SCALANCE X-400
SIMATIC NET
Industrial Ethernet switches
SCALANCE X-400
Operating Instructions
06/2015
C79000-G8976-C186-12
___________________
Introduction
___________________
Safety instructions
___________________
Description
___________________
Installation
___________________
Connecting
___________________
Configuration / project
engineering
___________________
Approvals
___________________
Technical specifications
___________________
Dimension drawings
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents
loading

Related Manuals for Siemens SCALANCE X-400

Summary of Contents for Siemens SCALANCE X-400

  • Page 1 ___________________ SCALANCE X-400 Introduction ___________________ Safety instructions ___________________ SIMATIC NET Description ___________________ Installation Industrial Ethernet switches SCALANCE X-400 ___________________ Connecting ___________________ Configuration / project engineering Operating Instructions ___________________ Approvals ___________________ Technical specifications ___________________ Dimension drawings 06/2015 C79000-G8976-C186-12...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    SCALANCE X408-2 ports ....................... 49 3.4.4 X-400 media modules ......................51 3.4.4.1 Overview of the media modules for SCALANCE X-400 ............51 3.4.4.2 Fast Ethernet media module MM491-2 (100Base-FX) ............55 3.4.4.3 Fast Ethernet media module MM491-2LD (100Base-FX) ............56 3.4.4.4...
  • Page 4 Connecting ............................99 Safety when connecting up ....................99 Ports ............................. 101 5.2.1 Connectors of the power supply (X1) of the SCALANCE X-400 ......... 101 5.2.2 Connectors of the signaling contact and grounding strap (X2) of the SCALANCE X- 400 ............................102 5.2.3...
  • Page 5 Media module MM492-2LH+ (1000Base-LX) - technical specifications ....... 150 Media module MM492-2ELH (1000Base-LX) - technical specifications ......151 8.10 Extender module EM495-8 - technical specifications ............152 8.11 Extender module EM496-4 - technical specifications ............153 Dimension drawings ..........................155 Index..............................163 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 6 Table of contents SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 7: Introduction

    Introduction Preface X400 Purpose of the Operating Instructions These Operating Instructions describe the functions of the SCALANCE X-400 product line of modular Industrial Ethernet switches and support you during installation, commissioning, and troubleshooting on site. separate Configuration Manual - SCALANCE...
  • Page 8 The descriptions in these operating instructions always apply to the devices of the SCALANCE X-400 product line listed under "Validity of the Operating Instructions" in this document unless the description relates to a specific device of the product line. In the remainder of the description, the devices are called IE Switches X-400.
  • Page 9 ● On the data medium that ships with some products: – Product CD / product DVD – SIMATIC NET Manual Collection ● On the Internet pages of Siemens Industry Online Support under the following entry IDs: – 27069465 (http://support.automation.siemens.com/WW/view/en/27069465) Industrial Ethernet / PROFINET Industrial Ethernet System Manual –...
  • Page 10 Introduction 1.1 Preface X400 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 11: Safety Instructions

    This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non- hazardous locations only. This equipment is suitable for use in Class I, Zone 2, Group IIC or non-hazardous locations only. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 12 Safety instructions SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 13: Description

    Due to support of IT standards such as VLAN, RSTP, IGMP, and GARP makes seamless integration of automation networks in existing office networks possible. The devices are designed for use in switching cubicles and cabinets. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 14 As a result, a functional, end-to-end structure is restored. For more detailed information, refer to the configuration manual "SCALANCE X-300 and SCALANCE X-400 Industrial Ethernet Switches". SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 15: Network Topologies

    With the fault mask, it is possible to monitor the port states using the signaling contact. In addition to interconnecting the switches, it is also possible to connect one or more end devices to every IE Switch X-400. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 16 Description 3.2 Network topologies Configuration example Sample configuration with SCALANCE X414-3E, SIMATIC S7-300/400 and operator panel as end devices. Figure 3-1 Linear structure (optical) SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 17: Star/Tree Structure

    With the fault mask, it is possible to monitor the port states using the signaling contact. In addition to connecting the switches to the central IE Switch X-400, it is also possible to connect one or more end devices. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 18 Description 3.2 Network topologies Configuration example Sample configurations electrical / optical with SCALANCE X-400, SCALANCE X-200, SIMATIC S7-300/400, SIMATIC ET 200, and operator panels as end devices. Figure 3-2 Star structure (electrical) SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 19: Ring With Redundancy Manager

    For more detailed information, refer to the config- uration manual "Industrial Ethernet Switches SCALANCE X-300 SCALANCE X-400". In contrast to the ring ports of the other switches, the ring ports of the redundancy manager are disconnected when the network is operating problem-free. The IE Switch X-400 operating in the redundancy manager mode monitors the connected bus over its ring ports and switches the ring ports through if there is an interruption on the connected bus;...
  • Page 20 Optical ring with redundancy manager (on the slots) Media module SCALANCE X414-3E SCALANCE X408-2 Gigabit MM492-2, MM492-2LD, 5 and 6 MM492-2LH, MM492-2LH+ or MM492-2ELH Fast Ethernet MM491-2, MM491-2LD or 6 and 7 5 and 6 MM491-2LH+ SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 21 FO cable. Configuration example Sample configurations with SCALANCE X-400, SIMATIC S7-200/300/400, operator control and monitoring system, H system, and PC as end devices. Figure 3-4...

