APPLICANT: MOTOROLA, INC. FCC ID: IHDT6ES1 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: EXHIBIT 8...
Page 2
Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola E398 series GSM wireless phone. Volume Key Headset Jack Camera Key Activate camera & take photos. Smart Key Stereo Speakers Left Soft Key...
Page 3
Check It Out! Camera Key Mirror Activate camera Aim camera lens & take photos. for self portraits. Camera Lens Stereo Speakers (both sides) 032385o.eps Integrated Short- Range Flash Feature Description Use Memory Set the memory location you want to use Card to store and retrieve files: Go to a multimedia menu (such as...
Page 4
Feature Description Rhythm Lights Activate rhythm lights to flash in sync with the sounds around you: M > Settings > Personalize > Rhythm Lights Ring Lights Choose ring lights for incoming calls: M > Settings > Ring Styles > Ring Lights >...
Page 5
1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
To obtain the More Here guide for your phone, or another copy of this guide, see the Motorola Web site at: http://motorola.com/consumer/manuals (U.S.A.) http://motorola.ca/consumer (Canada) or contact the Motorola Customer Call Center at...
Contact your service provider for more information. Optional Accessories This label identifies a feature that requires an optional Motorola Original™ accessory. Installing the SIM Card Your Subscriber Identity Module (SIM) card contains your phone number, service details, and phonebook/message...
Caution: Do not bend or scratch your SIM card. Avoid exposing your SIM card to static electricity, water, or dirt. 032386o 032387o 032389o 032388o Installing a Memory Card You can install a removable memory card in your phone. You can store additional multimedia objects (such as photos and sounds) on the memory card.
Caution: Do not bend or scratch your memory card. Avoid exposing your memory card to static electricity, water, or dirt. Battery Use Battery performance depends on many factors, including your wireless carrier’s network configuration; signal strength; the temperature at which you operate your phone;...
Page 13
To maximize your battery’s performance: • Always use Motorola Original batteries and battery chargers. The phone warranty does not cover damage caused from using non-Motorola batteries and/or battery chargers. • New batteries or batteries that have been stored for a long time may require a longer charge time.
Installing the Battery Your phone is designed to use only Motorola Original batteries and accessories. We recommend that you store batteries in their protective cases when not in use. Notes: • Your phone battery may be enclosed in a protective clear plastic case.
Charging the Battery New batteries are shipped partially charged. Before you can use your phone, you need to install and charge the battery as described below. Some batteries perform best after several full charge/discharge cycles. Action 1 Insert the travel charger plug into 032392o your phone with the...
Turning Your Phone On Action 1 Press and hold P 032393o.eps (power key) for 2 seconds to turn the phone on. Note: It may take up to 4 seconds for the display to illuminate after you turn the phone on. 2 If necessary, enter your SIM card PIN code and press OK (+) to unlock the SIM card.
Adjusting Volume Press the volume key up or down to: • increase or decrease 032394o.eps earpiece volume during a call • increase or decrease the ringer volume when the home screen is visible Tip: At the lowest volume setting, press the volume key down once to switch to vibrate alert.
Answering a Call When you receive a call, your phone rings and/or vibrates and displays an incoming call message. Press 1 N or answer the call ANSWER (+) end the call and “hang up” the phone when you are finished Viewing Your Phone Number To view your phone number from the home screen, press M #.
Locking and Unlocking the Keypad You can lock your phone keypad to prevent accidental keypresses (for example, when carrying your phone in a purse or pocket). Press lock or unlock your keypad Select M > Settings > Security > Lock Keypad to view instructions on how to lock/unlock the keypad.
Highlight Features You can do much more with your phone than make and receive calls! Using a Removable Memory Card You can use an optional memory card or other storage device with your phone to store and retrieve multimedia objects (such as photos and sounds). To install a memory card, see page 10.
The Storage Device menu can include the following options: Option Description Format Format the memory card. Rename Rename the memory card. When a memory card is installed on your phone, the phone prompts you to select a storage device when you download or store a multimedia object.
