Acer Air Monitor User Manual page 4

A tour of the device
Item
1 Function button &
Light sensor
2 Wall-mounting hole
3 Battery LED
indicator
4 Power switch
5 Micro-USB
connector
6 Wi-Fi indicator
7 Air quality
indicator
8 Front panel
•
Short press - Detect air quality immediately
•
Long press (5 secs), after the beep, immediately let go of the button -
Reset Wi-Fi for configuration. The recorded Wi-Fi AP and password
setting will be cleared
Used for hanging the device on a hook
Shows the battery status:
•
Green - Battery is fully-charged
•
Red - Battery is charging
•
Off - power adapter not connected
Turns the power on and off
There is no power LED indicator
Connects to the power adapter
Shows the wireless connection status:
•
Green - Local Wi-Fi network and Acer Cloud connected
•
Red - Local Wi-Fi network connected only (device can not access
internet or cannot connect to the Acer Cloud)
•
Off - Wi-Fi is not configured or device is disconnected from the Wi-Fi
network
Lights up using different colors to show the current air quality.
Detach to reveal the particulate matter sensor for maintenance
4
-
Description
-