  • Page 22: Options Of Media Redundancy

    There are various options available to increase the network availability of an Industrial Ethernet network with optical or electrical linear bus topologies: ● Mesh networks ● Parallel connection of transmission paths ● Closing a linear bus topology to form a ring topology SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 23: Media Redundancy In Ring Topologies

    1 and ring port 2. The test frames run round the ring in both directions until they arrive at the other ring port of the redundancy manager. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 24 ● HRP (High Speed Redundancy Protocol) Reconfiguration time: 0.3 seconds ● MRP (Media Redundancy Protocol) Reconfiguration time: 0.2 seconds The mechanisms of these methods are similar. HRP and MRP cannot be used in the ring at the same time. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 25: Redundant Coupling Of Network Segments

    This configuration is set in Web Based Management, Command Line Interface or using SNMP access. For more detailed information, refer to the configuration manual "SCALANCE X-300 and SCALANCE X-400 Industrial Ethernet Switches". The two devices connected in the configuration exchange data frames with each other to synchronize their operating statuses (one device is master and the other slave).

  • Page 26: System Description Of Scalance X-400

    System description of SCALANCE X-400 3.3.1 Properties, functionality and features of SCALANCE X-400 This chapter explains special properties, features, and options available to you with IE Switches X-400. The basic device always consists of the frame, the power supply and a CPU module. The basic device of the SCALANCE X414-3E has additional digital signal inputs.
  • Page 27 Description 3.3 System description of SCALANCE X-400 Components of the IE Switches X-400 The following table shows the components of the IE Switches X-400: Component Function Figure SCALANCE X414-3E IE Switch with management basic device functions and 12 Fast Ethernet RJ-45 •...
  • Page 28 Description 3.3 System description of SCALANCE X-400 Component Function Figure Media module Expands the basic device by two Fast Ethernet 100 Mbps fiber-optic ports. MM491-2, MM491-2LD (as of product version ES04), MM491-2LH+ Only for SCALANCE X414-3E Expands the basic device...

  • Page 29: Ports Of Scalance X-400

    Description 3.3 System description of SCALANCE X-400 3.3.2 Ports of SCALANCE X-400 Ports IE Switches X-400 provide you with electrical ports that can be used as gigabit and ring ports. The expansion with media modules provides you with additional optical ports.

  • Page 30: 1000Base-T

    Description 3.3 System description of SCALANCE X-400 Transmission range The maximum transmission range (segment length) is 100 m. Connectors The connectors used are 8-pin RJ-45 jacks with securing collars. The securing collar in conjunction with the cover ensures a flush fit and the locking mechanism with the...

  • Page 31: 100Base-Fx

    Description 3.3 System description of SCALANCE X-400 3.3.2.3 100Base-FX Transmission rate The transmission rate of the optical Fast Ethernet ports is 100 Mbps. Transmission mode Transmission with 100Base-FX is defined in the IEEE 802.3u standard and is specified as 100 Mbps transmission rate and full duplex.

  • Page 32: 1000Base-Sx

    Description 3.3 System description of SCALANCE X-400 3.3.2.4 1000Base-SX Transmission rate The transmission rate of the optical gigabit ports is 1 Gbps. Transmission mode Transmission with 1000Base-SX is defined in the IEEE 802.3z standard and is specified as 1000 Mbps transmission rate and full duplex.

  • Page 33: Compatibility Of Scalance X-400

    Description 3.3 System description of SCALANCE X-400 Transmission range The maximum transmission range (segment length) is 120 km for single mode FOC. Connectors SC duplex female connectors are used. 3.3.3 Compatibility of SCALANCE X-400 Compatibility list The following products and devices are compatible with IE Switches X-400: ●...

  • Page 34: Description Of The Product

    Overview of the connection options Media module Device type X414-3E X408-2 MM491-2 2 (with extender module 6) MM491-2LD 2 (with extender module 6) MM491-2LH+ 2 (with extender module 6) MM492-2 MM492-2LD MM492-2LH MM492-2LH+ MM492-2ELH EM495-8 EM496-4 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 35: Scalance X414-3E Basic Device

    2-port gigabit Ethernet module. Module variants for multimode (up to 750 m) and single mode (up to 70 km) are available. Figure 3-8 Basic device without media modules, protective caps and covers SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 36 ● Slot labels for slots 1 through 18 ● 1 connector for power supply (4-pin) ● 1 connector for signaling contact (4-pin) ● 2 connectors for digital inputs (5-pin) ● 1 sheet with 15 labeling strips SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 37 The modules in the individual slots have the following interfaces or control elements (slot 1 is reserved for a power supply unit): ● Slot 2 Power module with two 4-pin sockets for connecting a redundant power supply and for connecting the SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 38
 N o function in system. ● Slot 9 through 11
 E ach contains four RJ-45 jacks allowing attachment of 12 electrical (twisted pair) connections in total (10, 100 Mbps). These cannot be used by media modules. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 39: Scalance X414-3E Power Module