Press 1 CHANGE (+) select Name 2 keypad keys enter a name for the playlist 3 OK (+) store the name 4 CHANGE (+) select Audio Files scroll to a song 6 CHECK (+) add the song to the playlist Repeat steps 5 and 6 to add more songs to the playlist 7 DONE (-)
Option Description Timer Set the number of minutes rhythm lights stay active (up to 10 minutes). Sensitivity Set how loud the music has to be before rhythm lights respond. Values range from 1 (least sensitive) to 7 (most sensitive). Notes: •...
® Setting Up a Bluetooth Wireless Connection Your phone supports Bluetooth wireless connections. You can set up a wireless link with a Bluetooth-enabled headset accessory, speakerphone, or handsfree car kit, or connect to a computer or hand-held device to exchange and synchronize data. Searching for Other Devices To connect your phone to a headset accessory or handsfree device:...
Copying Objects to Another Device You can use a Bluetooth wireless connection to copy a picture, sound, phonebook entry, datebook event, or bookmark from your phone to another phone, computer, or hand-held device. Copying a Multimedia Object Highlight the object on your phone that you want to copy to the other device, then press M >...
Page 26
The active viewfinder image appears on your display. Press S up or down to zoom Photo Storage in or out. Space Used IMAGE (Phone or AREA Memory Card) Press S left or right to Photo Viewfinder decrease or Memory Used:72% increase image Press CAPTURE (+)
Page 27
Press scroll to Send in Message, Store Only, Send as TIM Click, Apply as Wallpaper, Apply as Screen Saver, or Apply as Phonebook Entry 4 SELECT (+) perform the storage option Press M to open the Pictures Menu when the camera is active.
Changing Phone Skin Change the look and feel of your phone’s display by selecting a different skin setting. M > Settings > Personalize Find the Feature > Skin> skin Your phone displays the new skin. Press BACK (-) to return to the previous skin. Sending a Multimedia Message A Multimedia Messaging Service (MMS) multimedia message contains one or more...
Page 29
Press scroll to Picture, Voice Record, Sound, Video, New Page, Quick Note, or Contact Info 6 SELECT (+) select the file type highlight the file you want 8 SELECT (+) insert the file To add another slide to the message, continue to step 9. To send the message, go to step 14.
Page 30
Press 15 S scroll to a Send To option: Highlight [One Time Entry] to enter one or more phone numbers and/or email addresses. Highlight [New Phonebook Entry] to enter a number/address and add it to the phonebook. Or highlight an existing phonebook entry.
Page 31
Press 24 SELECT (+) select the file type 25 S highlight the file you want 26 SELECT (+) attach the file 27 BACK (-) return to the message editor 28 S scroll to Receipt to request a receipt, if desired 29 CHANGE (-) select Receipt 30 ADD (+) or...
Playing Video Clips You can download and play video clips on your phone. You can store these video clips in phone memory, or on a memory card. Tip: To see the video clips stored on a memory card, go to the Videos menu, then press M > Switch Storage Device >...
Learning to Use Your Phone See page 1 for a basic phone diagram. Using the Display The home screen is displayed when you are not on a call or using the menu. You must be in the home screen to dial a phone number. Service Provider Messages Date...
Page 34
Labels at the bottom corners of the display show the current soft key functions. Press the left soft key (-) or right soft key (+) to perform the indicated function. Notes: • Your home screen may appear different than shown. For example, your service provider may hide the menu feature icons to allow a better view of the wallpaper image.
Page 35
The following status indicators can display: 5. Active 6. Messaging 4. Roam Line Presence 7. Message 3. Signal 8. Battery Service Provider Strength Level 10/15/04 2. GPRS 9. Ring Style 1. Data 10. Location Transmission STYLES SOUND 1. Data Transmission Indicator Shows connection and data transmission status.
