Remote Control See “Remote Control” in the owner’s instructions for details. 1 POWER Turns the TV on and off. 2 TV Selects the TV mode directly. 3 NUMERIC BUTTONS Press to change the channel. Press to select additional channels(digital and analog) being broadcast by the same station. For example, to select channel “54-3”, press “54”, then press “...
Connections Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box) via HDMI DVD Player or Cable Box/ Satellite receiver (Set-Top Box) HDMI Cable (Not supplied) Each DVD Player or Cable Box/Satellite receiver (Set-Top Box) has a different ➣ back panel configuration. Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box) via DVI DVD Player or Cable Box/ Satellite receiver (Set-Top Box)
Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box) via Component cables TV Rear Panel Component Cable (Not supplied) Audio Cable (Not supplied) Connecting a Camcorder Camcoder DVD Player or Cable Box / Satellite receiver (Set-Top Box) TV Side Panel Audio cable (Not supplied) Video Cable (Not supplied) S-Video Cable (Not supplied)
Connecting a VCR Video Connection VCR Rear Panel Follow the instructions in “Viewing a VCR or Camcorder Tape” to view your VCR tape. Each VCR has a different back panel configuration. ➣ When connecting a VCR, match the color of the connection terminal to the cable. ➣...
Connecting a Digital Audio System TV Rear Panel Optical Cable (Not supplied) Connecting an Amplifier/DVD Home Theater TV Rear Panel Audio Cable (Not supplied) Digital Audio System ➣ ➣ ➣ Amplifier/DVD Home Theater ➣ ➣ English-6 Connect an Optical Cable between the “DIGITAL AUDIO OUT (OPTICAL)”...
Connecting a PC TV Rear Panel D-Sub Cable (Not supplied) PC Audio Cable (Not supplied) TV Rear Panel HDMI/DVI Cable (Not supplied) 3.5 mm Stereo mini-plug/2RCA Cable (Not supplied) Using the D-Sub Cable Using the HDMI/DVI Cable Each PC has a different back panel ➣...
Press the POWER button on the remote control. You can also use the POWER button on the TV. Viewing the Menus With the power on, press the MENU button. The main menu appears on the screen. The menu’s left side has icons: Picture, Sound, Channel, Setup, Input.
Using this menu, you can Add/Delete or set Favorite channels and use the program guide for digital broadcasts. To use the Channel List function, first run “Auto Program”. Press the MENU button. Press the ▲ or ▼ button to select “Channel”, then press the ENTER Press the ▲...
Press the SOURCE button on the Remote Control You can select the TV mode or an input source connected to the TV set. Use this button to choose an input source that you would like to watch. Available signal sources: TV, AV, S-Video, Component, PC, HDMI. ➣...
Troubleshooting If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, call your nearest Samsung service center. Problem Poor picture Poor sound quality. No picture or sound.
Page 12
Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Contacte con SAMSUNG WORLDWIDE Si tiene alguna pregunta o comentario referente a nuestros productos, por favor contacte con nuestro Servicio de Atención al Cliente.