    If the SCALANCE X414-3E is set as the redundancy manager, the following errors are also reported: ● Bad link status of the ring ports, regardless of the status of the fault mask. ● Configuration of a second IE Switch X-400 as redundancy manager in the same ring. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 40: Scalance X414-3E Digital Inputs

    Depending on the configuration, the states of the digital inputs can be used to send E-mails and/or entries to the logbook of the SCALANCE X414-3E. It is also possible to read the statuses over SNMP. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 41: Scalance X414-3E Switch Functionality

    ● Management with the aid of the command interpreter (Command Line Interpreter, CLI) including setting of the IP address information. Input to the command interpreter is over command lines. For more detailed information, refer to the configuration manual "SCALANCE X-300 SCALANCE X-400 Industrial Ethernet Switches". SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 42: Scalance X414-3E Ports

    ● Configuration ● Commissioning The SCALANCE X414-3E can be configured either locally or over a network. For more detailed information, refer to the configuration manual "SCALANCE X-300 SCALANCE X-400 Industrial Ethernet Switches". 3.4.2.4 SCALANCE X414-3E ports Ports The basic version of the SCALANCE X414-3E without expansion with media modules provides 14 ports.
  • Page 43 Description 3.4 Description of the product Figure 3-15 Ports on the device Figure 3-16 Basic device with gigabit fiber-optic cable and Fast Ethernet twisted-pair cable SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 44: Scalance X408-2 Basic Device

    (up to 750 m) and single mode (up to 120 km) are available. Figure 3-17 SCALANCE X408-2 basic device without media modules, protective caps and covers Figure 3-18 SCALANCE X408-2 basic device with media modules and covers SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 45 – 10 connecting terminals for power supply and signaling contact 4-pin – 10 connecting terminals digital inputs 5-pin ● 1 location label (order number: 6ES7 912-0AA00-0AA0) ● 10 DIN A4 sheets each with 15 labeling strips
 (Order number: 6GK5 498-0AA00-0AA0) SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 46 (10, 100, 1000 Mbps). As an option (as of product version ES 04), slots 5 and 6 allow the use of any media module (1000Base-SX or 1000Base-LX; 100Base-FX; optical gigabit module with two ports). SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 47: Scalance X408-2 Power Module

    The front 4-pin connector is used for the power supply. The input voltage is 24 V DC (20.4 – 28.8 V). The signaling contact supplies the fault status at the rear 4-pin connector. If there is a fault, the contact opens. Figure 3-20 Slot of the power module SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 48: Scalance X408-2 Switch Functionality

    This module has four LEDs for displaying parameter assignments that can be modified by the user with software and a SELECT/SET button. Figure 3-21 LEDs on slot 3 Serial port The SCALANCE X408-2 has an RS-232 port. This is located on slot 8. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 49: Scalance X408-2 Ports

    IP address information. Input to the command interpreter is over command lines. For more detailed information, refer to the configuration manual "SCALANCE X-300 SCALANCE X-400 Industrial Ethernet Switches". Figure 3-22 Pin assignment of the serial interface 3.4.3.3...
  • Page 50 Description 3.4 Description of the product Figure 3-23 Ports on the basic device Figure 3-24 Basic device with gigabit cable and Fast Ethernet twisted-pair cable SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 51: X-400 Media Modules

    3.4 Description of the product 3.4.4 X-400 media modules 3.4.4.1 Overview of the media modules for SCALANCE X-400 Available module types Note Expanded temperature range To find out the product version as of which the media modules can be used for the expanded temperature range (-40°C to +70°C), refer to the section on technical specifications.
  • Page 52 10 km 1310 nm MM492-2LH 1000Base-LX Single mode SC duplex 40 km 1550 nm MM492-2LH+ 1000Base-LX Single mode SC duplex 70 km 1550 nm MM492-2ELH 1000Base-LX Single mode SC duplex 120 km 1550 nm SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 53 Slots 6 and 7 do not have any ports but allow two optical Fast Ethernet modules to be inserted each with ports. This gives you the opportunity of data transmission at a data transmission rate of 100 Mbps over multimode or single mode FOC. Figure 3-25 Slots of the media modules SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 54 ● In display mode B, the fixed transmission rate is displayed. ● In display mode C, the full duplex mode is always displayed. ● In display mode D, you can see whether or not the port is monitored. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 55: Fast Ethernet Media Module Mm491-2 (100Base-Fx)

    The signal is transmitted by LED with a wavelength of 1310 nm. The maximum cable length is 3 km. Connector The connectors are 2x2 BFOC sockets. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 56: Fast Ethernet Media Module Mm491-2Ld (100Base-Fx)

    Both ports of the module can be configured as ring ports. The signals are transmitted with a laser diode at a wavelength of 1310 nm. The maximum cable length is 26 km. Connector The connectors are 2x2 BFOC sockets. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 57: Fast Ethernet Media Module Mm491-2Lh+ (100Base-Fx)

