Page 1 OPERATION MANUAL Please read this operation manual carefully before using the camcorder. If you require any advice or assistance regarding your Sharp product, please visit our web-site www.sharp.co.uk/ customersupport. Customers without Internet access may telephone 08705 274277 during office hours (or (01)676...
Page 2 This equipment complies with the requirements of Directives 89/336/EEC and 73/ 23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE.
Page 3 WARNING: THIS AC ADAPTER IS NOT FOR USE WITH TOYS. THIS AC ADAPTER IS FOR USE WITH SHARP CAMCORDER MODEL VL-Z400H-T ONLY. This unit can be operated by connecting it to either the AC adapter or battery pack. The AC adapter incorporates the AUTO VOLTAGE (AC 110–240 V, 50/60 Hz) function.
Page 4 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 3A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked is also indicated on the pin face of the plug, must be used.
Page 5 NOTE: The LCD panel of this camcorder is a very high technology product with more than 215,000 thin-film transistors*, giving you fine picture detail. Occasionally, a pixel may appear on the screen as a fixed point of blue, green, red, or black.
Page 6: Table Of Contents
Warning Indicators ... 4 Attaching and Removing the Battery Pack ... 6 Charging the Battery Pack ... 8 Powering the Camcorder from an AC Outlet ... 9 Inserting and Removing a Cassette ... 10 Inserting and Removing a Card ... 11 Installing the Lithium Batteries ...
Page 7 Manual Iris ... 58 Manual Gain ... 59 Setting the Shutter Speed ... 60 Tips on Manual Settings ... 61 Setting the Camcorder to Full Auto Mode ... 61 Scene Menu (Program AE) ... 62 Digital Picture Effects ... 63...
Page 8 Installing the USB Driver ... 84 Slide Show Playback ... 89 Picture/Backlight Adjustments ... 90 Turning off the Confirmation Sound ... 91 Setting the Camcorder to Factory Presettings ... 91 Demonstration Mode ... 92 Useful Information ... 93 Troubleshooting ... 99 Specifications ...
Page 9: Supplied Accessories
Supplied Accessories Battery pack BT-L227 CR1216 type lithium battery for camcorder USB cable Optional Accessories Standard-life External battery with battery pack BT-L227 Power cord AC adapter Lens cap 8 MB SD Memory Card hand strap BT-LCA1 Audio/video/S-video cable CD-ROM...
Page 10: Precautions
If noise occurs, use a commercially available cleaning tape to clean the video heads (see page xii). • When the camcorder is not in use, re- member to remove the cassette tape, turn off the power, and disconnect the camcorder from the power source.
Page 11: Dew Formation
2 To use the camcorder again, turn on the power after waiting for a few hours. Be sure that “DEW” has disappeared. 3 Do not insert a cassette while “DEW” is flashing;...
Page 12: Dirty Video Heads
• Long-time use • Dew formation If the video heads become clogged, the v indicator appears on the screen. Contact your SHARP dealer for further advice or refer to page 99 “Troubleshooting”. Using a Cleaning Tape (Commer- cially Available) Available mode:...
Page 13: Operation References
Operation References Part Names For details on the use of each part, refer to the page number indicated in parentheses. Front view Zoom lens Stereo microphone Operation button (p. 32) DISPLAY/MODE SET button (p. 32)/ LCD LAMP button (p. 25) MENU button (p.
Page 14 (p. 20) Tripod socket* * When attaching a tripod with a guide pin, do not attach the pin to the bottom of the camcorder. USB terminal (p. 85) Terminal cover (pp. 28, 31, 65, 66, 85) DV terminal (p. 66) Lithium battery cover (p.
Page 15 Right view Window cleaning cover (p. 97) Viewfinder (pp. 18, 19) STANDBY indicator (p. 25) POWER/CHARGE (RED) indicator (pp. 8, 9, 23) Record Start/Stop button (p. 23) Power switch (v Camera Recording mode/w Playback mode select switch) (p. 22) Power Zoom Wide angle/ PHOTO button Telephoto control (p.
Page 16: Warning Indicators
The fluorescent lamp behind the LCD monitor is close to the end of its service life. Call your local L AMP authorized Sharp dealer to have it replaced. The battery is almost depleted when the camcorder transfers data through the USB cable.
Page 17 Delete unnecessary images (see page 78) or replace the card with FUL L a new one (see page 11). The card has no images recorded in the format the camcorder can NO DA T A ON recognize. MEMORY C ARD...
