  • Page 1 ABB Power Systems FOX61x LEDE1 User Manual...
  • Page 2 The contents of the manual may not be disclosed by the recipient to any third party, without the prior written agreement of ABB. An exception is the preparation of a backup copy of the software for your own use. For devices with embedded software, the end-user license agreement on the enclosed CD applies.

  • Page 3: Table Of Contents

    Table of Contents Preface Precautions and safety Symbols and notations Interfaces and circuit categories Document history Introduction General Unit view Functions and specifications Feature licences LEDE1 function overview Installation Prerequisites Slots for the LEDE1 unit Compatibility 4.3.1 FOX61x units 4.3.2 Previous ESW revisions Connections and cables 4.4.1...
  • Page 4 Maintenance 7.3.1 Inventory data 7.3.2 Unit ESW download FOXCST reference Introduction AP: / unit-x: LEDE1 8.2.1 AP: / unit-x, Overview 8.2.2 AP: / unit-x, Main 8.2.3 AP: / unit-x, Fault Management AP: / unit-x / port-y 8.3.1 AP: / unit-x / port-y, Overview 8.3.2 AP: / unit-x / port-y, Main 8.3.2.1...
  • Page 5 Figures Figure 1: LEDE1 used as an access unit (top) and as a transport unit (bottom) Figure 2: LEDE1 unit view Figure 3: Pin-out of the LEDE1 front connector, front view Figure 4: Side view of the cable tray and the cable in FOX615 Figure 5: Top view of the cable tray and the cable in FOX612 Figure 6:...
  • Page 6  FOX61x LEDE1...
  • Page 7 Tables Table 1: Electrical interfaces and circuit categories Table 2: Document history Table 4: Pins of the E1 ports Table 5: Wiring of the E1 ports Table 7: Managed objects (MOs) for LEDE1 Table 11: AP: / unit-x / port-y, Configuration - Synchronization Table 13: PM counter interval availability Table 14:...
  • Page 8  FOX61x LEDE1...

  • Page 9: Preface

    P R E F A C E Preface Precautions and safety Before you handle any equipment you must comply with the safety advices. Adherence to the safety instructions ensures compliance with the safety requirements as defined in EN 60950 (Safety of Information Technology Equipment).

  • Page 10: Document History

    P R E F A C E Document history Table 2: Document history Date FOX61x Changes since previous version Release December 2012 R1 This is the first release for FOX61x  FOX61x LEDE1...

  • Page 11: Introduction

    I N T R O D U C T I O N Introduction This section presents a general introduction to the LEDE1 unit. The section is closed with a unit view in section "Installation" (page 15). General This document describes the architecture and functions of the LEDE1 unit and shows how this unit is commissioned and operated as part of the FOX61x.

  • Page 12: Unit View

    I N T R O D U C T I O N Unit view Figure 2: LEDE1 unit view Figure 2 shows the LEDE1 unit hardware. On the front plate are two LEDs for unit- and traffic failure indication, and a connector for 8 E1 signals, based on the standard DIN 41 612.

  • Page 13: Functions And Specifications

    F U N C T I O N S A N D S P E C I F I C A T I O N S Functions and specifications Feature licences Part of the FOX61x functionality is subject to feature licences. For more information on feature licences please refer to "1KHW002459 FOX61x Release...
  • Page 14 F U N C T I O N S A N D S P E C I F I C A T I O N S Table 3: Functions and specifications (continued) Feature Rating or standard Release Protection - SNCP between any 2 P12 or P0-nc signals from the PBUS - SNCP protection modes - 1+1 unidirectional, revertive...

  • Page 15: Installation

    I N S T A L L A T I O N Installation This section presents the prerequisites for the installation of the LEDE1 unit in sections "Prerequisites" (page 15) "Slots for the LEDE1 unit" (page 15). Section "Compatibility" (page 15) gives information about the compatibility with other FOX61x units while section "Connections and cables"...

  • Page 16: Previous Esw Revisions

    I N S T A L L A T I O N 4.3.2 Previous ESW revisions The LEDE1 unit with ESW release LEDE1 R4B is the first release for the FOX61x release. Connections and cables 4.4.1 Front connector of the LEDE1 unit a b c Connector positions Tx-b...

  • Page 17: X 2 Mbit/S Cable 120 Ω

    120 Ω signal termination Please note: The cables provided by ABB are internally connected for 120 Ω (pins a, b). Please note: In transmit direction the b signals are available on three pins per port. → Avoid unintentional connections to the pins with the redundant out- puts.

  • Page 18: Figure 4: Side View Of The Cable Tray And The Cable In Fox615

    I N S T A L L A T I O N Figure 4: Side view of the cable tray and the cable in FOX615 When operating the LEDE1 unit in a FOX612, the cable must be attached to the cable tray as shown in the Figure Figure 5: Top view of the cable tray and the cable in FOX612...