    The MM492-2 gigabit media module can be inserted as an option in slots 5 and 6. Mixed operation with the gigabit Ethernet media modules MM492-2LD, MM492-2LH, MM492-2LH+ and MM492-2ELH and the Fast Ethernet media modules MM491-2, MM491-2LD and MM491 2LH+ is possible. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 58: Gigabit Media Module Mm492-2 Ld (1000Base-Lx)

    1310 nm. Both ports of the module can be configured as ring ports. The maximum cable length is 10 km when using SIMATIC NET fiber-optic cables. Connector SC duplex female connectors are used. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 59: Gigabit Media Module Mm492-2Lh (1000Base-Lx)

    Note This media module can be used as of product version 05 of the SCALANCE X414-3. This media module is recognized by the SCALANCE X414-3E and SCALANCE X408-2 only as of firmware version 2.2.0 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 60: Gigabit Media Module Mm492-2Elh (1000Base-Lx)

    DFB laser diode at a wavelength of 1550 nm. Both ports of the module can be configured as ring ports. The max. line length is 120 km. Connector SC duplex female connectors are used. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 61: Scalance X414-3E Extender Modules

    The transmission rate of the Ethernet ports is 10 Mbps or as a Fast Ethernet port 100 Mbps. No media module is required for data transfer with this extender module. Figure 3-27 Basic device with twisted pair extender module SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 62 For slots 12 and 13 of the twisted pair extender EM495-8, you can use the cover that can be used on slots 9 through 11 on the basic device. Two CV490 4x100 covers are supplied with the twisted pair extender. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 63: Em496-4 Extender For Media Modules

    The media module plug connectors are protected by protective caps. Connector Depending on the media module, the connectors used are 2x2 BFOC sockets or SC duplex sockets. Figure 3-29 Basic device with media module extender SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 64 Description 3.4 Description of the product Figure 3-30 Empty media module extender EM496-4 without protective caps for the media module terminal strips and without cover SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 65: C-Plug (Configuration Plug)

    This means that the configuration data remains available if the basic device is replaced. Note The C-PLUG must only be removed or inserted when the power supply to the device is turned off. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 66 If an IE Switch X-400 is replaced, the configuration with media modules and when using a SCALANCE X414-3E also the settings of the DIL switches on the CPU module and the optional configuration of extender modules must be adopted. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 67 C-PLUG and not the physical switch settings are adopted. A deviation is signaled by the diagnostic options. For more detailed information, refer to the configuration manual "SCALANCE X-300 SCALANCE X-400 Industrial Ethernet Switches". SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 68: Scalance X-400 Covers And Dummy Covers

    Description 3.4 Description of the product 3.4.7 SCALANCE X-400 covers and dummy covers 3.4.7.1 SCALANCE X414-3E covers/dummy covers Slots of the covers Note The protective caps for the media module terminal strips and the covers must be fitted in all slots that do not contain media modules.
  • Page 69 Slot 5 for the CV490 2x1000 cover Displays of the cover The port status of the two electrical gigabit ports 1 and 2 are displayed on the front panel of the cover by two LEDs. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 70 Use the CV490 2x100 cover not only for the
 S CALANCE X414-3E but also for slots 12 through 15 of the media module extender EM496-4 if no media modules are inserted. Figure 3-36 Slots 12 through 15 for CV490 2x100 cover on media module extender EM496-4 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 71 The CV490 4x100 cover can not only be used with the SCALANCE X414-3E but also for slots 12 and 13 of the twisted pair extender EM495-8. Figure 3-38 Slots 12 and 13 for the CV490 4x100 cover on the twisted pair extender module EM495-8 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 72 Slot 8 of the dummy cover SCALANCE X414-3E Displays of the dummy cover The LEDs of the dummy cover have no function and there is therefore no port information on the front panel of the dummy cover. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 73: Scalance X408-2 Covers/Dummy Covers

    Possible slots of the covers Available cover types To cover slots not used for media modules or slots for twisted pair, the following types of cover are available: ● CV490 2x1000 ● CV490 4x100 ● CV490 COVER SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 74 LEDs. Displays of the cover The status of each of the two Fast Ethernet ports 1 and 2 is displayed on the front panel of the CV490 4x100 cover by two LEDs. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 75 Slot 8 for the CV 490 4x100 cover Displays of the cover The status of each of the four Fast Ethernet ports 1 through 4 is displayed on the front panel of the CV490 4x100 cover by four LEDs. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 76 Slot 4 and 7 of the dummy cover SCALANCE X408-2 Displays of the dummy cover The LEDs of the dummy cover have no function and there is therefore no port information on the front panel of the dummy cover. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 77: Installation

    The device may only be operated in an environment with pollution degree 1 or 2 (see IEC 60664-1). WARNING When used in hazardous environments corresponding to Class I, Division 2 or Class I, Zone 2, the device must be installed in a cabinet or a suitable enclosure. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 78 80 °C, special precautions must be taken. If the equipment is operated in an air ambient in excess of 50 °C to 70 °C, only use cables with a permitted operating temperature of at least 80 °C. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 79: Installing / Uninstalling The Scalance X-400

    Installation 4.2 Installing / uninstalling the SCALANCE X-400 Installing / uninstalling the SCALANCE X-400 Notes on installation IE Switches X-400 are designed for installation on an S7-300 standard rail and installation on a 35 mm DIN rail. Clearances Certain minimum clearances between an IE Switch X-400 and neighboring equipment must be taken into account.