Page 36
2. GPRS Indicator Shows that your phone is using a high-speed General Packet Radio Service (GPRS) network connection. GPRS allows faster data transfer speeds. Other indicators can include: = GPRS PDP = GPRS packet context active data available 3. Signal Strength Indicator Vertical bars show the strength of the network connection.
Page 37
6. Messaging Presence Indicator Shows when instant messaging is active. Indicators can include: = IM active = available for IM = busy = invisible to IM = available for = offline phone calls When a Java™ application is active, a (Java midlet) indicator can display in this location.
9. Ring Style Indicator Shows the ring style setting. = loud ring = soft ring = vibrate = vibrate and ring = silent 10. Location Indicator Your phone may be able to send location information to the network during an emergency call. Indicators show when your phone is sending location information: Ö...
Using Menus From the home screen, press M to enter the main menu. Highlighted Right Soft Key Menu Feature Perform right Icon function. Phonebook Left Soft Key End Key Perform left Exit menu without EXIT SELECT function. making changes. 5-Way Navigation Menu Key Joystick With Enter menu...
Page 40
Menu Menu Icon Feature Icon Feature Multimedia ã Settings Chat Selecting a Menu Feature This guide shows you how to select a menu feature, starting from the home screen. M > Recent Calls > Dialed Calls Find the Feature This example shows that from the home screen, you must press M, scroll to and select Recent Calls from the main menu, then scroll to and select Dialed Calls.
Page 41
Selecting a Feature Option Some features require you to select an option from a list: Dialed Calls 10) John Smith Highlighted 9) Lisa Owens Option Press 8) Adda Thomas BACK (-) to 7) Jack Bradshaw go back to 6) Dave Thompson Press previous 5) John Smith...
Entering Text Some features require you to enter information. Entry Details Press S to Name: John Smith Highlighted Category: General scroll down to Option No.: 212-555-1212 other options. Type: Work Store To: Phone Press Voice Name: CHANGE(+) to Speed No.: 2 enter or edit Ringer ID: Continental information.
Page 43
Choosing a Text Entry Mode Multiple text entry modes make it easy for you to enter names, numbers, and messages. The mode you select remains active until you select another mode. Press # in any text entry screen to select one of the following entry modes: Primary The primary text entry mode (see...
Page 44
Using Capitalization Press 0 in any text entry screen to change text case. The following indicators show capitalization status: = no capital letters = capitalize next letter only = all capital letters Text Entry Mode Indicators When you select the Primary or Secondary text entry mode, indicators at the top of the display identify the text entry setting: Primary...
Page 45
Using Tap Mode This is the standard mode for entering text on your phone. Tap mode cycles through the letters and number of the key you press. Tap Extended mode also cycles through additional symbols as shown in the “Character Chart” on page 46. Press 1 a keypad key select a letter, number, or...
Page 46
When you enter text with Tap or Tap Extended mode, the soft key functions change. Character After displays at 2 seconds, insertion point. character is accepted and cursor moves to next position. Press DELETE (-) to delete DELETE character to left of insertion Press OK (+) to accept point.
Page 47
If you want a different word (such as progress), continue pressing keypad keys to enter the remaining characters. Character Chart Use this chart as a guide for entering characters with Tap Extended mode. . 1 ? ! , @ _ & ~ : ; " - ( ) ' ¿...
Page 48
• Press S left or right to move the flashing cursor to the left or right in a text message. • The first character of every sentence is capitalized. If necessary, press S down to change the character to lowercase before the cursor moves to the next position.
Page 49
If you want a different word (such as Progress), continue pressing keypad keys to enter the remaining characters. Entering Words In a text entry screen, you can press # to switch entry modes. An indicator tells you which mode is active (see page 43).
Page 50
you fill memory space for unrecognized words, your phone deletes the oldest words to add new words. Using Numeric Mode In a text entry screen, press # to switch entry modes until the (numeric) indicator displays. Press keypad keys to enter the numbers you want. When you finish entering numbers, press # to switch to another entry mode.