  • Page 19: Functional Description

    F U N C T I O N A L D E S C R I P T I O N Functional description This section gives the detailed functional description of the LEDE1 unit as a P12 access unit in the FOX61x subrack. Section "P12 termination modes"...

  • Page 20: Transparent Transport Modes

    F U N C T I O N A L D E S C R I P T I O N The V5 uplink modes are application specific modes used together with the V5 protocol converter unit COSI1. V5.x applications terminate the P12 signal and use all 5 Sa bits.

  • Page 21: Protection

    F U N C T I O N A L D E S C R I P T I O N Protection LEDE1 supports 1+1 subnetwork connection protection (SNCP) for P12 and P0-nc signals. P12 and P0-nc protection switching for signals from the network or aggre- gate side takes place on a tributary unit, e.g.
  • Page 22 F U N C T I O N A L D E S C R I P T I O N − Signal degraded (SD). • External command requests: − Activated from the channel status dialogue. Please note: The protection parameters holdoff time and guard time are not available for P12 and P0-nc SNCP.

  • Page 23: Commissioning

    C O M M I S S I O N I N G Commissioning This section describes the management of the basic system functions of the LEDE1 unit: • Description of the managed object model (MOM) of the LEDE1 unit (sec- tion "Commissioning of an E1 port"...

  • Page 24: Commissioning Of An E1 Port

    C O M M I S S I O N I N G Commissioning of an E1 port 6.1.1 Prerequisites Before starting the commissioning of a E1 port on the LEDE1 unit, the follow- ing prerequisites need to be fulfilled: 6.1.1.1 CESM1 unit In a FOX61x, a CESM1 needs to be in operation in slot 11 of the FOX61x...
  • Page 25 C O M M I S S I O N I N G E1 port configuration This action list shows step by step how to configure an E1 port. The E1 port will use the Transparent mode for the P12 transport and will be connected to another E1 port on the same LEDE1 unit.
  • Page 26 C O M M I S S I O N I N G  The “Create TDM Connection” dialogue opens. 3. Set the connection parameters:  Layer Rate = P12.  Directionality = Bidirectional.  Protected = No.  Label 1 = <anyName>. ...

  • Page 27: Operation And Maintenance

    O P E R A T I O N A N D M A I N T E N A N C E Operation and maintenance This section gives an overview of operational and maintenance aspects of the LEDE1 unit. You will find the following information: •...

  • Page 28: Loops

    O P E R A T I O N A N D M A I N T E N A N C E Table 6: LED signalling on LEDE1 (continued) LED name Colour State Meaning TRAFFIC Failure One or more active failures on the unit, independent of the sever- ity.

  • Page 29: Maintenance

    O P E R A T I O N A N D M A I N T E N A N C E Maintenance 7.3.1 Inventory data It is possible to read inventory data from the LEDE1 unit via the FOXCST with the following access point: AP: /unit-x, Main - Inventory.
  • Page 30 O P E R A T I O N A N D M A I N T E N A N C E  FOX61x LEDE1...

  • Page 31: Foxcst Reference

    F O X C S T R E F E R E N C E FOXCST reference This section gives a complete reference of the managed objects, properties, and commands of the LEDE1 functional unit of the FOX61x. In this section, you will find the following information: •...

  • Page 32: Ap: / Unit-X: Lede1

    F O X C S T R E F E R E N C E Table 7: Managed objects (MOs) for LEDE1 (continued) Description of the management functions chan-z Channels are the connection termination points (CTP) for the P0-nc and P12 traffic signal cross connections. refer to For the configuration of cross connections please "1KHW002467 FOX61x TDM Services"...

  • Page 33: Ap: / Unit-X, Fault Management

    F O X C S T R E F E R E N C E − “Main - Inventory”, − “Main - Logbooks”, and − “Main - Software” management functions description, please refer to "1KHW002466 FOXCST Operation". 8.2.3 AP: / unit-x, Fault Management For the a description of the general aspects of the −...

  • Page 34: Ap: / Unit-X / Port-Y

    F O X C S T R E F E R E N C E Table 8: AP: / unit-x, Fault Management (continued) Fault Cause Event Type Traffic Default Description Affecting Severity No Application Soft- Equipment  Major There is no application ESW installed on ware Alarm the unit, or the application ESW has not...

  • Page 35: Ap: / Unit-X / Port-Y, Main - Admin And Oper Status

    F O X C S T R E F E R E N C E 8.3.2.2 AP: / unit-x / port-y, Main - Admin And Oper Status Table 9: AP: / unit-x / port-y, Main - Admin And Oper Status Operation Name Parameter Name Range Description / Details...

  • Page 36: Ap: / Unit-X / Port-Y, Configuration - General

    F O X C S T R E F E R E N C E 8.3.3.1 AP: / unit-x / port-y, Configuration - General Table 10: AP: / unit-x / port-y, Configuration - General Operation Name Parameter Name Range Description / Details Clock and data transparent.

