Replacing The Main Battery - Motorola LS950v User Manual

your voice unit requires service, you can contact
any Motorola Service Organization.
Our service organizations are staffed with specially
trained technicians and are conveniently located
throughout the world. Please contact your paging
service representative or a Motorola sales office for
more information.

Replacing the Main Battery

To replace the main battery in your LS950v perform
the following steps:
1. Unlock the cover and slide it to the side as
illustrated below. Flip open the battery cover.
2. Remove the battery from the compartment.
3. Replace the battery with a new AA alkaline
battery, close, and lock the cover.
Locking Tab
Slide Out &
Flip Open
the Cover
Main Battery
Opening Battery Compartments
12
Remove Screw
To Open Cover
Back-up Battery