Page 18: Preparation
Attaching Make sure that the Power switch is set to OFF. Open the LCD monitor to a 90° angle to the camcorder body. 90° Slide the battery pack in the direction of the arrow with the “m” mark facing out.
Page 19 • To prevent damage to the battery pack when removing, be sure to firmly hold the battery pack while pressing the release. • Use only SHARP model BT-L227 battery packs with this camcorder. Use of other batteries may create a risk of fire or explosion.
Page 20: Charging The Battery Pack
• See pages 96 and 97 for more information on using the battery pack. • Charge only SHARP model BT-L227 battery packs. Other types of battery packs may burst, causing personal injury and damage.
Page 21: Powering The Camcorder From An Ac Outlet
Powering the Camcorder from an AC Outlet You can also power the camcorder from a power outlet by using the supplied AC adapter. Note: • The supplied AC adapter is specially designed for use with this camcorder, and should not be used as a power supply for other camcorders.
Page 22: Inserting And Removing A Cassette
• Do not apply force to the cassette holder except when pressing the “PUSH” mark to close it. • Do not tilt the camcorder or hold it upside down when you are inserting or removing a cassette. It may damage the tape.
Page 23: Inserting And Removing A Card
• The supplied card is preformatted for immediate use. • See page 95 for more information on the cards intended for use with this camcorder. • Do not remove the card from the camcorder while recording data on the card (S indicator flashes during record- ing).
Page 24: Installing The Lithium Batteries
Make sure that the Power switch is set to OFF. Open the LCD monitor to a 90° angle to the camcorder body. Slide the battery release in the direction of the arrow, then take the battery pack out.
Page 25: Not Supplied
Remote Control (Not supplied) The remote control (RRMCGA237WJSA) is not supplied with this camcorder. Contact the nearest SHARP service centre or your dealer for purchasing as specified part. The CR2032 type lithium battery is used to power the remote control unit.
Page 26: Setting The Date And Time
Preparation Setting the Date and Time Available modes: All modes Example: Setting the date to 2 June 2005 (2. 6. 2005) and the time to 10:30 am (10:30). Operation button MENU button Note: • Before performing the steps below, make sure that the CR1216 type lithium battery has been installed (see page 12).
Page 27: Changing To The 12-Hour Time Mode
Press m or l to select “30” (minute), then press the centre of the Operation button. SE T T I NG RETURN • The internal clock now starts operating with the seconds display. Press the MENU button to turn off the menu screen.
Page 28: Using The Lens Cap
When recording, remove the lens cap and attach the lens cap cord to the fastener so that the cap will not get in the way. Fastener Note: • Always attach the lens cap over the lens when not using the camcorder.
Page 29: Adjusting The Hand Strap
Adjusting the Hand Strap Open the hand strap flap (1) and grip strap (2). Hand strap flap Loosen the grip strap, pass your right hand through the hand strap, and put your thumb close to the Record Start/ Stop button and your index finger on the Power Zoom control.
Page 30: Detaching The Lens Hood
Preparation Detaching the Lens Hood Before using a commercially available conversion lens, detach the lens hood as shown below. Note: • You cannot attach the supplied lens hood or lens cap to a conversion lens. Using the Viewfinder You can record the subject using the electronic viewfinder.
Page 31: Adjusting The Dioptre
Push in the viewfinder completely. Notes: • Do not use excessive force when moving the viewfinder. • Do not pick up the camcorder by the viewfinder. • The viewfinder automatically turns off when the LCD monitor is opened. If the vertical rotation of the monitor is 180°...
Page 32: Using The Lcd Monitor
• When closing the LCD monitor, do not tilt it; otherwise the monitor may not close properly and may become damaged. • Do not pick up the camcorder by the LCD monitor. • Do not place the camcorder with the LCD monitor screen facing down.
Page 33: Tips On Recording Positions
