H1H103A970 C 0.001UF, K, C16602 F1H1H220A971 22PF, K, 50V...
  • Page 134 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description C16862 F1H1C104A143 0.1UF, K, 16V C17246 F1H1C104A143 0.1UF, K, 16V C16864 ECJ1VB1H104K 0.1UF, K, 50V C17247 F1H1C104A143 0.1UF, K, 16V...
  • Page 135 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description D853 MA165TA5 DIODE D4030 MA152K DIODE D854 MA165TA5 DIODE D4031 MA152K DIODE D856 MA165TA5 DIODE D4032 MA152K DIODE D1550...
  • Page 136 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description D16041 MA3DF46000LW ZENER DIODE D16660 B0HCMM000014 DIODE D16042 MA3DF46000LW ZENER DIODE D16661 MA2J11100L DIODE D16050 B0ECKP000047 DIODE D16662 MAZ81500ML...
  • Page 137 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description FL3000 F1J1E104A148 0.10UF, Z, IC251 AN1431TBTA INTEGRATED CIR- CUIT FL3001 F1J1E104A148 0.10UF, Z, IC352 AN1431TBTA INTEGRATED CIR- CUIT FL3003 F1J1E104A148 0.10UF, Z,...
  • Page 138 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description IC4904 C0DBAYY00183 IC16801 C0DBEYY00078 IC8005 C0JBAB000646 IC17101 C0JBAZ001120 IC8007 C0JBAR000419 IC17102 C0JBAZ001120 IC8008 C0JBAS000251 IC17103 C0JBAZ001120 IC8014 C0ZBZ0001361 IC17201 C0JBAZ001120...
  • Page 139 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description L1508 J0JHC0000078 CHIP INDUCTOR L4025 J0JHC0000096 CHIP INDUCTOR L2330 G0A221ZA0041 CHOKE COIL L4027 J0JHC0000096 CHIP INDUCTOR L2331 G0A221ZA0041 CHOKE COIL...
  • Page 140 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description MC602 MP00P33 MODULE Q301 VKFMA16N55G FIELD EFFECT TRANSISTOR MC603 MP00P30 MODULE Q302 VKFMA16N55G FIELD EFFECT MC701 MDPZDA101 MODULE TRANSISTOR...
  • Page 141 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description Q8202 2SD0601ARL TRANSISTOR Q16801 B1ADCN000007 TRANSISTOR Q9010 2SD0601ARL TRANSISTOR Q16805 2SC3063000RL TRANSISTOR Q9058 2SD0601ARL TRANSISTOR Q16806 2SC1473AEA TRANSISTOR Q9059...
  • Page 142 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R356 ER0S2THD1021 METAL FILM R601 ARRCR5J624M METAL GLAZE RESISTOR FIXED RESISTOR R359 ER0S2THD5361 METAL FILM R603 ARRCR1F3093T METAL GLAZE...
  • Page 143 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R819 ERJ3GEYD512V M 5.1KOHM,J,1/ R1510 ERJ3GEYD222V M 2.2KOHM,J,1/ R820 D0GB682JA041 M 6.8KOHM,J,1/ R1511 ERJ3GEYF302 M 3.0KOHM, R821 D1BB2612A055 M26.1KOHM,...
  • Page 144 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R2398 D0GBR00Z0002 M 0 OHM J 1/16W R3029 D0GB103JA041 M 10K OHM J 1/ R2399 ERJ3GEYJ220 22 OHM,J,1/ R3030...
  • Page 145 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R3077 ERJ3GEYJ560 56 OHM,J,1/ R3205 D0GB220JA041 22 OHM J 1/10W R3206 D0GB220JA041 22 OHM J 1/10W R3078 ERJ3GEYJ560 56 OHM,J,1/...
  • Page 146 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R3332 ERJ3GEYJ472 M 4.7KOHM,J,1/ R3398 ERJ3GEYJ472 M 4.7KOHM,J,1/ R3339 ERJ3GEYJ472 M 4.7KOHM,J,1/ R3399 ERJ3GEYJ220 22 OHM,J,1/ R3340 ERJ3GEYJ560 56 OHM,J,1/...
  • Page 147 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R3450 ERJ3GEYJ101 M 100 OHM,J,1/ R3501 EXB2HV473JV RESISTOR ARRAY R3502 ERJ3GEY0R00 0 OHM, 1/16W R3451 ERJ3GEYJ330 33 OHM,J,1/ R3503...
  • Page 148 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R3537 D0GB102JA057 1KOHM,J,1/ R3578 ERJ3GEY0R00 0 OHM, 1/16W R3579 D0GB473JA057 47KOHM,J,1/ R3538 ERJ3GEYJ101 M 100 OHM,J,1/ R3580 D0GB473JA057 47KOHM,J,1/...
  • Page 149 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R3615 D0GB103JA057 M 10K OHM J 1/ R3777 D0GD101JA036 M 100 OHM,J,0.25W R3616 D0GB473JA057 47KOHM,J,1/ R3778 D0GD473JA036 47KOHM,J,1/ R3617...
  • Page 150 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R4061 D0GBR00Z0002 M 0 OHM J 1/16W R4106 D0GB101JA041 M 100 OHM,J,1/ R4062 D0GB101JA041 M 100 OHM,J,1/ R4107 D0GB101JA041...
  • Page 151 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R4175 ERJ3GEYJ470 47 OHM,J,1/ R4218 D0GB101JA041 M 100 OHM,J,1/ R4176 ERJ3GEYJ470 47 OHM,J,1/ R4219 EXB2HV101J RESISTOR ARRAY R4220 EXB2HV101J...