  • Page 80: Installing / Uninstalling With An S7-300 Standard Rail

    Installation 4.2 Installing / uninstalling the SCALANCE X-400 4.2.1 Installing / uninstalling with an S7-300 standard rail Installing on an S7-300 standard rail For installation, you require a slotted screwdriver with a 5.5 mm wide blade. Note When installing the IE Switch X-400, hold it by the backplane and not by the modules, otherwise the device may be damaged.

  • Page 81: Installing / Uninstalling With A 35 Mm Din Rail

    Installation 4.2 Installing / uninstalling the SCALANCE X-400 Removing from the S7-300 standard rail To remove the device, you require a slotted screwdriver with a 5.5 mm wide blade. Note When uninstalling the IE Switch X-400, hold it by the backplane and not by the modules, otherwise the device may be damaged.
  • Page 82 Installation 4.2 Installing / uninstalling the SCALANCE X-400 To install the device, follow the steps below: 1. Place the central groove containing two spring clips on the back of the basic device on the upper edge of the DIN rail with the device tilted slightly towards the back. Note that both spring clips must be located behind the edge of the DIN rail.
  • Page 83 Installation 4.2 Installing / uninstalling the SCALANCE X-400 Removing the SCALANCE X414-3E from a 35 mm DIN rail Since the two captive screws are not used to secure the device when removing from a 35 mm DIN rail, it is not absolutely necessary to remove the covers and the blind cover, although this does make it easier to handle the basic device.
  • Page 84 Installation 4.2 Installing / uninstalling the SCALANCE X-400 To remove the device, follow the steps below: 1. Using a slotted screwdriver with a 5.5 mm wide blade, pull down the clip on the basic device slightly and pull out the lower part of the basic device to the front so that the spring clips can no longer engage.

  • Page 85: Installing / Removing The Media Modules, Covers, And Dummy Cover

    6. Tighten the captive screw on the front of the media module with a slotted screwdriver with a 2.8 mm wide blade. 7. Secure the labeling strip on the front of the media module. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 86 5. Remove the media module by pulling it upwards. 6. Fit the protective cap on the module terminal strip on the backplane of the basic device. Fit a suitable cover on the slot of the media module. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 87: Fitting / Removing A Cover/Dummy Cover

    3. Press the upper part of the cover/dummy cover onto the basic device until the fluted middle section of the cover/dummy cover is heard to click into place. 4. Secure the labeling strip on the front of the cover/dummy cover. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 88 2. At the same time, tilt the cover/dummy cover down at an angle, the two guides initially remain in the recesses at the lower edge of the basic device. 3. Remove the cover/dummy cover by pulling it upwards. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 89: Installing / Uninstalling The Extender Modules For Scalance X414-3E

    7. Using a slotted screwdriver with a 5.5 mm wide blade, tighten the captive screw between slots 12 and 13 in the lower part of the extender module. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 90 6. Pull out the lower part of the extender module slightly towards the front and lift it from the S7-300 standard rail. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 91 DIN rail with the module tilted slightly towards the back. Make sure that there is adequate clearance between the guide bolts of the extender module and the basic device. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 92 11 of the basic device in the upper and lower recesses as far as they will go. 3. Push the extender module slowly to the right while keeping it straight until the two guide bolts of the extender module are completely outside the holes in the basic device. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 93: Installing / Uninstalling The Em496-4 Media Module Extender For Scalance X414-3E

    2. Remove the right-hand side panel of the basic device. To do this, use a slotted screwdriver with a 2.8 mm wide blade to loosen the two captive slug screws on slot 11 in the upper and lower recesses as far as they will go. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 94 CV490 2x100 covers are in place. Figure 4-8 Installing the media module extender on the S7-300 standard rail SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 95 The DIN rail does not provide adequate support for the media module extender with vibration greater than 10 g. For installation, you require a slotted screwdriver with a 2.8 mm wide blade. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 96 Then push the extender module to the left as far as it will go so that it is flush with the right side of the basic device. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 97 5. Lift the extender module up and off the DIN rail. 6. Replace the right side panel of the basic device so that the guide bolts fit into the two holes in the basic device. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 98 11. The screws lock the two guide bolts, so do not use excessive force when tightening them. 8. Fit a suitable cover on slot 11 of the basic device. Note The basic device must not be used permanently without the right side panel. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 99: Connecting

    WAN (Wide Area Network). Safety notices on use in hazardous areas General safety notices relating to protection against explosion WARNING EXPLOSION HAZARD DO NOT CONNECT OR DISCONNECT EQUIPMENT WHEN A FLAMMABLE OR COMBUSTIBLE ATMOSPHERE IS PRESENT. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 100 If you use the device under HazLoc conditions you must also keep to the following safety notices in addition to the general safety notices for protection against explosion: WARNING EXPLOSION HAZARD DO NOT DISCONNECT WHILE CIRCUIT IS LIVE UNLESS AREA IS KNOWN TO BE NON-HAZARDOUS. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 101: Ports

    5.2 Ports Ports 5.2.1 Connectors of the power supply (X1) of the SCALANCE X-400 Polarity reversal protection X1, X2 The two 4-pin male connectors (X1, X2) for the power supply and the signaling contact have no polarity reversal protection. If the connectors are accidentally swapped over, this does not cause damage or destroy circuits.