To create images that are easy to watch during playback, try to record with an upright posture and steady hands to prevent a shaky image. Holding the camcorder Put your right hand through the hand strap, and place your left hand under the camcorder for support. Basic posture...
Page 34: Basic Operations
• To turn the power off, set the Power switch to OFF without pressing the Lock button. • Do not change the camcorder mode by operating the Media Selection switch during recording or playback, as this may cause damage to the tape or card.
Page 35: Easy Camera Recording On Tape In Full Auto Mode
Hold down the Lock button and set the Power switch to v. • The picture from the lens now displays and the POWER/CHARGE (RED) indicator lights up green. • The camcorder is now ready to record (Recording Standby mode). POWER/CHARGE (RED) indicator A U T O...
Page 36: Zooming
• The zoom speed depends on how far you push the Power Zoom control. Notes: • The camcorder is unable to focus when zooming in on subjects closer than 1.5 m. • See page 34 for how to use the digital zoom.
Page 37: Power Standby Mode
— When the camcorder remains in Power Standby mode for more than 5 minutes — When the camcorder is set to Card Camera, Tape Playback or Card Playback mode — When removing the battery pack —...
Page 38: Auto Focus
1.5 m. Set the zoom control to wide angle, and try refocusing again. • If the lens is dirty or fogged, the camcorder may not be able to focus correctly. Macro Shots...
Page 39: Remaining Battery Power Display
Remaining Battery Power Display Available modes: All modes When using the camcorder with the battery pack as the power source, the remaining battery power indicator is displayed. If the battery power becomes very low, a warning indicator appears. Replace the battery pack.
Page 40: Using Earphones (Commercially Available)
Stereo earphones with a 3.5 mm diameter plug can be used with this camcorder. Connect the plug of stereo earphones to the earphones jack on the camcorder as shown below. Earphones jack Notes: • Before connecting stereo earphones, turn the camcorder volume down to the lowest setting.
Page 41: Playback
• When selecting “5 MIN” or “10 MIN” in power save mode and remaining in stop mode Power switch without any operation for 5 or 10 minutes, the camcorder will turn off automatically. Watching the playback in the viewfinder You can also watch the playback in the viewfinder by closing the LCD monitor with the screen facing in.
Page 42: Volume Control
To return to normal playback, press m again. Notes: • The sound is off in Still mode. • To protect the tape, the camcorder automati- cally returns to normal playback if it is left in Still mode for more than 5 minutes. Video Search...
Page 43: Watching Playback On A Tv
Watching Playback on a TV Available modes: Tape Playback, Card Playback You can connect the camcorder to a TV to allow a larger audience to enjoy playback. Open the terminal cover on the camcorder (see page 2). Terminal cover Connect the camcorder to your TV (or VCR) with the supplied audio/video/ S-video cable, as shown.
Page 44: Useful Features
S E L E C T P A U S E Using the Mode Screens In the mode screens, you can adjust the camcorder settings by using the Operation button. Set to the desired camcorder mode by using the Media Selection switch and the Power switch (see page 22).
Page 45: Using The Menu Screens
O F F O F F • Certain menu items are common to all camcorder modes. If the BEEP menu item, for example, is set to “OFF” in Tape Camera mode, it will be automatically set to “OFF” in other modes.
Page 46: Camera Recording
Useful Features Useful Features Camera Recording Setting the Digital Zoom Available mode: Tape Camera You can select three different zoom ranges: 1–10K (optical zoom), 10–40K (digital zoom) or 10–700K (digital zoom). The digital zoom allows you to record powerful close-up pictures with the same operation as normal zooming.
Page 47: Backlight Compensation (Blc)
Backlight Compensation (BLC) Available modes: Tape Camera, Card Camera When the subject is backlit, the image will appear dark if it is recorded normally. Use the backlight compensation (BLC) function to brighten the entire screen. • The example screens shown are for Tape Camera mode.
Page 48: Gain-Up
