SITRANS P
Pressure transmitter
SITRANS P220
Compact Operating Instructions
7MF1567-.....-....
02/2019
A5E03304437-AB
Introduction
Safety instructions
Description
Installing/mounting
Connecting
Commissioning
Service and maintenance
Technical specifications
Dimension drawings
Appendix A
1
2
3
4
5
6
7
8
9
A
Advertisement
Table of Contents
Related Manuals for Siemens SITRANS P Series
Summary of Contents for Siemens SITRANS P Series
- Page 1 Introduction Safety instructions Description SITRANS P Installing/mounting Pressure transmitter SITRANS P220 Connecting Commissioning Compact Operating Instructions Service and maintenance Technical specifications Dimension drawings Appendix A 7MF1567-..-..02/2019 A5E03304437-AB...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Table of contents Introduction..............................5 Purpose of this documentation....................5 Checking the consignment.......................5 Transportation and storage ......................6 Notes on warranty ........................6 Safety instructions ............................7 Prerequisites for safe use ......................7 2.1.1 Laws and directives........................7 2.1.2 Conformity with European directives..................7 Improper device modifications ....................8 Requirements for special applications ..................8 Use in hazardous areas ......................8 Description..............................11... - Page 4 Table of contents Technical specifications..........................27 Dimension drawings ...........................31 Dimensional drawings electrical connections.................31 Dimensional drawings process connections ................31 Appendix A ..............................33 Technical support........................33 Certificates ..........................34 Index................................35 SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
-
Page 5: Introduction
Introduction Purpose of this documentation These instructions contain all information required to commission and use the device. Read the instructions carefully prior to installation and commissioning. In order to use the device correctly, first review its principle of operation. The instructions are aimed at persons mechanically installing the device, connecting it electronically, configuring the parameters and commissioning it, as well as service and maintenance engineers. -
Page 6: Transportation And Storage
The content reflects the technical status at the time of publishing. Siemens reserves the right to make technical changes in the course of further development. -
Page 7: Safety Instructions
Safety instructions Prerequisites for safe use This device left the factory in good working condition. In order to maintain this status and to ensure safe operation of the device, observe these instructions and all the specifications relevant to safety. Observe the information and symbols on the device. Do not remove any information or symbols from the device. -
Page 8: Improper Device Modifications
If you need additional information not covered by these instructions, contact your local Siemens office or company representative. Note Operation under special ambient conditions... - Page 9 Safety instructions 2.4 Use in hazardous areas WARNING Use in hazardous area Risk of explosion. ● Only use equipment that is approved for use in the intended hazardous area and labelled accordingly. ● Don't use devices that have been operated outside the conditions secified for hazardous areas.
- Page 10 Safety instructions 2.4 Use in hazardous areas SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
-
Page 11: Description
Description Application The pressure transmitter P220, Type 7MF1567, is used for measuring the relative pressure and absolute pressure of gases and liquids in the following industrial areas: ● Mechanical engineering ● Power engineering ● Water supply ● Shipbuilding ● Chemical industry ●... -
Page 12: Layout Of The Nameplate
Description 3.3 Layout of the nameplate 7MF1567 with cable (2 m) ● Type 7MF1567-*****-3**1 7MF1567 with fast-fit cable gland ● Type 7MF1567-*****-4**1 Device structure without explosion protection The pressure transmitter consists of a piezo-resistive measuring cell with a diaphragm installed in a stainless steel enclosure. - Page 13 Description 3.3 Layout of the nameplate Decoding for year, month and day information Code Year 2010 2011 2012 2013 2014 2015 H (G) 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 Code Month January February March April...
- Page 14 Description 3.3 Layout of the nameplate The letter G is not permitted for new applications since it deviates from DIN EN 60062. It serves only for coding back. SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
-
Page 15: Installing/Mounting
Refer to the information in Technical specifications (Page 27). Note Material compatibility Siemens can provide you with support concerning selection of sensor components wetted by process media. However, you are responsible for the selection of components. Siemens accepts no liability for faults or failures resulting from incompatible materials. -
Page 16: Additional Notes On Installation Of Explosion Protection Devices
Installing/mounting 4.3 Installation Additional notes on installation of explosion protection devices The following specifications are to be observed for the types 7MF1567-***01-1**1, 7MF1567- ***01-2**1, and 7MF1567-***01-5**1 : Operation is permitted only when connected to certified intrinsically-safe resistive circuits with the following maximum values: ≤... -
Page 17: Connecting
Connecting Basic safety instructions WARNING Unsuitable cables, cable glands and / plug-in connectors Danger of explosion in hazardous areas. ● Only use cable glands/plug-in connectors that fulfill the requirements of the relevant type of protection. ● Only use cables that have been designed for an ambient temperature of at least 20 K higher. - Page 18 Connecting 5.1 Basic safety instructions WARNING Unprotected cable ends Risk of explosion through unprotected cable ends in hazardous areas. ● Protect unused cable ends in accordance with IEC/EN 60079-14. WARNING Connecting device in an energized state / Disconnecting device from power supply in an energized state Risk of explosion in hazardous areas.
