Reviewing crimps

Viewing data

• Select job site (Figure 05)

• Select crimp to review from crimp list (Figure 06)

Note: If no crimp data is available, data can be transferred from the tool or downloaded from the cloud (if

previously uploaded to the cloud.)

—

Inspecting and approving crimps

• When logged in as an inspector, select Data Exchange (Figure 07)

• Select Download Data (Figure 07)

• Select job site to review

• Once data is downloaded on the mobile device, select crimp from crimp list

• Review crimp and under the Edit Crimp Data section, select Approved,

Rejected, or None (Figure 09)

• Select Close to apply changes (Figure 10)

• To upload changes to the cloud, select:

Data Exchange

Upload Data

Select Job Site

Intro

Scan

Transfer

Review

Upload
