Page 1: User Manual
Power Zoom Camera User Manual imagine Thanks you for purchasing this Samsung product. To receive a more complete service, please visit our website www.samsungsecurity.com the possibilities SCC-C4237P SCC-C4337P SCC-C4239P SCC-C4339P... - Page 2 overview CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit.
- Page 3 Continued use in such a condition may cause fi re or electric shock. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifi cations or attempted repair.) When cleaning, do not spray water directly onto parts of the product.
-
Page 4: Important Safety Instructions
overview IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifi... -
Page 5: Table Of Contents
CONTENTS OVERVIEW INSTALLATION & CONNECTION APPENDIX Important Safety Instructions Contents Features What’s Included Part Names and Functions Preparing Installation Connecting the Cables Main Menu SETUP Profi le Camera Set Intelligent Video Privacy Zone Preset Other Set Communication System Info Language Shortcut Keys Specifi... -
Page 6: Overview
600-line high resolution implemented. High Sensitivity: It implements images of high sensitivity using the up-to-date Super- HAD IT CCD(SCC-C4237P/C4337P)/ExView-HAD PS CCD(SCC-C4239P/C4339P). VPS(Virtual Progressive Scan): This is an advanced technology that reproduces a sharp progressive image. This is appropriate to high quality recording and fi le transfer via the Internet. -
Page 7: What's Included
WHAT’S INCLUDED Please check if your camera and accessories are all included in the product package. Camera PART NAMES AND FUNCTIONS SIDE VIEW Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied ethanol. - Page 8 Rear Panel SCC-C4337P SCC-C4237P Input/Output Connector This connector has input and output ports for RS-485 control signals, DAY/NIGHT switching, and alarm output signals. SCC-C4239P/C4339P 8_ overview SCC-C4339P SCC-C4239P SCC-C4237P/C4337P...
- Page 9 1. ALARM OUT Alarm out jack for motion detection. (Open Collector, On Gnd) 2. GND Grounding jack. 3. TRIGGER IN (SCC-C4239P/C4339P) Displays the current still image when it receives the Trigger signal. (Normal Open Type) 4.5.6 FOCUS, COM, ZOOM This port is used for ZOOM/FOCUS, MENU CONTROL, HOME RETURN, and ONEAF by using an external controller.
- Page 10 * 2 : For short voltage supply during MENU OFF, executes ONEAF and for more than 2 second * 3 : For more than 2 second long voltage supply, moves to the PRESET 0(HOME) position. 7. 5V OUT Power supply jack for RS-485 JIG. Use within typical DC +5V 100mA. 8.
-
Page 11: Installation & Connection
installation & connection PREPARING INSTALLATION To install and use the camera, fi rst prepare the following cables. POWER ADAPTER CABLE (SOLD SEPARATELY) The requirements for the power adapter, which connects to the camera’s POWER IN terminal, are as follows: - SCC-C4237P/C4239P : DC 12V 600mA - SCC-C4337P/C4339P: AC 24V 300mA VIDEO CABLE(SOLD SEPARATELY) Use a BNC cable, such as the one shown below, to connect the camera’s VIDEO... - Page 12 installation & connection BNC cable(not included) 3. Plug in the power adapter(not inlcluded). Use a “minus” screwdriver to connect one part of the power adapter, which consists of two lines, to the POWER terminal of the camera as follows : 12_ installation &...
- Page 13 6. The requirements for RS485 control is as follows : - Signaling Speed: 9600 bps - Data Bit : 8 bits - Stop Bit : 1 bit - Parity Bit : none SYSTEM INFO 4_34 ZOM_WDR_P 4_34 ZOM_WDR_P SAMSUNG SAMSUNG RS485,HALF RS485,HALF 9600 9600 V1.00_090817 V1.00_090817...
-
Page 14: Setup
setup Using OSD icons ◄► : If these icons appear in the left and right corner of a menu item, you can use them move to the previous or next menu. (EXIT): Exits the menu setup screen. Before exiting the setup screen, select <SAVE> to save your settings to the whole menus, or <QUIT>... -
Page 15: Profi Le
COMMUNICATION Confi gures the settings pertaining to RS-485 communication. SYSTEM INFO Shows the system information such as the camera version or communication settings. LANGUAGE Select a preferred one from the supported languages. PROFILE You can select one from the pre-determined confi gurations as appropriate to your specifi... - Page 16 setup CAMERA SETUP MENU STANDARD Parent Menu Sub-menus LEVEL BACKLIGHT IRIS WEIGHT Custom Setting Custom Setting WDR LEVEL Custom Setting Custom Setting WHITE BAL Custom Setting Custom Setting Custom Setting Custom Setting Custom Setting (F.FAST) MOTION MEDIUM SHUTTER AUTO X4 SENSE UP MEDIUM NIGHT...
-
Page 17: Camera Set
The camera ID will be displayed in the specifi ed position. If you set it to <ON>, the camera images will be displayed in progressive mode. VPS is only available for SCC-C4239P and SCC-C4339P. CAMERA SET CAMERA ID CAMERA ID... - Page 18 As long as you use the VPS function, the WDR will not be available as the CCD read method differs accordingly. If you set VPS to ON, WDR will be set to <OFF> accordingly. WDR is only available for SCC-C4239P and MANUAL : Adjust the iris level manually. The overall brightness target of a camera will be set to ALC level 0, while the iris can be adjusted manually.
- Page 19 With this, you can adjust the AGC level of a camera. With AGC active, if the signal strength falls below the standard level, AGC will amplify the video signal to automatically improve the sensitivity. If <SENS-UP> is set to <OFF> or <FIX> mode, the <MOTION>...