(see page 58). • The e indicator will disappear and Gain-up mode will cancel if you aim the camcorder in a bright location. S E T E X E C U T E P A U S E...
Page 49: Fade In And Fade Out
Record Start/Stop • The image and sound fade out as the button picture gradually turns white. The camcorder then returns to Recording Standby mode. To cancel Fade mode Select “OFF” in step 3 above. To use Fade Out only...
Page 50: Quick Return
• Quick return will not work if you remove the cassette and reload it after recording or if nothing has been recorded since loading. • When the camcorder remains in Recording S T A R T Standby mode for more than 5 minutes and S T O P enters stop mode, quick return will not work.
Page 51: Edit Search
6.5 times the normal playback. • You may experience picture noise during reverse edit search. • When the camcorder remains in Recording Standby mode for more than 5 minutes and enters stop mode, edit search will not work.
Page 52: Digital Image Stabilization (Dis)
• The DIS function cannot compensate for excessive image shaking. • When image shaking does not occur (e.g. when using the camcorder on a tripod), turn off the DIS function. The picture will appear more natural when the DIS function is off.
Page 53: Wide Mode
Wide Mode Available mode: Tape Camera The wide screen function lets you record scenes with the wide-screen feel of a movie shown in a theatre. The top and bottom of the picture are masked with black bands to produce an effective screen aspect ratio of 16:9.
Page 54: Power Save Mode
Available modes: All modes Power save mode will turn off the camcorder automatically to save battery power when the camcorder is not in use for 5 or 10 minutes. Note: • To resume recording or playback, set the Power switch to OFF, then back to v or w.
Page 55: Self Recording
If the camcorder is steadied, you can record yourself in the scene by watching yourself on the LCD monitor. The remote control is useful for such occasions.
Page 56: Self Recording With Reversed Grip
Rotate the lens section 105° vertically as shown below. 105° Open the LCD monitor to a 90° angle to the camcorder body (1), and then rotate it 180° vertically (2). 90° 180° Set the Media Selection switch to V.
Page 57: Recording In Lp (Long Play Recording) Mode
Recording in LP (Long Play Recording) Mode Available mode: Tape Camera This camcorder allows you to record in LP (Long Play Recording) mode for approxi- mately 50% more recording time with the same picture quality as that in SP (Standard Play Recording) mode.
Page 58: Selecting The 16-Bit Audio Recording Mode
Selecting the 16-bit Audio Recording Mode Available mode: Tape Camera The camcorder normally records audio in the 12-bit audio recording mode. For higher- quality audio recording, select the 16-bit audio recording mode. In Tape Camera mode, press the MENU button to display the menu screen.
Page 59: Windbreak
Windbreak Available mode: Tape Camera The windbreak function allows you to reduce annoying noise from strong winds when recording. In Tape Camera mode, press the MENU button to display the menu screen. Press l or m on the Operation button to select Y, then press the centre of the Operation button.
Page 60: Using The Remote Control (Not Supplied)
(Not Supplied) Available modes: All modes The remote control (RRMCGA237WJSA) is not supplied with this camcorder. Contact the nearest SHARP service centre or your dealer for purchasing as specified part. Activating • The example screens shown are for Tape Playback mode.
Page 61: Selecting The Date And Time Of Recording Display
Selecting the Date and Time of Recording Display Available modes: All modes Follow the procedure below to select the date, or both the date and time, of recording display on the screen. You can display the date and time during both recording and playback.
Page 62: Picture Effect Playback
Useful Features Playback Picture Effect Playback Available modes: Tape Playback, Card Playback These picture effects let you play back images with a more dramatic effect. Types B/W: The picture is displayed in black-and-white. SEPIA: The picture is displayed in sepia colour similar to that of an old photograph.
Page 63: Rotate Playback