  • Page 37: Ap: / Unit-X / Port-Y, Configuration - Synchronization

    SSI-Sa5 Use the Sa5 bit in time slot 0 for the transport of the synchronization status indication (SSI). The SSI method is ABB proprietary and is com- patible with the FOX51x. This parameter value is only available with the termination modes “PCM30”, “PCM30C”, “PCM31”...

  • Page 38: Ap: / Unit-X / Port-Y, Configuration - Channels

    F O X C S T R E F E R E N C E Please note: The “Usage” parameter is read-only. Please note: For more information regarding quality level handling please refer to "1KHW002467 FOX61x TDM Services". 8.3.3.3 AP: / unit-x / port-y, Configuration - Channels “Create Channel”...
  • Page 39 F O X C S T R E F E R E N C E Table 12: AP: / unit-x / port-y, Configuration - Synchronization (con- Operation Name Parameter Name Range Description / Details The channel index is used to identify the chan- Create Channel Index 0 …...

  • Page 40: Ap: / Unit-X / Port-Y, Fault Management

    F O X C S T R E F E R E N C E Table 12: AP: / unit-x / port-y, Configuration - Synchronization (con- Operation Name Parameter Name Range Description / Details The start index is the channel index of the first Create Multiple Start Index 0 …...

  • Page 41: Ap: / Unit-X / Port-Y, Performance Management - G.826

    F O X C S T R E F E R E N C E Table 13: PM counter interval availability (continued) Counter interval G.826 P12 Events History 15min History 24h Alarm 15min Alarm 24h 8.3.4.1 AP: / unit-x / port-y, Performance Management - G.826 Table 14: PM group: G.826 PM parameter...

  • Page 42: Ap: / Unit-X / Port-Y, Status

    F O X C S T R E F E R E N C E 8.3.5 AP: / unit-x / port-y, Status 8.3.5.1 AP: / unit-x / port-y, Status - Maintenance Table 16: AP: / unit-x / port-y, Status - Maintenance Operation Name Parameter Name Range Description / Details...

  • Page 43: Ap: / Unit-X / Port-Y, Status - Ql

    F O X C S T R E F E R E N C E 8.3.5.2 AP: / unit-x / port-y, Status - QL Table 17: AP: / unit-x / port-y, Status - QL Operation Name Parameter Name Range Description / Details Unknown The synchronization method “None”...

  • Page 44: Ap: / Unit-X / Port-Y / Chan-Z, Main - Admin And Oper Status

    F O X C S T R E F E R E N C E management function, please refer to "1KHW002466 FOXCST Operation". 8.4.2.2 AP: / unit-x / port-y / chan-z, Main - Admin And Oper Status Table 18: AP: / unit-x / port-y / chan-z, Main - Admin And Oper Status Operation Name Parameter Name Range Description / Details...
  • Page 45 F O X C S T R E F E R E N C E Table 19: AP: / unit-x / port-y / chan-z, Configuration - CTP Operation Name Parameter Name Range Description / Details CTP Configuration Layer Rate Unstructured 2048 kbit/s. P0_nc Structured n x 64 kbit/s.

  • Page 46: Ap: / Unit-X / Port-Y / Chan-Z, Fault Management

    F O X C S T R E F E R E N C E Please note: The z-End of a protected connection shows two entries in the “Connected to CTPs” table, one for the working and one for the protecting path. 8.4.4 AP: / unit-x / port-y / chan-z, Fault Management For the a description of the general aspects of the...

  • Page 47: Ap: / Unit-X / Port-Y / Chan-Z, Performance Management - Protection

    F O X C S T R E F E R E N C E Table 21: PM counter interval availability (continued) Counter interval Protection Alarm 24h 8.4.5.1 AP: / unit-x / port-y / chan-z, Performance Management - Protection Table 22: PM group: Protection PM parameter Description...
  • Page 48 F O X C S T R E F E R E N C E Table 24: AP: / unit-x / port-y / chan-z, Status - CTP Operation Name Parameter Name Range Description / Details Managed object address of the CTP (connec- Trail Status Working Trail, <MO Address>...

  • Page 49: Annex

    A N N E X Annex Associated documents 1KHW028514 FOX61x Terms and Abbreviations 1KHW002497 FOX61x Precautions and Safety 1KHW002459 FOX61x Release Notes 1KHW002460 FOX61x Product Features and Characteristics 1KHW002461 FOX615 Installation 1KHW002462 FOX612 Installation 1KHW002463 FOX61x Lightning Protection 1KHW002464 FOX61x System Description 1KHW002465 FOXCST Installation 1KHW002466...
  • Page 50 A N N E X  FOX61x LEDE1...
  • Page 52 Contact us ABB Switzerland Ltd Power Systems Bruggerstrasse 72 CH-5400 Baden Tel. +41 58 585 77 37 +41 58 585 55 77 E-mail: utility.communication@ch.abb.com www.abb.com/utilitycommunication...