- Page 20 setup SHUTTER You can select a fi xed fast electronic shutter speed in 7 options ranging from 1/120 to 1/10k, which is mostly used to take a picture of a fast moving object. As long as SENSE UP is set to AUTO, FIXED / FLICKERLESS to ON / BACKLIGHT to WDR, the SHUTTER menu is not available.
- Page 21 setup DAY/NIGHT You can specify a recording mode according to the scene. Select <CAMERA SET> - <DAY/NIGHT>. Select a screen transition mode according to the illumination, and set options as appropriate. DAY : Fixed to DAY mode, regardless of the scene. NIGHT : Fixed to NIGHT mode, regardless of the scene.
-
Page 22: White Bal
setup If <BACKLIGHT> is set to <BLC>, the MASK AREA function is not available. EXT : The interface to an external alarm enables an automatic switch between DAY and NIGHT mode. If you use an infrared light source while in AUTO mode, this may cause a failure in AUTO SWITCH or AUTO FOCUS. - Page 23 Select <CAMERA SET> - <WHITE BAL>. Select a mode where you set the <WHITE BAL>. DAY : You can set the RED, and BLUE value in DAY mode. The screen will be displayed in colors according to your settings. You can set the R-GAIN, and B-GAIN value only in <AWC>...
-
Page 24: Focus Mode
setup FOCUS MODE You can select a focus mode according to the angle that you adjusted for camera recording. - AF : This will monitor the screen continuously to focus automatically. If you adjust the focus manually, that will operate the same as in <MF>. - Page 25 It’s a must to use AC 24V power supply when you select line lock for SCC-C4337P and SCC-C4339P. Line lock is not available for SCC-C4237P and SCC-C4239P. AGC COLOR SUP You can adjust the color reproduction range according to AGC.
-
Page 26: Intelligent Video
setup If you set the digital zoom to a larger ratio than the actual enlargement for compensation, the <DIS> function will be disabled. <DIS> may not work properly in the following images: Flat, i.e., no regular-patterned image / Low contrast scene / High frequency image taken under a fl... -
Page 27: Alarm Out
MASK AREA Select the number of the area to be masked that will be excluded from motion detection. Select the mask number and set the mask size and its coverage. DISPLAY When selected <ON>, it displays the motion detected and detection of confi gured advanced function. -
Page 28: Privacy Zone
setup PRIVACY ZONE You can set up to 12 privacy zones that will be hided for privacy of the subject when recording. Zone Setup Select <MAIN MENU>-<PRIVACY ZONE>. Select the number of the zone and press [ENTER]. The Zone setup screen appears. Select the <ZOOM>... -
Page 29: Preset
PRESET This function provides preset camera settings such as zoom and focus so to enable quicker and easier accessing and monitoring, which supports up to 512 presets. Select <MAIN MENU>-<PRESET>. Select the preset number. Select <POSITION>. Set <PRESET ID> to <ON> and enter the name. -
Page 30: Other Set
setup OTHER SET You can reset the system by running FACTORY DEFAULTS, or set the font color etc. Select <MAIN MENU>-<OTHER SET>. Select each item and set appropriately. EXTERNAL TRG Set the EXTERNAL TRG menu to ON and press the SETUP switch to display the appropriate screen. -
Page 31: Communication
PROTOCOL ADDRESS ADDRESS COMM. TYPE COMM. TYPE BAUD RATE BAUD RATE SERIAL NO. SERIAL NO. CAMERA VER. CAMERA VER. Near COMMUNICATION SAMSUNG SAMSUNG 9600 9600 SYSTEM INFO 4_34 ZOM_WDR_P 4_34 ZOM_WDR_P SAMSUNG SAMSUNG RS485, HALF RS485, HALF 9600 9600 000000000000000 000000000000000 v1.00 _ _ 00000... -
Page 32: Language
setup LANGUAGE You can set the language of the user interface. Select <MAIN MENU>-<LANGUAGE>. Select your language using the up/down keys. 32_ setup LANGUAGE ENGLISH ENGLISH PУCCKNЙ PУCCKNЙ POLSKI POLSKI ČESKY ČESKY TÜRKÇE TÜRKÇE... -
Page 33: Shortcut Keys
appendix SHORTCUT KEYS You may control this camera by using Controller (SSC-5000). Function DAY/NIGHT - DAY DAY/NIGHT - NIGHT DAY/NIGHT - AUTO DAY/NIGHT - EXT IRIS – ALC – BACKLIGHT – WDR CAMERA SET IRIS – ALC – BACKLIGHT – OFF IRIS - ALC IRIS - MANU FOCUS MODE –... -
Page 34: Specifications
SCC-C4237P, SCC-C4239P: 4.2W Power Consumption SCC-C4337P, SCC-C4339P: 5.6W TV Standard PAL STANDARD COLOR SYSTEM SCC-C4239P/C4339P: ExView-HAD PS CCD Image Sensor SCC-C4237P/C4337P: Super-HAD IT CCD Effective Pixels 752(H) × 582(V) Horizontal : 15, 625 Hz (INT) / 15, 625 Hz (L/L) - Page 35 Item SCC-C4239P/C4339P: x160 WDR is not available for SCC-C4237P/C4337P. Signal Output COMPOSITE VIDEO OUT : 1.0 Vp-p 75 ohms/BNC x34 Zoom Lens Integrated Focal length : 3.4 ~ 115.6mm Lens Aperture : F1.65(Wide) F3.7(Tale) - MOD(Minimum Object Distance) : 1000mm...
- Page 36 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