-
Page 19: Electrical Connections
Connecting 5.2 Electrical connections Electrical connections Legend Output current Auxiliary power Output voltage Grounding Load Connecting with current output and connector in accordance Connecting with voltage output and connector in accordance with EN 175301 with EN 175301 Connecting with current output and connector M12x1 Connecting with voltage output and connector M12x1 Connecting with current output and cable Connecting with voltage output and cable... - Page 20 Connecting 5.2 Electrical connections Version with explosion protection: 4 to 20 mA The grounding connection is conductively bonded to the transmitter enclosure. Connecting with current output and connector in accordance with EN 175301 (Ex) Connecting with current output and connector M12x1 (Ex) SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
-
Page 21: Commissioning
Commissioning WARNING Improper commissioning in hazardous areas Device failure or risk of explosion in hazardous areas. ● Do not commission the device until it has been mounted completely and connected in accordance with the information in Technical specifications (Page 27). ●... - Page 22 Commissioning 6.1 Correction of zero point and span SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
-
Page 23: Service And Maintenance
WARNING Impermissible repair of explosion protected devices Risk of explosion in hazardous areas ● Repair must be carried out by Siemens authorized personnel only. WARNING Use of a computer in a hazardous area If the interface to the computer is used in the hazardous area, there is a risk of explosion. -
Page 24: Return Procedure
Enclose the bill of lading, return document and decontamination certificate in a clear plastic pouch and attach it firmly to the outside of the packaging. Required forms ● Delivery note ● Return document (http://www.siemens.com/processinstrumentation/returngoodsnote) with the following information: – Product (item description) – Number of returned devices/replacement parts –... -
Page 25: Disposal
Further information about devices containing batteries can be found at: In‐ formation on battery/product return (WEEE) (https:// support.industry.siemens.com/cs/document/109479891/) Note Special disposal required The device includes components that require special disposal. ● Dispose of the device properly and environmentally through a local waste disposal contractor. - Page 26 Service and maintenance 7.5 Disposal SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
-
Page 27: Technical Specifications
Technical specifications Mode of operation Measuring range ≥ 2.5 ... ≤ 600 bar Piezo-resistive with stainless steel diaphragm Input Measured variable input Measuring range for relative Overload limit Burst pressure pressure 0 ... 2.5 bar g ≥ -0.8 / ≤ 6.25 bar g 25 bar g 0 ... - Page 28 Technical specifications Input 0 ... 6000 psi g ≥ -14.5 / ≤ 14000 psi g 34800 psi g 0 ... 8700 psi g ≥ -14.5 / ≤ 21755 psi g 36250 psi g 0 ... 14500 psi g ≥ -14.5 / ≤ 21755 psi g 36250 psi g Output Current signal...
- Page 29 Technical specifications Rated conditions Degree of protection (to EN 60529) ● IP65 with connector to EN 175301-803-A ● IP67 with M12 connector ● IP67 with cable ● IP67 with fast-fit cable gland Electromagnetic compatibility ● To EN 61326-1 ● To EN 61326-2-3 ●...
- Page 30 Technical specifications Explosion protection acc. to cCSAus; 7MF1567-..1-..-Z; E21C Identification IS; Ex n; Ex ic; A/Ex nA CL I, DIV 1, GP ABCD T4 ... T6; CL II, DIV 1, GP EFG; CL III; Ex ia IIC T4 ... T6: CL I, DIV 2, GP ABCD T4 ...
-
Page 31: Dimension Drawings
Dimension drawings Dimensional drawings electrical connections 36 (1.42) M12x1/Fixcon M16x1.5 or 0.5-14 NPT Dimensional drawings process connections Figure 9-1 Max. 30 Nm SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB... - Page 32 Dimension drawings 9.2 Dimensional drawings process connections Figure 9-2 Max. 20 Nm Figure 9-3 Max. 20 Nm Figure 9-4 Max. 20 Nm; Pmax ≤ 60 bar SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
-
Page 33: Technical Support
In addition to our documentation, Siemens provides a comprehensive support solution at: ● Service&Support (http://www.siemens.com/automation/service&support) Personal contact If you have additional questions about the device, please contact your Siemens personal contact at: ● Partner (http://www.automation.siemens.com/partner) In order to find the contact for your product, select under 'All Products and Branches' the path 'Automation Technology >... -
Page 34: Certificates
Appendix A A.2 Certificates Certificates You can find certificates on the Internet at Certificates (http://www.siemens.com/ processinstrumentation/certificates) or on an included DVD. SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB... -
Page 35: Index
Index Certificates, 7, 34 Test certificates, 7 Customer Support Hotline, 33 Warranty, 6 Hazardous area Laws and directives, 7 Qualified personnel, 8 Hotline, 33 Internet, 33 Laws and directives Disassembly, 7 Personell, 7 Modifications correct usage, 8 improper, 8 Qualified personnel, 8 Return procedure, 24 Scope of delivery, 5 Service, 33... - Page 36 Index SITRANS P220 Compact Operating Instructions, 02/2019, A5E03304437-AB...