• When executing rotate playback during Tape Playback, playback will stop. Press m to begin rotate playback. • Even if the camcorder is in rotate playback mode, the image output via a DV connection will display as normal playback. • When you want to display the menu screen during rotate playback, press the centre of the Operation button.
Page 64: Copying An Image From Tape To Card
Insert the recorded Mini DV cassette and a card in the camcorder. Set the camcorder to Tape Playback mode, then begin tape playback. Press m on the Operation button at the point where the desired image appears.
Page 65: Stretch Playback
Useful when you want to play back images recorded by a camera other than this camcorder in wide mode on a 4:3 TV. Squeezed image Stretch playback...
Page 66: Advanced Features
Available modes: Tape Camera, Card Camera Auto Focus may not be able to focus on the subject in the situations shown below. In such situations, set the camcorder to Manual Focus mode and focus manually. Subject is too dark. Fast-moving subject.
Page 67: Returning To Auto Focus
Returning to Auto Focus Available modes: Tape Camera, Card Camera You can set Manual Focus mode to Auto Focus mode with the operation below. • The example screens shown are for Tape Camera mode. In Tape Camera or Card Camera mode, press the DISPLAY/MODE SET button until the mode screen appears.
Page 68: Adjusting White Balance
Advanced Features Camera Recording Adjusting White Balance Available modes: Tape Camera, Card Camera The colour of the subject on the screen looks different depending on lighting conditions. Selecting a White Balance setting that matches the lighting conditions. Types AUTO: Colouring adjusted automati- cally for the current lighting condition.
Page 69 Press j in step 4 in “Selecting” on the previous page or step 3 in “Locking” to display “AUTO”. To return to Full Auto mode Set the camcorder to Full Auto mode (see page 61). Note: • White Balance setting cannot be used...
Page 70: Manual Iris
Camera Recording Manual Iris Available modes: Tape Camera, Card Camera The camcorder is preset to Auto Iris mode, which automatically selects the optimal aperture. However, when there is too much contrast in brightness between the subject and background, you may not be able to record a clear image.
Page 71: Manual Gain
To return to Auto Gain mode Press j in step 4 above to display “AUTO”. To return to Full Auto mode Set the camcorder to Full Auto mode (see page 61). Note: • Manual Gain mode cannot be used when a scene setting is selected.
Page 72: Setting The Shutter Speed
To return to Auto Shutter Speed mode Press j in step 4 above to display “AUTO”. To return to Full Auto mode Set the camcorder to Full Auto mode (see page 61). Recommended Shutter Speeds The faster the shutter speed, the darker the picture becomes.
Page 73: Tips On Manual Settings
A U T O S HU T . S P E E D R E T U RN Setting the Camcorder to Full Auto Mode Available modes: Tape Camera, Card Camera You can set all the settings shown in the screen to Full Auto mode in one operation.
Page 74: Scene Menu (Program Ae)
Scene Menu (Program AE) Available modes: Tape Camera, Card Camera You can set the camcorder to a shooting mode that will create the best results for a specific situation. Just select one of the six scene settings shown below. The...
Page 75: Digital Picture Effects
Digital Picture Effects Available mode: Tape Camera These digital picture effects let you record the subject with a more dramatic effect. Types B/W: To record in black-and-white. SEPIA: To record in sepia colour similar to that of an old photograph. SOLARI: To record with enhanced contrast, creating an unique artistic image.
Page 76: Advanced Features
Advanced Features Advanced Features Playback Playback Using the Time Code Available modes: Tape Camera, Tape Playback The time code shows the hour, minute and second of recording, and the frame number (1 frame = approx. 1/25 sec.). This is automatically recorded along with the subject when you are recording on the tape.
Page 77: Editing
This camcorder lets you monitor the source program on the built-in LCD monitor without having to connect it to an external TV or video monitor. Preparation Connect the camcorder to a VCR with the supplied audio/video/S-video cable, as shown. Recording (VCR) L-AUDIO-R...
Page 78: Editing With The Dv Terminal (Ieee1394)
