VACUUM CLEANER
SERVICE MANUAL
MODEL : V-KC702HTU
CAUTION
BEFORE SERVICING THE UNIT, READ THE
"SAFETY PRECAUTIONS" IN THIS MANUAL.
P/NO : MFL52434307
Internal Use Only
Website http://biz.lgservice.com
September, 2009
Printed in Korea

Advertisement

Table of Contents
loading

Summary of Contents for LG V-KC702HTU

  • Page 1 삼 흥 정 판 Internal Use Only Website http://biz.lgservice.com VACUUM CLEANER SERVICE MANUAL MODEL : V-KC702HTU CAUTION BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS" IN THIS MANUAL. September, 2009 P/NO : MFL52434307 Printed in Korea...
  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ....................... 3 CAUTIONS ............................. 3 DESCRIPTION ..........................4 SPECIFICATIONS .......................... 4 DISASSEMBLY .......................... 5~6 TROUBLE SHOOTING GUIDE ....................7~9 SCHEMATIC DIAGRAM ....................... 10 CIRCUIT DIAGRAM ........................11 EXPLODED VIEW ........................12~15 REPLACEMENT PARTS LIST ....................16~17...
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS BEFORE OPERATING THIS VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND OBSERVE EACH POINT CAREFULLY. 1. Motor filter(Air Cleaner) 3. Avoid suction such materials as : 1) This filter is reusable. 1) Liquid or wet dust : Clogs the ventilation holes, reduces the suction 2) Never use the vacuum cleaner without filter.
  • Page 4: Description

    DESCRIPTION Dust Tank Flexible Hose Assembly Brush Assembly,Dust Cord Reel Button Telesscopic Pipe Assembly Power Cord Body Cover Carpet and Floor Nozzle Nozzle Assembly,Quilt SPECIFICATIONS • MODEL : REFER TO THE COVER PAGE • NET DIMENSION : 280 X 440 X 286 (W X D X H)mm •...
  • Page 5: Disassembly

    DISASSEMBLY NOTE: Before attempting to service or adjust any part of the vacuum cleaner, disconnect the electrical power supply cord from the wall outlet. • Almost all of the parts of this vacuum cleaner can be 3) Disassemble the body cover, raising the body cover. disassembled with a screw driver and each connecting component easily fits each other.
  • Page 6 3. Cord Reel Assembly Replacement 4. Disassembly of motor housing 1) Remove the two screws fastening the body base. 1) Lift the cord reel assembly from body base. Cord Real Assembly...
  • Page 7: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE 1. SWITCH ON BUT MOTOR DOSE NOT TURN. CHECKING CAUSE SOLUTION CHECK THE POWER The fuse is melt down in the Exchange the fuse. SOURCE coverknife switch. Poor plug insertion Insert again. Power cord cut Repair or exchange. Interior lead wire cut Exchange the lead wire.
  • Page 8 3. SWITCH OFF BUT MOTOR TURNS Poor connection Repair. 4. WEAK SUCTION POWER Motor armature cut Exchange the motor. Foreign matters attached to Low rotation speed Remove the foreign matters. the impeller Inquire to the power utility Low voltage company. Hose and extension wands Remove the foreign matters are clogged with foreign...
  • Page 9 5. VIBRATION NOISES Loose parts Secure firmly. Unbalanced motor assembly Exchange or repair the motor. Foreign matters are attached Remove the foreign matters. to the impeller. Armature is cut or foreign Exchange the motor matters attached. Remove foreign matters. 6. RADIO, TV RECEPTION DISTURBANCE Poor cord, lead wire Exchange cord, lead wire.
  • Page 10: Schematic Diagram

    SCHEMATIC DIAGRAM C/REEL ASM SLIDE VOLUME MAIN LED PWB ASM PRESSURE S/W C-2 TYPE -10-...
  • Page 11: Circuit Diagram

    CIRCUIT DIAGRAM HMS8(1)(7)C1102A -11-...
  • Page 12: Exploded View

    #EV# EXPLODED VIEW BASE ASSEMBLY, BODY V-KC702HTU(V-KC702HTU.AXRQSBI) MCKBC1 MCQBM1 ACQBE1 ADQBE1 EAUBA1 MCKBE8 MFGBA1 MCQBA1 MDSBA1 MDJBE1 MEABE1 AHDBR1 MDSBA2 MEKBM1 MBGBR1 MHYBC1 EBRBM1 MCKBE9 MCKBD8 MAMBB1 MEBBC1 AHJBA1 MCKBD9 AJWBA1 -12-...
  • Page 13 #EV# COVER ASSEMBLY, BODY MCKCT1 MCKCA1 MCKCD1 MEGCL1 EBRCD1 EADCS1 MDSCA1 MDSCA2 MCKCZ1 MGECB1 MGECC1 MDSCA3 ACVCA1 EBFCZ1 MEACA1 MCKCD8 MCKCB1 MCKCR8 MCKCR9 MCKCD9 -13-...
  • Page 14 #EV# TANK ASSEMBLY, DUST AJLTD1 MCKTD1 MCKTS1 ADVTF1 MCQTA1 MBLTD1 MDSTA2 MJMTC1 MHYTA1 MFGTA1 MJMTD1 MHYTC1 MHYTC2 MFGTA3 MFGTA2 MJCTA1 MGJTS1 MDSTA1 MGJTB1 -14-...
  • Page 15 #EV# ACCESSORIES AEMAF1 AGRPT1 AGBN50 AGBN58 ABCAD1 -15-...
  • Page 16: Replacement Parts List

    REPLACEMENT PARTS LIST LOC. NO. PART NO. DESCRIPTION REMARK ABCAD1 5203FI1216D Brush Assembly ACQBE1 3551FI2451E Cover Assembly,Exhaust ACVCA1 4901FI2001Y Damper Assembly ADQBE1 5231FI2472D Filter Assembly,Exhaust ADVTF1 3211FI1005B Frame Assembly,Filter AEMAF1 AEM61730905 Hose Assembly,Flexible AGBN50 5249FI1445J Nozzle Assembly,Floor AGBN58 AGB32061205 Nozzle Assembly,Quilt AGRPT1 5201FI2508G Pipe Assembly,Telescopic...
  • Page 17 LOC. NO. PART NO. DESCRIPTION REMARK MCQBM1 MCQ30443201 Damper,Motor Mount MCQTA1 3920FI3966B Damper,Absorbing MDJBE1 5230FI3797C Filter,Exhaust MDSBA1 MDS32309801 Gasket MDSBA2 4036FI3677G Gasket MDSCA1 3920FI3963A Gasket MDSCA2 3920FI3964A Gasket MDSCA3 403683I002A Gasket MDSTA1 MDS52146901 Gasket MDSTA2 MDS52147001 Gasket MEABE1 4974FI1017A Guide,Exhaust MEACA1 4974FI2414A Guide,Air...