Page 51
Symbol Chart Use this chart as a guide for entering characters with symbol mode. . ? ! , @ _ & ~ : ; " - ( ) ' ¿ ¡ % £ $ ¥ @ _ \ / : ; "...
Using the Smart The smart key gives you another way to perform many basic phone functions. It anticipates the next action you are likely to perform. For example, when you highlight a menu item, you can press the smart key to select it. You can use the smart key to make and end calls, turn features on and off, and open your phonebook.
Changing a Code, PIN, or Password Your phone’s 4-digit unlock code is originally set to 1234, and the 6-digit security code is originally set to 000000. Your service provider may reset these codes before you receive your phone. If your service provider has not reset these codes, we recommend that you change them to prevent others from accessing your personal information.
Page 54
Locking Your Phone Manually M > Settings > Security Find the Feature > Phone Lock > Lock Now Press 1 keypad keys enter your unlock code 2 OK (+) lock the phone Unlocking Your Phone Tip: Your phone’s unlock code is originally set to 1234. Your service provider may reset the unlock code to the last 4 digits of your phone number.
If You Forget a Code, PIN, or Password Note: Your phone’s 4-digit unlock code is originally set to 1234, and the 6-digit security code is originally set to 000000. Your service provider may reset the unlock code to the last 4 digits of your phone number before you receive your phone.
Page 56
Storing a Phone Number Enter a phone number in the home screen, then press STORE (+) to create a phonebook entry with that number. Fill in the other fields to complete the entry. Select MORE to store another number (for example, a work number) for the same Name.
Page 57
When sorting by name, you can view All numbers or just the Primary number for each name. To set the primary number for a name, see page 83. Setting a Picture ID for a Phonebook Entry Press M > Phonebook > entry, press M > Edit > Picture >...
Setting Up Your Phone Storing Your Name and Phone Number To store or edit your name and phone number information on your SIM card: M > Settings > Phone Status Find the Feature > My Tel. Numbers Shortcut: Press M # from the home screen to edit your name and phone number.
You can select one of 5 different ring styles. The ring style indicator in the display shows the current ring style (see page 37). To set a ring style: M > Settings > Ring Styles Find the Feature > Style > style name Each ring style has settings for specific event alerts, ringer ID, and ringer and keypad volume.
Setting Event Lights When event lights are activated, your phone displays a light pattern to notify you of the following events: incoming calls from phonebook categories, incoming text and voicemail messages, alarms, power up, power down, ® battery charging, Bluetooth connect, Bluetooth activity, and Bluetooth disconnect.
Press 4 SELECT (+) select the image scroll to Layout 6 CHANGE (+) adjust the image layout scroll to Center, Tile, or Fit-to-screen Center places the image in the center of the display. Tile fills the display with adjacent copies of the image. Fit-to-screen resizes the image, if necessary, to fit the display.
Press scroll to Picture 2 CHANGE (+) open the picture viewer 3 S up or down scroll to a picture/animation Scroll to (None) to turn off the screen saver image. 4 SELECT (+) select the image scroll to Delay 6 CHANGE (+) set the delay interval scroll to the inactivity interval that starts the screen saver...
automatically when no activity is detected for a period of time. The backlight turns back on when you press any key. Setting Display Timeout To extend battery life, you can set the display to turn off when no activity is detected for a period of time. M >...
Calling Features For basic instructions on how to make and answer calls, see page 16. Changing the Active Line Change the active phone line to make and receive calls from your other phone number. Note: This feature is available only for dual-line-enabled SIM cards.
Using Automatic Redial When you receive a busy signal, your phone displays Call Failed, Number Busy. Press N or RETRY (+) redial the number When the call goes through, your phone rings or vibrates one time, displays Redial Successful, and connects the call. Using Caller ID Incoming Calls Calling line identification (caller ID) displays the...