Playback Editing with the DV Terminal (IEEE1394) Available mode: Tape Playback This camcorder can be used as a digital video editor. A DV cable transfers all dubbing signals including video and audio directly to the camcorder. Preparation Connect the camcorder to video equipment with a DV terminal using a commercially available DV cable.
Page 79: Selecting The Audio Playback Mode
Selecting the Audio Playback Mode Available mode: Tape Playback You can select any of the following audio playback modes. Audio 1H2 • 12-bit recording in stereo (Audio 1 and Audio 2 channels) • 16-bit recording in stereo (left and right channels) Audio 1 •...
Page 80: Audio Dubbing Feature
Audio Dubbing Feature Available mode: Tape Playback You can add narration to recordings made with this camcorder, while preserving the original audio and video recordings. Microphone for Audio Dubbing You can use the built-in stereo microphone to record narration. Built-in stereo...
Page 81: Audio Dubbing
Notes: • It is recommended that you use Audio Dubbing only with recordings made with this camcorder. Use of recordings made with other digital video equipment may result in poor audio quality. • Audio dubbing will automatically pause if the original audio changes from 12-bit mode to 16-bit mode or vice versa.
Page 82: Digital Still Camera Features
PHOTO button Media Selection switch Insert a card into the camcorder (see page 11). Remove the lens cap. Set the Media Selection switch to u. Hold down the Lock button and set the Power switch to v.
Page 83: Selecting The Picture Quality
Selecting the Picture Quality Available mode: Card Camera The picture quality of still images recorded on the card depends on the picture quality setting. Select the appropriate setting to match your recording objectives. Types NORMAL: Records images with standard picture quality. ECONOMY: Allows you to take more shots than in NORMAL mode but with lower quality.
Page 84: Recording With The Self-Timer
Selecting the time-lag When you hold the PHOTO button half-way down in 2 SEC mode, the camcorder will lock the focus. This will prevent the camera movement. But it will not lock the focus in 10 SEC mode.
Page 85 Notes: E X E C U T E • When recording with the self-timer, stabilize the camcorder in the horizontal plane by attaching it to a tripod, etc. • Self-timer mode cancels after recording one image. Repeat steps 1 to 4 to record another image with the self-timer.
Page 86: Formatting A Card
Press the MENU button to turn off the menu screen. Notes: • The supplied card is preformatted for immediate use. • Use this camcorder to format a card. The camcorder may not recognize the images on a card formatted by a computer or other equipment. EXECUT E...
Page 87: Setting The File Numbering Method
Setting the File Numbering Method Available mode: Card Camera The camcorder automatically assigns file numbers to captured images. You can select two different methods of file number- ing. Types SERIAL: Defines file numbers by incrementing up from the last image captured when inserting a new card.
Page 88: Card Playback
• You can also set in the mode screen to display the images in full screen or thumbnails. • Depending on the amount of image data recorded by a camera other than this camcorder, the picture quality indicator displayed during playback may not match the picture quality setting used during recording.
Page 89: Delete Protection
Delete Protection Available mode: Card Playback You can prevent your important images recorded on the card from accidental erasure. In Card Playback mode, press the DISPLAY/MODE SET button until the mode screen appears. Press l or m on the Operation button to select “PROTECT”, then press the centre of the Operation button.
Page 90: Deleting Stored Images
Digital Still Camera Features Playback Deleting Stored Images Available mode: Card Playback Deleting One Stored Image You can delete unwanted images to free up memory of a card for new images. Note: • Deleted images cannot be restored. Check whether or not you want the images before performing the procedure below.
Page 91: Deleting All Stored Images
Deleting All Stored Images You can delete all stored images on a card in one operation. Notes: • Deleted images cannot be restored. Check whether or not you want the images before performing the procedure below. • If you want to keep some images on the card, first delete-protect them (see page 77), and then perform the procedure below.
