Installation Procedures

Important: Install the WLAN Adapter utilities before inserting the WLAN
Adapter into your computer.
Installing the WLAN utilities and driver
Follow these instructions to install the
WLAN Adapter utilities and driver. Insert
the support CD into your optical drive.
If autorun is enabled in your computer,
the CD automatically displays the utility
matically displays the utility
menu. Click Install ASUS WLAN Card
Utilities/Driver. If autorun is disabled,
double-click SETUP.EXE in the root
directory of the CD.
Insert the WLAN Adapter into your computer
's USB port using the correct orientation.
Windows will automatically detect and
configure the WLAN Adapter using the
utilities and drivers installed in the previous
steps.
Reading the WLAN status indicators
The device comes with two LEDs that indicate the status of the WLAN
Adapter.
ACT LED
Blinking: Transmitting data; the blinking
speed indicates the link speed.
OFF:
Radio off or Adapter is disabled.
LINK LED
ON:
Connected to wireless device.
OFF:
No wireless connection.
ASUS Super Speed N Wireless USB Adapter

Quick Start Guide

Windows XP users: When the program is
launched for the first time (during Windows
restart), you are asked to choose one utility
to configure the WLAN Adapter. Select "Only
use our WLAN utilities and disable Windows
wireless function".
ACT
LINK