Outgoing Calls You can show or hide your phone number as an ID for the calls that you make. M > Settings > In-Call Setup Find the Feature > My Caller ID You can override the default caller ID setting when you make a call.
Turning Off a Call Alert You can turn off your phone’s incoming call alert before answering the call. Press either volume key turn off the alert Calling an Emergency Number Your service provider programs one or more emergency phone numbers, such as 911 or 112, that you can call under any circumstances, even when your phone is locked or the SIM card is not inserted.
Viewing Recent Calls Your phone keeps lists of the calls you recently received and dialed, even if the calls did not connect. The lists are sorted from newest to oldest entries. The oldest entries are deleted as new entries are added. Shortcut: Press N from the home screen to view the dialed calls list.
The Last Calls Menu can include the following options: Option Description Store Create a phonebook entry with the number in the No. field. Delete Delete the entry. Delete All Delete all entries in the list. Hide ID/Show ID Hide or show your caller ID for the next call.
• X Missed Calls, where X is the number of missed calls Press 1 VIEW (+) see the received calls list select a call to return make the call Using the Notepad The most recent set of digits entered on the keypad are stored in your phone’s notepad memory.
Attaching a Number While dialing (with digits visible in the display): Press M > Attach Number attach a number from the phonebook or recent calls lists Calling With Speed Dial Each entry you store in your phonebook is assigned a unique speed dial number.
Using Voicemail Voicemail messages that you receive are stored on the network. To listen to your messages, you must call your voicemail phone number. Note: Your service provider may include additional information about using this feature. Listening to Voicemail Messages M >...
Storing Your Voicemail Number If necessary, use the following procedure to store your voicemail phone number on your phone. Usually, your service provider has already done this for you. M > Messages Find the Feature M > Voicemail Setup Press 1 keypad keys enter your voicemail number 2 OK (+)
Press answer the new call 2 SWITCH (+) switch between calls LINK (-) connect the 2 calls M > End Call On Hold end the call on hold You must turn on call waiting to use the feature. To turn call waiting on or off: M >...
Page 75
Announce the Call Transfer M > Hold Find the Feature Press 1 keypad keys dial the number where you are transferring the call call the number and speak to the person who answers open the menu scroll to Transfer 5 SELECT (+) select Transfer 6 OK (+) confirm the transfer...
Phone Features Main Menu This is the standard main menu layout. Menu organization and feature names may vary on your phone. Not all features may be available on your phone. Phonebook Games & Apps á Recent Calls Web Access • Received Calls •...
Settings Menu Personalize Phone Status • Rhythm Lights • My Tel. Numbers • Home Screen • Credit Info/Available • Main Menu • Active Line • Skin • Battery Meter • Greeting • Storage Devices • Wallpaper • Other Information • Screen Saver Headset •...
Feature Quick Reference This section helps you locate features on your phone that are not described in this guide. For more detailed information, see the More Here guide (described on page 8). Calling Features Feature Description Conference During a call: M >...
Page 79
Messages Feature Description Send Text Send a text message: M > Messages Message > Create Message > New Short Message Send Send a multimedia Multimedia message: M > Messages Message > Create Message > New Multimedia Msg Send Letter Send a multimedia letter: M >...
Page 80
Instant Messaging Feature Description Log In Log in to instant messaging: M > IM > Log In Find Others After you sign on: Select Contact List to see a Online list of other users. Start Start a conversation: From your Contact List, Conversation highlight a name in Online Contacts, press...
Page 81
Chat Feature Description Start Chat Start a new chat session: M > Chat M > New Chat Receive When you receive a chat Chat request: Press ACCEPT (+) or Request IGNORE (-). End Chat During a chat session: M > End Chat Email Feature Description...
Page 82
Feature Description Create Create a group mailing list as a Group phonebook entry: M > Phonebook Mailing List M > New > Mailing List Dial Number Call a number stored in the phonebook: M > Phonebook, highlight the phonebook entry, press N to call Voice Dial Voice dial a number stored in the Number...