Page 92: Print Order
Digital Still Camera Features Playback Print Order Available mode: Card Playback The print order function allows you to add print information called DPOF to still images recorded on a card. About DPOF DPOF (Digital Printing Order Format) defines the print information for the specific images and number of each image on memory cards.
Page 93 To cancel the print order for an image Select the image for cancelling out of print order in step 5 above, then press the centre of the Operation button. Press l to select “0”, then press the centre of the Operation button. •...
Page 94: Direct Print
See the printer's operation manual for the details. • When connecting the camcorder to a printer, “CHECK THE PRINTER SETTINGS.” may appear. In this case, disconnect and connect the USB cable before or after printing. If the message still appears, turn off and on the printer.
Page 95: Transferring Data On Card To Computer
To transfer data from the card, first install the software from the supplied CD-ROM. The CD-ROM includes “USB Driver”, “PixLab Media Browser” and other related files. • “USB Driver” is the software that transfers images from the camcorder when connecting to the PC with the supplied USB cable.
Page 96: Installing The Usb Driver
Turn on the computer. • Do not connect the camcorder to the computer with the USB cable at this point. Insert the supplied CD-ROM containing the USB driver into the CD-ROM drive. • The License Agreement/Install Key screen will display automatically.
Page 97 • Connect the USB cable directly to the USB terminal of computer. • To prevent malfunction, turn off the camcorder when you connect to the computer. Set the Media Selection switch to u. Hold down the Lock button and set the Power switch to w.
Page 98 Digital Still Camera Features Playback Using the PDF Manual Use of the installed “PixLab Media Browser” is explained in the PDF Operation Manual. Installing Adobe Reader Adobe Reader 6.0 (or Adobe Acrobat Reader 4.0 or later) is required for viewing the PDF manual.
Page 99: Disconnecting The Usb Cable
Transferring the data on Card to Computer Connecting the camcorder to the computer Connect the camcorder to the computer with the supplied USB cable (see page 85). Transferring data Turn on the computer, then connect the camcorder with the supplied USB cable.
Page 100 • • • • • • 100SHARP DVC00001.JPG DVC00002.JPG Note: • If you copy any data incompatible with this camcorder to the card, the camcorder will not be able to recognize it. Sub-folder of still images Serial number (100 to 999)
Page 101: Slide Show Playback
5 seconds. This is useful when confirming the data recorded on a card. Set the camcorder to Card Playback mode. Press j, k, l or m on the Operation button to select the image from which you want to begin slide show playback.
Page 102: Appendix
Appendix Appendix Picture/Backlight Adjustments Available modes: All modes If the picture is difficult to see due to ambient light or other factors, adjust the monitor picture settings. • The example screens shown are for Tape Camera mode. Adjusting the Picture Press the MENU button to display the menu screen.
Page 103: Turning Off The Confirmation Sound
Setting the Camcorder to Factory Presettings Available modes: All modes You can set the camcorder to the factory presettings in one operation. • The example screens shown are for Tape Camera mode. Press the MENU button to display the menu screen.
Page 104: Demonstration Mode
You can watch a brief demonstration of the special camcorder features in Demo mode. If the demonstration appears on the screen when you turn on the camcorder for the first time, cancel the Demo mode to use your camcorder. Watching •...
Page 105: Useful Information
• Be sure to use only Mini DV cassettes with the i mark. • This camcorder can record and play back using Mini DV cassettes with built in memory (MIC), but it cannot record to, or play back from this memory.
Page 106 Some digital video recording with prere- corded copyright protection signals can still be played back on this camcorder. If you play a digital video recording that has a copyright protection signal on video equipment with a DV terminal and attempt to record a copy of that software on this camcorder, “COPYRIGHT PROTECTED.”...
