- Inverter Split System Air Conditioner -
Contents
1.
GENERAL .......................................................... 3
2.
3.
4.
5.
POSITION ......................................................... 17
6.
7.
DEVICE.............................................................. 19
8.
85264189998000 © SANYO 2006
INSTALLATION INSTRUCTIONS
This air conditioner uses the new refrigerant R410A.
Page
SANYO FISHER COMPANY
A DIVISION OF SANYO NORTH AMERICA CORPORATION
21605 Plummer Street
Chatsworth, CA 91311 U.S.A.
Model Combinations
Combine indoor and outdoor units only as listed
below.
Indoor Unit
KMHS0772
KMHS0972
KMHS1272
KMHS1872
KMHS2472
Power Source:
60 Hz, single-phase, 230 / 208 VAC
Combinations of indoor and outdoor units
Connect indoor and outdoor units only in the combi-
nations listed in the catalog or installation manual.
CAUTION
Connecting any other model may result in
operation failure and system damage.
Be sure to read the yellow instruction sheet
attached to the outdoor unit for models using the
new refrigerant R410A.
NOTE
The illustrations are based on the typical appearance of
a standard model. Consequently, the shape may differ
from that of the air conditioner that you are installing.
For Indoor Unit
COOL / DRY/ HEAT Model
Outdoor Unit
CMH1972
CMH2472
CMH3172
In Canada
SANYO Canada Inc.
300 Applewood Crescent, Concord
Ontario, L4K 5C7, Canada