  • Page 102: Connectors Of The Signaling Contact And Grounding Strap (X2) Of The Scalance

    Neumarkt, Germany. 5.2.2 Connectors of the signaling contact and grounding strap (X2) of the SCALANCE X-400 Polarity reversal protection X1, X2 The two 4-pin male connectors (X1, X2) for the power supply and the signaling contact have no polarity reversal protection. If the connectors are accidentally swapped over, this does not cause damage or destroy circuits.
  • Page 103 By inserting a strap between protective earth GND and M3, IE Switches X-400 can be operated with grounded reference potential. When the device ships, no strap is fitted (non-grounded reference potential). Conn. 2 Floating signaling contact relay connector 1 Ground Protective earth Floating signaling contact relay connector 2 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 104: Connectors Of The Digital Inputs Of The Scalance X414-3E

    Digital inputs 1 through 4 are connected using a 5-pin connector at the front terminal block on the DI module. Figure 5-3 Pins of connector X1 (inputs 1-4) Conn. 1 Digital input 1 Digital input 2 Ground Digital input 3 Digital input 4 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 105: Connectors For The Twisted Pair Cables

    IE FC standard cable 2x2 as a four-wire cable is suitable for RJ-45 plugs. This means that the maximum transmission rate is 100 Mbps. The flexible eight-wire patch cable (TP cord) for gigabit transmission allows a maximum cable length of 10 m. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 106 IE FC RJ-45 modular outlet insert 1GE With the IE FC RJ-45 modular outlet insert 2FE, the eight-wire FastConnect cable is split over two RJ-45 jacks and allows a transmission rate of 2 x 100 Mbps. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 107 TP cord. Normally, FastConnect cable with a length of 90 m is used. The remaining 10 m is then available for TP cord at both ends (total of 10 m). Figure 5-8 FastConnect cabling A1 TP cord 4x2 A2 TP cord 4x2 B IE FC standard cable 4x2 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 108 If this is the situation, do the following: 1. Press the catch on the RJ-45 plug to the left with a small screwdriver. 2. Remove the cable. Figure 5-9 Unlocking the FastConnect RJ-45 plug SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 109: Connectors For Fiber-Optic Cables

    When a media module is inserted, port 1 is to the front and port 2 to the rear. Note Fiber-optic cable connectors are susceptible to contamination and mechanical damage to the face. Protect open connections with the supplied dust caps. Figure 5-10 SC duplex plug with gigabit media module MM492-2LD SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 110 Note Fiber-optic cable connectors are susceptible to contamination and mechanical damage to the face. Protect open connections with the supplied dust caps. Figure 5-11 BFOC plug with Fast Ethernet media module MM491-2 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 111: Fitting Ie Fc Rj-45 Plug 180

    12. Press down the contact elements their colors on the contact elements of go into the contact elements of the FC as far as the limit stop to contact the the FC RJ-45 plug. RJ-45 plug. cores. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 112 Cable ends that have had a connector fitted, must not be used twice but must Connect white with yellow - 150 cables with a PUR outer jacket be cut off before fitting a new connect- Connect blue with orange. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 113: Configuration / Project Engineering

    X414-3E, the extender module configuration on the new device as was on the old device. • Use the C-PLUG of the old device in the new one. This means that the previous device configuration will be adopted automatically when the new device starts up. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 114: Slot Numbers Of The Modules And Covers

    2. Place the tongue in the opening on the module. 3. Press the slot number into the recess on the front of the housing with your finger. The slot number breaks out of the wheel. Figure 6-1 Slot number plate SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 115: Factory Default

    The default settings for RM and ring ports are the same for the basic devices SCALANCE X414-3E and SCALANCE X408-2. Other device properties R1 and R2 enable ring redundancy when the product ships. Note in this mode, RSTP/STP cannot be enabled. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 116 When the product ships, the C-PLUG is empty and is initialized with the factory settings the first time the device starts up. All subsequent configuration changes are adopted automatically in the internal device memory of the X-400 IE switch and on the C_PLUG. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 117: Operator Controls

    Below the labeling strip of the CPU module, on slot 4 there are the four DIP switches. These DIP switches can have two states (ON/OFF). Figure 6-2 Power module, digital inputs and CPU module with operator controls on the SCALANCE X414-3E SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 118 ● With the R1 and R2 switches, you can specify the ring ports, refer also to the section "Configurable ring ports". Changes to the switch settings during operation lead to the Fault display and to activation of the signaling contact. The settings are adopted the next time the device is restarted. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 119 Port 1 of slot 6 is the first ring port. Port 1 of slot 7 is the second ring port. All other ports on slots 6 and 7 can be used for optical connection of remote nodes or subnets. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 120 With this setting, you cannot enable Rapid Spanning Tree / Span- ning Tree. For more detailed information, refer to the configuration manual "SCALANCE X-300 and SCALANCE X-400 Industrial Ethernet Switches". Configurable ring ports With the R1 and R2 switches, you can specify the ring ports on slots 5 to 7.