Page 107 • Be aware that formatting will erase all image data stored on the card. Note: • Sharp Corporation cannot be held liable for data that is lost through improper handling of the storage media. Cleaning •...
Page 108: Battery Pack
(see page 7). Note: • Use only SHARP BT-L227 battery packs. These are designed specifically for use with this camcorder. Storage • Store the battery pack in a fully dis- charged state.
Page 109 LCD monitor. If the monitor becomes dark or difficult to view, the fluorescent lamp may need to be replaced. Contact the nearest SHARP service centre or your dealer for further advice. Cleaning • Many plastic parts are used in the camcorder casing.
Page 110: Using Your Camcorder Abroad
When you are abroad, check the sections below before using the AC adapter or connecting the camcorder to a TV. AC Adapter (Supplied Accessory) The supplied AC adapter is compatible with 50 Hz and 60 Hz electrical systems in the range of 110 V to 240 V AC.
Page 111: Troubleshooting
Where this is not possible, please visit our web-site www.sharp.co.uk/customersupport. Customers without Internet access may telephone 08705 274277 during office hours (or (01)676 0648 if telephoning from Ireland).
Page 112 Appendix Symptom No image appears on connected TV screen. Cannot rewind or fast forward tape. Video noise in image. No sound. Tape does not work. Still images in Card mode are rotated 180° upside down. Motion images are rotated 180° upside down.
Page 113 Symptom Cannot delete image Image is delete-protected. on card. Cannot format card. Battery pack is easily Using camcorder in extremely cold depleted. environment. Battery pack is not fully charged. Clock has been re- Lithium battery is not properly in- set.
Page 114 The characters on the monitor should be normal. Set the date and time, then resume operation. Possible cause The camcorder may be damaged. Suggested solution Do not take out a cassette, and call...
Page 115: Specifications
Specifications Camcorder Signal System: PAL standard Recording System: 2 rotary heads, helical scanning system Recording/Playback Time: 90 minutes (DVM60, LP mode) Tape Speed: SP mode: 18.831 mm/second Pickup Device: Lens Filter Diameter: 30 mm Viewfinder: 0.16" LCD panel (with 113,578 pixels), slide type...
Page 116: On-Screen Display Index
Appendix On-screen Display Index Tape Camera mode p. 27 p. 40 p. 61 p. 26 A U T O A U T O A U T O 3 0min M A NU A L S E T E X E C U T E F O C U S A U T O F O C U S B L C / G A I N...
Page 117: Menu Button
Tape Playback mode p. 27 AUDIO 2 p. 67 P L A Y S T O P R EW DISPLAY/MODE SET button AUDIO 2 P I C . E F F E C T O F F AUD I O DUB S TRE TCH P B S E L E C T Mode screens...
Page 118 Appendix Card Camera mode p. 27 p. 70 p. 61 A U T O A U T O A U T O M A NU A L S E T E X E C U T E F O C U S A U T O F O C U S B L C / G A I N A U T O...
Page 119 Card Playback mode - 0 1 0 NORMA L p. 76 S E L E C T I MG S E L E C T I MG F U L L F U L U L L MULT I MULT I DISPLAY/MODE SET button - 0 1 0 F U L L...
Page 120: Index
Appendix Index AC adapter ... 8, 9 Audio dubbing ... 68, 69 Audio playback mode ... 67 Audio recording mode ... 46 Auto focus ... 26 AV terminal ... 31, 65 Backlight ... 25, 90 Backlight compensation (BLC) ... 35 Battery release ...
Page 121 Manual focus ... 54 Manual setting ... 55 Media Selection switch ... 22 MENU button ... 33 Menu screen ... 33 Mini DV cassette ... 10, 93, 94 Mode screen ... 32 MultiMediaCard ... 95 Operation button ... 32 Part names ... 1-3 Phones volume ...
Page 122 Note...
Page 123 SHARP CORPORATION SHARP ELECTRONICS (U.K.) LTD. Sharp House, Thorp Road, Newton Heath Manchester M40 5BE Printed in Malaysia TINSEA083WJN1 04P04-M-G Printed on 100% post-consumer recycled paper.

Sharp Viewcam VL-Z400H-T Operation Manual

Operation References

Preparation

Basic Operations

Camera Recording

Playback

Useful Features

Camera Recording

Playback

Advanced Features

Camera Recording

Playback

Advanced Features

Digital Still Camera Features

Camera Recording

Playback

Appendix

Quick Links

Related Manuals for Sharp Viewcam VL-Z400H-T

Summary of Contents for Sharp Viewcam VL-Z400H-T

Table of Contents
