USB Hub 2040x

Use
- Providing a desktop PC or notebook with three further USB ports
A-type connector
Fig.: Detailed view of the USB ports
In order to connect several USB devices to a computer it is necessary to have the corresponding
number of USB ports. By using a hub you can increase one port to four ports. Take the connector cable
from the underside of the USB hub and insert it into a free USB port on your computer. If necessary,
make the connector cable longer with the USB extension cable.
The USB hub is an active component which requires the installation of a driver upon first use. This
® ®
occurs automatically under Microsoft Windows Vista™, Windows XP or Windows 2000 operating
systems (see page 6 - Procedure).
After the driver has been installed you will now have four ports on the USB hub where you can connect
any USB device.