  • Page 121: Select/Set Button

    5 seconds have elapsed, the action is aborted. After 5 seconds the redundancy manager is activated/deactivated. If the redundancy manager as well as ring redundancy were deactivated, ring redundancy is also activated at the same time. If you deactivate, only the redundancy manager is deactivated. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 122: Led Display

    Signal at input CPU module Device is operating as RM for X414-3E Device operates in standby mode. and X408-2 Ports for Port status Transmission Half / full duplex Fault mask X414-3E and rate X408-2 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 123: Startup Behavior Of The Scalance X-400

    Configuration / project engineering 6.5 LED display 6.5.1 Startup behavior of the SCALANCE X-400 Startup behavior of the IE Switch X-400 While the device is starting up, the red LED on the power module indicates the current status of the device. For more detailed information, refer to the following table:...

  • Page 124: Selecting The Display Modes

    LEDs of the power module. Figure 6-6 Example of the LED display of the power module and the CPU module in DMode A SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 125 Power supply L2 is not monitored. If L2 falls below 17 V, the signaling contact does not respond. Green Power supply L2 is monitored. If L2 falls below 17 V, the signal- ing contact responds. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 126: Led Display - Cpu Module

    The standby function is enabled and the standby ports are disa- bled. flashes The standby function is enabled and the standby ports are ena- bled; in other words, the send and receive frames. Green Green SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 127: Led Display Of The Ports (Dmode A Through Dmode D)

    Yellow flashes / lit Link exists, port is in normal status and data is being received at the port. Figure 6-9 Display of the port status of port 1 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 128 LED goes off. Port statuses in DMode C In display mode C, the current mode (half duplex, full duplex) is indicated. Port Color Status Meaning Port operating in half duplex Green Port operating in full duplex SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 129 Port is monitored; in other words, if there is no link established at the port (for example cable not plugged in or connected device turned off), this triggers the signaling contact and the fault state is adopted. Figure 6-12 Example: Monitoring of port 1 is "on“ SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 130: Replacing The C-Plug

    The notch in the casing must be on the right. The C-PLUG is inserted by pressing it into the receptacle until the C-PLUG is flush with the front surface of the CPU. Figure 6-13 Removing the C-PLUG from the SCALANCE X414-3E SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 131 Configuration / project engineering 6.6 Replacing the C-PLUG Figure 6-14 Removing the C-PLUG from the SCALANCE X408-2 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 132: Show Location

    This can be used, for example, when assigning addresses to make sure that the correct node receives the address. All port LEDs of the addressed node flash green at 2 Hz. With the PST Tool V3.0, you can trigger this function with "Module \ Ring". SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 133: Approvals

    The SIMATIC NET products described in these operating instructions meet the requirements of EC directive 2004/108/EC "Electromagnetic Compatibility" for the following areas of application: Field of application Requirements Emission Immunity to interference Industry EN 61000-6-4 : 2007 EN 61000-6-2 : 2005 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 134 Approvals EU declaration of conformity You will find EC declaration of conformity for these products on the Internet pages of Siemens Industry Online Support (http://support.automation.siemens.com/WW/view/en/33118389/134200). WARNING Personal injury and property damage can occur The installation of expansions that are not approved for SIMATIC NET products or their target systems may violate the requirements and regulations for safety and electromagnetic compatibility.
  • Page 135 Area". You will find this document • on the data medium that ships with some devices. • on the Internet pages of Siemens Industry Online Support (http://support.automation.siemens.com/WW/view/en). Enter the document identification number C234 as the search term. SIMATIC NET products meet the requirements of the EC directive:94/9/EC "Equipment and Protective Devices for Use in Potentially Explosive Atmospheres".
  • Page 136 ● IEC 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements) ● IEC 60079-28 (Explosive atmospheres - Part 28: Protection of equipment and transmission systems using with optical radiation) You will find the current versions of the standards in the currently valid IECEx certificates. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 137 Cl. 1, Div. 2, GP. A, B, C, D, T4 A Cl. 1, Zone 2, GP. IIC T4 Cl. 1, Zone 2, Aex nC IIC T4 Report no. E240480 The product meets the requirements of the AS/NZS 2064 standard (Class A). SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 138 ● MM492-2LD ● MM492-2LH ● MM492-2LH+ ● MM492-2ELH Figure 7-1 FDA and IEC approvals CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 139: Technical Specifications