  • Page 152 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R4262 D0GB101JA041 M 100 OHM,J,1/ R4313 D0GB103JA041 M 10K OHM J 1/ R4263 D0GB101JA041 M 100 OHM,J,1/ R4314 EXB38V101JV...
  • Page 153 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R4372 D0GB103JA041 M 10K OHM J 1/ R4469 EXB28V220J RESISTOR ARRAY R4470 ERJ3GEYJ220 22 OHM,J,1/ R4377 D0GBR00Z0002 M 0 OHM J 1/16W...
  • Page 154 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R4564 ERJ3GEYJ682 M 6.8KOHM,J,1/ R8007 D0GDR00Z0002 0 OHM, 1/10W R8009 D0GBR00Z0002 M 0 OHM J 1/16W R4566 D0GB101JA041 M 100 OHM,J,1/...
  • Page 155 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R8110 D0GB103JA041 M 10K OHM J 1/ R9121 ERJ2GEJ104 M 100KOHM, J,0.063W R8111 ERJ3GEYJ122 M 1.2KOHM,J,1/ R9122 ERJ2GEJ332 M 3.3KOHM, J,0.063W...
  • Page 156 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R9174 ERJ2GEJ102X OHM J R9224 ERJ2GEJ220 22 OHM, J,0.063W R9175 ERJ2GEJ101 M 100 OHM, R9225 ERJ2RHD272 2.7KOHM, J, J,0.063W...
  • Page 157 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R9295 ERJ2GEJ101 M 100 OHM, R9578 ERJ2GEJ472 M 4.7KOHM, J,0.063W J,0.063W R9296 ERJ2GEJ101 M 100 OHM, R9599 ERJ2GEJ680 68 OHM, J,0.063W...
  • Page 158 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R9952 ERJ2GEJ470 47 OHM, R14907 ERJ3GEYJ220 22 OHM,J,1/ J,0.063W R9953 ERJ2GEJ470 47 OHM, R14908 ERJ3GEYJ220 22 OHM,J,1/ J,0.063W R9954...
  • Page 159 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R14962 ERJ6GEYJ331V 330 OHM J 1/ R16041 ERJT08J5R6V M 5.6 OHM,F,0.33W R14963 ERJ6GEYJ331V 330 OHM J 1/ R16051 ERJT08J5R6V M 5.6...
  • Page 160 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R16242 EXB38V472JV RESISTOR ARRAY R16331 ERJT06J101V M 100 OHM,F,0.25W R16251 ERJ6ENF1401 M 1.4KOHM, R16333 ERJ6ENF3303 M 330KOHM, R16252 ERJ6ENF3902...
  • Page 161 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R16511 ERJ6GEYF473 47KOHM,J,1/ R16606 D0GD103JA036 10KOHM,J,0.25W R16512 ERJ6GEYF473 47KOHM,J,1/ R16607 ERJ6ENF7151 M7.15KOHM, R16513 ERJ6GEYF473 47KOHM,J,1/ R16608 ERJT08J102V 1KOHM,J, 0.33W...
  • Page 162 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R16702 ERJ6GEYJ332V M 3.3K OHM J 1/ R16775 ERJ6GEYJ472V M 4.7K OHM J 1/ R16703 D0GD103JA036 R16776 D0GD101JA036 M 100 10KOHM,J,0.25W...
  • Page 163 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description R16867 ERJ6GEYF473 47KOHM,J,1/ R17204 ERJT14J6R8U C6.8 OHM, J,1/4W R17205 ERJT14J6R8U C6.8 OHM, J,1/4W R16869 ERJ8GEYJ473 47KOHM, J,1/ R17207 EXB38V471J...
  • Page 164 TH-42PF11UK Safety Ref. Part No. Part Name & Pcs Remarks Safety Ref. Part No. Part Name & Pcs Remarks Description Description K1MND6BA0264 6P CONNECTOR ZA3007 K4CD01000013 AV TERMINAL SD11 K1MN20BA0231 20P CONNECTOR ZA3008 K4CD01000011 AV TERMINAL SD42 K1KB23AA0234 23P CONNECTOR...
  • Page 165: Schematic Diagram For Printing With Letter Size

    Model No. : 42PF11UK Note...
  • Page 166 Model No. : 42PF11UK Exploded View...
  • Page 167 Model No. : 42PF11UK Cabinet part location...
  • Page 168 Model No. : 42PF11UK Fan part location...
  • Page 169 Model No. : 42PF11UK Flat cable...
  • Page 170 Model No. : 42PF11UK Accessories...
  • Page 171 Q'ty Remarks EUR7636070R REMOTE CONTROLER K2CG3YY00023 AC CORD L6FAYYYH0050 FAN(80MM-T25) L6FAYYYH0051 FAN UNIT(60MM) MD42F11S1J PLASMA DISPLAY PANEL TBMA226 PANASONIC BADGE TBXA46704A 5KEY BUTTON TBXA54001 POWER BUTTON TESD031 POWER BUTTON SPRING TKGA5475S FRONT GLASS 1 PAVCA TKKC5213-1 LED PANEL TKKC5276 REMOTE SENSOR PANEL...
  • Page 172 Model No. : 42PF11UK Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks TSXL490 CABLE (DS1-DN1/DS3-DN2) TSXL519 CABLE (SU11-SD11) TSXL597 CABLE (C10-C20) TSXL657 CABLE ASSY (D20-SC20) 1 PAVCA TSXL660 CABLE (D31-C11/D32-C12/D33-C21) TUXK058 REAR COVER SPACER RING 4 PAVCA TXALK01VZTU INLET ASSY 1 PAVCA...

Table of Contents
