Brother DCP-L5500D Quick Setup Manual

DCP‑L5500D / DCP‑L5500DN / DCP‑L5600DN / DCP‑L6600DW /
MFC‑L5700DN / MFC‑L5750DW / MFC‑L5755DW / MFC‑L5900DW /
MFC‑L6700DW / MFC‑L6800DW / MFC‑L6900DW
Quick Setup Guide
Unpack the machine and check the components
Drum Unit and Toner Cartridge
DCP‑L5500D / DCP‑L5500DN /
DCP‑L5600DN / DCP‑L6600DW /
MFC‑L5700DN / MFC‑L5750DW /
MFC‑L5755DW / MFC‑L5900DW /
MFC‑L6700DW / MFC‑L6800DW /
MFC‑L6900DW (For Oceania))
Watch our Video FAQs for
help with setting up your
Brother machine:
solutions.brother.com/videos.
1
Remove the packing materials and install the drum unit and toner cartridge assembly
DCP‑L5500D / DCP‑L5500DN / DCP‑L5600DN / DCP‑L6600DW / MFC‑L5700DN / MFC‑L5750DW / MFC‑L5755DW / MFC‑L5900DW / MFC‑L6700DW / MFC‑L6800DW / MFC‑L6900DW (For Oceania)
MFC‑L6900DW ONLY (Except for Oceania)
2

Load paper in the paper tray

3
Connect the power cord and turn the machine on
Back
5 Select your language (if needed)
(Only for certain models)
1.
On the machine's Touchscreen, press
[Initial Setup] > [Local Language].
2.
Press your language.
3.
Press .
Drum Unit
Assembly
(pre‑installed in model
(pre‑installed in models
MFC‑L6900DW only
(Except for Oceania))
AC Power Cord
Quick Setup Guide Product Safety Guide
Telephone Line Cord Adapter
Installation CD‑ROM
(Australia only) (For MFC models)
Discard the silica gel pack.
Remove the orange part.
Adjust the paper
Front
[Settings] > [All Settings] >
Read the Product Safety Guide first, then read this Quick
Setup Guide for the correct installation procedure.
Not all models are available in all countries.
The latest manuals are available at the Brother Solutions
Center: solutions.brother.com/manuals.
Inbox Toner Cartridge
(model MFC‑L6900DW only
(Except for Oceania))
(For U.K.)
Telephone Line Cord
(For MFC models)
Basic User's Guide
or Reference Guide
(only for certain models)
Remove the orange part.
guides.
4
NOTE:
• The available connection interfaces vary depending on the
model.
• You must purchase the correct interface cable for the interface
you want to use.
USB cable
We recommend using a USB 2.0 cable (Type A/B) that is
no more than 2 metres long.
Network cable
(Except for DCP‑L5500D)
Use a straight‑through Category 5 (or greater) twisted‑pair
(For Others)
cable.
• The illustrations in this Quick Setup Guide show the
MFC‑L6900DW.
Remove the orange part.
Select your country/language
(Initial setup only)
After turning the machine on, you may be required to set your country
or language (depending on your machine).
If required, follow the on‑screen instructions.
D0056H001‑01
UK
Version A