    VT AD 24 V, article no. 918 402 device DEHN Blitzductor VT AD 24 V, article no. 918 Power consumption (without 15 W modules) at
 2 4 V DC SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 140 With TP cord up to 10 m,
 with FastConnect cabling system up FastConnect cabling system up to 100 m. to 100 m. Redundancy reconfiguration times Redundancy Reconfiguration times 300 ms Standby link 300 ms 200 ms SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 141 8127 81274 1518 Note The IE Switches X-400 support full wire speed switching complying with IEEE 802.3 on all ports. The number of packets depends on the packet length according to the IEEE802.3 standard. SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 142 Fast Ethernet media module MM491-2LD 141 years 6GK5 491-2AC00-8AA2 Fast Ethernet media module MM491-2LH+ 125 years 6GK5 491-2AE00-8AA2 Gigabit media module MM492-2 400 years 6GK5 492-2AL00-8AA2 Gigabit media module MM492-2LD 400 years 6GK5 492-2AM00-8AA2 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 143 Technical specifications 8.1 SCALANCE X414-3E and X408-2 - technical specifications Device type MTBF Gigabit media module MM492-2LH 400 years 6GK5 492-2AN00-8AA2 Gigabit media module MM492-2LH+ 400 years 6GK5 492-2AP00-8AA2 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 144: Media Module Mm491-2 (100Base-Fx) - Technical Specifications

    Max. 2000 m RF interference level EN 55081 Class A Immunity EN 61000-6-2: 2001 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 260 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 145: Media Module Mm491-2Ld (100Base-Fx) - Technical Specifications

    EN 55081 Class A Immunity EN 61000-6-2: 2001 Laser protection Class 1 complying with IEC 60825-1 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 260 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 146: Media Module Mm491-2Lh+ (100Base-Fx) - Technical Specifications

    EN 55081 Class A Immunity EN 61000-6-2: 2001 Laser protection Class 1 complying with IEC 60825-1 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 260 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 147: Media Module Mm492-2 (1000Base-Sx) - Technical Specifications

    EN 55081 Class A Immunity EN 61000-6-2: 2001 Laser protection Class 1 complying with IEC 60825-1 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 250 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 148: Media Module Mm492-2Ld (1000Base-Lx) - Technical Specifications

    EN 55081 Class A Immunity EN 61000-6-2: 2001 Laser protection Class 1 complying with IEC 60825-1 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 250 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 149: Media Module Mm492-2Lh (1000Base-Lx) - Technical Specifications

    EN 55081 Class A Immunity EN 61000-6-2: 2001 Laser protection Class 1 complying with IEC 60825-1 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 250 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 150: Media Module Mm492-2Lh+ (1000Base-Lx) - Technical Specifications

    EN 55081 Class A Immunity EN 61000-6-2: 2001 Laser protection Class 1 complying with IEC 60825-1 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 250 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 151: Media Module Mm492-2Elh (1000Base-Lx) - Technical Specifications

    EN 55081 Class A Immunity EN 61000-6-2: 2001 Laser protection Class 1 complying with IEC 60825-1 Construction Dimensions (W x H x D) 35 x 145 x 90 mm Weight 250 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 152: Extender Module Em495-8 - Technical Specifications

    Max. 2000 m RF interference level EN 55081 Class A Immunity EN 61000-6-2: 2001 Construction Dimensions (W x H x D) 86 x 145 x 112.4 mm Weight 560 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 153: Extender Module Em496-4 - Technical Specifications

    Max. 2000 m RF interference level EN 55081 Class A Immunity EN 61000-6-2: 2001 Construction Dimensions (W x H x D) 154 x 145 x 112.4 mm Weight 980 g Degree of protection IP20 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 154 Technical specifications 8.11 Extender module EM496-4 - technical specifications SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 155: Dimension Drawings

    Dimension drawings Dimension drawing X414-3E Figure 9-1 SCALANCE X414 front SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 156 Dimension drawings Figure 9-2 SCALANCE X414 top Figure 9-3 SCALANCE X414 left SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 157 Dimension drawings Dimension drawing X408-2 Figure 9-4 SCALANCE X408 front SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 158 Dimension drawings Figure 9-5 SCALANCE X408 top Figure 9-6 SCALANCE X408 left SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 159 Dimension drawings Dimension drawing EM495-8 Figure 9-7 Extender module EM495-8 front SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 160 Dimension drawings Figure 9-8 Extender module EM495-8 left SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 161 Dimension drawings Dimension drawing EM496-4 Figure 9-9 Extender module EM496-4 front SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 162 Dimension drawings Figure 9-10 Extender module EM496-4 left SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

  • Page 163: Index

    CPU module, 38, 41 LED display CPU module, 126 Power module, 125 DI module, 40 Dummy cover SCALANCE X408-2, 76 SCALANCE X414-3E, 72 Media module, 26 Media modules, 51 Multimode fiber-optic cable, 109 Ethernet switches, 13 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...
  • Page 164 Selecting the display modes, 124 Signaling contact, 39 SIMATIC NET glossary, 9 SIMATIC NET manual, 9 Single mode, 14 Single mode fiber-optic cable, 109 Slot number, 114 Slots SCALANCE X414-3E, 37 Startup behavior, 123 System manual, 9, 134 SCALANCE X-400 Operating Instructions, 06/2015, C79000-G8976-C186-12...

Table of Contents