Page 83
Feature Description Set Picture View phonebook entries as text list, ID View or with picture caller ID photos: M > Phonebook M > Setup > View by > list view Set the category for a phonebook Category for entry: M > Phonebook > entry Entry M >...
Page 84
Feature Description Set Primary Set the primary number for a Number phonebook entry with multiple numbers: M > Phonebook, scroll to entry, press M > Set Primary > phone number. Copy Copy a phonebook entry to another Phonebook phone, computer, or device: M >...
Page 85
Feature Description Keypad Set keypad keypress volume: M > Settings > Ring Styles > Style Detail Volume > Key Volume Reminders Set reminder alerts for messages that you receive: M > Settings > Ring Styles > Style Detail > Reminders Clock View Display an analog clock or digital time readout in the home screen:...
Page 86
Feature Description Shortcuts Create a shortcut to a menu item: Highlight the menu item, then press and hold M. Select a shortcut: M > Office Tools > Shortcuts > shortcut name Menu Features Feature Description Language Set menu language: M > Settings > Initial Setup > Language Master Reset all options except unlock code, Reset...
Page 87
Dialing Features Feature Description Fixed Dial Turn fixed dialing on or off: M > Settings > Security > Fixed Dial Use the fixed dial list: M > Office Tools > Dialing Services > Fixed Dial Service Dial service phone numbers: M >...
Page 88
the moment you end the call by pressing O. This time includes busy signals and ringing. The amount of network connection time you track on your resettable timer may not equal the amount of time for which you are billed by your service provider. For billing information, please contact your service provider directly.
Page 89
obey the laws and regulations on the use of these products. Feature Description Speaker- Activate a connected phone external speakerphone during a call: Press SPEAKER (+) (if available) or M > Spkrphone On. Auto Automatically answer calls when connected to a car kit Answer (car kit or or headset:...
Page 90
Feature Description Charger Charge the phone for a Time specified time after the (car kit) ignition is switched off: M > Settings > Car Settings > Charger Time Data and Fax Calls Feature Description Send Data Connect your phone to the or Fax device, then place the call through the device application.
Page 91
® Bluetooth Wireless Connections Feature Description Set Up a Set up a Bluetooth wireless Wireless connection to a headset accessory, Connection car kit, or external device: M > Settings > Connection > Bluetooth Link > Handsfree > [Look For Devices] Make Phone Allow an unknown Bluetooth Visible to...
Page 92
Feature Description Copy Copy a phonebook entry, Phonebook/ datebook event, or Datebook bookmark to another device: Entry to Highlight the item, press M > Send > Bluetooth, select the Device device name. Edit Device Edit the properties of a Properties recognized device: Highlight the device name and press M >...
Page 93
Feature Description View View or edit event details: M > Office Tools > Datebook, highlight the Datebook Event day, press the center select button, press VIEW (+) Event View event reminder: VIEW (+) Reminder Dismiss event reminder: EXIT (-) Copy Copy a datebook event to another Datebook phone, computer, or device:...
Page 94
Security Feature Description SIM PIN Lock or unlock the SIM card: M > Settings > Security > SIM PIN Caution: If you enter an incorrect PIN code 3 times in a row, your SIM card is disabled and your phone displays SIM Blocked.
Page 95
Feature Description Apply Phone Apply a grouped set of Theme image and sound files to your phone: M > Multimedia > Themes > theme Download Download a Java™ game Game or or application with the Application micro-browser: M > Web Access > Browser, (Micro- Browser) highlight the application, press...
Page 96
Feature Description Manage Manage video clips: M > Multimedia > Videos Video Clips Edit Sounds Edit MIDI-based songs that you can With use with your phone: M > Multimedia > MotoMixer > [New Mix] MotoMixer or mix file name Create Ring Create iMelody ring tones that you Tones can use with your phone:...
Specific Absorption Rate Data The model wireless phone meets the government’s requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S.
Page 98
2. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.
