Page 2
(M4 x L8) (M4 x L20) (M4 x L14) CHECK LG TV (Compatible TV models) y 55UJ652 y 55UJ654 (Asia) y 55UJ670 (Except Middle East and Iran) y 55UJ690 (Only Iran) y 55UJ701 LG Sound Bar Before installation, you have to detach TV's • When detaching or attaching the stand of the...
Page 3
Installation CAUTION for moving a TV (M4 x L8) Be careful not to get your fingers caught between the TV and the Sound Bar. (M4 x L20) (M4 x L14)
CAUTION Positioning For safety installation, there should be enough space between the wall and the installed product. 1 1 c m Cable management You can arrange the cables behind of your TV by using a supplied cable management clip. Compatible TV models Only TVs that have 1 pole type stand are available.
